TOYOTA YARIS iA 2017 Owners Manual (in English)

5618-3. Customizable Features
YARIS iA_OM_OM99N89z_(U)
8
Specifications
■Ve h i c l e
●Power Door locks ( →P. 9 8 )
● Keyless entry system ( →P. 8 8 )
FeatureFactory
SettingAvailable SettingsSettings Change Method
Changes the auto lock/
unlock function setting for
all the doors according to
the vehicle speed, the
vehicle power supply con-
dition, and the selector
lever position. Lock: When
Driving/
Unlock: IGN
Off Lock: When
Driving/
Unlock: In Park
AD ×
Lock: Out of
Park/Unlock: In Park
Lock: Shift- ing Out of
Park
Lock: When Driving/
Unlock: IGN Off
Lock: When Driving
Off
123
FeatureFactory
SettingAvailable SettingsSettings Change Method
The method for unlocking
the doors using the smart
key can be changed. Driver’s:
Once/All Doors:
Tw i c e All Doors:
Once
AE ×Driver’s:
Once/All Doors: Twice
The time required for the
doors to relock automati-
cally after unlocking with
the smart key can be
changed.
60 seconds
90 seconds
A–×
60 seconds
30 seconds
123

5628-3. Customizable Features
YARIS iA_OM_OM99N89z_(U)
●Illuminated entry system ( →P. 402)
● Daytime running lights ( →P. 178)
● Auto headlight off ( →P. 175)
*: When set to Off, the lights-on reminder is operable.
FeatureFactory
SettingAvailable SettingsSettings Change Method
Time until interior lights
turn off after closing door 15 seconds60 seconds
A–×30 seconds
15 seconds
7.5 seconds
Time until interior lights
turn off automatically
when any door is not
closed completely
30 minutes
60 minutes
A–×
30 minutes
10 minutes
123
FeatureFactory
SettingAvailable SettingsSettings Change Method
Operational/non-opera-
tional OnOn
A– ×
Off
123
FeatureFactory
SettingAvailable SettingsSettings Change
Method
Time until headlights turn
off 30 seconds120 seconds
A–×
90 seconds
60 seconds
30 seconds
Off
*
123

5638-3. Customizable Features
YARIS iA_OM_OM99N89z_(U)
8
Specifications
●Lights-on reminder* (→ P. 513)
*: The setting of the lights-on reminder can be changed with the time set-
ting of auto headlight off function set to Off. Refer to Lights-On Reminder
on P. 513.
● Coming home light ( →P. 177)
● Leaving home light ( →P. 177)
FeatureFactory
SettingAvailable SettingsSettings Change Method
Warning beep volume OffHigh
A– ×
Low
Off
123
FeatureFactory SettingAvailable SettingsSettings Change Method
Time until headlights turn
off 30 seconds120 seconds
A–×
90 seconds
60 seconds
30 seconds
Off
123
FeatureFactory SettingAvailable SettingsSettings Change Method
Operational/non-opera-
tional OnOn
A– ×
Off
123

5648-3. Customizable Features
YARIS iA_OM_OM99N89z_(U)
●Turn indicator ( →P. 180)
● Three-flash turn signal ( →P. 181)
■System
● Language
*: Available only in display from the center display.
●Temperature unit
FeatureFactory
SettingAvailable SettingsSettings Change Method
Beep volume HighHigh
A– ×
Low
123
FeatureFactory
SettingAvailable SettingsSettings Change Method
Operational/non-opera-
tional OnOn
A– ×
Off
123
FeatureFactory
SettingAvailable SettingsSettings Change Method
Language indicated in dis-
play English
Depends on
market
*A– ×
123
FeatureFactory
SettingAvailable SettingsSettings Change Method
Temperature unit indi-
cated in display °F or °C°F
A– ×
°C
123

5658-3. Customizable Features
YARIS iA_OM_OM99N89z_(U)
8
Specifications
●Distance unit
■Fuel Economy Monitor ( →P. 199)
●
Ending display
●Fuel economy resetting procedure
FeatureFactory SettingAvailable SettingsSettings Change Method
Distance unit indicated in
display mi or kmmi
A– ×
km
123
FeatureFactory
SettingAvailable SettingsSettings Change Method
On/off OffOn
B– ×
Off
123
FeatureFactory
SettingAvailable SettingsSettings Change Method
Linkage/non-linkage with
fuel economy reset and
trip meter reset Off
On
B– ×
Off
123

5668-3. Customizable Features
YARIS iA_OM_OM99N89z_(U)

