VAUXHALL VIVARO C 2020 Infotainment system

Phone111
Select Dial.
Enter the desired number: Select the
desired digits and confirm each digit with OK.
To start dialling, select OK on the
display.
Using the phone book
The phone book contains contact
names and numbers.
Press MENU and then select
Telephone .
Select Call and then select Directory.
To start dialling, scroll through the list and select the desired entry name.
Using the call list
All incoming, outgoing, or missed
calls are registered in the call list.
Press MENU and then select
Telephone .
Select Call and then select Calls list.
To start dialling, scroll through the list
and select the desired entry.
Sending contacts from a mobile
device to the Infotainment system
With certain telephones connected byBluetooth, you can send a contact to
the directory of the Infotainment
system. Contacts imported this way
are saved in a permanent directory
visible to all, irrespective of the
telephone connect.
To enter this directory, press MENU
and then select Telephone.
Select Directory management .
The menu for this directory is not
accessible if it is empty.Putting incoming calls
automatically on hold
For safety reasons the Infotainment
system can put all incoming calls on
hold by default.
To activate this function, press
MENU and then select Telephone.
Select Telephone management and
then select Telephone parameters .
To activate the Automatic on hold
function, press OK.
Incoming phone call If an audio mode, e.g. the radio mode,
is active at the time of an incoming
call, the relating audio source will be
muted and stay muted until the call
ends.
To answer the call, select Yes in the
message shown in the display.

112PhoneTo reject the call, select No in the
message shown in the display or
press and hold A on the steering
wheel.
To put an incoming call on hold, select
On hold in the message shown in the
display.
Second incoming phone call
If a second phone call comes in
during an ongoing call, a message is
displayed.
To answer the second call and end the ongoing call: select Yes in the
message shown in the display.
To reject the second call and continue the ongoing call: select No in the
message shown in the display.
Functions during a phone call During an ongoing phone call, you
can use the functions of the
contextual menu.
Press OK to open the contextual
menu.
To end the call, select Hang up.
To switch off the microphone, activate Micro OFF . To switch the microphone
on, deselect Micro OFF.
To transfer the call to the telephone
(for example to leave the vehicle
while continuing the conversation),
activate Telephone mode . To transfer
the call to the Infotainment system,
deselect Telephone mode .
To put the call on hold, select On
hold during an ongoing call. If a call
has been put on hold, the menu item
On hold changes to Resume. To
return to a call put on hold, select Resume .
To switch between two calls, select
Switch .
Mobile phones and CB radio
equipment
Installation instructions and
operating guidelines
The vehicle specific installation
instructions and the operating
guidelines of the mobile phone and
handsfree manufacturer must be
observed when installing and
operating a mobile telephone. Failure
to do so could invalidate the vehicle
type approval (EU directive 95/54/
EC).
Recommendations for fault-free
operation:
● Professionally installed exterior antenna to obtain the maximum
range possible,
● Maximum transmission power 10 watts,
● Installation of the phone in a suitable spot, consider relevant
Note in the Owner's Manual,
section Airbag system .

Phone113Seek advice on predetermined
installation points for the external
antenna or equipment holder and
ways of using devices with a
transmission power exceeding
10 watts.
Use of a handsfree attachment without external antenna with mobile
telephone standards GSM
900/1800/1900 and UMTS is only
permitted if the maximum
transmission power of the mobile
telephone is 2 watts for GSM 900 or
1 watt for the other types.
For reasons of safety, do not use the
phone while driving. Even use of a handsfree set can be a distractionwhile driving.9 Warning
Operation of radio equipment and
mobile telephones which fail to
meet above mentioned mobile
telephone standards is only
permitted using an antenna
located outside of the vehicle.
Caution
Mobile telephones and radio
equipment may lead to
malfunctions in the vehicle
electronics when operated inside
the vehicle with no exterior
antenna, unless the above
mentioned regulations are
observed.

