VAUXHALL VIVA 2015.75 Owner's Manual

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
200 Service and Maintenance
Recommended
Fluids, Lubricants,
and Parts
Recommended Fluids
and Lubricants
Only use products that meet the
recommended specifications.
Damage resulting from the use of
products not compliant with these
specifications will not be covered by
the warranty.
{Warning
Operating materials are
hazardous and could be
poisonous. Handle with care. Pay
attention to information given on
the containers.
Engine oil
Engine oil is identified by its quality
and its viscosity. Quality is more
important than viscosity when
selecting which engine oil to use.
The oil quality ensures e.g. engine
cleanliness, wear protection and oil
ageing control, whereas viscosity
grade gives information on the oil's
thickness over a temperature range.
Dexos is the newest engine oil
quality that provides optimum
protection for petrol and diesel
engines. If it is unavailable, engine
oils of other listed qualities have to
be used. Recommendations for
petrol engines are also valid for
Compressed Natural Gas (CNG),
Liquefied Petroleum Gas (LPG) and
Ethanol (E85) fuelled engines.
Select the appropriate engine oil
based on its quality and on the
minimum ambient temperature
0
Recommended Fluids and
Lubricants0200. Topping up engine oil
Engine oils of different
manufacturers and brands can be
mixed as long as they comply with
the required engine oil quality and
viscosity.
Use of engine oil with only ACEA
A1/B1 or only A5/B5 quality is
prohibited, since it can cause
longterm engine damage under
certain operating conditions.
Select the appropriate engine oil
based on its quality and on the
minimum ambient temperature
0
Recommended Fluids and
Lubricants
0200.
Additional engine oil additives
The use of additional engine oil
additives could cause damage and
invalidate the warranty.

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
Service and Maintenance 201
Engine oil viscosity grades
The SAE viscosity grade gives
information of the thickness of
the oil.
Multi-grade oil is indicated by two
figures, e.g. SAE 5W-30. The first
figure, followed by a W, indicates
the low temperature viscosity and
the second figure the high
temperature viscosity.
Select the appropriate viscosity
grade depending on the minimum
ambient temperature
0
Recommended Fluids and
Lubricants0200.
All of the recommended viscosity
grades are suitable for high ambient
temperatures.
Coolant and antifreeze
Use only organic acid type-long life
coolant (LLC) antifreeze approved
for the vehicle. Consult a workshop.
The system is factory filled with
coolant designed for excellent
corrosion protection and frost
protection down to approx. -36 °C.
In northern countries with very low
temperatures the factory filled
coolant provides frost protection
down to approx. -50 °C. This
concentration should be maintained
all year round. The use of additional
coolant additives intended to give
additional corrosion protection or
seal against minor leaks can cause
function problems. Liability for
consequences resulting from the
use of additional coolant additives
will be rejected.
Brake and clutch fluid
Over time, brake fluid absorbs
moisture which will reduce braking
effectiveness. The brake fluid
should therefore be replaced at the
specified interval.

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
202 Service and Maintenance
European service schedule
Required engine oil qualityAll European countries with European service interval
Engine oil quality Petrol engines (including CNG, LPG, E85)
dexos 1
dexos 2
V
In case dexos quality is unavailable you may use max. 1 litre engine oil quality ACEA C3 for topping up once between
each oil change.
Engine oil viscosity grades
All European countries with European service interval
Ambient temperature Petrol
down to -25 °C SAE 5W-30 or SAE 5W-40
below -25 °C SAE 0W-30 or SAE 0W-40

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
Service and Maintenance 203
International service schedule
Required engine oil qualityAll countries with international service interval
Engine oil quality Petrol engines (including CNG, LPG, E85)
dexos 1
V
dexos 2V
In case dexos quality is unavailable you may use the oil qualities listed below :
All countries with international service interval
Engine oil quality Petrol engines (including CNG, LPG, E85)
GM-LL-A-025
V
GM-LL-B-025 -
ACEA A3/B3
V
ACEA A3/B4V
ACEA C3V
API SMV
API SN resource conservingV

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
204 Service and Maintenance
Engine oil viscosity grades
All countries with international service interval
Ambient temperature Petrol
down to -25 °C SAE 5W-30 or SAE 5W-40
below -25 °C SAE 0W-30 or SAE 0W-40
down to -20 °C SAE 10W-30 1) or SAE 10W-40 1)
1) Permitted, but use of SAE 5W-30 or SAE 5W-40 with dexos quality is recommended.

