change time TOYOTA YARIS HATCHBACK 2020 Owners Manual (in English)

8
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
Please be aware that this manual applies to all models, equipment
and options. As a result, you may find some explanations for equip-
ment not installed on your vehicle.
■Important Notes A bout This Manual
Keep this manual in the glove box as a handy reference for the safe
and enjoyable use of your Toyota. Should you resell the vehicle,
leave this manual with it for the next owner.
All specifications and descripti ons are accurate at the time of print-
ing. Because improvement is a co nstant goal at Toyota, we reserve
the right to make changes in specifications at any time without
notice and without obligation.
■Air Conditioning and the Environment
Your Toyota’s genuine air conditioner is filled with a refriger ant that
has been found not to damage the earth’s ozone layer. If the ai r
conditioner does not operate properly, consult your Toyota deal er.
■Perchlorate
Certain components of this vehicle such as [air bag modules, seat
belt pretensioners, lithium batteries,...] may contain Perchlor ate
Material-- Special handling may apply for service or vehicle en d of
life disposal. See www.dtsc.ca.gov/hazardouswaste/perchlorate.

24
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
1-1. Seats
The front seats are electrically heated. The ignition must be switched
ON.
Press the seat warmer switch to
illuminate the indicator light while
the ignition is switched ON. The
mode changes as follows each
time the seat warmer switch is
pressed.
OFF
High
Mid
Low
●If the ignition is switched off while the seat warmer is operating (High, Mid or
Low) and then switched ON again, the seat warmer will automatic ally oper-
ate at the temperature set before switching off the ignition.
● Use the seat warmer when the engine is running. Leaving the seat warmer
on for long periods with the engine not running could cause the battery
power to be depleted.
● The temperature of the seat warmer cannot be adjusted beyond Hi gh, Mid
and Low because the seat warmer is controlled by a thermostat.
Seat Warmer (if equipped)
1
2
3
4
WARNING
■ Be careful when using the seat warmer
The heat from the seat warmer may be too hot for some people, a s indi-
cated below, and could cause a low-temperature burn.
● Infants, small babies, elderly people, and physically challenge d people
● People with delicate skin
● People who are excessively fatigued
● People who are intoxicated
● People who have taken sleep-inducing medicine such as sleeping pills or
cold medicine
■ Do not use the seat warmer with anything having high moisture-r eten-
tion ability such as a blanket or cushion on the seat
The seat may be heated excessively and cause a low-temperature burn.

34
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
1-2. Seat Belt Systems
WARNING
■Do not wear twisted seat belts
Twisted seat belts are dangerous. In a collision, the full widt h of the belt is
not available to absorb the impact. This puts more force on the bones
beneath the belt, which could cause serious injury or death. So , if your seat
belt is twisted, you must straighten the seat belt to remove any twists and to
allow the full width of the belt to be used.
■ Never use one seat belt on more than one person at a time
Using one seat belt for more than one person at a time is dangerous. A seat
belt used in this way cannot spread the impact forces properly and the two
passengers could be crushed together and seriously injured or even killed.
Never use one belt for more than one person at a time and alway s operate
the vehicle with each occupant properly restrained.
■ Do not operate a vehicle with a damaged seat belt
Using a damaged seat belt is dangerous. An accident could damag e the
belt webbing of the seat belt in use. A damaged seat belt cannot provide
adequate protection in a collision. Have your Toyota dealer ins pect all seat
belt systems in use during an accident before they are used aga in.
■ Have your seat belts changed immed iately if the pretensioner or load
limiter has been expended
Always have your Toyota dealer immediately inspect the seat bel t preten-
sioners and air bags after any collision. Like the air bags, the seat belt pre-
tensioners and load limiters will only function once and must b e replaced
after any collision that caused them to deploy. A seat belt with an expended
pretensioner or load limiter is still better than wearing no se at belt at all;
however, if the seat belt pretensioners and load limiters are n ot replaced,
the risk of injury in a collision will increase.
■ Positioning the Shoulder P ortion of the Seat Belt
Improper positioning of the shoulder portion of the seat belt i s dangerous.
Always make sure the shoulder portion of the seat belt is posit ioned across
your shoulder and near your neck, but never under your arm, on your neck,
or on your upper arm.
■ Positioning the Lap Portion of the Seat Belt
The lap portion of the seat belt worn too high is dangerous. In a collision,
this would concentrate the impact force directly on the abdomin al area,
causing serious injury. Wear the lap portion of the belt snugly and as low as
possible.

