08 Car care
Washing and cleaning the car
08

199
Automatic washing – simple and quickWe do NOT recommend washing your car in an
automatic wash during the first six months
(because the paint will not have hardened suf-
ficiently).
An automatic wash is a simple and quick way
to clean your car, but it is worth remembering
that it may not be as thorough as when you
yourself go over the car with sponge and water.
Keeping the underbody clean is most impor-
tant, especially in the winter. Some automatic
washers do not have facilities for washing the
underbody.
CAUTION
•Before driving into an automatic car
wash, turn off the optional rain sensor to
avoid damaging the windshield wipers.
•Make sure that side view mirrors, auxil-
iary lamps, etc, are secure, and that any
antenna(s) are retracted or removed.
Otherwise there is risk of the machine
dislodging them
•Chromed wheels: Clean chrome-
plated wheels using the same deter-
gents used for the body of the vehicle.
Aggressive wheel-cleaning agents can
permanently stain chrome-plated
wheels.
WARNING
•When the car is driven immediately after
being washed, apply the brakes several
times in order to remove any moisture
from the brake linings.
•Engine cleaning agents should not be
used when the engine is warm. This
constitutes a fire risk.
Exterior lightingCondensation may form temporarily on the
inside of the lenses of exterior lights such as
headlights, fog lights, or taillights. This is nor-
mal and the lights are designed to withstand
moisture. Normally, condensation will dissi-
pate after the lights have been on for a short
time.
Polishing and Waxing
•Normally, polishing is not required during
the first year after delivery, however, wax-
ing may be beneficial.
•Before applying polish or wax the vehicle
must be washed and dried. Tar spots can
be removed with kerosene or tar remover.
Difficult spots may require a fine rubbing
compound.
•After polishing use liquid or paste wax.
•Several commercially available products
contain both polish and wax.
•Waxing alone does not substitute for pol-
ishing a dull surface.
•A wide range of polymer-based waxes can
be purchased today. These waxes are easy
to use and produce a long-lasting, high-
gloss finish that protects the bodywork
against oxidation, road dirt and fading.
•Do not polish or wax your vehicle in direct
sunlight (the surface of the vehicle should
not be warmer than 113 °F (45 °C).
CAUTION
Volvo does not recommend the use of long-
life or durable paint protection coatings,
some of which may claim to prevent pitting,
fading, oxidation, etc. These coatings have
not been tested by Volvo for compatibility
with your vehicle's clear coat. Some of them
may cause the clear coat to soften, crack,
or cloud. Damage caused by application of
paint protection coatings may not be cov-
ered under your vehicle's paint warranty.

09 Maintenance and servicing
Engine oil09
213
WARNING
Do not allow oil to spill onto or come into
contact with hot exhaust pipe surfaces
NOTE
Volvo uses different systems to indicate a
low oil level or pressure. Some models have
an oil pressure sensor, in which case a
warning symbol (see page 57) is used to
indicate low oil pressure. Other models have
an oil level sensor, in which case the driver
is alerted by the warning symbol in the cen-
ter of the instrument panel and a text in the
information display. Some models use both
systems. Contact an authorized Volvo
retailer for more information.

09 Maintenance and servicing
Fuses 09
230* Option/accessory, for more information, see Introduction.
24.Not in use
25.Not in use
26.Ignition switch15A
27.A/C compressor10A
28.Not in use
29.Front fog lights*15A
30.Not in use
31.Not in use
32.Fuel injectors10A
33.Heated oxygen sensor, vac-
uum pump20A
34.Ignition coils, climate unit
pressure sensor10A
35.Engine sensor valves, A/C
relay, relay coil, PTC ele-
ment oil trap, canister, mass
air meter15A
36.Engine control module
(ECM), throttle sensor10A

09 Maintenance and servicing
Fuses 09
232* Option/accessory, for more information, see Introduction.
Fuses in the passenger compartment
G020246
-Fuse 37-42, not in use-
43.Audio system, Blue-
tooth,Volvo Navigation sys-
tem*15A
44.Supplemental Restrain Sys-
tem (SRS), engine control
module10A
45.12-volt socket in rear seat15A
46.Lighting – glove compart-
ment, instrument panel, and
footwells5A
47.Interior lighting5A
48.Rear liftgate wiper/washer15A
49.Supplemental Restrain Sys-
tem (SRS), Occupant
Weight Sensor (OWS)10A
50.Not in use
51.Fuel filter relay10A
52.Transmission control mod-
ule (TCM), ABS5A
53.Power steering10A
54.Park assist*, Dual Xenon
headlights*10A
55.Not in use
56.Volvo Navigation System
remote key module, alarm
siren control module10A
57.On-board diagnostic
socket, brake light switch15A
58.Right high beam, auxiliary
lights relay7.5A
59.Left high beam7.5A