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
Technical Data 205
Technical Data
Vehicle Identification
Vehicle IdentificationNumber (VIN) . . . . . . . . . . . . . . . 205
Engine Identification . . . . . . . . . . 205
Identification Plate . . . . . . . . . . . . 206
Vehicle Data
Engine Data . . . . . . . . . . . . . . . . . . 207
Performance . . . . . . . . . . . . . . . . . 207
Vehicle Weight . . . . . . . . . . . . . . . 208
Vehicle Dimensions . . . . . . . . . . 208
Capacities and Specifications . . . . . . . . . . . . . . . 209
Tyre Pressure . . . . . . . . . . . . . . . . 209
Vehicle Identification
Vehicle Identification
Number (VIN)
The Vehicle Identification Number is
located in the engine compartment.
The Vehicle Identification Number
may be embossed on the instrument
panel, visible through the
windscreen.
Engine Identification
The technical data tables show the
engine identifier code. Engine data
0Engine Data 0207.
To identify the respective engine,
refer to the engine power in the
EEC Certificate of Conformity
provided with your vehicle or other
national registration documents.

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
206 Technical Data
Identification Plate
The identification plate is on the left
side door frame.
Information on identification label:
1 = Manufacturer
2 = Type approval number
3 = Vehicle Identification Number
4 = Permissible gross vehicle
weight rating in kg
5 = Permissible gross train
weight in kg
6 = Maximum permissible front axle
load in kg
7 = Maximum permissible rear axle
load in kgThe combined total of front and rear
axle loads must not exceed the
permissible gross vehicle weight.
For example, if the front axle is
bearing its maximum permissible
load, the rear axle can only bear a
load that is equal to the gross
vehicle weight minus the front
axle load.
The technical data is determined in
accordance with European
Community standards. We reserve
the right to make modifications.
Specifications in the vehicle
documents always have priority over
those given in this manual.

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
Technical Data 207
Vehicle Data
Engine Data
Sales designation1.0
Engine identifier code L5Q
Number of cylinders 3
Piston displacements [cm³] 999
Engine Power [kW] at rpm 55
Torque [Nm] at rpm 95
Octane rating RON
recommended 95
possible 98
possible 91
Fuel type Petrol
Performance
Engine 1.0
Top speed [km/h] ([mph])
Manual gearbox 106 mph
Automatic transmission -

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
208 Technical Data
Vehicle Weight
Kerb weight, Basic model without any optional equipment
Engine4 seater 5 seater
Without/without air
conditioning [kg] L5Q
938/947 939/945
Optional equipment and accessories increase the Kerb weight.
Loading information.
Vehicle Dimensions
Length [mm] 3675
Width without exterior mirrors [mm] 1595
Width with two exterior mirrors [mm] 1876
Height (without aerial) [mm] w/o roof rack 1485
Length of load compartment floor [mm] 486
Length of load compartment with folded rear seats [mm] 1109
Load compartment width [mm] 978
Load compartment height [mm] 522
Height of load compartment opening [mm] 608
Wheelbase [mm] 2385
Turning circle diameter [m] 9.6(14"), 10.4(15")

Vauxhall Viva Owner Manual (GMK-Localizing-EU RHD-9231169) - 2016 -
CRC - 5/7/15
Technical Data 209
Capacities and Specifications
Engine oil1.0
including Filter [l] 4.5 L
between MIN and MAX [l] 1
Fuel tank
petrol, nominal capacity [l] 32
Tyre Pressure
TypeFront[kPa/bar] ([psi])
Rear[kPa]
Comfort ECO Full load Comfort ECO Full load
165/65R14 220/2.2 (32) 270/2.7 (39) 260/2.6 (38) 210/2.1 (30) 250/2.5 (36) 300/3.0 (43)
185/55R15 220/2.2 (32) 270/2.7 (39) 260/2.6 (38) 210/2.1 (30) 250/2.5 (36) 300/3.0 (43)
195/45R16 220/2.2 (32) 270/2.7 (39) 260/2.6 (38) 210/2.1 (30) 250/2.5 (36) 300/3.0 (43)
T105/70D14 (Spare) 420/4.2 (60)
