VOLVO XC90 2007 Owners Manual

2007 Volvo XC90
Location of tail light bulbs
1. Parking light
2. Turn signal
3. Back-up light
4. Parking light
5. Brake light
NOTE: If the message indicating a burned out bulb remains in the information \
display after a bulb has
been replaced, consult an authorized Volvo retailer or workshop.
Replacing bulbs in the tail light cluster
- Switch off all lights and turn ignition key to position 0.
- Fold down the lower section of the tailgate, and fold up the rear sect\
ion of the cargo area floor.
- If the vehicle is equipped with the optional grocery bag holder, detac\
h the holder's bands.
- Remove the corner panel (A in the illustration above).
- Open the cover (B) in the side panel by pulling the tab (C) upward\
/outward.
- Loosen the bolts (D).
- Pull the entire tail light housing straight out.
- Disconnect the wiring.
file:///K|/ownersdocs/2007/2007_XC90/07xc90_09.htm (25 of 37)12/30/200\
6 5:53:50 PM

2007 Volvo XC90
- Place the tail light housing on a soft cloth to avoid scratching the l\
ens.
- Turn the lamp holder(s) counterclockwise and pull out.
- Turn signal, back-up light, brake light bulbs: Turn the bulb countercl\
ockwise and remove it.
- Parking light bulbs: Pull the bulb straight out.
- Insert a new bulb.
- Place the lamp holder in the groove and turn clockwise.
- Press wiring back into place.
- Align the tail light housing with the holes for the retaining bolts an\
d press it into place.
- Tighten the retaining bolts.
- Reinsert the side and corner panels.
pg. 199 Maintenance
Replacing bulbs
Rear fog light
- Switch off the ignition.
- Carefully insert a small screwdriver (see illustration above).
- Pry out the lamp housing.
- Turn the bulb holder counterclockwise and remove it.
- Turn the bulb counterclockwise and remove it.
- Insert a new bulb and press the lamp housing back into place.
file:///K|/ownersdocs/2007/2007_XC90/07xc90_09.htm (26 of 37)12/30/200\
6 5:53:50 PM

2007 Volvo XC90
Door step courtesy lights
The door step courtesy lights are located under the dashboard on the dri\
ver's and passenger's sides. To
replace a bulb:
- Carefully insert a screwdriver and pry out the lens.
- Replace the defective bulb.
- Reinstall the lens.
Cargo compartment light
- Carefully insert a screwdriver and pry out the lens.
- Pry out the bulb and replace it.
- Press the lens back into place.
pg. 200 Maintenance
Replacing bulbs
file:///K|/ownersdocs/2007/2007_XC90/07xc90_09.htm (27 of 37)12/30/200\
6 5:53:50 PM

2007 Volvo XC90
Vanity mirror lights
- Carefully insert a screwdriver and pry out the lens.
- Pry out the bulb and replace it.
- Carefully press the lower edge of lens onto the four tabs and press th\
e upper edge of the lens into place.
License plate lights
- Switch off the ignition.
- Loosen the screws with a Torx screwdriver.
- Turn the bulb holder counterclockwise and pull it out.
- Pull out the defective bulb and insert a new one.
- Reinsert the bulb holder into the housing and turn it clockwise.
- Reinstall the housing and screw it into place.
NOTE: Other bulbs may be difficult for you to replace yourself. Let an author\
ized Volvo retailer
replace these bulbs if necessary.
pg. 201 Maintenance
file:///K|/ownersdocs/2007/2007_XC90/07xc90_09.htm (28 of 37)12/30/200\
6 5:53:50 PM

2007 Volvo XC90
Fuses
Replacing fuses
If an electrical component fails to function, it is possible that a fuse\
has blown.
The fuse boxes are located in four different places:
l Relays/fuse box in the engine compartment
l Fuse box in the passenger compartment, behind the plastic cover
l Fuse box in the passenger compartment, on the edge of the dashboard
l Fuse box in the cargo compartment.
A label on the inside of each cover indicates the amperage and the elect\
rical components that are
connected to each fuse.
The easiest way to see if a fuse is blown is to remove it. Pull the fuse\
straight out. If a fuse is difficult to
remove, you will find a special fuse removal tool (and several extra fu\
ses) in the passenger compartment
fuse box on the driver's end of dashboard. From the side, examine the cu\
rved metal wire (see the
illustration above) to see if it is broken. If so, put in a new fuse of\
the same color and amperage
(written on the fuse). Spare fuses are stored in the fuse box in the e\
ngine compartment and the passenger
compartment. If fuses burn out repeatedly, have the electrical system in\
spected by an authorized Volvo
retailer.
WARNING!
Never use fuses with higher amperage than those stated on the following \
pages. Doing so could
overload the vehicle's electrical system.
pg. 202 Maintenance
file:///K|/ownersdocs/2007/2007_XC90/07xc90_09.htm (29 of 37)12/30/200\
6 5:53:50 PM

