02 Instruments and controls
Center console controls
0261
NOTE
If the door mirrors have been inadvertently
pushed out of position (in a car wash, park-
ing lot, etc.) manually return them to normal
position. If mirror adjustment does not seem
to operate after manual folding, reset the
folding mirrors as follows:•
Turn the ignition key to position II.
•
Manually fold the mirror(s) to the normal
position.
•
Press the button to fold both mirrors in.
•
Press the button again to fold the mir-
rors out to their normal position.
Park Assist (option/accessory as
available)
This system provides an audi-
ble warning when the vehicle is
being parked or if it is driven
close to a person or object. For
more information see
page 147.
NOTE
The system activates automatically when
the engine is started, and can be deacti-
vated by pressing this button (e.g. when
towing a trailer) or reactivated if necessary.
Auxiliary lights
This button is used to switch on
auxiliary lights (if installed). A
light in the button will light up to
indicate that the auxiliary lights
are illuminated.
12 volt socket
This 12 volt socket can be used
to plug in certain accessories
such as cellular telephones,
etc. The ignition key must be in
position I (or higher) for the aux-
iliary socket to function.
NOTE
The auxiliary sockets can also be used for
cigarette lighters, which are available as
accessories at your Volvo retailer.Power child locks (option)
For more information on this
function, see page 124.

02 Instruments and controlsSteering wheel adjustment
0262
G026999
Both the height and the reach of the steering
wheel can be adjusted to a comfortable posi-
tion for the driver. Pull down the lever on the
left of the steering column. Adjust the steering
wheel to a suitable position and press the lever
back into place to lock the steering wheel in the
new position. Check that the steering wheel is
locked in the new position.
WARNING
Never adjust the steering wheel while driv-
ing.

02 Instruments and controls
Lighting panel
02``
*Option/accessory, for more information, see Introduction.
63
3501866mG027132
Headlight/parking light switchFront fog lightsRear fog lightInstrument panel lightingFuel filler door unlock button
Parking lightsThe front and rear parking lights can be turned
on even when the ignition is switched off.•
Turn switch (1) to position
.
The license plate lights also illuminate when the
parking lights are switched on.
Headlights1.
Turn the ignition key to position II.
2. The low beam headlights (daytime running
lights) illuminate automatically, except
when the light switch (1) is in position
1.
For information on switching between high and
low beams, see page 66.
NOTE
Active Bi-Xenon
Ÿ headlights*: Turn the
headlight switch to position 0 to activate a
daylight sensor, which automatically
switches the low beams on or off, depend-
ing on ambient light conditions. When driv-
ing in daylight, the headlights will switch off
and the daytime running lights will come on.
In darkness, the daytime running lights will
switch off and the Active Bi-Xenon
Ÿ head-
lights will switch on.
G020789
Active Bi-Xenon
Ÿ headlight beams
1On Canadian models, the daytime running lights will remain on with the light switch in this position.

02 Instruments and controlsLighting panel
0264
Active Bi-Xenon
Ÿ headlights (ABL)—
option
When the ABL function is activated, the head-
light beams adjust laterally to help light up a
curve according to movements of the steering
wheel (see the right-pointing beam in the illus-
tration).
This function is activated automatically when
the engine is started and can be deactivated/
reactivated by pressing the ABL button (see
page 60.Fog lightsFront fog lights (option)The front fog lights can be used in combination
with either the headlights or the parking lights.•
Turn the ignition key to position II.
•
Press button (2) to turn on the front fog
lights.
An indicator light in the button illuminates when
the front fog lights are on.
Rear fog lightThe single rear fog light is located in the driver's
side of the vehicle.
The rear fog light will only function in combi-
nation with the high/low beam headlights or the
optional front fog lights.
•
Turn the ignition key to position II.
•
Press button (3) to turn on the rear fog light.
An indicator light in the button illuminates when
the rear fog light is on.NOTE
The rear fog light is considerably brighter
than the normal tail lights and should be
used only when conditions such as fog, rain,
snow, smoke or dust reduce visibility for
other vehicles to less than 500 ft.
(150 meters).Instrument panel lightingThe instrument panel lighting illuminates when
the ignition key is in position II and the light
switch (1) is in either position
or
.
•
Move the thumb wheel (4) up to increase
brightness or down to decrease bright-
ness.
Unlocking the fuel filler doorPress button (5) when the vehicle is at a stand-
still to unlock the fuel filler door. Please note
that the fuel filler door will remain unlocked until
the vehicle begins to move forward. An audible
click will be heard when the fuel filler door
relocks.
NOTE
If the fuel filler door does not unlock after the
button has been pressed, drive the vehicle
at a speed of at least 5 mph (8 km/h), stop
the vehicle, and press the button again.For information on unlocking the fuel filler door
manually, see page 65.

02 Instruments and controlsManually unlocking the fuel filler door
0265
G027077
Panel on passenger's side of cargo areaTo manually unlock the fuel filler door1. Open the upper and lower sections of the
tailgate, and fold up the rear section of the
cargo area floor.
2. If the vehicle is equipped with the optional
grocery bag holder, detach the holder's
bands.
3. Remove the corner panel from the floor of
the cargo area.
4. Open the cover in the side panel by pulling
the tab upward/outward.
5. Pull down the insulating material (4) to
access the fuel filler door motor (5).
G027034
6. Move the catch (6) rearward to unlock the
fuel filler door lock, or move it forward to
lock the filler door.

