2-2. Advanced Keyless Entry System
The system operates only when the driver is in the vehicle or w ithin
operational range while the key is being carried.
■Locking, Unlocking the D oors and the Liftgate
Operational range
■Opening the Liftgate/Trunk Lid Operational range
●When the battery power is low, or in places where there are hig h-intensity
radio waves or noise, the operational range may become narrower or the
system may not operate. For determining battery replacement, Re fer to
Keyless Entry System on P. 92.
● The system may not operate if you are too close to the windows or door
handles.
● If the key is left in the following areas and you leave the vehicle, the doors
may be locked depending on the radio wave conditions even if th e key is left
in the vehicle.
• Around the dashboard
• In the storage compartments such as the glove compartment or the cen- ter console
• On the rear parcel shelf (4–door)
• Next to a communication device such as a mobile phone
Operational Range
Exterior antenna
31 in. (800 mm)
31 in. (800 mm)
Exterior antenna
31 in. (800 mm)

271
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
4-2. Audio System
4
Interior Features
Antenna
4-Door
■AM/FM Radio Antenna
The AM/FM radio antenna receives both AM and FM signals.
The antenna is embedded into the window glass.
■Satellite Radio Antenna (if equipped)
The satellite radio antenna
receives SiriusXM signals.
5-Door
■AM/FM Radio Ante nna (if equipped)
The AM/FM radio antenna receives both AM and FM signals.
Ty p e A
To remove the antenna, turn
it counterclockwise.
To install the antenna, turn it
clockwise.
Make sure the antenna is
securely installed.
Antenna
NOTICE
■ AM/FM Radio Antenna
When washing the inside of the window which has an antenna, use a soft
cloth dampened in lukewarm water, gently wiping the antenna lin es. Use of
glass cleaning products could damage the antenna.
1
2

272
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
4-2. Audio System
Ty p e B
■Antenna for AM/FM and Satellite Radio Antenna (if equipped)
The antenna for AM/FM and
satellite radio antenna receives
both AM and FM signals and
SiriusXM signals.
NOTICE
■ AM/FM Radio antenna
Type A only:
● To prevent damage to the antenna, remove it before entering a c ar wash
facility or passing beneath a low overhead clearance.
● Be careful around the antenna when removing snow from the roof. Other-
wise the antenna could be damaged.
● When leaving your vehicle unattended, we recommend that you rem ove
the antenna and store it inside the vehicle.