2007 Volvo XC90
Fuses
Fuses in the engine compartment
When replacing fuses, be sure to replace a blown fuse with a new one of \
the same color and amperage
(written on the fuse). No. Amperage
1. ABS 30
2. ABS 30
3. Headlight washers 35
4. -
5. Auxiliary lights (option) 20
6. Starter motor relay 35
7. Windshield wipers 25
8. Fuel pump 15
9. Transmission control module (V8 and 6- cyl.) 15
10. Ignition coils, engine control module 20
11. Throttle pedal sensor, A/C compressor, e-box fan 10
12. Engine control module, fuel injectors, mass airflow sensor 15
13. Throttle control (V8), Intake manifold actuator (6-cyl.) 10
14. Heated oxygen sensor. 20
15. Crankcase ventilation, solenoid valves, A/C connection, leakage diag\
nostics, engine
control module (V8, 6-cyl.), mass airflow sensor (V8) 15
16. Driver's side low beam headlight 20
17. Passenger's side low beam headlight 20
file:///K|/ownersdocs/2007/2007_XC90/07xc90_09.htm (30 of 37)12/30/200\
6 5:53:51 PM

2007 Volvo XC90
18. -
19. Engine control module feed, engine relay 5
20. Parking lights 15
21. -
pg. 203 Maintenance
Fuses
Fuses in the passenger compartment
Fuses are located inside the access panel on the edge of the dashboard, \
on the driver's side. There are
also a number of spare fuses. When replacing a blown fuse, be sure to re\
place it with a new one of the
same color and amperage (written on the fuse).
No. Amperage
1. Blower - climate system 30
2. Audio amplifier 30
3. Power driver's seat (option) 25
4. Power passenger's seat (option) 25
5. Driver's door - central locking, power windows, door mirror 25
6. Front passenger's door - central locking, power windows, door mirror \
25
7. -
8. Radio, CD player, Rear Seat Entertainment (RSE) 15
9. Volvo Navigation System (option), Sirius satellite radio (option)\
10
10. On-board diagnostics, headlight switch, steering wheel angle sensor,\
steering wheel
module 5
file:///K|/ownersdocs/2007/2007_XC90/07xc90_09.htm (31 of 37)12/30/200\
6 5:53:51 PM

2007 Volvo XC90
11. Ignition switch, SRS, engine control module (V8, 6-cyl.) immobiliz\
er, transmission
control module (V8, 6-cyl.)7.5
12. Ceiling lighting, upper electronic control module 10
13. Moonroof (option) 15
14. -
15. -
16. -
17. -
18. -
19. -
20. -
21. -
22. -
23. -
24. -
25. -
26. -
27. -
28. -
29. -
30. -
31. -
32. -
33. -
34. -
35. -
36. -
37. -
38. -
pg. 204 Maintenance
file:///K|/ownersdocs/2007/2007_XC90/07xc90_09.htm (32 of 37)12/30/200\
6 5:53:51 PM

2007 Volvo XC90
Fuses
Fuse box in the passenger compartment, behind the plastic cover, driver'\
s side
This fuse box is located behind the plastic cover below the steering whe\
el. When replacing a blown fuse,
be sure to replace it with a new one of the same color and amperage (wr\
itten on the fuse). No. Amperage
1. Heated passenger's seat 15
2. Heated driver's seat 15
3. Horn 15
4. -
5. Audio system 10
6. -
7. -
8. Alarm siren 5
9. Brake light switch feed 5
10. Instrument panel, climate system, power driver's seat, Occupant Weig\
ht Sensor 10
11. 12-volt sockets - front and rear seats 15
12. -
13. -
14. -
15. ABS, STC/DSTC 5
16. Power steering, Active Bi-Xenon headlights (option) 10
17. Driver's side front foglight (option) 7.5
18. Passenger's side front foglight (option) 7.5
19. -
file:///K|/ownersdocs/2007/2007_XC90/07xc90_09.htm (33 of 37)12/30/200\
6 5:53:51 PM

2007 Volvo XC90
20. Coolant pump (V8)5
21. Transmission control module 10
22. Driver's side high beam 10
23. Passenger's side high beam 10
24. -
25. -
26. -
27. -
28. Power passenger's seat (option) 5
29. -
30. -
31. -
32. -
33. Vacuum pump 20
34. Pump - windshield and tailgate washers 15
35. -
36. -
pg. 205 Maintenance
Fuses
