VOLKSWAGEN JETTA GLI 2013 1B / 6.G Owner's Guide

Maximum power output (SAE net) Injection technologyEngine ID codeMaximum torque No. of cylinders Displacement
200 hp at 5100 – 6000 rpm (147 kW at 5100 – 6000 rpm) TSI® CBFA, CCTA2.0T
207 lb-ft at 1700 – 5000 rpm (280 Nm at 1700 - 5000 rpm)
4 cylinders 121 CID 1984 ccm

Dimensions

Vehicle key set

Remote control vehicle keys

Fig. 17 Remote control vehicle key with panic button.

Canadian customers can contact an authorized Volkswagen dealer or Volkswagen Service Facility or call the Volkswagen Canada Customer CARE Center at 1-800-822-8987.
NOTICE
The remote control vehicle keys contain electrical components. Protect them from damage, moisture and rough handling.
Do not press the buttons on the remote control vehicle key unless you actually want to use the function in question. Since terrain and conditions vary, pressing a button on the remote control vehicle key when it is not necessary may unlock the vehicle or set off the panic alarm, even if you think you are out of range.
Remote control vehicle key functions can be temporarily disrupted by interference from transmit-ters near the vehicle that use the same frequency range (such as radio equipment or cellular phones).
Things between the remote control vehicle key and vehicle, bad weather, as well as a weak battery can reduce the operating range.
If the remote control vehicle key buttons or the power locking buttons are pushed repeatedly in quick succession, the power locking system is switched off for a brief period to help keep it from being overloaded. The vehicle is then unlocked for about 30 seconds. Unless a door or the luggage com-partment lid is opened in this span of time, the vehicle is automatically locked afterwards.
Indicator light in the remote control vehicle key

Fig. 18 Indicator light in the remote control vehicle key.

Replacing the remote control vehicle key battery

Fig. 19 Remote control vehicle key: Open battery compartment cover.

Fig. 20 Remote control vehicle key: Remove old battery.

x Make sure the plus and minus poles of the battery are correctly positioned.
Dispose of old batteries in an environmentally responsible manner and keep them out of the reach of children.
Batteries of the type used in your remote control vehicle key may contain Perchlorate Material. Special handling may apply – see http://www.dtsc.ca.gov/hazardouswaste/perchlorate. Obey all legal requirements regarding handling and disposal of these batteries. Authorized Volkswagen dealers and authorized Volkswagen Service Facilities are familiar with the requirements, and we recommend that you have them perform this service for you.
Synchronizing the remote control vehicle key

Doors

Fig. 27 In the right rear door: Child safety lock A deactivated, B activated.

Luggage compartment lid

Warning light
