VOLKSWAGEN JETTA HYBRID 2015 1B / 6.G Owner's Manual

Menu Function See
Settings
Includes various submenus and
settings such as time, speed warn-
ing for winter tires, language, and
units.

MFI menu (Multi-Function Indicator)

Display Function
Travel time Driving time in hours (h) and minutes (min) corre-
sponding to trip memories 1 and 2 (toggle).
Consumption
--.- mpg
Current fuel consumption in miles per gallon
(l/100 km) while driving.
When units are set to miles, dashes appear instead of
a number when the engine is running and the vehicle
is standing still.
When units are set to kilometers, the display shows
liters consumed per hour when the engine is running
and the vehicle is standing still.
Consumption
--.- l/100 km
Av. consump-
tion
--.- mpg
Average fuel consumption in miles per gallon
(l/100 km) on trips per trip memories 1 and 2 (toggle)
is displayed once the vehicle has been driven about
330 feet (100 m). Until then, dashes appear instead
of a number. The value displayed is updated every
5 seconds.
Av. consump-
tion
--.- l/100 km
Range  -- mi Estimated distance in miles (km) that the vehicle can
go with the fuel left in the tank the way you are cur-
rently driving. Takes account of the current fuel con-
sumption, among other things. Range  -- km
Route -- mi Distance driven in miles (km) per trip memories 1 and
2 (toggle). Route -- km
Average speed
-- mph
Average speed on trips per trip memories 1 and 2
(toggle). Displayed once the vehicle has been driven
about 300 feet (100 m). Until then, dashes may ap-
pear instead of a number. The value displayed is
updated every 5 seconds.
Average speed
-- km/h
-- mph
Digital display of the current vehicle speed.
-- km/h

Display Function
Oil tempera-
ture ---°F
Current engine oil temperature.
Oil tempera-
ture ---°C
Speed warning
--- mph When the set speed (from 20–155 mph or 30–
250 km/h) is exceeded, an acoustic warning sounds
and a visual message may also appear in the instru-
ment cluster display. Speed warning
--- km/h

Switching between the displays
x Use the arrow up and down buttons (* and +) on the multi-function steering wheel.
Storing speed for the speed warning
x Select the Speed warning display.
x Press the /+ button to save the current speed and to activate the warning.
x If the speed is not right, press buttons * or + on the multi-function steering wheel to set a differ-ent speed within about 5 seconds. Then press the /+ button a second time or just wait a few seconds. The speed is saved and the warning is activated.
x To deactivate, toggle to Speed warning and press the /+ button. The set speed is deleted.
Manually erasing trip memory 1 or 2
x Select the trip memory to be erased.
x Press the /+ button for about 2 seconds.
Enabling and disabling displays
Use the Settings menu, submenu MFI data to enable displays you want to be available under the MFI menu in the instrument cluster display. The units in which data is displayed can also be changed
⇒  Settings menu.
Settings menu

Settings menu Function
Language Set the language for messages in the display and
navigation system.
MFI data Select the features you want to have displayed in the
MFI menu in the instrument cluster display
Convenience Convenience function settings
Lights & Vi-
sion Vehicle lighting settings
Time
Set hours and minutes for the instrument cluster clock
and the Radio & Navigation System clock. The time
can be displayed in 12 or 24 hour format, and can
also be set to daylight savings time.
Snow tires
Set up a visual and acoustic speed warning. Use the
feature only when winter tires are installed that have
a speed rating less than top vehicle speed.
Units
Set the units in which temperature, fuel consumption,
and distances should be displayed (for example,
whether to show distance driven in miles or kilome-
ters).
Service View the service reminder display
Factory set-
ting
Reset the functions in the Settings menu back to
the factory settings.

Volkswagen Car-Net: Connecting you and your
vehicle

WARNING
Driver distraction causes accidents, collisions and serious personal injury! Using application software and Volkswagen Car-Net services while driving can distract the driver from traffic.
x Always drive attentively and responsibly.

