Specifications

pg. 163 Specifications
Label information164
Weights165
Dimensions 166
Capacities167
Lubricants168
Cooling system168
Suspension169
Electrical system171
Engine specifications172
All specifications are subject to change without prior notice.
pg. 164 Specifications
file:///K|/ownersdocs/2005/2005_XC90/05xc90_10.htm (1 of 10)12/30/2006\
4:42:41 PM

2005 VOLVO XC90

Label information
1. Vehicle Emission Control Information
Your Volvo is designed to meet all applicable emission standards, as evi\
denced by the certification label
on the underside of the hood. For further information regarding these re\
gulations, please consult your
Volvo retailer.
2. Vacuum hose routing
(underside of hood)
3. Loads and Tire Pressures
(on inside of fuel filler door). Canadian models only.
4. Model plate
Vehicle Identification Number (VIN). Codes for color and upholstery, e\
tc. The plate is located in the
engine compartment, on the inside of the left front fender.
file:///K|/ownersdocs/2005/2005_XC90/05xc90_10.htm (2 of 10)12/30/2006\
4:42:41 PM

2005 VOLVO XC90
5. Vehicle Identification Number (VIN) 1
The VIN plate is located on the top left surface of the dashboard. The V\
IN is also stamped on the right
hand door pillar.
6. Federal Motor Vehicle Safety Standards (FMVSS) specifications (USA\
) and Ministry of
Transport (CMVSS) standards (Canada)
Your Volvo is designed to meet all applicable safety standards, as evide\
nced by the certification label on
the facing side of the driver's door. For further information regarding \
these regulations, please consult
your Volvo retailer.
7. Child safety latch label
8. Loads and Tire Pressures U.S. models only
Certain models will only have one decal, depending on the specifications\
of the vehicle.
1 The Vehicle Identification Number (VIN) should always be quoted in a\
ll correspondence concerning your vehicle with the
retailer and when ordering parts.

pg. 165 Specifications
Weights
Gross vehicle weight* USACanada
5-seat, 5-cyl, FWD 5640
lbs -
5-seat, 5-cyl, AWD 5790
lbs 2630 kg
5-seat, 6-cyl, AWD 5900
lbs 2680 kg
7-seat, 5-cyl, FWD 5840
lbs -
7-seat, 5-cyl, AWD 6005
lbs 2720 kg
7-seat, 6-cyl, AWD 6080
lbs 2760 kg
Capacity weight
file:///K|/ownersdocs/2005/2005_XC90/05xc90_10.htm (3 of 10)12/30/2006\
4:42:41 PM

2005 VOLVO XC90
5-seat models 1160
lbs 525 kg
7-seat models 1210
lbs 550 kg
Permissible axle weight, front*
5-seat, 5-cyl, FWD 2710
lbs -
5-seat, 5-cyl, AWD 2820
lbs 1280 kg
5-seat, 6-cyl, AWD 2880
lbs 1310 kg
7-seat, 5-cyl, FWD 2710
lbs -
7-seat, 5-cyl, AWD 2820
lbs 1280 kg
7-seat, 6-cyl, AWD 2880
lbs 1310 kg
FWD = Front Wheel Drive
AWD = All Wheel Drive
* Permissible axle weight or gross vehicle weight must never be exceeded\
. Permissible axle weight, rear* USA Canada
5-seat, 5-cyl, FWD 3060 lbs -
5-seat, 5-cyl, AWD 3150 lbs 1430 kg
5-seat, 6-cyl, AWD 3150 lbs 1430 kg
7-seat, 5-cyl, FWD 3170 lbs -
7-seat, 5-cyl, AWD 3240 lbs 1470 kg
7-seat, 6-cyl, AWD 3240 lbs 1470 kg
Curb weight
5-seat, FWD 4310-4340
lbs -
5-seat, AWD 4440-4620
lbs 2030-2090 kg
7-seat, FWD 4450-4490
lbs -
7-seat, AWD 4590-4770
lbs 2085-2150 kg
file:///K|/ownersdocs/2005/2005_XC90/05xc90_10.htm (4 of 10)12/30/2006\
4:42:41 PM

