1-CONTENTS
LOCATION OF THE WARNING AND
SPECIFICATION LABELS ...................... 1-1
SAFETY INFORMATION ......................... 2-1
DESCRIPTION AND MACHINE
IDENTIFICATION ................................... 3-1
Identification number records ............... 3-3
Key identification number .................... 3-5
Vehicle identification number ............... 3-7
Model label ........................................... 3-9
CONTROL FUNCTIONS ........................ 4-1
Main switch .......................................... 4-1
Indicator lights ..................................... 4-3
Handlebar switches ............................. 4-5
Throttle lever ....................................... 4-9
Speed limiter ...................................... 4-11
Front brake lever ............................... 4-13
Rear brake pedal and lever ............... 4-13
Parking brake .................................... 4-15
Shift pedal ......................................... 4-17
Drive select lever ................................ 4-17
Recoil starter ..................................... 4-19
1234
Fuel tank cap .................................... 4-19
Fuel cock ........................................... 4-21
Starter (choke) .................................. 4-23
Seat.................................................... 4-25
Storage box........................................ 4-29
Front carrier ....................................... 4-29
Rear carrier ........................................ 4-29
Rear shock absorber adjustment ....... 4-31
PRE-OPERATION CHECKS .................. 5-1
Front and rear brakes .......................... 5-5
Fuel ...................................................... 5-9
Engine oil ........................................... 5-13
Final gear oil ...................................... 5-17
Throttle lever ..................................... 5-17
Fittings and Fasteners ...................... 5-19
Lights ................................................. 5-19
Switches............................................. 5-19
Battery ............................................... 5-19
Tires .................................................. 5-21
How to measure tire pressure ........... 5-25
Tire wear limit .................................... 5-27
5
EE.book Page 1 Monday, June 25, 2001 3:46 PM

OPERATION ...........................................6-1
Starting a cold engine ...........................6-3
Starting a warm engine ........................6-9
Warming up ..........................................6-9
Drive select lever operation and
reverse driving .................................6-11
Shifting ...............................................6-15
To start out and accelerate: ...............6-17
To decelerate: ....................................6-19
Engine break-in ..................................6-21
Parking ...............................................6-23
Parking on a slope .............................6-25
Accessories and loading ....................6-27
RIDING YOUR ATV..................................7-1
Getting to know your ATV .....................7-3
Ride with care and good
judgement ...........................................7-5
Be careful where you ride ...................7-27
Turning your ATV ................................7-41
Climbing uphill.....................................7-47
Riding downhill ....................................7-57
Crossing a slope .................................7-61
Crossing through shallow water ..........7-65
Riding over rough terrain ....................7-69
Sliding and skidding ............................7-71
67
What to do if ... ................................... 7-75
What to do ... ...................................... 7-75
PERIODIC MAINTENANCE AND
ADJUSTMENT ......................................... 8-1
Owner’s manual and tool kit ................. 8-3
Periodic maintenance/lubrication ......... 8-7
Engine oil ............................................ 8-13
Final gear oil ....................................... 8-23
Spark plug inspection ......................... 8-29
Air filter cleaning ................................. 8-33
Carburetor adjustment ....................... 8-39
Idle speed adjustment ....................... 8-41
Valve clearance adjustment .............. 8-43
Throttle lever adjustment ................... 8-43
Front brake pad inspection ................ 8-45
Rear brake shoe inspection ............... 8-45
Brake fluid level inspection ................ 8-47
Brake fluid replacement ...................... 8-49
Front brake adjustment ...................... 8-51
Rear brake adjustment ...................... 8-53
Adjusting the rear brake light switch ... 8-59
Clutch adjustment .............................. 8-61
Cable inspection and lubrication......... 8-63
Brake lever and brake pedal
lubrication ........................................ 8-65
Steering shaft lubrication ................... 8-65
8
EE.book Page 2 Monday, June 25, 2001 3:46 PM

2-1
EBU00019*
SAFETY INFORMATION
AN ATV IS NOT A TOY AND CAN BEHAZARDOUS TO OPERATE.
An ATV handles
differently from other vehicles including
motorcycles and cars. A collision or rollover can
occur quickly, even during routine maneuvers
such as turning and riding on hills or over
obstacles, if you fail to take proper precautions.
SEVERE INJURY OR DEATH can result if you do
not follow these instructions:


Read this manual and all labels carefully and
follow the operating procedures described.


Never operate an ATV without proper instruc-
tion.


Always follow the age recommendation:
– A child under 16 years old should never oper-
ate an ATV with engine size greater than 90cc.
EE.book Page 1 Monday, June 25, 2001 2:27 PM

2-17
WARNING


Always turn off the engine when refueling.


Do not refuel right after the engine has
been running and is still very hot.


Do not spill gasoline on the engine or ex-
haust pipe/muffler when refueling. Never
refuel while smoking, or while in the vicini-
ty of sparks, open flames, or other sources
of ignition such as the pilot lights of water
heaters and clothes dryers. Gasoline can
catch fire and you could be burned.