Volkswagen Car-Net service

WARNING
Vehicle health reports do not replace the information provided by the vehicle warning and indicator lights. Failure to heed warning lights and instrument cluster text messages can cause the vehicle to break down in traffic and result in a collision and serious personal injury.
x Never ignore warning lights or text WARNINGS.
x Always stop the vehicle as soon as it is safe to do so.
x Park the vehicle at a safe distance from moving traffic and where no part of the hot cata-lytic converter and exhaust system can come into contact with flammable materials under the vehicle, such as dry grass, brush, spilled fuel, etc.
x A broken down vehicle presents a high accident risk for itself and others. Switch on emergency flashers and set up a warning triangle to warn oncoming traffic.
x Before opening the engine hood, always switch off the engine and let the engine cool down.
x Always be very careful when working in the engine compartment, which is a potentially dangerous area in any motor vehicle and can cause serious personal injury.
NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
Volkswagen collects, processes, transmits, uses and shares information about you and your vehicle in accordance with the Volkswagen Car-Net Terms of Service and Privacy Policy. See the Volkswagen Car-Net Terms of Service and Privacy Policy at http://www.vw.com/carnet for more de-tails.
Volkswagen Car-Net services use a system based on a wireless communication network. If all technical and other conditions are met and Volkswagen Car-Net still does not work properly, please try using the service again later.
Features

Safe & Secure:
Feature Description
Automatic Crash
Notification (ACN)
Automatic Crash Notification is initiated in the event
of airbag deployment or rollover. When the feature is
activated the Volkswagen Car-Net Response Center
is notified of your location and contacts your vehicle
to determine the risk of injury and to dispatch help.
Help is dispatched even if the Volkswagen Car-Net
Response Center does not connect to the vehicle's
occupants. Automatic Crash Notification may be
engaged for up to 6 months without activating a trial
or paid subscription.
Manual Emergency
Call
In the case of an emergency, press the • button in
the 3-button module: The Volkswagen Car-Net de-
vice initiates a connection to the Volkswagen Car-
Net Response Center. The location of the vehicle
and customer data for identification is sent at the
same time.
Roadside Assis-
tance
Press the > button in the 3-button module: The
vehicle will connect directly to the Volkswagen
Roadside Assistance Call Center. The vehicle’s lo-
cation is also transmitted in order to more quickly
provide assistance.
Stolen Vehicle Lo-
cation Assistance
For use by law en-
forcement authori-
ties only. See
Terms of Service at
www.vw.com/carnet
for details.
After you have reported your vehicle as stolen to law
enforcement, you may provide the case information
to the Volkswagen Car-Net Response Center. Once
the information has been verified, the VW Car-Net
Customer Specialist will be able to provide law en-
forcement with vehicle location data sent by the VW
Car-Net module.


Family Guardian:
Feature Description

Family Guardian:
Feature Description
Boundary
Alert
By logging on to your Volkswagen Car-Net account, you
can designate an area on a map as a “virtual fence.” The
vehicle owner can then choose notification channels (text
message or email) for receiving alerts when the vehicle
crosses the defined boundary (texts and data rates apply).
Speed Alert
Volkswagen Car-Net can be configured to inform the vehi-
cle owner whenever the vehicle exceeds a speed set by
the owner. The owner can select to be informed through
multiple channels, including text messages and email (text
and data rates apply).


Remote Vehicle Access:
Feature Description
Remote Door
Unlock
You can send a request to unlock the vehicle doors
through your Volkswagen Car-Net iPhone® or Android®
app, the Volkswagen Car-Net website or by calling the
Volkswagen Car-Net Response Center (text and data rates
apply). If none of the vehicle doors are opened within
about 30 seconds, the car will lock again.
Remote Honk
and Flash
You can send a honk and flash signal to the car using the
Volkswagen Car-Net website or the VW Car-Net iPhone®
or Android® app (text and data rates apply). The car will
honk the horn and blink the headlights and emergency
flashers for up to 10 seconds.
Last Parked
Location
You can locate your last parked location using your
Volkswagen Car-Net iPhone® or Android® app (text and
data rates apply).

Remote Vehicle Access:
Feature Description
Destinations
Only applica-
ble for vehi-
cles
equipped
with a facto-
ry-installed
navigation
system.
Points of Interest (POIs) or other destinations can be im-
ported remotely into the factory-installed navigation system
(if equipped) from a computer or the Volkswagen Car-Net
iPhone® or Android® app (text and data rates apply). These
destinations can be called up and used by the navigation
system.
Destination
Download
Only applica-
ble for vehi-
cles
equipped
with a facto-
ry-installed
navigation
system.
Press the • button in the 3-button module: The vehicle will
connect directly to the Volkswagen Car-Net Response
Center where a Volkswagen Car-Net Customer Specialist
will assist with destinations. The address of a dealer’s loca-
tion can also be sent by the Customer Specialist to your
factory-installed navigation system (if equipped).
Remote Sta-
tus Check
Current information about the vehicle can be viewed
through a computer or your Volkswagen Car-Net iPhone®
or Android® app (text and data rates apply). You can find
out if the doors, luggage compartment and engine hood
are open or closed, whether the car lights are on or off, the
level of fuel in the tank, when the vehicle needs to be ser-
viced next and more.


Diagnostics & Maintenance:
Feature Description
