VOLVO XC90 TWIN ENGINE 2018 Owners Manual

DRIVER SUPPORT
}}
279
Activating and starting Speed
Limiter
The Speed Limiter (SL 13
) function must be
selected and activated in order to regulate
speed.
Putting Speed Limiter in standby mode Note: This illustration is general and details may vary
depending on model.
–
Press ◀ (1) or ▶ (3) and scroll to the Speed
Limiter function (4).
>

The symbol (4) will appear, indicating that
the Speed Limiter is in standby mode.
Starting the Speed LimiterThe Speed Limiter can only be activated while
the engine is running. The lowest maximum
speed that can be set is 30 km/h (20 mph). –
With the Speed Limiter in standby mode and
the symbol displayed, press the
button (2) on the steering wheel key-
pad.
>

The Speed Limiter will be started and the
vehicle's current speed will be set as the
maximum speed.
Related information
• Speed limiter (p. 278) Managing Speed Limiter speed
The Speed Limiter (SL
14
) can be set to various
speeds.
Setting/changing set speed Note: This illustration is general and details may vary
depending on model.
–
Change a set speed by pressing the (1)
or (3) buttons briefly or by pressing and
holding them:
• Press briefly: Press briefly: each press
changes the speed in +/- 5 mph
(+/- 5 km/h) increments.
• Press and hold: Release the button when
the set speed indicator (4) has moved to
the desired speed.
• The most recently set speed will be stored. 13
Speed Limiter

||DRIVER SUPPORT
280
Related information
•
Speed limiter (p. 278) Deactivating and putting Speed
Limiter in standby mode
The Speed Limiter (SL 15
) can be temporarily
deactivated and put in standby mode. Note: This illustration is general and details may vary
depending on model.
To deactivate the Speed Limiter and put it in
standby mode:
–
Press the button on the steering wheel
(2).
>

The speed limit markings and symbols in
the instrument panel will change from
WHITE to GRAY. This indicates that the
Speed Limiter is temporarily deactivated
and the driver can exceed the set maxi-
mum speed.
Temporarily deactivating using the
accelerator pedal
The set maximum speed can be temporarily
deactivated and exceeded using the accelerator
pedal without first putting the Speed Limiter in
standby mode, e.g. when quick acceleration is
required.
To do so:
1. Depress the accelerator as far as possible and then release it when the desired speed
has been reached.
> The Speed Limiter will remain activatedand the symbol in the instrument panel
will be WHITE.
2. Release the accelerator pedal fully when the temporary acceleration is completed.
> The vehicle will automatically slow downto a speed below the most recently set
maximum speed.
Related information
• Speed limiter (p. 278) 14
Speed Limiter
15 Speed Limiter

DRIVER SUPPORT
}}
281
Reactivating Speed Limiter from
standby mode
Speed Limiter (SL 16
) can be reactivated after
having been temporarily deactivated and put in
standby mode. Note: This illustration is general and details may vary
depending on model.
To reactivate the Speed Limiter from standby
mode:
–
Press the button on the steering wheel
(1).
>

The speed limit markings in the instru-
ment panel will change from GRAY to
WHITE. The vehicle's speed will once
again be limited to the most recently set
speed.
or –
Press the button on the steering wheel
(2).
>

The speed limit markings and symbols in
the instrument panel will change from
GRAY to WHITE and the vehicle's current
speed will be set as the maximum speed.
Related information
• Speed limiter (p. 278) Turning off Cruise Control
The Speed Limiter (SL 17
) can be turned off. Note: This illustration is general and details may vary
depending on model.
1.
Press the button on the steering wheel
(2).
>

The Speed Limiter will go into standby
mode.
2. Press the ◀ (1) or ▶ (3) buttons on the
steering wheel to select another function.
> The Speed Limiter symbol and marking (4) in the instrument panel will go out and
the set maximum speed will be erased.
3. Press the (2) button on the steering
wheel keypad again.
>

Another function will be activated. 16
Speed Limiter

||DRIVER SUPPORT
282
Related information
•
Speed limiter (p. 278) Cruise Control limitations
On steep downgrades, the Speed limiter's brak-
ing capacity may not be sufficient and the set
maximum speed may be exceeded. If this hap-
pens,
Speed limit exceeded will be displayed in
the instrument panel to alert the driver.
NOTE A text message on exceeded max. speed is
activated if the speed is exceeded by at least
3 km/h (ca 2 mph).
Related information
•
Speed limiter (p. 278) Automatic Speed Limiter
The Automatic Speed Limiter (ASL 18
) function
helps the driver adapt the vehicle's maximum
speed to the posted speed limits.
The Speed Limiter (SL 19
) function can be
switched to Automatic Speed Limiter (ASL).
The Automatic Speed Limiter function uses
speed information from the Road Sign Informa-
tion function 20
to automatically adapt the vehi-
cle's maximum speed. 17
Speed Limiter
18 Automatic Speed Limiter
19 Speed Limiter
20 Road Sign Information – RSI

