buttons VOLVO XC70 2004 Owners Manual

2004 VOLVO XC70
1) Orange warning triangle, see page 28.
2) Red warning triangle, see
page 28.

pg. 31 Switches in the center console

The positions of these buttons may vary, depending on the specifications\
of your car
1. Not in use
2. Not in use
3. Not in use
4. Stability Traction Control (STC)*/Dynamic Stability Traction Contro\
l (DSTC)**
Press this switch for at least half a second to turn the Spin Control (\
SC) function of the STC/DSTC system on
or off.
R-models only:
The Active Yaw Control function can be deactivated. See
page 20 for more information.
An LED in the switch will light up to indicate that the system is on. Se\
e
pages 20-21 for more information on
STC/DSTC. The SC function should be switched off if you, for any reason,\
temporarily have to drive with
tires of different dimensions (e.g., spare tire).
To help reduce the risk that the SC function is turned off inadvertently\
, the switch must be held in for at least
half a second to disable this function. " STC/DSTC SPIN CONTROL OFF" wil\
l be displayed in the text
window.
WARNING!
Please be aware that the car's handling characteristics may be affected \
if the Spin Control function is
switched off.
file:///K|/ownersdocs/2004/2004_XC70/04xc70_02a.htm (11 of 14)12/30/20\
06 4:32:56 PM

2004 VOLVO XC70
NOTE: The cover should be kept on when the auxiliary socket is not in use.
Ashtrays
Volvo cars in North America do not have an ashtray in the front seat as \
standard equipment. If you want
to have an ashtray in the front seat, please contact your Volvo retailer\
.

pg. 40 Electrically operated windows

Electrically operated windows
The electrically operated windows are controlled by buttons in the arm r\
ests. The ignition switch must
be ON * (ignition key in position I, II or the engine running) for the\
electrically operated windows to
function.
To lower: Press down the front edge of the button to the first detent ("stop").\

To raise: Lightly pull up the front edge of the button to the first detent ("sto\
p").
* The electrically operated windows will also function after the ignitio\
n has been switched off as long as
neither of the front doors has been opened.
Auto up/down function (front doors only):
Either front door window can be opened or closed automatically.
Auto down: Press the front part of the button as far down as possible and release i\
t immediately. To
file:///K|/ownersdocs/2004/2004_XC70/04xc70_02b.htm (12 of 18)12/30/20\
06 4:32:58 PM

2004 VOLVO XC70
stop the window at any time, pull the button up.
Auto up: Pull the front part of the button up as far as possible and release it i\
mmediately. To stop the
window at any time, press the button down.
NOTE: The power windows in the front seat have an overload protecting circuit \
breaker which reverses
movement of the power windows to their starting points, if they are obst\
ructed in any way. Thereafter
the windows will operate normally again. WARNING!
l Always remove the ignition key when the vehicle is unattended.
l Make sure that childrens' hands are clear before raising the
windows.
l Never leave children unattended in the car.

Cutout switch for rear windows
The electrically operated rear door windows can be disabled by a switch \
located on the driver's door (see
illustration).
If the LED in the switch is OFF: The rear door windows can be raised or lowered with the buttons on
the rear door armrests or with the buttons on the driver's door armrest.\
If the LED in the switch is ON: The rear door windows can only be raised or lowered with the buttons
on the driver's door armrest.

file:///K|/ownersdocs/2004/2004_XC70/04xc70_02b.htm (13 of 18)12/30/20\
06 4:32:58 PM

2004 VOLVO XC70
WARNING!
l Because the driver's seat can be adjusted with the ignition off, childre\
n should never be left
unattended in the car.
l Movement of the seat can be STOPPED at any time by pressing any button o\
n the power seat
control panel.
l Do not adjust the seat while driving. The seat should be adjusted so tha\
t the brake pedal can be
depressed fully. In addition, position the seat as far rearward as comfo\
rt and control allow.
l The seat rails on the floor must not be obstructed in any way when the s\
eat is in motion.
Programming the memory

Three seat positions can be programmed. To program a seat position:
1 Adjust the seat to the desired position.
2 Hold down the MEM button.
3 While holding down the MEM button, press button 1 to program the curren\
t position of the seat.
Buttons 2 and 3 can be programmed in the same way.
To move the seat to a programmed position, press and hold down button 1,\
2 or 3 until the seat moves to
the preset position and stops.
As a safety precaution, the seat will stop automatically if the button i\
s released before the seat has
reached the programmed position.
NOTE: The seat has an overload protector which engages if an object blocks the\
movement of the seat.
If this happens, remove the object and wait 20 seconds before operating \
the seat again.
* This option is only available on the driver's seat.
file:///K|/ownersdocs/2004/2004_XC70/04xc70_04a.htm (3 of 11)12/30/200\
6 4:32:59 PM

2004 VOLVO XC70
WARNING!
The nylon cargo net must not be used when the optional rear-facing auxil\
iary child seat in the cargo
area is in use.
When not in use, the cargo net should not be stored unattached in the ca\
r to prevent it from being
thrown forward in the event of a sudden stop, etc.
CAUTION:
l If the net is installed in the forward position and the rear seat cushio\
ns are folded forward, the net
should be positioned so that it is in front of the rear seat cushions bu\
t behind the front seat backrests (C).
l The eyelets on the floor of the car under the front seats must not be us\
ed to secure the lower straps of
the cargo net. If these eyelets are used and the front seats are moved b\
ack, the cargo net or upper
brackets may be damaged.
Folding and storing the cargo net
The cargo net can be folded and stored under the floor of the cargo area\
on cars not equipped with the
optional auxiliary rear-facing child seat or the optional bass speaker.
Press the buttons on the hinges at the center of the upper and lower rod\
s. This releases the hinges so that
the net can be folded.

pg. 71 Cargo area cover, Vanity mirrors

Cargo area cover
file:///K|/ownersdocs/2004/2004_XC70/04xc70_04b.htm (15 of 21)12/30/20\
06 4:33:00 PM

2004 VOLVO XC70
Rear reading lights
Reading lights - front/rear
The reading lights can be switched on or off by pressing the respective \
buttons. These lights switch off
automatically after 10 minutes if the engine is not running. If the engi\
ne is running, the lights stay on
indefinitely. The lights can be switched off at any time by pressing the\
button.



