VOLKSWAGEN PASSAT CC 2013 1.G Owners Manual

The auto-dimming feature can be switched on and off with the switch on the inside mirror (2) A or (2)
B. When auto-dimming is activated, the indicator light (1) is on.
If the ignition is switched on, the sensor (3) automatically darkens the inside mirror depending on the
amount of light shining into the vehicle from the rear.
The auto-dimming feature is deactivated when you shift the transmission into reverse or switch on the
interior lights or the reading light.
Do not attach external navigation devices to the windshield or in the vicinity of the auto-dimming inside
mirror ⇒ .
WARNING
The illuminated display on an external navigation device can cause the auto-dimming inside
mirror to malfunction, which can result in crashes and serious injuries.
x Malfunctions in the auto-dimming function can result in the inside mirror being unable to
evaluate the exact distance of vehicles in the rear or other objects.
If the light striking the sensor is filtered or blocked (such as by a sunshade), the auto-dimming
inside mirror will not work properly or may not work at all.
Outside mirrors

Fig. 86 In the driver door: Adjusting knob for the outside mirrors.

Turn the rotary knob to the desired position:
2 Adjust the right outside mirror by pressing the knob to left/right
and up/down.
/ Neutral position. Outside mirror folded out, no heating or
adjustment possible.

Synchronous mirror adjustment
x In the Settings - Convenience menu, select Mirror adjust - Both mirrors for
synchronous outside mirror adjustment
x Turn the adjusting knob to the L position.
x Adjust the left outside mirror. The right (passenger) outside mirror will automatically adjust at the
same time.
x If needed, correct the position of the right mirror by turning the adjusting knob to the R position.
Auto-dimming outside mirror on the driver side
Some models are equipped with an auto-dimming outside mirror, which is controlled together with the
auto-dimming inside mirror
Memory for front passenger side mirror (when backing up)
On vehicles equipped with memory seats, the passenger side mirror settings for backing up can be
stored as follows:
x Choose the remote control vehicle key that will be used with the settings about to be made.
x Unlock the vehicle with that remote control vehicle key.
x Set the electronic parking brake.
x Switch on the ignition.
x Activate the function Mirror down in the Settings - Convenience menu.
x Shift the transmission into Reverse (R).
x Adjust the passenger outside mirror for a clear view of the curb, for example.
x The adjusted mirror position is automatically stored and assigned to the vehicle key used to unlock
the vehicle. The preselected position will be recalled when the key assigned to that mirror adjustment
position is used again.
Recalling passenger side mirror settings
x Turn the adjusting knob for the side mirrors to the R position.
x Shift the transmission into reverse gear with the ignition switched on.
x The mirror moves back to the regular position when the vehicle moves forward faster than about
10 mph (15 km/h) or the adjusting knob is turned to the O or L position.
WARNING
Improper use of the folding outside mirrors can cause personal injury.
x Always make sure that nobody is in the way when folding the mirrors in or out.
x Make sure that you do not get your finger caught between the mirror and the mirror base
when moving the mirrors.

WARNING
Incorrectly estimating distances with the right outside mirror can cause collisions and
serious injury.
x The right outside mirror has a convex (curved) surface. This widens your field of vision.
But vehicles or other objects seen in a convex mirror will look smaller and farther away than
they really are.
x If you use the right outside mirror to judge distances from vehicles behind you when
changing lanes, you could estimate incorrectly and cause a crash and serious injuries.
x Whenever possible, use the inside mirror to more accurately judge distance and size of
vehicles or other objects seen in the convex mirror.
x Always make sure you have a clear view to the rear of the vehicle.
NOTICE
Always fold in the outside mirrors when taking the vehicle through an automatic car wash.
x Never fold power mirrors in manually because doing so could damage the electrical drive.
To reduce fuel consumption, use outside mirror heating only when needed.
When first switched on, outside mirror heating works with maximum heat for about 2 minutes.
If power mirror adjustment does not work, the outside mirrors can be adjusted by hand by
pressing on the edges of the mirror surface.

