fog light TOYOTA YARIS HATCHBACK 2020 Owners Manual (in English)

3
1
8 7
6 4 3
2
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
5
2-5. Steering WheelSteering Wheel.................. 127
2-6. Mirrors Mirrors ............................... 129
2-7. Windows Power Windows ................ 132
2-8. Security System Modification and Add-On Equipment ......... 135
Immobilizer System ........... 136
Theft Deterrent System ..... 138
2-9. Driving Tips Break-In Period ................. 141
Saving Fuel and Protection of the
Environment .................... 142
Hazardous Driving............. 143
Floor Mat ........................... 144
Rocking the Vehicle .......... 145
Winter Driving.................... 146
Driving In Flooded Area ................................ 149
Overloading ....................... 150
Driving on Uneven Road ............................... 151
2-10. Towing Trailer Towing ................... 152
Recreational Towing ......... 153 3-1. Start/Stop Engine
Ignition Switch ................... 156
Starting the Engine ............ 158
Turning the Engine Off ...... 163
3-2. Combination Meter and Display
Meters and Gauges ........... 164
Warning/Indicator Lights ............................... 173
3-3. Transaxle Manual Transaxle Operation......................... 177
Automatic Transaxle Controls ........................... 181
3-4. Switches and Controls Lighting Control ................. 192
Fog Lights .......................... 198
Turn and Lane-Change Signals............................. 199
Windshield Wipers and Washer ..................... 201
Rear Window Wiper and Washer ............................ 206
Rear Window Defogger.......................... 207
Hazard Warning Flasher ............................ 208
3-5. Brake Brake System .................... 209
Hill Launch Assist (HLA) .... 213
3When Driving

155
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
3When Driving
3-1. Start/Stop EngineIgnition Switch ................... 156
Starting the Engine ........... 158
Turning the Engine Off ...... 163
3-2. Combination Meter and Display
Meters and Gauges .......... 164
Warning/Indicator Lights .............................. 173
3-3. Transaxle Manual Transaxle Operation ........................ 177
Automatic Transaxle Controls........................... 181
3-4. Switches and Controls Lighting Control ................. 192
Fog Lights ......................... 198
Turn and Lane-Change Signals ............................ 199
Windshield Wipers and Washer..................... 201
Rear Window Wiper and Washer............................ 206
Rear Window Defogger ......................... 207
Hazard Warning Flasher ............................ 208 3-5. Brake
Brake System.................... 209
Hill Launch Assist (HLA) ... 213
3-6. ABS/TCS/DSC Antilock Brake System (ABS) .............................. 215
Traction Control System (TCS) .............................. 216
Dynamic Stability Control (DSC) .............................. 218
3-7. Fuel Economy Monitor Fuel Economy Monitor ...... 221
3-8. Drive Selection Drive Selection (Automatic Transaxle) ..... 224
3-9. Power Steering Power Steering ................. 226
3-10. Active Safety System Active Safety System ........ 227
Low Speed Pre-Collision System ............................ 228
Laser Sensor..................... 234
3-11. Cruise Control Cruise Control ................... 236
3-12. Tire Pressure Monitoring System
Tire Pressure Monitoring System ............................ 241
3-13. Rear View Monitor Rear View Monitor ............ 245

198
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
3-4. Switches and Controls
Fog Lights
The fog lights can be used when the ignition is switched ON.
The fog lights turn on when the
fog light switch is turned to the
position and turn off when the
switch is turned to the OFF posi-
tion.
The fog lights turn on when the
headlights are turned on. They will
not turn on if the headlight switch is
in the position or OFF posi-
tion.
● The fog lights will turn off when the headlights are set at hig h beams.
● With auto-light control:
If the fog light switch is in the position and the headlight switch is in the
AUTO position, the fog lights will turn on when the headlights, the exterior
lights and dashboard illumination turn on.
: If equipped
Use this switch to turn on the fog lights. The fog lights will
improve visibility at night and during foggy conditions.
Fog light switch