DRIVER SUPPORT
283
WARNING•
The ASL function is supplementary driver
support intended to facilitate driving and
help make it safer – it cannot handle all
situations in all traffic, weather and road
conditions.
• Even if the driver can clearly see the
speed limit sign, the speed information
from the Road Sign Information (RSI)
function to ASL may be incorrect. In such
cases, the driver must intervene and
accelerate or brake to an appropriate
speed.
• ASL is not a substitute for the driver's
attention and judgment. The driver is
always responsible for ensuring the vehi-
cle is driven in a safe manner, at the
appropriate speed, with an appropriate
distance to other vehicles, and in accord-
ance with current traffic rules and regula-
tions.
• See also the heading "Road Sign Infor-
mation limitations".Is SL or ASL active?The symbols in the instrument panel indicate
which Speed Limiter function is active: Symbol
SLASL A
✓ ✓ Road sign symbol
B
after "70" = ASL is
activated. ✓ A
WHITE symbol: The function is active. GRAY symbol: Standby
mode.
B See "ASL symbol" below for an explanation of the symbol's dif-
ferent colors.
ASL symbol
The road sign symbol (next to the
stored speed ("70" here) in the center
of the speedometer) can be displayed
in three different colors, which are
explained in the following table: Road sign
symbol's color Explanation
Greenish-yel- low ASL is active
Gray

ASL is in standby mode
Amber/orange ASL is temporarily in standby mode, e.g. because
a speed limit sign could not
be read.
Related information
•Speed limiter (p. 278)

DRIVER SUPPORT
284Activating/deactivating Automatic
Speed Limiter
The Automatic Speed Limiter (ASL 21
) is a sup-
plement to the Speed Limiter (SL 22
) and can be
activated/deactivated.
Activating ASLThe Speed Sign Assist but-
ton is located in the center dis-
play's Function view. To activate the Automatic Speed Limiter:
1.
Tap the Speed Sign Assist button.
>

ASL will go into standby mode and a
green indicator light will illuminate. A road
sign symbol will be displayed in the center
of the speedometer in the instrument
panel.
2. Pressing the button on the steering
wheel keypad.
>

ASL will be activated and set to the vehi-
cle's current speed.
NOTE •
If the Automatic Speed Limiter function is
activated, road sign information is shown
in the driver display even if RSI is not
activated.
• To remove road sign information from the
driver display, you must deactivate both
Automatic Speed Limiter and RSI.
• When the Automatic Speed Limiter func-
tion is activated but RSI is deactivated, no
warnings are given from RSI. In this situa-
tion, settings for RSI cannot be adjusted
either - to be able to adjust settings as
well as receive warnings, RSI must be
activated.Deactivating ASLTo deactivate the Automatic Speed Limiter:
–
Tap the
Speed Sign Assist button in Func-
tion view.
>
ASL will be deactivated, the indicator light
in the button will be GRAY and SL will be
activated instead.
WARNING The vehicle will no longer follow the posted
maximum speed after switching from ASL to
SL – it then only follows the maximum speed
stored in the memory.
Related information
•
Speed limiter (p. 278) 21
Automatic Speed Limiter
22 Speed Limiter

DRIVER SUPPORT
* Option/accessory.285
Changing Automatic Speed Limiter
tolerance
The Automatic Speed Limiter (ASL
23
) can be set
to different tolerance levels.
It is also possible to allow the vehicle to drive
above or below the posted speed limit. For exam-
ple, if the vehicle is following a current posted
speed limit of 70 km/h (43 mph), the driver can
instead allow the vehicle to maintain a speed of
75 km/h (47 mph). Function buttons and symbols
24
. –
Tap the (1) button on the steering
wheel keypad until 70 km/h (43 mph) has
been changed to 75 km/h (47 mph) in the
center of the speedometer (4).
>

The vehicle will then use the selected tol-
erance of 5 km/h (4 mph) as long as the
posted speed limit the vehicle passes is
70 km/h (43 mph).
This tolerance level will be followed until
the vehicle passes a sign with a lower or
higher speed. The vehicle will then adjust
to the new speed limit and the set toler-
ance will be deleted from the system's
memory.
If Road Sign Information* is activated, the
posted speed limit will then be indicated
by a RED marking on the speedometer's
speed scale.
The set tolerance can be adjusted in the same
way as for the Speed Limiter's speed.
NOTE The highest possible selectable tolerance is
+/- 10 km/h (5 mph).
Related information
•
Speed limiter (p. 278) Automatic Speed Limiter limitations
ASL utilizes the speed limit information provided
by the RSI 25
system, not from the speed limit
signs that the vehicle passes.
If RSI 25
is unable to interpret and provide ASL
with speed information, ASL will go into standby
mode and switch over to SL. The driver will then
have to actively brake to bring the vehicle down
to the appropriate speed.
ASL will be reactivated when RSI 25
is once again
able to interpret and provide speed information to
ASL.
See "Road Sign Information limitations" for more
information.
Related information
• Speed limiter (p. 278) 23
Automatic Speed Limiter
24 Note: This illustration is general and details may vary depending on mod\
el.
25 Road Sign Information (RSI)

