VOLKSWAGEN PASSAT CC 2013 1.G Owners Manual

Storage areas

NOTICE
x The defroster heating wires or antenna in the rear window can be damaged by hard or sharp
things on the shelf below the rear window.
x Do not keep any food, medicine, or other items sensitive to heat or cold in the vehicle. They
can be damaged or made unusable by heat or cold.
x Things that are made of transparent materials (such as eyeglasses, magnifying glasses, or
transparent suction cups on the windows) can magnify sunlight and damage the vehicle.
The ventilation slots between the rear window and the shelf behind the rear seat backrest must
not be blocked so that stale air can escape from the vehicle.
Storage compartment in the driver door

Fig. 97 In the driver door: Storage compartment.

Storage compartment on the driver side

Fig. 98 On driver side: Storage compartment.

Storage compartment in the front center console

Fig. 100 In the front center console: Storage compartment.

WARNING
Never let a passenger, especially a child, ride on the center armrest.
A telephone cradle for the cell phone package may be installed in the upper section of the
storage compartment ⇒ Booklet Mobile Phone Package.
There may be an AUX-IN jack in the center armrest storage compartment ⇒ Booklet Radio, or
⇒ Booklet Navigation system.
Glove compartment

Fig. 102 On the passenger side: Glove compartment.

Fig. 103 Inside the glove compartment.

Opening and closing the glove compartment
If necessary, unlock the glove compartment with the emergency key. It is locked when the key slot is
vertical.
To open, pull the handle ⇒ fig. 102.
To close, push the lid up.
Opening and closing the Owner's Manual storage compartment
The storage compartment at the top of the glove compartment is designed to hold the Owner's Manual
or the MDI (MEDIA-IN) jack.
The Owner's Manual or MDI (MEDIA-IN) jack is located in a storage compartment at the top, which
can be pulled down to open ⇒ fig. 103 (3).
The strap (2) indicates the handle for opening the storage compartment.
If the vehicle is not equipped with the MDI (MEDIA-IN) jack, always keep the Owner's Manual in this
storage compartment. To stow the Owner's Manual, place it in the slot with the binding facing the
inside of the glove compartment door.
Holders
Depending on the model, there may be holders for a pen and a notepad in the glove compartment.
Cooling the glove compartment
There is an air vent (1) in the back of the glove compartment. Cool air can be directed into the glove
compartment if the air conditioner is on. Open or close the air vent by turning it.
WARNING
An open glove compartment door can increase the risk of serious injury during sudden
braking or driving maneuvers or in a crash.
x Always keep the glove compartment closed while the vehicle is moving.
NOTICE
Keep the storage compartment with the CD changer (3) closed while the vehicle is moving,
otherwise the CD changer may be damaged by vibrations.
NOTICE
In some vehicle models, design considerations have made it necessary to have openings in the
glove compartment behind the Owner's Manual slot, for example. Small items may fall through
these openings and get behind the instrument panel. This can cause unusual noises and
damage the vehicle. Never put any small objects in the glove compartment for this reason.
Depending on options, a factory-installed CD changer or Media Device Interface (MDI) /
(MEDIA-IN) may be located in the glove compartment ⇒ Booklet Radio, or ⇒ Booklet Navigation
system.

Rear center armrest storage compartment

Fig. 104 Storage compartment in the rear center armrest.

Other storage compartments

Fig. 105 In the luggage compartment: Side storage compartment.

Cup holders

Cup holders in the front center console

Fig. 106 In the front center console: Cup holders.