96
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
2-1. Keys
■Smart Key
●With theft deterrent system:
The hazard warning lights flash when the theft deterrent system is armed or
turned off.
Refer to Theft Deterrent System on P. 138.
● With the advanced keyless function:
A beep sound can be heard for confirmation when the doors and t he liftgate
are locked/unlocked using the key. If you prefer, the beep sound can be
turned off. The volume of the beep sound can also be changed.
Refer to Customizable Features on P. 555.
Use the following procedure to change the setting.
Switch the ignition off and close all of the doors and the lift gate/trunk lid.
Open the driver’s door.
Within 30 seconds of opening the driver’s door, press and hold the LOCK
button on the key for 5 seconds or longer (All of the doors and the liftgate
are locked and unlocked when the LOCK button on the key is pressed
and held for 5 seconds.).
The beep sound activates at the currently set volume. The setting
changes each time the LOCK button on the key is pressed and the beep
sound activates at the set volume. (If the beep sound has been set to not
activate, it will not activate.)
The setting change is completed by doing any one of the followi ng:
• Switching the ignition to ACC or ON.
• Closing the driver’s door.
• Opening the liftgate/trunk lid.
• Not operating the key for 10 seconds.
• Pressing any button except the LOCK button on the key.
• Pressing a request switch.
■ Lock button
●The doors and the liftgate can be locked by pressing the lock b utton while
any other door or the liftgate/trunk lid is open. The hazard wa rning lights will
not flash.
● When the lock button is pressed while any door is open and then the door is
closed, all the doors and the liftgate are locked.
● Confirm that all doors and the liftgate are locked visually or audibly by use of
the double click.
● Make sure all doors and the liftgate are locked after pressing the button.
● With theft deterrent system:
When the doors are locked by pressing the lock button on the key while the
theft deterrent system is armed, the hazard warning lights will flash once to
indicate that the system is armed.
1
2
3
4

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
972-1. Keys
2
Before Driving
■Unlock button
●The system can be set to unlock all doors by performing a single operation.
Refer to Customizable Features on P. 555.
Use the following procedure to change the setting.
Switch the ignition off and close all of the doors and the lift gate/trunk lid.
Open the driver’s door
Within 30 seconds of opening the driver’s door, press and hold the
UNLOCK button on the key for 5 seconds or longer (the sound of the
doors locking/unlocking can be heard).
After this, the system switches the setting each time the UNLOC K button
is pressed (the sound of the doors locking/unlocking can be hea rd).
The setting change is completed by doing any one of the followi ng:
• Switching the ignition to ACC or ON.
• Closing the driver’s door.
• Opening the liftgate/trunk lid.
• Not operating the key for 10 seconds.
• Pressing any button except the UNLOCK button on the key.
• Pressing a request switch.
● Auto re-lock function:
After unlocking with the key, all doors and the liftgate will a utomatically lock
if any of the following operations are not performed within about 60 sec-
onds. If your vehicle has a theft deterrent system, the hazard warning lights
will flash for confirmation.
The time required for the doors to lock automatically can be ch anged.
Refer to Customizable Features on P. 555.
• A door or the liftgate/trunk lid is opened.
• The ignition is switched to any position other than off.
● With theft deterrent system:
When the doors are unlocked by pressing the unlock button on th e key while
the theft deterrent system is turned off, the hazard warning li ghts will flash
twice to indicate that the system is turned off.
■ Panic button
The panic button will work whether any door or the liftgate/tru nk lid is open or
closed.
1
2
3
4

104
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
2-3. Door and Locks
■To l o c k
To lock the doors and the liftgate, press the request switch and the
hazard warning lights will flash once.
A beep sound will be heard once.
■To unlock
● Driver’s door request switch
To unlock the driver’s door, p ress the request switch. A beep
sound will be heard twice and t he hazard warning lights will flash
twice.
To unlock all doors and the liftgate, press the request switch
again within three seconds a nd two more beep sounds will be
heard.
● Front passenger door request switch
To unlock all doors and the liftgate, press the request switch. A
beep sound will be heard twice and the hazard warning lights wi ll
flash twice.
● The system can be set to unlock all doors by performing a singl e operation.
Refer to Customizable Features on P. 555.
Use the following procedure to change the setting.
Switch the ignition off and close all of the doors and the lift gate/trunk lid.
Open the driver’s door.
Within 30 seconds of opening the driver’s door, press and hold the
UNLOCK button on the key for 5 seconds or longer (the sound of the
doors locking/unlocking can be heard).
After this, the system switches the setting of pressing the dri ver’s request
switch once or twice to unlock all doors and the liftgate each time the
UNLOCK button is pressed (the sound of the doors locking/unlocking can
be heard).
The setting change is completed by doing any one of the followi ng:
• Switching the ignition to ACC or ON.
• Closing the driver’s door.
• Opening the liftgate/trunk lid.
• Not operating the key for 10 seconds.
• Pressing any button except the UNLOCK button on the key.
• Pressing a request switch.
1
2
3
4