567
YARIS iA_OM_OM99N89z_(U)
Index
Alphabetical index ..................... 568

568Alphabetical index
YARIS iA_OM_OM99N89z_(U)
Alphabetical index
Accessory Socket.................... 404
Active Safety System .............. 204Laser Sensor ........................ 211
Pre-Crash Safety Technology ......................... 204
Smart City Brake Support (SCBS) ............................... 205
Add-On Non-Genuine Parts
and Accessories.................... 522
Air Bag/Front Seat Belt Pretensioner System
Warning Beep ........................ 513
Air Bag Systems ........................ 62
Ambient Temperature Display ................................... 153
Antilock Brake System (ABS) ...................................... 193
Audio Control Switch Adjusting the Volume ............ 295
Seek Switch .......................... 296
Audio System........................... 244 Antenna ................................ 244
Audio Control Switch ............ 295
Audio Set (Type A [non-touchscreen]) ............. 258
Audio Set (Type B [touchscreen])..................... 274
AUX/USB mode .................... 298
Operating Tips for Audio System ............................... 245
Automatic Transaxle ............... 164 Active Adaptive Shift (AAS) .................................. 167
Driving tips ............................ 174
Manual shift mode ................ 168
Shift-lock override ................. 168
Shift-lock system................... 167
Shift position indication ......... 165
Transaxle ranges .................. 165
Warning light ......................... 165 Battery ...................................... 434
Maintenance ......................... 435
Replacement ........................ 435
Specifications ....................... 554
Battery runs out....................... 491
Jump-Starting ....................... 491
Bluetooth
®............................... 319
Bluetooth® Audio
(Type A) ............................. 378
Bluetooth
® Audio
(Type B) ............................. 382
Bluetooth
®Hands-Free
(Type A) ............................. 354
Bluetooth
® Hands-Free
(Type B) ............................. 365
Troubleshooting .................... 395
Body Lubrication ..................... 430
Bottle Holder ............................ 406
Brakes Brake assist .......................... 190
Foot brake ............................ 187
Pad wear indicator ................ 189
Parking brake ....................... 188
Warning light......................... 189
Break-In Period ........................ 126
AB

569Alphabetical index
YARIS iA_OM_OM99N89z_(U)
Capacities................................. 555
Carbon Monoxide .................... 109
Cargo Sub-Compartment ........ 409
Cell Phones .............................. 523
Child RestraintChild-restraint precautions ...... 41
Child-restraint system installation ............................ 46
Installing child-restraint systems ....... ......................... 48
LATCH child-restraint
systems ....... ......................... 57
Child Safety Locks for Rear Doors ...................................... 102
Climate Control System .......... 234 Gas specifications................. 557
Manual Type ......................... 237
Operating Tips ...................... 234
Vent Operation...................... 235
Clock ......................................... 262
Collision warning..................... 515
Combination Meter .................. 148
Coming Home Light ................ 177
Cruise Control.......................... 213
Cruise Control Switch ........... 213
Cruise Main Indicator Light (Amber)/Cruise Set
Indicator Light (Green) ....... 214
Cup Holder ............................... 405
Customizable Features ........... 560
Dashboard Illumination........... 152
Daytime Running Lights ......... 178
Defogger Mirror .................................... 185
Rear window ......................... 185
Dimensions .............................. 556
Door Locks ................................. 94 Drive selection ......................... 201
Driving In Flooded Area .......... 134
Driving Tips
Automatic transaxle .............. 174
Break-in period ..................... 126
Driving in flooded area.......... 134
Driving on uneven road ........ 136
Floor mat .............................. 129
Hazardous driving................. 128
Overloading .......................... 135
Rocking the vehicle .............. 130
Saving fuel and protection of the environment ............. 127
Winter driving........................ 131
Driving on Uneven Road......... 136
Dynamic Stability Control (DSC) ...................................... 196
DSC OFF Indicator Light ...... 197
DSC OFF Switch .................. 197
TCS/DSC Indicator Light ...... 197
Emergency Starting Push-Starting ........................ 495
Starting a Flooded Engine .... 494
Emergency Towing Tiedown Hooks ..................... 499
Towing Description ............... 498
Emission Control System ....... 108
Ending Display ........................ 200
Engine Coolant ................................. 425
Engine Compartment Overview ............................ 421
Exhaust gas .......................... 109
Hood release ........................ 419
Oil ......................................... 422
Essential information .............. 412
Event Data Recorder ............... 524
C
D
E

570Alphabetical index
YARIS iA_OM_OM99N89z_(U)
Exhaust Gas ............................. 109
Exterior Care ............................ 462Aluminum Wheel Maintenance ....................... 468
Bright-Metal Maintenance ..... 467
Maintaining the Finish ........... 464
Plastic Part Maintenance ...... 469
Flasher Hazard warning..................... 186
Headlights ............................. 175
Flat Tire..................................... 477 Mounting the Spare Tire ....... 487
Removing a Flat Tire ............ 483
Floor Mat .................................. 129
Fluid Brake/Clutch ......................... 428
Washer ................................. 429
Fluids
Classification......................... 555
Fog Lights ................................ 179
Foot Brake ................................ 187
Front Seat ................................... 21
Fuel Filler lid and cap.................... 110
Gauge ................................... 151
Requirements ....................... 107
Tank capacity........................ 555
Fuel Consumption Display ..... 200
Fuel Economy Monitor ............ 199
Ending display ...................... 200
Fuel consumption display ..... 200
Fuses ........................................ 455 Panel description .................. 458
Replacement......................... 455
Gauges ..................................... 148
Glove Compartment ................ 408 Hazard Warning Flasher ......... 186
Hazardous Driving................... 128
Head Restraint ........................... 27
Headlights
Coming home light................ 177
Control .................................. 175
Flashing ................................ 176
High-low beam...................... 176
Leaving home light ............... 177
Hill Launch Assist (HLA) ........ 191
Hood Release........................... 419
Horn .......................................... 112
If a Warning Light Turns On or Flashes ........................ 501
Ignition
Switch ................................... 140
Ignition not switched off (STOP) warning beep............ 515
Illuminated Entry System ....... 402
Immobilizer System................. 121
Indicator Lights ....................... 158 Low engine coolant temperature ........................ 159
Wrench ................................. 159
Inside Trunk Release Lever .... 105
Inspecting Brake/Clutch
Fluid Level ............................. 428
Inspecting Coolant Level ........ 425
Inspecting Engine Oil Level ... 424
Inspecting Washer Fluid Level ....................................... 429
F
G
H
I
