VOLVO XC90 TWIN ENGINE 2018 Owners Manual

SEATS AND STEERING WHEEL
* Option/accessory.189
•
Storing memory settings in power front
seats* (p. 186)
• Using stored memory in a powered front seat
(p. 187)
• Adjusting front seat cushion length (p. 189)
• Front seat massage settings* (p. 188)
• Adjusting front seat side bolster settings*
(p. 190)
• Adjusting front seat lumbar support* (p. 190)
• Adjusting the passenger seat from the driv-
er's seat* (p. 191) Adjusting front seat cushion length
The settings can be adjusted using either the
multifunction control* on the seat or the center
display. The adjustment settings are shown in
the center display. Multifunction control, located on the side of the seat
cushion.
Turn the control up or down to activate the multi-
function control.
Adjusting the seat cushionThe length of the seat cushion can be adjusted
using the multifunction control on the side of the
seat.
1. Activate the multifunction control by turning the control upward/downward. The seat set-
tings view will appear in the center display. 2.
Select Cushion extension in the seat set-
tings view.
• Push in the front part of the four-way but-
ton (the round one) to extend the seat
cushion.
• Press the rear part of the four-way button
to shorten the seat cushion.
Related information
• Manual front seats (p. 184)
• Power front seats* (p. 185)
• Adjusting the power front seats* (p. 185)
• Storing memory settings in power front
seats* (p. 186)
• Using stored memory in a powered front seat
(p. 187)
• Adjusting front seat massage settings*
(p. 188)
• Front seat massage settings* (p. 188)
• Adjusting front seat side bolster settings*
(p. 190)
• Adjusting front seat lumbar support* (p. 190)
• Adjusting the passenger seat from the driv-
er's seat* (p. 191)

SEATS AND STEERING WHEEL
* Option/accessory.
190 Adjusting front seat side bolster
settings*
The settings can be adjusted using either the
multifunction control* on the seat or the center
display. The adjustment settings are shown in
the center display. Multifunction control, located on the side of the seat
cushion.
The side bolsters in the front seat backrests can
be inflated/deflated to adjust the amount of sup-
port provided.
To adjust the side bolsters:
1.

Activate the multifunction control by turning
the control upward/downward . The seat
settings view will appear in the center dis-
play. 2.
Select Side bolsters in the seat settings
view.
• Press the front part of the four-way button
to increase side bolster support .
• Press the rear part of the four-way button
to decrease side bolster support.
Related information
• Manual front seats (p. 184)
• Power front seats* (p. 185)
• Adjusting the power front seats* (p. 185)
• Storing memory settings in power front
seats* (p. 186)
• Using stored memory in a powered front seat
(p. 187)
• Adjusting front seat massage settings*
(p. 188)
• Adjusting front seat cushion length (p. 189)
• Front seat massage settings* (p. 188)
• Adjusting front seat lumbar support* (p. 190)
• Adjusting the passenger seat from the driv-
er's seat* (p. 191) Adjusting front seat lumbar
support*
Activate the multifunction control* by turning the
control upward/downward. The seat settings
view will appear in the center display. Multifunction control, located on the side of the seat
cushion.
Lumbar support can be adjusted in four direc-
tions by pressing the four-way lumbar support
button on the side of the seat cushion. The lum-
bar support can be adjusted forward/backward
and up/down.
Adjusting front seat lumbar support*To adjust the lumbar support:
1. Activate the multifunction control by turning the control upward/downward. The seat set-
tings view will appear in the center display.