207
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
3-4. Switches and Controls
3
When Driving
Rear Window Defogger
The ignition must be switched ON to use the defogger.
Press the switch to turn on the rear window defogger. The rear win-
dow defogger operates for about 15 minutes and then turns off a uto-
matically.
The indicator light illuminates when the defogger is operating.
To turn off the rear window defogger before the 15 minutes has
elapsed, press the switch again.
This defogger is not designed for melting snow. If there is an accumulation of
snow on the rear window, remove it before using the defogger.
To turn on the mirror defoggers, switch the ignition ON and pre ss the
rear window defogger switch ( P. 207).
The rear window defogger clears fog from the rear window.
Manual Climate ControlFully Automatic Climate Con-
trol
NOTICE
Do not use sharp instruments or window cleaners with abrasives to clean
the inside of the rear window surface. They may damage the defo gger grid
inside the window.
Mirror Defogger (if equipped)
Indicator lightIndicator light

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
2293-10. Active Safety System
3
When Driving
●The Low Speed Pre-Collision System will not operate if the driv er is deliber-
ately performing driving operations (accelerator pedal and stee ring wheel).
● The Low Speed Pre-Collision System will operate under the follo wing condi-
tions.
• The engine is running.
• The Low Speed Pre-Collision System warning light (amber) does not illu-
minate.
• The vehicle speed is between about 2 to 18 mph (4 to 30 km/h).
• The Low Speed Pre-Collision System is not turned off.
• The DSC is not malfunctioning.
● The Low Speed Pre-Collision System detects a vehicle ahead by emitting a
near-infrared laser beam and receiving the beam reflected off the reflector
of the vehicle ahead, and then using it for the measurement. Co nsequently,
the Low Speed Pre-Collision System may not operate under the following
conditions:
• Reflection of the laser is poor due to the shape of the vehicl e ahead.
• The vehicle ahead is significantly dirty.
• Under bad weather condition, such as rain, fog and snow.
• The window washer is being used or the windshield wipers are not used when it’s raining.
• The windshield is dirty.
• The steering wheel is turned completely left or right, or the vehicle is
accelerated rapidly and comes close to the vehicle ahead.
• Trucks with low loading platforms and vehicles with an extreme ly low or
high profile.
• Vehicles with certain shapes such as a vehicle carrier.
● Under the following conditions, the Low Speed Pre-Collision Sys tem may
not operate normally.
• Heavy luggage is loaded in the luggage compartment or on the r ear seat.
• If there is the possibility of partial contact with a vehicle ahead.
• When driving on continuously curving roads, and entering and e xiting
exits.
• Elongated luggage or cargo is loaded onto installed roof rails and covers
the laser sensor.
• Exhaust gas from the vehicle in front, sand, snow, and water v apor rising
from manholes and grating, and water splashed into the air.
• When towing a malfunctioning vehicle.
• When driving with tires having significantly different wear.

256
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
4-1. Climate Control System
Operating Tips
• Operate the climate control system with the engine running.
• To prevent the battery from being discharged, do not leave the fan
control dial on for a long perio d of time with the ignition switched
ON when the engine is not running.
• Clear all obstructions such as l eaves, snow and ice from the hood
and the air inlet in t he cowl grille to imp rove the system efficiency.
• Use the climate control system to defog the windows and dehumi d-
ify the air.
• The recirculate mode should be used when driving through tunne ls
or while in a traffic jam, or when you would like to shut off o utside
air for quick cooling of the interior.
• Use the outside air position for ventilation or windshield defrosting.
• If the vehicle has been parked in direct sunlight during hot weather,
open the windows to let warm air escape, then run the climate con-
trol system.
• Run the air conditioner about 10 minutes at least once a month to
keep internal parts lubricated.
• Have the air conditioner checke d before the weather gets hot. Lack
of refrigerant may make the ai r conditioner less efficient.
The refrigerant specifications
are indicated on a label
attached to the inside of the
engine compartment. Check
the label before refilling the
refrigerant. If the wrong type of
refrigerant is used, it could
result in a serious malfunction
of the air conditioner.
For details, consult your Toyota
dealer.
Label