12 Index
12
276
1, 2, 3 ...
12-volt sockets.......................................... 62
A
A/C (air conditioning)................................. 90
ABS (anti-lock brake system).................. 153
Airbags
front...................................................... 22
inflatable curtain................................... 30
side impact........................................... 29
Airbag system............................................ 22
Air conditioning.......................................... 90
Air distribution table................................... 99
Air vents..................................................... 92
Alarm system........................................... 132
turning off sensors.............................. 133
Anti-lock Brake System (ABS)................. 153
Approach lighting...................................... 83
Audio files................................................ 250
Audio system
audio functions................................... 236
automatic sound control..................... 239AUX port............................................. 236
CD changer......................................... 249
CD player/changer.............................. 249
compact disc care.............................. 251
Dolby Surround Pro Logic II............... 239
equalizer............................................. 239
HD digital radio................................... 243
menu settings..................................... 253
radio functions.................................... 241
selecting a sound source.................... 236
Sirius satellite radio............................245
sound settings.................................... 238
steering wheel keypad........................ 237
storing radio stations.......................... 241
USB/iPodŸ connector........................ 237
Auto-dim rearview mirror........................... 77
Autolock..................................................... 82
Automatic locking retractor....................... 36
Automatic sound control.........................239
Automatic transmission........................... 150
kickdown............................................ 151
oil........................................................ 267
shiftlock override................................ 152
Automatic transmission - Geartronic....... 151
AUX port.................................................. 236
Axle weight......................................180, 265
B
Backrest, rear seat, folding...................... 115
Bass......................................................... 238
Battery
maintenance....................................... 217
remote key, replacing......................... 123
specifications...................................... 272
warning symbols................................. 217
Battery – replacing................................... 218
Black Box (Vehicle Event Data)............... 206
Blind Spot Information System (BLIS)..... 161
Bluetooth cell phone connection............. 254
Booster cushion
accessory............................................. 43
Brake fluid........................................ 215, 267
Brake lights................................................ 63
Brake system
anti-lock brakes (ABS)........................ 153
emergency brake assistance.............. 154
fluid..................................................... 215
general information............................. 153
Bulbs
headlights........................................... 219
list of................................................... 272

12 Index
12
280
Mirrors....................................................... 77
Model plate.............................................. 263
Moonroof................................................... 80
Motor oil........................................... 212, 269
checking............................................. 212
N
Net in cargo area..................................... 119
O
Occupant safety........................................ 16
Occupant weight sensor............................ 26
Octane recommendations.......................142
Oil............................................................. 212
changing............................................. 212
checking............................................. 212
On Call Roadside Assistance.................. 275
Opening the hood.................................... 210
Owner maintenance................................. 208
P
Panel lighting, instrument.......................... 64
Park assist............................................... 165
Parking brake............................................. 75
Parking lights............................................. 63
Passenger’s side front airbag, disabling. . . 26
Periodic owner-performed maintenance. 208
Permissible axle weight........................... 180
Personal settings....................................... 82
Power door mirrors.................................... 78
Power front seat...................................... 106
memory function................................. 107
Power moonroof........................................ 80
Power steering fluid................................. 215
Power windows......................................... 76
Pregnancy, using seat belts during........... 19
R
Radio
Sirius satellite radio............................245
Radio functions........................................ 241
HD digital radio................................... 243Rain sensor - windshield wipers................ 72
Rear fog light............................................. 64
Rear park assist....................................... 165
Rear seat backrests, folding down.......... 115
Rearview mirror.......................................... 77
auto-dim function................................. 77
Rearview mirror with compass.................. 77
Recalls, child restraints.............................. 46
Refrigerant (A/C system).................... 90, 267
Refueling.................................................. 144
fuel tank volume.................................267
Registering child restraints........................ 46
Remote key.............................................. 122
battery replacement............................ 123
functions............................................. 122
key blade............................................ 124
Replacing fuses....................................... 227
Reporting safety defects
Canada................................................. 17
USA....................................................... 16
Roof loads............................................... 160

12 Index
12
282
tread wear indicator............................ 172
uniform tire quality grading................. 181
winter driving...................................... 182
Tire sealing system.................................. 187
Top tether anchors (child restraint sys-
tems).......................................................... 45
Towing the vehicle................................... 157
Transmission
Geartronic........................................... 151
manual................................................149
shiftlock override................................ 152
Tread wear indicator................................ 172
Treble....................................................... 238
Trip computer............................................ 67
Trips, long distance................................. 140
Turn signals............................................... 65
indicator lights...................................... 53
U
Uniform Tire Quality Grading...................181
V
Vehicle dimensions.................................. 264
Vehicle Event Data................................... 206
Vehicle loading........................................ 180
roof loads............................................ 160
Vehicle maintenance
performed by the owner.....................208
Vehicle towing.........................................157
Vehicle weights........................................ 265
VIN (Vehicle Identification Number)......... 263
Volvo Inflatable Curtain.............................. 30
Volvo On Call Roadside Assistance........ 275
W
Warning flashers, hazard........................... 74
Warning symbol......................................... 55
Warranties................................................ 206
Washer fluid..................................... 214, 267
Washer fluid reservoir......................211, 214
Water, driving through............................. 139
Weights.................................................... 265Wheel nuts............................................... 184
Wheels.....................................................170
changing............................................. 185
storing................................................. 171
Whiplash Protection System (WHIPS)....... 32
Windows
power.................................................... 76
Windshield washer fluid reservoir............211
Windshield wiper blades.......................... 216
Windshield wipers...................................... 71
rains sensor.......................................... 72
Winter tires............................................... 182
Wiper blades
replacing liftgate wiper....................... 216
replacing windshield wipers............... 216