SEATS AND STEERING WHEEL
}}
* Option/accessory. 191
2.
Select Lumbar in the seat settings view.
• Press the four-way button (the round but-
ton) up/down to move the lumbar support
upward/downward.
• Press the front part of the four-way button
to increase lumbar support.
• Press the rear part of the four-way button
to decrease lumbar support.
Related information
• Manual front seats (p. 184)
• Power front seats* (p. 185)
• Adjusting the power front seats* (p. 185)
• Storing memory settings in power front
seats* (p. 186)
• Using stored memory in a powered front seat
(p. 187)
• Adjusting front seat massage settings*
(p. 188)
• Adjusting front seat cushion length (p. 189)
• Front seat massage settings* (p. 188)
• Adjusting front seat side bolster settings*
(p. 190)
• Adjusting the passenger seat from the driv-
er's seat* (p. 191) Adjusting the passenger seat from
the driver's seat*
The front passenger seat can be adjusted from
the driver's seat.
Activating the functionThe function is activated via the function view in
the center display:
Tap the Adjust PassengerSeat button to activate.
Adjust passenger seatThe driver must adjust the passenger seat within
10 seconds of activating the function. If no
adjustment is made within this time, the function
will be deactivated.
The driver adjusts the passenger seat using the
controls on the driver's seat: Move the passenger seat forward/rearward
by moving the control forward/rearward.
Change the backrest tilt of the passenger
seat by moving the control forward/back-
ward.
Related information
•
Manual front seats (p. 184)
• Power front seats* (p. 185)
• Adjusting the power front seats* (p. 185)
• Storing memory settings in power front
seats* (p. 186)
• Using stored memory in a powered front seat
(p. 187)
• Adjusting front seat massage settings*
(p. 188)
• Adjusting front seat cushion length (p. 189)
• Front seat massage settings* (p. 188)

SEATS AND STEERING WHEEL
* Option/accessory.
192 •
Adjusting front seat side bolster settings*
(p. 190)
• Adjusting front seat lumbar support* (p. 190) Folding the second row backrests
The second row of seats has three individual
seating positions. The backrests can be folded
down separately.
WARNING •
Adjust the seat and ensure it locks into
position before driving. Use caution when
adjusting the seat. Uncontrolled or care-
less adjustments could lead to injury.
• Long objects must always be securely
tied down to help prevent injury or dam-
age in the event of sudden braking.
• Always turn off the engine and apply the
parking brake when loading or unloading
the vehicle.
• Put the gear selector in P to help prevent
the gear selector from being inadvertently
moved.
CAUTION When the backrest is folded down, make sure
there are no objects in the rear seat, and the
seat belts are not buckled. Otherwise there is
a risk of damage to the upholstery.
CAUTION The seat cushion of the integrated child
restraint* must be in the stowed position
before the center seat backrest can be folded
down.
The armrest* in the center seat must be
raised before the seat backrest is folded
down.
If the vehicle has private locking*, the ski
hatch must be closed before the seat back-
rest is folded down.
NOTE The front seats may need to be pushed for-
ward and/or the backrest adjusted so that the
rear seat backrests can be fully lowered.
The rear seats may also need to be moved
rearward.
The seats in the second row must be in the
upright position before they can be folded
down completely. They should not be folded
down when they are tilted forward to access
the third row of seats.

SEATS AND STEERING WHEEL
}}
193
Center seat To fold down the backrest:
1.

Fold down the head restraint manually.
2. Pull the strap on the right side of the center seat.
3. Fold the backrest down until it locks into position. The seat cushion will move down-
ward/forward when the backrest is folded
down and create a flat surface.
To return the backrest to the upright position:
1. Pull the strap.
2. Fold up the backrest and release the strap. Push the backrest until it locks into position.
3. Adjust the head restraint if necessary.
Outboard seats To fold down the backrest:
NOTE
When folding down a second row seat back-
rest, always start from the seat's normal
upright position. Do not use the handle for
folding down the seat when the seat is in the
position for accessing the third row.
1. Pull up and hold the handle on the side of
the seat while the backrest is being folded
down. 2.