2005 VOLVO XC90
Max. roof load 220 lbs 100 kg
Trailer weight, w/o brakes 1700 lbs 750 kg
Trailer weight, with brakes See the table on
page 105
Max. tongue weight See the table on
page 105
pg. 166 Specifications
Dimensions
Dimensions
Length 188.9 in (479.8 cm)
Width 74.7 in (189.8 cm)
Height 70.2 in (178.4 cm)
Wheelbase 112.5 in (285.7 cm)
Front track 64.3 in (163.4 cm)
Rear track 63.9 (162.4 cm)
Turning
circle 39-40 ft. (11.9-12.3 m)
Cargo capacity
With optional 3rd row of seats folded down:
5-seat: 41.6 cu ft (1178 litres)
7-seat: 43.3 cu ft (1225 litres)
Behind 1st row of seats, with 2nd (and optional 3rd) row of seats fold\
ed down:
5-seat: 84.9 cu ft (2403 litres)
7-seat: 85.1 cu ft (2410 litres)
Behind 1st row of seats, with front passenger seat, 2nd row (and option\
al 3rd row) of seats folded
down:
5-seat: 92.0 cu ft (2606 litres)
7-seat: 93.2 cu ft (2640 litres)
pg. 167 Specifications
file:///K|/ownersdocs/2005/2005_XC90/05xc90_10.htm (5 of 10)12/30/2006\
4:42:41 PM

2005 VOLVO XC90
Capacities
Fuel tank Models with 6-cylinder turbo engines - 19 US gallons (72 liters).
Models with 5-cylinder turbo engines - 18 US gallons (68 liters).
Minimum octane requirement - AKI 87 (RON 91) - unleaded fuel (See
also
page 86)
Engine oil
B5254T2 6.1 US qts. (5.8 liters)
B6294T 7.0 US qts. (6.6 liters)
Transmission oil
Automatic 7.6 US qts. (7.2 liters)
Miscellaneous
Power steering 0.9 US qts. (0.9 liters)
Windshield washer
reservoir 6.9 US qts. (6.5 liters)
Brake fluid 0.63 US qts. (0.6 liters)
Air conditioning system Front - 2.2 lb. (1 kg), Rear (option) 2.9 lb. (1.3 kg) R 134a (HF\
C134a)
WARNING!
When adding accessories, equipment, luggage and other cargo to your vehi\
cle, the total capacity
weight must not be exceeded.
pg. 168 Specifications

Lubricants
Engine oil
Meeting minimum ILSAC specification GF-2, including ACEA A1, API SJ, SJ/\
CF and SJ/Energy
file:///K|/ownersdocs/2005/2005_XC90/05xc90_10.htm (6 of 10)12/30/2006\
4:42:41 PM

2005 VOLVO XC90
Conserving.
Oil additives must not be used.
Transmission
Oil grade:
JWS 3309
Different types of oil should never be mixed.
Power steering
Grade: Volvo synthetic power steering fluid (Pentosin CHF 11S) P/N 1161529 \
or equivalent.
Brake fluid
Fluid type: DOT 4+ boiling point >536°F (280°C), P/N 9437433
Cooling system
Type Positive pressure, closed system.
Coolant Volvo original coolant/antifreeze
Volume 5-cyl. turbo 9.5 US qts. (9.0 liters)
6-cyl. turbo 11.0 US qts (10.5 liters)
The thermostat begins to open at 194°F (90°C).
pg. 169 Specifications
Suspension
Rear suspension
Individual rear wheel suspension with longitudinal support arms, double \
link arms and track rods.
Front suspension
Spring strut suspension with integrated shock absorbers and control arms\
linked to the support frame.
Power-assisted rack and pinion steering. Safety type steering column.
pg. 170 Specifications
Three-way catalytic converter cautions
file:///K|/ownersdocs/2005/2005_XC90/05xc90_10.htm (7 of 10)12/30/2006\
4:42:41 PM

