VAUXHALL MOVANO_B 2016 User Guide

In brief9Exterior mirrorsManual adjustment
Swivel mirror in required direction.
Exterior mirrors 3 33.
Electric adjustment
Select the relevant exterior mirror and
adjust it.
Convex exterior mirrors 3 33,
Electric adjustment 3 33, Folding
exterior mirrors 3 33, Heated
exterior mirrors 3 34.
Steering wheel adjustment
Unlock lever, adjust steering wheel,
then engage lever and ensure it is fully locked.
Do not adjust steering wheel unless
vehicle is stationary and steering
wheel lock has been released.
Airbag system 3 49, Ignition
positions 3 117.

10In briefInstrument panel overview

In brief111Fixed air vents .................... 114
2 Headlight range
adjustment ........................... 97
Ultrasonic parking assist .....142
Traction control system ......136
Electronic Stability
Program ............................. 137
3 Side air vents .....................113
4 Light switch .......................... 95
Turn and lane-change
signals .................................. 98
High beam and low beam,
headlight flash ......................96
Sidelights .............................. 95
Automatic light control .......... 95
Exit lighting ......................... 101
Front fog lights .....................98
Rear fog light ........................ 99
High beam assist ..................965Instruments .......................... 77
Transmission display ............81
Driver Information Centre
(DIC) ..................................... 89
6 Horn ..................................... 73
Driver airbag ........................ 52
7 Remote control on
steering wheel .......................73
Cruise control .....................139
8 Windscreen wiper,
windscreen washer system ..74
Trip computer ........................ 92
9 Coin tray ............................... 64
10 Power outlet, USB slot .........76
11 Centre air vents .................. 113
12 Storage compartment ...........64
13 Front passenger airbag .........52
Storage compartment ..........64
14 Glovebox .............................. 65
15 Cupholders ........................... 6516Climate control system ....... 103
Electronic climate control
system ................................. 105
Seat belt reminder ................. 84
Front passenger airbag
deactivation ........................... 53
17 Cigarette lighter .................... 77
Power outlet ......................... 76
18 Gear lever, Manual
transmission ........................ 130
Manual transmission
automated ........................... 130
19 Cruise control and speed
limiter ................................. 139
Manual transmission
automated,
Winter and Laden modes ....132
Idle speed control ...............118
Stop-start system ................119
ECO mode .......................... 116
20 Ignition switch with
steering wheel lock ............117
21 Steering column controls .....73

12In brief22Steering wheel adjustment ..73
23 Bonnet release lever ..........155
24 Auxiliary heater ...................109
25 Storage compartment ..........64
Fuse box ............................ 171Exterior lighting
Turn outer light switch:
7:off0:sidelights9 P:headlightsAUTO:automatic light control:
headlights are switched on
and off automatically.
Lighting 3 95, Automatic light
control 3 95, Headlight warning
device 3 91, Adaptive forward
lighting 3 98.
Front and rear fog lights
Turn inner light switch:
>:front fog lightsr:rear fog lights
Front and rear fog lights 3 98,
3 99.

In brief13Headlight flash, high beam and
low beam
Pull lever.
High beam 3 96, Headlight flash
3 97.
Turn and lane-change signalslever up:right turn signallever down:left turn signal
Turn and lane-change signals
3 98.
Hazard warning flashers
Operated with the ¨ button.
Hazard warning flashers 3 98.

14In briefHorn
Press j.
Washer and wiper systems
Windscreen wiper0:offP /AUTO:timed interval wiping or
automatic wiping with
rain sensor1:slow2:fast
Windscreen wiper 3 74, Wiper
blade replacement 3 162.
Windscreen washer
Pull lever.
short
pull:wiper swipes once and
washer fluid is sprayed onto
the windscreenlong
pull:wiper swipes for a few strokes and washer fluid is
sprayed onto the
windscreen
Windscreen washer 3 74, Washer
fluid 3 159.

In brief15Climate control
Heated rear window
Heating is operated by pressing Ü.
Heated rear window 3 37.
Heated exterior mirrors
Pressing Ü also activates the heated
exterior mirrors.
Heated exterior mirrors 3 34.
Demisting and defrosting the
windows
Climate control system
● Set temperature control to warmest level.
● Set fan speed to highest level.
● Set air distribution control to V.
● Switch on heated rear window Ü.
● Switch cooling AC on.
● Open side air vents as required and direct them towards door
windows.
Climate control system 3 103.
Electronic climate control system
Press V.
Temperature and air distribution are
set automatically and the fan runs at
a high speed.
Electronic climate control system 3 105.

16In briefTransmission
Manual transmission
Reverse: with the vehicle stationary,
depress clutch pedal and then pull up
the collar on the selector lever and
engage the gear.
If the gear does not engage, set the
lever to neutral, release the clutch
pedal and depress again; then repeat gear selection.
Manual transmission 3 130.
Manual transmission automatedN:neutralo:drive position+:higher gear-:lower gearA/M:switch between automatic and
manual modeR:reverse gear. Engage only
when vehicle is stationary.
Manual transmission automated
3 130.
Starting off
Check before starting off ● Tyre pressure and condition 3 176, 3 219.
● Engine oil level and fluid levels 3 156.
● All windows, mirrors, exterior lighting and number plates are
free from dirt, snow and ice and
are operational.
● Proper position of mirrors, seats and seat belts 3 33, 3 39,
3 47.
● Brake function at low speed, particularly if the brakes are wet.

In brief17Starting the engine
● Turn key to position 1.
● Move the steering wheel slightly to release the steering wheel
lock.
● Operate clutch and brake.
● Do not operate accelerator pedal.
● Turn the key to position 2 for
preheating and wait until control
indicator ! extinguishes in the
Driver Information Centre (DIC).
● Turn key to position 3 and
release.
Starting the engine 3 118.
Stop-start system
If the vehicle is at low speed or in
standstill and certain conditions are
fulfilled, activate an Autostop as
follows:
● Depress the clutch pedal.
● Move the selector lever to N.
● Release the clutch pedal.
An Autostop is indicated when control indicator Ï illuminates green in the
instrument cluster.
To restart the engine, depress the
clutch pedal again.
Stop-start system 3 119.
Parking9 Warning
● Do not park the vehicle on an
easily ignitable surface. The
high temperature of the
exhaust system could ignite the
surface.
● Always apply parking brake without pressing release
button. Apply as firmly as
possible on a downhill slope or
uphill slope. Depress brake
pedal at the same time to
reduce operating force.
● Switch off the engine.
● If the vehicle is on a level surface or uphill slope, engage
first gear. On an uphill slope,
turn the front wheels away from
the kerb.
If the vehicle is on a downhill
slope, engage reverse gear.
Turn the front wheels towards the kerb.

18In brief● Close the windows.
● Turn the ignition key to position
0 and remove it. Turn the
steering wheel until the
steering wheel lock is felt to
engage.
● Lock the vehicle by pressing e on
the remote control 3 21.
● Activate the anti-theft alarm system 3 31.
● The engine cooling fans may run
after the engine has been
switched off 3 155.
Caution
After running at high engine
speeds or with high engine loads,
operate the engine briefly at a low load or run in neutral for approx.30 seconds before switching off, in
order to protect the turbocharger.
Keys, locks 3 19, Laying the vehicle
up for a long period of time 3 154.