Make sure that backrest and head restraint
do not come in contact with the seat in front
while the backrest is being folded down. Fold
the backrest down until it locks into position.
> The seat cushion will move downward/ forward when the backrest is folded down
and create a flat surface. The head
restraint folds down automatically when
the backrest is lowered.
WARNING Make sure the backrest is securely locked
into position after it is folded down.
To return the backrest to the upright position:
1.

Pull up and hold the handle on the side of
the seat while the backrest is being folded
up.
2. Make sure that backrest and head restraint do not come in contact with the seat in front
while the backrest is being folded up. Fold up
the backrest and release the handle.
3. Press the backrest until it locks into position.
4. Fold up the head restraint manually.

||SEATS AND STEERING WHEEL
* Option/accessory.
194
WARNING Make sure that the rear seat backrest and
head restraint are locked securely in place
after the seat is folded up.
The head restraints at the outer seats must
always be raised when there is a passenger in
one of these spots of the rear seat.
WARNING
The head restraints on the outboard second-
row seats must always be folded up when
there are passengers in the third row of
seats*.
Related information
•
Adjusting the second row head restraints
(p. 194)
• Moving the second row seats forward/rear-
ward* (p. 195)
• Adjusting the second row backrest tilt
(p. 196)
• Getting into and out of the third row of
seats* (p. 197)
• Folding the third row backrests* (p. 198) Adjusting the second row head
restraints
Adjust the center head restraint in the rear seat
to the seat occupant's height. Fold down the
outboard head restraints* to improve rear visibil-
ity.
Adjusting the center head restraint The center head restraint should be adjusted to
suit the passenger's height. The entire back of
the head should be covered if possible. Manually
move the restraint up or down as needed. To lower the restraint, press and hold the button
(located between the backrest and the head
restraint, see illustration) while carefully lowering
the head restraint.
WARNING
The center seat head restraint must be in its
lowest position when the seat is not occupied.
When the center seat is occupied, the head
restraint must be correctly adjusted to the
passenger's height, covering the entire back
of the head if possible.

SEATS AND STEERING WHEEL
}}
* Option/accessory. 195
Electrically folding down the rear seat's
outboard head restraints*The outer head restraints can be folded via the
center display's function view. The head restraint
can be folded down when the vehicle is in igni-
tion mode 0.
Tap the Headrest Fold button
to activate/deactivate folding. Manually push the head restraint until it clicks
into position.WARNING Do not lower the head restraint if there are
passengers in any of the rear seats.
WARNING
The head restraint must be locked in the
upright position after it has been folded up.
WARNING
The head restraints on the outboard second-
row seats must always be folded up when
there are passengers in the third row of
seats*.
Related information
•
Folding the second row backrests (p. 192)
• Moving the second row seats forward/rear-
ward* (p. 195)
• Adjusting the second row backrest tilt
(p. 196)
• Getting into and out of the third row of
seats* (p. 197)
• Folding the third row backrests* (p. 198) Moving the second row seats
forward/rearward*
In vehicles with 7 seats*, the seats in the second
row can be moved forward or rearward individu-
ally to help optimize legroom for passengers in
the second and third rows. The second row
seats cannot be moved forward or backward in
5-seat models. Lift the handle under the seat.
Move the seat forward or backward to the
desired position.
3.

Release the handle and press the seat until
it locks into position.
Check to make sure the seat is securely locked
into place after its position has been changed.

||SEATS AND STEERING WHEEL
* Option/accessory.
196
WARNING •
Adjust the seat and ensure it locks into
position before driving. Use caution when
adjusting the seat. Uncontrolled or care-
less adjustments could lead to injury.
• Long objects must always be securely
tied down to help prevent injury or dam-
age in the event of sudden braking.
• Always turn off the engine and apply the
parking brake when loading or unloading
the vehicle.
• Put the gear selector in P to help prevent
the gear selector from being inadvertently
moved.
Related information
• Folding the second row backrests (p. 192)
• Adjusting the second row head restraints
(p. 194)
• Adjusting the second row backrest tilt
(p. 196)
• Getting into and out of the third row of
seats* (p. 197)
• Folding the third row backrests* (p. 198) Adjusting the second row backrest
tilt
Backrest tilt can be adjusted separately for each
seat in the second row.
Center seat 1. Pull the strap on the right side of the center
seat.
2.