2005 VOLVO XC90
l Keep your engine properly tuned. Certain engine malfunctions, particular\
ly involving the electrical,
fuel or distributor ignition systems, may cause unusually high three-way\
catalytic converter
temperatures. Do not continue to operate your vehicle if you detect engi\
ne misfire, noticeable loss of
power or other unusual operating conditions, such as engine overheating \
or backfiring. A properly tuned
engine will help avoid malfunctions that could damage the three-way cata\
lytic converter.
l Do not park your vehicle over combustible materials, such as grass or le\
aves, which can come into
contact with the hot exhaust system and cause such materials to ignite u\
nder certain wind and weather
conditions.
l Excessive starter cranking (in excess of one minute), or an intermitte\
ntly firing or flooded engine can
cause three-way catalytic converter or exhaust system overheating.
l Remember that tampering or unauthorized modifications to the engine, the\
Electronic Control
Module, or the vehicle may be illegal and can cause three-way catalytic \
converter or exhaust system
overheating. This includes:
- Altering fuel injection setting or components.
- Altering emission system components or location or removing components\
.
- Repeated use of leaded fuel.
NOTE: Unleaded fuel is required for vehicles with three-way catalytic converte\
rs.
pg. 171 Specifications
Electrical system

12-volt system with voltage controlled generator. Single wire system in \
which the chassis and engine
block are used as conductors, grounded on the chassis.
Battery 2.5TT6
Voltage 12 V12 V
Cold start capacity
(CCA) 520 A
600 A
Reserve capacity (RC) 90
min 115 min
If you must replace your battery, be sure to replace it with a battery o\
f the same cold start capacity and
reserve capacity as the original (See the decal on the battery). Generator max. current 140 A*160 A
Starter motor, power 1.4 kW 1.7 kW
Spark plugs P/N272313-8 or equivalent
file:///K|/ownersdocs/2005/2005_XC90/05xc90_10.htm (8 of 10)12/30/2006\
4:42:41 PM

2005 VOLVO XC90
Gap 0.028 in.0.7 mm
Tightening torque 22 ft. lbs. (30 Nm)
Firing order 1-2-4-5-3 1-5-3-6-2-4
* Models equipped with the optional rear A/C unit have 160 A generators.\

pg. 172 Specifications
Engine specifications,
B5254T2 B6294T
Output (kW/rps) 154/83 200/87
- (hp/rpm) 208/5000 268/5200
Torque (Nm/rps) 320/25-75 380/30-83
- (ft. lbs./rpm) 236/1500-4500 280/1800-5000
No. of cylinders 5 6
Bore (in./mm) 3.27/83 3.27/83
Stroke (in./mm) 3.67/93.2 3.54/90
Cylinder displacement,
liters 2.52 (153.8 cu
in)
2.92 (178.3 cu in)
Compression ratio 9.0:1 8.5:1
Charge air cooler (Intercooler)
Turbocharged engines employ a turbo-compressor to force air into the eng\
ine inlet manifold and a
charge air cooler to cool the compressed inlet air. The resulting increa\
se in air flow raises pressure in the
intake manifold and increases engine power over that developed by the no\
rmally-aspirated engine. The
charge air cooler (which resembles a radiator) is located between the \
turbo-compressor and inlet
manifold.
Fuel system
The engine is equipped with a multiport fuel injection system.
pg. 173 Specifications
Volvo On Call Roadside Assistance
Your new Volvo comes with a four year ON CALL roadside assistance. Addit\
ional information,
features, and benefits are described in a separate information package i\
n your glove compartment.
file:///K|/ownersdocs/2005/2005_XC90/05xc90_10.htm (9 of 10)12/30/2006\
4:42:41 PM

2005 VOLVO XC90
If you have misplaced your package, dial:
In the U.S.A.
1-800-638-6586 (1-800-63-VOLVO)
In Canada:
1-800-263-0475
Technician certification
In addition to Volvo factory training, Volvo supports certification by t\
he National Institute for
Automotive Excellence (A.S.E.). Certified technicians have demonstrate\
d a high degree of competence
in specific areas. Besides passing exams, each technician must also have\
worked in the field for two or
more years before a certificate is issued. These professional technician\
s are best able to analyze vehicle
problems and perform the necessary maintenance procedures to keep your V\
olvo at peak operating
condition.