02 Instruments and controlsLeft-side steering wheel lever
0266
Lever positions
G026954
Turn signals, lane change positionTurn signals, position for normal turnsHigh beam flashToggle between high and low beams,
Home Safe lighting
Turn signalsWhen turningMove the lever as far up or down as possible
(to position 2) to start the turn signals. The turn
signals will be cancelled automatically by the
movement of the steering wheel, or the lever
can be returned to its initial position by hand.When changing lanesThe driver can automatically flash the turn sig-
nals 3 times by:•
Moving the turn signal lever up or down to
position (1) and releasing it.
•
Moving the lever up or down to position (2)
and immediately back to its original posi-
tion.NOTE
•
This automatic flashing sequence can
be interrupted by immediately moving
the lever in the opposite direction.
•
If the turn signal indicator flashes faster
than normal, check for a burned-out
turn signal bulb.
High/low beam headlightsContinuous high beams1.
Turn the ignition key to position II.
2. With the light switch (1) in position
, (see page 63) pull the turn signal
lever toward the steering wheel (position 4)
to toggle between high and low beams
(this also applies on models equipped with
the optional Active Bi-Xenon
Ÿ headlights).
High beam flash1.
Turn the ignition key to position II.
2. Pull the turn signal lever to position (3). The
high beams will remain on until the lever is
released.Home safe lightingWhen you leave your vehicle at night, you can
make use of the home safe lighting function to
illuminate the area in front of the vehicle.
1. Remove the key from the ignition switch.
2. Pull the direction indicator lever as far as
possible towards the steering wheel (to
position 4) and release it.
3. Exit the vehicle and lock the doors.
The headlights and parking lights will illuminate
and remain on for 30
1, 60 or 90 seconds. The
1Factory setting

02 Instruments and controls
Left-side steering wheel lever
0267
time interval can be changed by a trained and
qualified Volvo service technician.

02 Instruments and controlsRight-side steering wheel lever
0268
Windshield wipers
G026953
Thumb wheelRain sensor on/off
Windshield wipers off
If the lever is in the 0 position and
you move it upwards, the wipers
will sweep one stroke at a time for
as long as you hold the lever up.
Single sweep position
Move the lever slightly upward
from the 0 position for one sweep
of the wipers. The lever returns
automatically to 0 when released.
Intermittent wiper function
With the lever in this position, you
can set the wiper interval by twist-
ing the control ring 1 upward to
increase wiper speed or down-
ward to decrease the speed.
Windshield washer/headlight washer
(certain models)When the lever is pulled to wash the wind-
shield, high pressure jets mounted in the
bumper will spray the headlights.
CAUTION
•
Use ample washer fluid when washing
the windshield to avoid scratching the
glass. The windshield should be thor-
oughly wet when the wipers are in oper-
ation.
•
Before using the wipers, ice and snow
should be removed from the wind-
shield/rear window. Be sure the wiper
blades are not frozen in place.
•
To conserve washer fluid in driving condi-
tions where the windshield washers are
used frequently, the headlights will only be
washed once for every five times the wind-
shield is washed within a 10-minute period.
•
A short pull on the lever will wash the wind-
shield only.
•
When approximately 1 US quart (1 liter)
remains in the washer fluid reservoir, the
headlights will not be washed when the
lever is pulled to conserve washer fluid for
the windshield.
Continuous wiper functionTop arrow: normal speed
Bottom arrows: higher speed

02 Instruments and controls
Right-side steering wheel lever
0269 Tailgate wiper/washer
G027127
Intermittent wiping: Press the upper
section of the switch Neutral position: The wiper is switched
off Normal (continuous) wiping: Press the
lower section of the switch
Move the lever forward to start the tailgate
washer. After washing the rear window, the
wiper will make several additional sweeps.
Tailgate wiper and reverse gearIf the front wipers are on and the transmission
is put into reverse gear, the tailgate wiper will
go into intermittent wiping function
1.
If the tailgate wiper is already in normal wiping
function, the normal wiping function will con-
tinue.
Rain sensor (option)The rain sensor automatically regulates wiper
speed according to the amount of water on the
windshield.
Thesensitivity of the sensor can be adjusted
by twisting ring 1 up (the wipers will sweep the
windshield more frequently) or down (the wip-
ers will sweep the windshield less frequently).Activating the rain sensor:1. Turn the ignition key to at least position I
and put the windshield wiper lever in posi-
tion0.
2. Press button (2).
> A light in the button will light up to indi-
cate that the rain sensor is active.Deactivating the rain sensor:•
Press button (2).
or
•
Move the windshield wiper lever down to
another position. Moving the lever up will
not deactivate the rain sensor. Doing so
will cause the wipers to sweep the wind-
shield until the lever is released, at which
time the wipers return to rain sensor mode.
The rain sensor is also deactivated when the
key is removed from the ignition.CAUTION
The rain sensor should be deactivated when
washing the vehicle in an automatic car
wash, etc. If the rain sensor function is left
on, the wipers will start inadvertently in the
car wash and could be damaged.
1Consult your Volvo retailer if you would like to have this function deactivated.

02 Instruments and controlsHazard warning flashers
0270
Hazard warning flashers
12
3
45
6
78
9 ABC
DEF
GHI
JKL
MNO
PQRS
TUVWXYZ
0*
#POWERVOLUMECDAM FM
G027096
The four-way flasher should be used to indi-
cate that the vehicle has become a traffic haz-
ard. To activate the flashers, press the triangu-
lar button in the center dash. Press the button
again to turn off the flashers.
NOTE
Regulations regarding the use of the hazard
warning flasher may vary, depending on
where you live.
Rear window and door mirror defroster
Press the switch to start heat-
ing the rear window and door
mirrors to remove ice or con-
densation. A light in the switch
will light up.
A timer automatically switches off the heating
after approximately 12 minutes. The LED will
go out correspondingly.