Driving tips

WARNING
Heavy loads will influence the way your vehicle handles and increase stopping distances.
Heavy loads that are not properly stowed or secured can cause loss of control and serious
injury.
x Secure the load properly to keep it from shifting.
x Always remember when transporting heavy objects that a change in the center of gravity
also changes the way your vehicle handles:
– Always distribute the load as evenly as possible.
– Secure heavy objects properly as far forward in the luggage compartment as possible.
– Always tie down heavy items securely with suitable straps using the tie-downs in the
luggage compartment.
x Securely latch the rear seat backrest in the upright position.
x Never exceed the Gross Axle Weight Rating or the Gross Vehicle Weight Rating on the
safety compliance sticker on the left door jamb. Exceeding permissible weight can cause the
vehicle to skid and handle differently.
x Always adapt your speed and driving to the heavier load and the weight distribution in the
vehicle. Take road, weather, traffic, and visibility conditions into account as well.
x Always accelerate gently and avoid sudden braking and driving maneuvers.
x Always brake earlier than you would if you were not driving a loaded vehicle.
Stowing luggage

Driving with an open luggage compartment lid can lead to serious personal injury. If you have to drive
with an open luggage compartment lid, make sure that all objects and the lid itself are properly
secured and take appropriate measures to keep toxic exhaust fumes from entering the vehicle.
WARNING
Driving with an unlatched or open luggage compartment lid can lead to serious personal
injury.
x Never transport objects larger than those that fit completely in the luggage compartment,
because the luggage compartment lid cannot be fully closed properly.
x After closing the lid, always pull up on it to make sure that it is properly closed and cannot
open suddenly when the vehicle is moving.
x Always stow all objects securely in the luggage compartment. Loose objects can fall out
of the luggage compartment and injure others on the road behind you.
x Drive carefully; anticipate what other drivers will do.
x Avoid abrupt or sudden acceleration, steering, or braking, because the unlatched luggage
compartment lid can move suddenly.
x Always mark objects sticking out from the luggage compartment clearly for others to see.
Obey all applicable legal requirements.
x Never use the luggage compartment lid to “clamp” or “hold” objects that stick out of the
luggage compartment.
x Always remove any luggage rack or other rack mounted on the luggage compartment lid
(along with any luggage on the rack) before driving with an open luggage compartment lid.
WARNING
Driving with an open luggage compartment lid can cause poisonous carbon monoxide in the
engine exhaust to get into the passenger compartment.
x Carbon monoxide causes drowsiness, inattentiveness, poisoning, and loss of
consciousness. It can lead to accidents and severe personal injuries.
x Always keep the luggage compartment lid closed while driving to help keep poisonous
exhaust fumes from being drawn into the vehicle.
x Never transport objects that are too large to fit completely into the luggage area, because
then the luggage compartment lid cannot be fully closed.
x If you absolutely must drive with an open luggage compartment lid, do the following to
reduce the risk of carbon monoxide poisoning:
– Close all windows and the power sunroof.
– Switch off the climate control system's air recirculation feature.
– Open all air vents in the instrument panel.
– Set the fresh air fan to the highest speed.
NOTICE
The open luggage compartment lid changes the vehicle height.
Driving a loaded vehicle

For good handling when driving a loaded vehicle, please observe the following:
x Securely stow all luggage
x Drive especially carefully and accelerate gently.
x Avoid sudden braking and driving maneuvers.
x Brake earlier than you would if you were not driving a loaded vehicle.
x If applicable, observe information about driving with a trailer
x If applicable, observe information about driving with a roof rack
WARNING
Heavy loads can change the way your vehicle handles and increase stopping distances.
Heavy loads that are not properly stowed or secured can shift suddenly, causing loss of
control and serious injury.
x Secure the load properly to keep it from shifting.
x Always remember when transporting heavy objects that they change the vehicle's center
of gravity and also the way it handles.
– Always distribute the load as evenly as possible.
– Secure heavy objects as far forward in the luggage compartment as possible.
– Use your vehicle's luggage compartment tie-downs with suitable straps.
x Always tie down heavy items securely with suitable straps.
x Securely latch the rear seat backrest in the upright position.
x Never exceed the Gross Axle Weight Rating or the Gross Vehicle Weight Rating on the
safety compliance sticker on the left door jamb. Exceeding permissible weight can cause the
vehicle to skid and handle differently.
x Always adapt speed and driving to the heavier load and the weight distribution in the
vehicle. Take road, weather, traffic, and visibility conditions into account as well.
x Always accelerate gently and avoid sudden braking and driving maneuvers.
x Always brake earlier than you would if you were not driving a loaded vehicle.
Weights and axle weights