When transporting the machine in another
vehicle, be sure it is kept upright and that
the fuel cock is in the “OFF” position. Oth-
erwise, fuel may leak out of the carburetor
or fuel tank.


Gasoline is poisonous. If you should swal-
low some gasoline or inhale a lot of gaso-
line vapor, or get some gasoline in your
eyes, see your doctor immediately. If gaso-
line spills on your skin, wash with soap
and water. If gasoline spills on your cloth-
ing, change your clothes.
EE.book Page 17 Monday, June 25, 2001 2:27 PM

4-1
EBU00040
CONTROL FUNCTIONS
EBU00041
Main switch
Functions of the respective switch positions are as
follows:
ON:
Engine can be started only at this position and the
headlight and taillight come on when the light
switch is on.
OFF:
All electrical circuits are switched off. The key can
be removed in this position.
EE.book Page 1 Monday, June 25, 2001 2:27 PM

4-5 1. Lights switch “LIGHTS”
2. Engine stop switch “ENG. STOP”
3. Start switch “START”
1. Contacteur d’éclairage “LIGHTS”
2. Coupe-circuit du moteur “ENG. STOP”
3. Contacteur du démarreur “START”
1. Interruptor de luces “LIGHTS”
2. Interruptor de paro del motor “ENG. STOP”
3. Interruptor de arranque “START”
EBU00053
Handlebar switches
EBU00054
Engine stop switch “ENG. STOP”
Make sure that the engine stop switch is in the
“RUN” position. The engine stop switch controls
ignition and can be used at all times to stop the en-
gine, especially in an emergency. The engine will
not start or run when the engine stop switch is
turned to “OFF”.
EBU00056
Start switch “START”
The starter motor cranks the engine when this
switch is pushed.CAUTION:
See starting instructions prior to starting en-
gine (see page 6-3 for details).
EE.book Page 5 Monday, June 25, 2001 2:27 PM

4-7
NOTE:If the starter switch is pushed with the main switch
“ON” and the engine stop switch “OFF”, the starter
motor will be activated but the engine will not start.
To start the engine, be sure to position the engine
stop switch at “RUN”.
EBU00734
Light switch “LIGHTS”
Turn the switch to the “LO” position to switch on
the low beam and the taillight.
Turn the switch to the “HI” position to switch on the
high beam and the taillight.
Turn the switch to the “OFF” position to switch off
the headlight and the taillight.CAUTION:
Do not use the headlight with the engine
turned off for more than thirty minutes. The
battery may discharge to the point that the
starter motor will not operate properly. If this
should happen, remove the battery and re-
charge it.
EE.book Page 7 Monday, June 25, 2001 2:27 PM

4-9 1. Throttle lever
1. Levier d’accélération
1. Palanca de aceleración
EBU00063
Throttle lever
Once the engine is running, movement of the
throttle lever will increase the engine speed.
Regulate the speed of the machine by varying the
throttle position. Because the throttle is spring-
loaded, the machine will decelerate, and the en-
gine will return to an idle any time the hand is re-
moved from the throttle lever.
Before starting the engine, check the throttle to be
sure it is operating smoothly. Make sure it returns
to the idle position as soon as the lever is released.
WARNING
Malfunction of the throttle could make it diffi-
cult to speed up or slow down when you need
to. This could cause an accident. Check the
operation of the throttle lever before you start
the engine. If the throttle does not work
smoothly, check for the cause. Correct the
problem before riding the ATV or consult a
Yamaha dealer.
EE.book Page 9 Monday, June 25, 2001 2:27 PM

4-11 1. Locknut 2. Adjuster a. 12 mm
1. Contre-écrou 2. Vis de réglage
1. Contratuerca 2. Ajuste
EBU00565
Speed limiter
The speed limiter keeps the throttle from fully
opening, even when the throttle lever is pushed to
the maximum. Screwing in the adjuster limits the
maximum engine power available and decreases
the maximum speed of the ATV.
WARNING
Improper adjustment of the speed limiter and
throttle could cause throttle cable damage or
improper throttle operation. You could lose
control, have an accident or be injured. Do not
turn the speed adjuster out more than 12 mm
or the throttle cable could be damaged. Always
make sure the throttle lever free play is adjust-
ed to 3 ~ 5 mm. See page 8-43.
EE.book Page 11 Monday, June 25, 2001 2:27 PM

4-15 1. Lock plate
1. Verrou
1. Placa de bloqueo
1. Lock plate
1. Verrou
1. Placa de bloqueo
EBU00075
Parking brake
Use the parking brake when you have to start the
engine or park the machine, especially on a slope.
Apply the rear brake lever and push down the lock
plate to apply the parking brake. Squeeze the rear
brake lever to release the parking brake.
WARNING


Always set the parking brake before start-
ing the engine. The ATV could start mov-
ing unexpectedly if the parking brake is not
applied. This could cause loss of control or
a collision.


Always be sure you have released the
parking brake before you begin to ride. The
brake could overheat if you ride the ATV
without releasing the parking brake. You
could lose braking performance which
could cause an accident. You could also
wear out the brakes prematurely.
EE.book Page 15 Monday, June 25, 2001 2:27 PM