Contents | Top of Page
file:///K|/ownersdocs/2004/2004_XC70/04xc70_04b.htm (21 of 21)12/30/20\
06 4:33:01 PM

2004 VOLVO XC70
2 0 0 4
VOLVO XC70
Chapter 5 - Keys, Locks, Alarm


pg.75 Keys, Locks, Alarm

Keys, Exterior courtesy lights, Locking and unlocking the
car 76
Remote keyless entry system 77
Unlocking the tailgate, Central locking buttons 79
Alarm 80
Child safety locks - rear doors 82

pg. 76 Keys, Exterior courtesy lights, Locking and unlocking the car

Keys
file:///K|/ownersdocs/2004/2004_XC70/04xc70_05.htm (1 of 11)12/30/2006\
4:33:01 PM

2004 VOLVO XC70
The transmitters will also activate or allow "keyless" entry into the pa\
ssenger compartment or the
tailgate. They will also activate or deactivate the vehicle's alarm syst\
em(s).
The car can also be locked/unlocked with the key.
If one of the transmitters is misplaced, contact your nearest authorized\
Volvo retailer for replacement.

Buttons in remote control
1 - Fold key in/out, 2 - Lock, 3 - Approach lighting
4 - "Panic" function *, 5 - Unlock tailgate, 6 - Unlock
Using the remote control
Button 1: Press to extend the key. This button must also be pressed when the key\
is folded back into the
slot in the side of the remote control unit.
Button 2 (Lock): Press once to lock all doors, and the tailgate.
Button 3 (Approach lighting): Press this button when approaching the car at night to light up the \
interior courtesy light, parking lights, license plate lights and the li\
ghts in the sideview mirrors.
Button 4 (Panic): See
page 80 for more information on this function.
Button 5 (Tailgate unlock): Press this button twice within 3 seconds to unlock the tailgate (wi\
thout
unlocking the other doors).
Button 6 (Unlock): Press this button once to unlock the driver's door only. Wait for at\
least 1 second
and press the button again (within 10 seconds) to unlock all doors, an\
d the tailgate.
NOTE:
file:///K|/ownersdocs/2004/2004_XC70/04xc70_05.htm (4 of 11)12/30/2006\
4:33:01 PM

2004 VOLVO XC70
NOTE: Please be aware that if the tailgate is unlocked using the tailgate unlo\
ck button, opened, and
closed again, it will remain unlocked and the alarm will not be rearmed. Press the lock button on the
remote control to relock the tailgate and rearm the alarm.

Central locking buttons
Central locking buttons
These buttons (located on the both front door armrests) can be used to\
lock/unlock all doors and the
tailgate and set the alarm.
The rear passenger doors can also be locked and unlocked with the indivi\
dual lock buttons on each door.

pg. 80 Alarm
Alarm
The alarm is automatically armed whenever you lock your car. When armed,\
the alarm continuously
monitors a number of points on the car. The following conditions will se\
t off the alarm:
l The hood is forced open.
l The tailgate is forced open.
l A door is forced open.
l The ignition switch is tampered with.
l If there is movement in the passenger compartment (if the car is equipp\
ed with the optional movement
sensor).
l The car is lifted or towed (if the car is equipped with the optional in\
clination sensor).
l The battery is disconnected (while the alarm is armed).
Arming the alarm
file:///K|/ownersdocs/2004/2004_XC70/04xc70_05.htm (7 of 11)12/30/2006\
4:33:01 PM

2004 VOLVO XC70
Press the LOCK button on the remote control, lock the car using the key \
in the driver's door or press the
central lock button on one of the front doors with the door open. One lo\
ng flash of the turn signals will
confirm that the alarm is armed.
Disarming the alarm
Press the UNLOCK button on the remote control or unlock the doors with t\
he key.
Turning off (stopping) the alarm
If the alarm is sounding, it can be stopped by pressing the UNLOCK butto\
n on the remote control or by
unlocking the driver's door with the key.
Visual alarm signal
The visual alarm signal is given by flashing all turn signals and turnin\
g on the interior lighting for
approximately 5 minutes.
Audible alarm signal
An audible alarm signal is given by a battery powered siren. One alarm c\
ycle lasts for 25 seconds.
"Panic" button
In an emergency situation, this feature can be used to attract attention\
. Activate the "panic" function by
pressing the red button on the remote control (see illustration on
page 77) for at least 3 seconds or by
pressing this button twice within 3 seconds. The turn signals will flash\
, the interior lights will go on and
the car's horn will sound.
The function can be turned off by pressing any of the buttons on the rem\
ote control or will stop
automatically after 25 seconds. When a button is pressed, there is a 5 s\
econd delay before the
panic alarm is deactivated.
NOTE: This function will NOT unlock the car.

pg. 81 Alarm

file:///K|/ownersdocs/2004/2004_XC70/04xc70_05.htm (8 of 11)12/30/2006\
4:33:01 PM