x Roof load including the roof rack system.
x Factory-installed or retrofitted accessories.
x Hitch weight and tongue weight for trailer towing.
Please refer to the Gross Vehicle Weight Rating (GVWR) and the Gross front and rear Axle Weight
Ratings (GAWR) for your vehicle, which are printed on the vehicle's Safety Compliance Certification
Label on the driver door jamb.
WARNING
Exceeding maximum permissible weight ratings can result in vehicle damage, accidents, and
serious personal injury.
x Never let the actual weights at the front and rear axles exceed the permissible Gross Axle
Weight Rating. Also, never let the total of these actual weights exceed the Gross Vehicle
Weight Rating.
x Always remember that the vehicle's handling and braking will be affected by extra load
and the distribution of this load. Adjust your speed accordingly.
NOTICE
x Always distribute the load evenly and as low as possible in the vehicle. The vehicle capacity
weight figures apply when the load is distributed evenly in the vehicle (passengers and
luggage).
x When transporting a heavy load in the luggage compartment, carry the load as close to the
rear axle (as far forward) as possible so that the vehicle's handling and braking are affected as
little as possible.

Luggage compartment

WARNING
Unsecured or incorrectly stowed items can fly through the vehicle, causing serious personal
injury during hard braking or sharp steering or in an accident. Loose items can also be struck
and thrown through the passenger compartment by the front airbags if they inflate. To help
reduce the risk of serious personal injury:
x Always stow all objects securely in the vehicle. Always put luggage and heavy items in the
luggage compartment.
x Always secure objects in the passenger compartment properly with suitable straps so that
they cannot move into the deployment zone of a side or front airbag during sudden braking,
in a sudden maneuver, or in a collision.
x Always keep storage compartments closed while driving.
x Never stow hard, heavy, or sharp objects in the vehicle's open storage compartments, on
the shelf behind the rear seat bench, or on the top of the instrument panel.
x Always remove hard, heavy, or sharp objects from clothing and bags in the vehicle
interior and stow them securely in the luggage compartment.
WARNING
Transporting heavy objects causes the handling characteristics of the vehicle to change and
increases braking distances. Heavy loads which are not properly stowed or secured in the
vehicle can lead to a loss of vehicle control and cause serious personal injury.
x Transporting heavy items causes the handling characteristics of the vehicle to change by
shifting the vehicle's center of gravity.
x Always distribute luggage evenly and as low as possible within the vehicle. The vehicle
capacity weight figures apply when the load is distributed evenly in the vehicle (passengers
and luggage).
x Always stow luggage and heavy items in the luggage compartment as far forward of the
rear axle as possible and secure them with appropriate straps to the tie-downs provided.
x Never exceed the vehicle's Gross Vehicle Weight Rating or Gross Axle Weight Ratings,
which are printed on the Safety Compliance Certification Label located on the door jamb of
the driver door. Exceeding the permissible weight can cause the vehicle to skid and behave
differently.
x Always adapt your speed and driving style to accommodate your payload and its weight
distribution within your vehicle.
x Be especially cautious and gentle when stepping on the accelerator pedal and avoid
sudden braking and other maneuvers.
x Brake earlier than you would if you were not driving a loaded vehicle.
NOTICE
The defroster heating wires or antenna in the rear window can be damaged by objects that rub
against them.
The ventilation slots between the rear window and the shelf behind the rear seat backrest must
not be blocked so that stale air can escape from the vehicle.