Adjust backrest tilt forward/backward by
decreasing/increasing pressure on the back-
rest.
3. Release the strap to lock the backrest in its new position and press on the backrest until
the lock engages.
Check to make sure the seat is securely locked
into place after its position has been changed.
Outboard seats 1. Pull the handle on the side of the seat
upward.
2.

Adjust backrest tilt forward/backward by
decreasing/increasing pressure on the back-
rest.
3. Release the handle to lock the backrest in its new position and press on the backrest until
the lock engages.
Check to make sure the seat is securely locked
into place after its position has been changed.

SEATS AND STEERING WHEEL
* Option/accessory.197
WARNING•
Adjust the seat and ensure it locks into
position before driving. Use caution when
adjusting the seat. Uncontrolled or care-
less adjustments could lead to injury.
• Long objects must always be securely
tied down to help prevent injury or dam-
age in the event of sudden braking.
• Always turn off the engine and apply the
parking brake when loading or unloading
the vehicle.
• Put the gear selector in P to help prevent
the gear selector from being inadvertently
moved.
Related information
• Folding the second row backrests (p. 192)
• Adjusting the second row head restraints
(p. 194)
• Moving the second row seats forward/rear-
ward* (p. 195)
• Getting into and out of the third row of
seats* (p. 197)
• Folding the third row backrests* (p. 198) Getting into and out of the third row
of seats*
The second row of seats can be adjusted for
easier access to the third row of seats*. To fold down the backrest:
1.
Pull the handle on the upper side of the right
or left outboard second row seat upward/
forward.
2. Fold the backrest down and move the entire seat forward.
To return the seat to the upright position:
– Push the seat rearward to its end position.
The backrest should then easily return to the
correct position.
NOTE If a backrest in the second row of seats does
not lock back into the upright position after
being folded down (e.g. for getting in or out of
the third row of seats), it may need to be
pushed forward again and then pushed back
with more force.
WARNING
Make sure that the rear seat backrest and
head restraint are locked securely in place
after the seat is folded up.
The head restraints at the outer seats must
always be raised when there is a passenger in
one of these spots of the rear seat.
Related information
•
Folding the second row backrests (p. 192)
• Adjusting the second row head restraints
(p. 194)
• Moving the second row seats forward/rear-
ward* (p. 195)
• Adjusting the second row backrest tilt
(p. 196)
• Folding the third row backrests* (p. 198)

SEATS AND STEERING WHEEL
* Option/accessory.
198 Folding the third row backrests*
The third row has two individual seats. These
can be folded down separately.
CAUTION To fold down the third-row seat backrests, it
may be necessary to change the position/tilt
the seats in the second row.
1. Pull the handle on the upper side of the
backrest upward/forward. 2.

Make sure that backrest and head restraint
do not come in contact with the seat in front
while the backrest is being folded down. Fold
the backrest down.
> The seat cushion will move downward/ forward when the backrest is folded down
and create a flat surface. The head
restraint folds down automatically when
the backrest is lowered.
To return the seat to the upright position, fold the
backrest up manually until it locks into position.
Fold up the head restraint manually.
WARNING Make sure that the rear seat backrest and
head restraint are locked securely in place
after the seat is folded up.
The head restraints at the outer seats must
always be raised when there is a passenger in
one of these spots of the rear seat.
Related information
•
Folding the second row backrests (p. 192)
• Adjusting the second row head restraints
(p. 194)
• Moving the second row seats forward/rear-
ward* (p. 195)
• Adjusting the second row backrest tilt
(p. 196) •
Getting into and out of the third row of
seats* (p. 197)
