VOLKSWAGEN JETTA HYBRID 2015 1B / 6.G Owners Manual

CAR menu

Fig. 128 In the radio or Navigation system display: Overview of Zero emissions driving time.

You can always go back to the previously active menu by pressing the

Cruise control

Display
Different cruise control versions are available. The stored speed is shown in the instrument cluster display on some equipment versions.
Status fig. 129
(A) Cruise control temporarily deactivated. Stored speed displayed in small numbers.
(B) System malfunction. See an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
(C) Cruise control activated. No speed stored in memory.
(D) Cruise control is active. Stored speed displayed in large numbers.
Indicator lights

Lights up Possible cause
%
Cruise control is regulating the vehicle speed.
#25)3%

When the ignition is switched on, several warning and indicator lights come on briefly for a function check. They go out after a few seconds.
WARNING
Failure to heed warning lights and instrument cluster text messages can cause the vehicle to break down in traffic and result in a collision and serious personal injury.
x Never ignore warning lights or text WARNINGS.
x Always stop the vehicle as soon as it is safe to do so.
NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.

Cruise control operation

Fig. 130 Left-hand side of the multi-function steering wheel: Buttons for operating the cruise control.

In order to: You must: ⇒ fig. 130 Result:
Increase set
speed (while
cruise control is
actively control-
ling vehicle
speed).
Briefly press the 2%3 but-
ton on the multi-function
steering wheel to increase
the speed in small incre-
ments of 1 mph (1 km/h)
and to store the speed.
The vehicle will accelerate
until the new higher speed
is reached and saves the
new higher speed in the
memory.
Press the

In order to: You must: ⇒ fig. 130 Result:
Press and hold the

Rear View Camera system

WARNING
The Rear View Camera system technology cannot overcome the laws of physics and the limits of the system. Careless or unintentional use of the Rear View Camera system may result in accidents and severe injuries.
x Always adjust your speed and driving style to road, traffic, weather, and visibility condi-tions.
x Always keep an eye on the parking direction and the vehicle surroundings. The front of the vehicle swings out more than the rear of the vehicle.
x Never pay so much attention to the graphics shown on the screen that you fail to notice what is going on around you.
x Always watch for people, especially small children, animals, and objects, because the Rear View Camera system may not always be able to detect them.
x The system may not be able to clearly show everything behind the vehicle.
x Use the Rear View Camera system only when the luggage compartment lid is completely closed.
NOTICE
x The Rear View Camera system shows only two-dimensional images on the screen. Due to the lack of depth of field, it may be difficult or impossible to identify protruding objects or recesses in the road, for example.
x Things like thin rods, fences, posts, and trees may not be detected by the Rear View Cam-era system and could damage the vehicle.
Special considerations

x Park the vehicle in a safe place on a firm, level surface.
x Apply the parking brake to help prevent the vehicle from moving ⇒  Parking brake.
x Switch on the ignition.
x Switch on the radio or the navigation system (if not already on) ⇒ Booklet Radio or
⇒ Booklet Navigation system.
x Shift into Reverse (R).
x Depending on the equipment version, tap the • or the Options function key on the screen.
x Adjust the desired settings in the menu.
Camera

Fig. 131
