VOLKSWAGEN JETTA GLI 2013 1B / 6.G Owner's Manual
Manufacturer: VOLKSWAGEN, Model Year: 2013, Model line: JETTA GLI, Model: VOLKSWAGEN JETTA GLI 2013 1B / 6.GPages: 276, PDF Size: 4.54 MB
Page 21 of 276
Main menus Function See
Settings Includes the Convenience and Lights & Vision submenus, as well as many settings such as time, speed warning for winter tires, language, and units.
MFI menu (Multi-Function Indicator)
Page 22 of 276
Display Function
Range I ‐‐ km in the tank the way you are currently driving. Takes account of the cur-rent fuel consumption, among other things.
Route ‐‐ mi Distance driven in miles (km) per trip memories 1 and 2 (toggle).
Route ‐‐ km
Average speed ‐‐ mph Average speed on trips per trip memories 1 and 2 (toggle). Displayed once the vehicle has been driven about 300 feet (100 m). Until then, dashes may appear instead of a number. The value displayed is updated every 5 seconds. Average speed ‐‐ km/h
‐‐ mph Digital display of current vehicle speed.
‐‐ km/h
Speed warning ‐‐‐ mph When the set speed (from 20–155 mph or 30–250 km/h) is exceeded, an acoustic warning sounds and a visual message may also appear in the instrument cluster display. Speed warning ‐‐‐ km/h
Switching between the displays
x Use the arrow up and down buttons *and + on the multi-function steering wheel.
Storing speed for the speed warning
x Select the Speed warning ‐‐ mph or Speed warning ‐‐ km/h display.
x Press the OK button to save the current speed and to activate the warning.
x If the speed is not right, press buttons * or + on the multi-function steering wheel to set a different speed within about 5 seconds. Then press the OK button a second time or just wait a few seconds. The speed is saved and the warning is activated.
x To deactivate, toggle to ‐‐‐ mph or ‐‐‐ km/h and press the OK button. The set speed is deleted.
Manually erasing trip memory 1 or 2
x Navigate to MFI > Route.
x Select the memory to be erased.
x Press the OK button for about 2 seconds.
Enabling and disabling displays
Use the Settings menu, submenu MFI data to enable displays you want to be available under the MFI menu in the instrument cluster display. The units in which data is displayed can also be changed 29.
Settings menu
Page 23 of 276
Settings menu Function
Compass Calibrating the compass on vehicles without a factory-installed naviga-tion system. To calibrate, follow the instructions in the instrument cluster display
Convenience Convenience function settings
Lights & Vision Vehicle lighting settings
Time Set hours and minutes for the instrument cluster clock and the Radio & Navigation System clock. The time can be displayed in 12 or 24 hour format, and can also be set to daylight savings time.
Snow tires Set up a visual and acoustic speed warning. Use the feature only when winter tires are installed that have a speed rating less than top vehicle speed.
Units Set the units in which temperature, fuel consumption, and distances should be displayed (for example, whether to show distance driven in miles or kilometers).
Alt. speed dis. Activate/deactivate alternative speed display (mph or km/h).
Service Display service messages or reset service reminder display.
Factory setting Reset the functions in the Settings menu back to the factory settings.
Convenience submenu