114IndexAActivating Bluetooth music .........105
Activating the Infotainment system 94
Activating the radio .....................100
Activating the USB function ........105
Adjust time and date .....................98
Automatic volume adjustment ......97
Auto volume.................................. 97
AUX input ................................... 105
B Balance......................................... 97
Basic operation ............................. 96
Bass.............................................. 97
Blocking out traffic announcements ......................101
Bluetooth Bluetooth connection ..............109
Bluetooth music....................... 104
Phone ...................................... 110
Bluetooth connection ..................109
Bluetooth music Activating................................. 105
General information ................104
Operation ................................ 105
Prerequisites ........................... 105C
Call Functions during a call ............110
Incoming call ........................... 110
Initiating a phone call ..............110
Call lists ...................................... 110
Change display language .............98
Control elements Infotainment system ..................91
Phone ...................................... 108
Steering wheel .......................... 91
Control elements overview ...........91
D DAB ............................................ 102
Date adjust......................................... 98
Digital audio broadcasting ..........102
Display activate automatic scrolling .......98
adjust brightness .......................98
adjust units for temperature
and fuel consumption ................98
change language ......................98
Distribution.................................... 97
Dynamic audio adaption .............102
E Equaliser....................................... 97

115F
Factory default settings ................98
G General information ....104, 107, 108
Bluetooth music....................... 104
Infotainment system ..................90
Phone ...................................... 108
USB port.................................. 104
I Infotainment control panel ............91
M
Menu operation............................. 96 Mobile phones and CB radio equipment .............................. 112
Mute.............................................. 94
O
Operation .................................... 110
Bluetooth music....................... 105
Infotainment system ..................94
Menu ......................................... 96
Phone ...................................... 110
Radio ....................................... 100
USB port.................................. 105P
Personal settings ..........................98
Phone Activating................................. 110
Bluetooth ................................. 108
Bluetooth connection ..............109
Call lists ................................... 110
Control elements .....................108
Dialling a number ....................110
Functions during a call ............110
General information ................108
Important information ..............108
Incoming call ........................... 110
Phone book ............................. 110
Selecting the ring tone ............110
Phone book ................................ 110
Playing audio .............................. 105
R
Radio Activating................................. 100
Band selection ........................ 102
Configuring DAB .....................102
Digital audio broadcasting
(DAB) ...................................... 102
Dynamic audio adaption .........102
Radio data system (RDS) .......101
Radio traffic service................. 101
Selecting the waveband ..........100
Station search ......................... 100Station tuning.......................... 100
Traffic announcements ...........101
Usage ...................................... 100
Radio data system .....................101
Radio traffic service ....................101
RDS ............................................ 101
Ring tone Selecting the ring tone ............110
S Selecting the waveband .............100
Sound ........................................... 97
Speech recognition .....................107
Station search............................. 100
Switching the Infotainment system on .................................. 94
Switching the radio on ................100
System settings ............................ 98
T
Theft-deterrent feature ................. 90
Time adjust......................................... 98
Tone and volume settings ............97
Traffic announcements ...............101
Treble ........................................... 97
U Update software ........................... 98
Usage ........................... 94, 100, 107
Bluetooth music....................... 105

116Infotainment system..................94
Menu ......................................... 96
Phone ...................................... 110
Radio ....................................... 100
USB port.................................. 105
USB menu .................................. 105
USB port Activation................................. 105Connecting the USB device ....104
General information ................104
Important information ..............104
Operation ................................ 105
Removing the USB device ......105
USB menu ............................... 105
V Voice recognition ........................107
Volume Mute function............................. 94Setting the volume ....................94

Copyright by Vauxhall Motors Ltd.The information contained in this publication is effective as of the date indicated below. Vauxhall Motors Ltd. reserves the right to make changes to the technical specifications, features and design of the vehicles relative to the information contained in this publication, as well as changes to the publication itself.
Edition: March 2019, Vauxhall Motors Ltd.Printed on chlorine-free bleached paper.