DRIVER SUPPORT
* Option/accessory.
286 Cruise control
Cruise Control (CC 26
) helps the driver maintain
an even speed to provide a more relaxing driving
experience on highways and long, straight roads
with even traffic flows.
Overview Function buttons and symbols
27
. : Activates Cruise Control from standby
mode and resumes the set speed : Increases the set speed
: From standby mode - activates Cruise
Control and sets the current speed : From active mode - deactivates/puts
Cruise Control in standby mode : Reduces the set speed
Marker for set speed
The vehicle's current speed
Set speed
NOTE
In vehicles equipped with Adaptive Cruise
Control*, it is possible to switch between
cruise control and Adaptive Cruise Control –
see the heading "Switching between CC and
ACC".
WARNING •
The cruise control function is supplemen-
tary driver support intended to facilitate
driving and help make it safer – it cannot
handle all situations in all traffic, weather
and road conditions.
• The driver is advised to read all sections
in the Owner's Manual about this function
to learn of its limitations, which the driver
must be aware of before using the func-
tion (see the link list at the end of this
article).
• Cruise control is not a substitute for the
driver's attention and judgment. The driver
is always responsible for ensuring the
vehicle is driven in a safe manner, at the
appropriate speed, with an appropriate
distance to other vehicles, and in accord-
ance with current traffic rules and regula-
tions.
Related information
• Activating and starting Cruise Control
(p. 287)
• Managing Cruise Control speed (p. 288)
• Deactivating and putting Cruise Control in
standby mode (p. 289) 26
Cruise Control
27 Note: This illustration is general and details may vary depending on mod\
el.

DRIVER SUPPORT
287
•
Reactivating Cruise Control from standby
mode (p. 290)
• Switching off Cruise Control (p. 290) Activating and starting Cruise
Control
The Cruise Control (CC 28
) function must be
selected and activated in order to regulate
speed. Note: This illustration is general and details may vary
depending on model.
Putting Cruise Control in standby modeTo put Cruise Control in standby mode:
–
Tap ◀ (1) or ▶ (3) and scroll to the (4) function.
>

A symbol will appear and Cruise Control
can then be activated.
Activating/starting Cruise ControlIn order to start Cruise Control from standby
mode, the vehicle's current speed must be
30 km/h (20 mph) or higher. The lowest speed
that can be set is 30 km/h (20 mph).
To start Cruise Control:
– With the function displayed, press
(2) on the steering wheel keypad.
>

Cruise Control will be started and the
vehicle's current speed will be set.
NOTE Cruise control can then not be connected at
speeds below 30 km/h (20 mph).
Related information
•
Cruise control (p. 286) 28
Cruise Control

DRIVER SUPPORT
288Managing Cruise Control speed
Cruise Control (CC 29
) can be set to various
speeds.
Setting/changing set speed Note: This illustration is general and details may vary
depending on model.
For vehicles with only CC
–
Change a set speed by pressing the (1)
or (3) buttons briefly or by pressing and
holding them:
• Press briefly: Press briefly: each press
changes the speed in +/- 1 mph
(+/- 1 km/h) increments.
• Press and hold: Release the button when
the set speed indicator (4) has moved to
the desired speed. •
The most recently set speed will be stored.
If speed is increased by depressing the accelera-
tor pedal while pressing the (1) button on
the steering wheel, the vehicle's speed when the
button is pressed will be stored as the set speed.
Temporarily increasing speed using the accelera-
tor pedal, e.g. when passing another vehicle, will
not affect the setting. The vehicle will return to
the set speed when the accelerator pedal is
released.
For vehicles with both CC and ACC
– Change a set speed by pressing the (1)
or (3) buttons briefly or by pressing and
holding them:
• Press briefly: Press briefly: each press
changes the speed in +/- 5 mph
(+/- 5 km/h) increments.
• Press and hold: Release the button when
the set speed indicator (4) has moved to
the desired speed.
• The most recently set speed will be stored.
If speed is increased by depressing the accelera-
tor pedal while pressing the (1) button on
the steering wheel, the vehicle's speed when the
button is pressed will be stored as the set speed.
Temporarily increasing speed using the accelera-
tor pedal, e.g. when passing another vehicle, will not affect the setting. The vehicle will return to
the set speed when the accelerator pedal is
released.
Using engine braking instead of
applying the brakes
Cruise Control regulates speed by lightly applying
the brakes. On downgrades, it can sometimes be
desirable to roll a bit faster and let speed be
reduced instead by engine braking alone. The
driver can temporarily disengage the Cruise Con-
trol braking function.
To disengage CC:
– Press the accelerator pedal about halfway
down and then release it.
>

Cruise Control will automatically disen-
gage the automatic brake function and
speed will only be reduced using the
engine braking function.
How drive mode affects cruise controlThe way the cruise control maintains the vehicle's
speed can vary depending on the selected drive
mode 30
. 29
Cruise Control
30 For more information, see "Drive modes".