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
1052-3. Door and Locks
2
Before Driving
●Confirm that all doors and the liftgate are securely locked.
For the liftgate/trunk lid, move it without pressing the electr ic liftgate/trunk lid
opener to verify that the liftgate/trunk lid has not been left ajar.
● All doors and the liftgate cannot be locked when any door or the liftgate is
open.
● It may require a few seconds for the doors to unlock after the request switch
is pressed.
● A beep sound is heard for confirmation when the doors and the l iftgate are
locked/unlocked using the request switch. If you prefer, the beep sound can
be turned off.
The volume of the beep sound can also be changed. Refer to Cust omizable
Features on P. 555.
Use the following procedure to change the setting.
Switch the ignition off and close all of the doors and the lift gate/trunk lid.
Open the driver’s door.
Within 30 seconds of opening the driver’s door, press and hold the LOCK
button on the key for 5 seconds or longer (All of the doors and the liftgate
are locked and unlocked when the LOCK button on the key is pressed
and held for 5 seconds.).
The beep sound activates at the currently set volume. The setting
changes each time the LOCK button on the key is pressed and the beep
sound activates at the set volume. (If the beep sound has been set to not
activate, it will not activate.)
The setting change is completed by doing any one of the followi ng:
• Switching the ignition to ACC or ON.
• Closing the driver’s door.
• Opening the liftgate/trunk lid.
• Not operating the key for 10 seconds.
• Pressing any button except the LOCK button on the key.
• Pressing a request switch.
1
2
3
4

106
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
2-3. Door and Locks
●With theft deterrent system:
The hazard warning lights flash when the theft deterrent system is armed or
turned off.
Refer to Theft Deterrent System on P. 138.
● The setting can be changed so that the doors and the liftgate a re locked
automatically without pressing the request switch.
Refer to Customizable Features on P. 555.
Walk-away auto lock function:
A beep sound is heard when all doors and the liftgate are close d while the
advanced key is being carried. All doors and the liftgate are l ocked auto-
matically after about three seconds when the advanced key is ou t of the
operational range. Also, the hazard warning lights flash once. (Even if the
driver is in the operational range, all doors and the liftgate are locked auto-
matically after about 30 seconds.) If you are out of the operat ional range
before the doors and the liftgate/trunk lid are completely clos ed or another
key is left in the vehicle, the function will not work. Always make sure that
all doors and the liftgate/trunk lid are closed and locked befo re leaving the
vehicle. The function does not close the power windows.
● Auto re-lock function:
After unlocking with the request switch, all doors and the liftgate will auto-
matically lock if any of the following operations are not performed within
about 60 seconds. If your vehicle has a theft deterrent system, the hazard
warning lights will flash for confirmation.
The time required for the doors to lock automatically can be ch anged. Refer
to Customizable Features on P. 555.
• Opening a door or the liftgate/trunk lid.
• Switching the ignition to any position other than off.

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
1092-3. Door and Locks
2
Before Driving
Settings can be changed using the following procedure.
Safely park the vehicle. All doors and the liftgate must remain
closed.
Switch the ignition ON.
Press and hold the lock side of the driver’s door-lock switch
within 20 seconds of switching the ignition ON, and make sure a
beep sound is heard about e ight seconds afterwards.
Refer to the auto lock/unlock function setting table, determine the
function number for the desired setting. Press the unlock side of
the driver’s door-lock switch the same number of times as the
selected function number (Ex. If you select function 2, press t he
unlock side of the s witch only 2 times).
Three seconds after the function setting has been changed, a
beep sound will beep in the amount of the selected function num-
ber. (Ex. Function number 3 = 3 beep sounds)
Manual transaxle vehicles
1
2
3
4
5
Current Function Number
Press unlock side of lock switch once
Function Number 1
Function Number 2
Function Number 3 Press 2 times
Press 3 times
Press 4 times
Cancel setting Press lock side of lock switch
Cancel setting
Wait for 3 second
Function set (The number of
beeps heard is the same as the
selected function number)

136
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
2-8. Security System
Immobilizer System
If someone attempts to start the engine with an unrecognized ke y, the
engine will not start, thereby helping to pre vent vehicle theft.
If you have a problem with the i mmobilizer system or the key, consult
your Toyota dealer.
● The keys carry a unique electronic code. For this reason, and t o assure your
safety, obtaining a replacement key requires some waiting time. They are
only available through your Toyota dealer.
● Always keep a spare key in case one is lost. If a key is lost, consult your
Toyota dealer as soon as possible.
● If you lose a key, your Toyota dealer will reset the electronic codes of your
remaining keys and immobilizer system. Bring all the remaining keys to your
Toyota dealer to reset.
Starting the vehicle with a key that has not been reset is not possible.
The immobilizer system allows the engine to start only with a
key the system recognizes.
NOTICE
● Radio equipment like this is governed by laws in the United Sta tes.
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the e quipment.
● To avoid damage to the key, do not:
• Drop the key.
• Get the key wet.
• Expose the key to any kind of magnetic field.
• Expose the key to high temperatures on places such as the dash board
or hood, under direct sunlight.
● If the engine does not start with the correct key, and the secu rity indicator
light keeps illuminating or flashing, the system may have a mal function.
Consult your Toyota dealer.