268
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
4-1. Climate Control System
■Air intake selector
Outside or recirculated air positions can be selected. Press th e
switch to select outside/ r ecirculated air positions.
● Recirculated air po sition (indicator light illuminated)
Outside air is shut off. Use this position when going through t un-
nels, driving in congested traffic (high engine exhaust areas) or
when quick cooling is desired.
● Outside air position (indi cator light turned off)
Outside air is allowed to enter t he cabin. Use this mode for venti-
lation or windshield defrosting.
■Rear window defogger switch
Press the rear window defogger switch to defrost the rear windo w.
Refer to Rear Window Defogger on P. 207.
■ Mode selector dial
●With the airflow mode set to the position and the temperature control
dial set at a medium temperature, heated air is directed to the feet and air at
a comparably lower temperature will flow through the central, left and right
vents.
● When the fan control dial is ON, and the mode selector dial is in the
or position, the air conditioner is automatically turned on and the out-
side air position is automatically selected to defrost the windshield. In the
or position, the outside air position cannot be changed to th e
recirculated air position.
■ A/C switch
The air conditioner may not function when the outside temperatu re
approaches 0 °C (32 °F).
WARNING
■ Do not use the position in cold or rainy weather:
Using the position in cold or rainy weather is dangerous as it will
cause the windows to fog up. Your vision will be hampered, whic h could
lead to a serious accident.

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
2694-1. Climate Control System
4
Interior Features
Set the mode selector dial to the AUTO position.
Set the air intake selector to the outside air position (indicator light
turned off).
Set the fan control dial to the AUTO position.
Press the A/C switch to operate the air conditioner (turn indic ator
light on).
Set the temperature control dial to the desired position.
To turn off the system, set the fan control dial to the 0 position.
■Operation of Automatic Air conditioner
●If the recirculated air position is used for long periods in co ld weather or high
humidity, the windshield may fog up more easily.
● Setting the temperature to maximum hot or cold will not provide the desired
temperature at a faster rate.
● When selecting heat, the system will restrict airflow until it has warmed to
prevent cold air from blowing out of the vents.
Set the mode selector dial to t he position and turn the fan co n-
trol dial to the desired speed.
In this position, the outside air position is automatically sel ected, and
when the fan control dial is ON , the air conditioner automatica lly turns
on. The air conditioner will directly dehumidify the air to the front wind-
shield and side windows ( P. 258). Airflow amount will be increased.
Use the temperature control dial to increase the air flow temperature and
defog the windshield more quickly.
Operation of Automatic Air Conditioner
Windshield Defrosting and Defogging
WARNING
■Set the temperature control to the hot or warm position when de fog-
ging ( position):
Using the position with the temperature control set to the col d posi-
tion is dangerous as it will cause the outside of the windshiel d to fog up.
Your vision will be hampered, which could lead to a serious accident.
1
2
3
4
5
6

270
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
4-1. Climate Control System
■Rear window defogger switch
●Sunlight sensor
Do not place objects on the
sunlight sensor. Otherwise,
the interior temperature may
not adjust correctly.
● Interior temperature sensor
Do not cover the interior tem-
perature sensor. Otherwise,
the interior temperature may
not adjust correctly.
Sunlight/Temperature Sensor
Sunlight sensor
Interior temperature sensor

419
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
5-3. Owner Maintenance
5
Maintenance and Care
Light Bulbs
■Front
With Halogen Headlights
Headlights (Low/High beam)/
Daytime running lights
Front side-marker lights
Overhead lights/Map lights
Side turn signal lights (if
equipped)
Front turn signal lights/Park-
ing lights
Fog lights (if equipped)
With LED Headlights
Headlights (High beam)
Headlights (Low beam)
Front side-marker lights
Overhead lights/Map lights
Side turn signal lights (if
equipped)
Front turn signal lights/Park-
ing lights
Daytime running light/Park-
ing light
Fog lights
1
2
3
4
5
6
1
2
3
4
5
6
7
8
