key YAMAHA DT125R 2000 Owners Manual

IMPORTANT MANUAL INFORMATION
1
2
3
4
5
6
7
8
9
EAU00005
Particularly important information is distinguished in this manual by the following notations:
The Safety Alert Symbol means ATTENTION! BECOME ALERT! YOUR SAFETY
IS INVOLVED!
Failure to follow WARNING instructions could result in severe injury or death to the
motorcycle operator, a bystander or a person inspecting or repairing the motorcycle.A CAUTION indicates special precautions that must be taken to avoid damage to
the motorcycle.A NOTE provides key information to make procedures easier or clearer.
Qw
cCNOTE:
NOTE:
8This manual should be considered a permanent part of this motorcycle and should remain
with it even if the motorcycle is subsequently sold.
8Yamaha continually seeks advancements in product design and quality. Therefore, while this
manual contains the most current product information available at the time of printing, there
may be minor discrepancies between your motorcycle and this manual. If there is any ques-
tion concerning this manual, please consult your Yamaha dealer.
3MB-9-E7 12/27/00 2:52 PM Page 2

TABLE OF CONTENTS
1
2
3
4
5
6
7
8
9 MOTORCYCLE CARE AND STORAGE.............7-1
Care..................................................................7-1
Storage.............................................................7-4
SPECIFICATIONS...............................................8-1
How to use the conversion table.......................8-5
CONSUMER INFORMATION..............................9-1
Identification number records...........................9-1
Key identification number.................................9-1
Vehicle identification number............................9-1
Model label.......................................................9-2
789
3MB-9-E7 12/27/00 2:52 PM Page 7

3-1
ON
OFF
EAU00028
Main switchThe main switch controls the ignition
and lighting systems. Its operation is
described below.
EAU00036
ON
Electrical circuits are switched on.
The engine can be started. The key
cannot be removed in this position.
EAU00038
OFF
All electrical circuits are switched off.
The key can be removed in this posi-
tion.EAU00027
INSTRUMENT AND CONTROL FUNCTIONS
1
23
4
5
6
7
8
9
EAU00063
High beam indicator light Ò
&Ó
This indicator comes on when the
headlight high beam is used.
EAU01313
Oil level indicator light Ò
7
Ó
This indicator comes on when the oil
level is low. This light circuit can be
checked by the procedure on page 3-
2.EC000000
cCDo not run the motorcycle until
you know it has sufficient engine
oil.NOTE
Even if the oil is filled to the specified
level, the indicator light may flicker
when riding on a slope or during sud-
den acceleration or deceleration, but
this is normal.
1
2
3
4
EAU00056
Indicator lights
EAU00057
Turn indicator light Ò5Ó
This indicator flashes when the turn
switch is moved to the left or right.
EAU00061
Neutral indicator light ÒNÓ
This indicator comes on when the
transmission is in neutral.1.Turn indicator light Ò5Ó
2.High beam indicator light Ò&Ó
3.Neutral indicator light ÒNÓ
4.Oil level indicator light Ò
7
Ó
3MB-9-E7 12/27/00 2:52 PM Page 13

3-6
INSTRUMENT AND CONTROL FUNCTIONS
1
23
4
5
6
7
8
9
1
1.Front brake lever
EAU00158
Front brake leverThe front brake lever is located on
the right handlebar. Pull it toward the
handlebar to apply the front brake.
1
1.Rear brake pedal
EAU00162
Rear brake pedalThe rear brake pedal is on the right
side of the motorcycle. Press down
on the brake pedal to apply the rear
brake.
31
2
EAU00177
Fuel tank capTo open
Insert the key and turn it 1/4 turn
counterclockwise. Turn the cap 1/3
turn counterclockwise and remove it
from the tank.
To close
Put the cap in the filler neck and turn
it 1/3 turn clockwise. Lock the cap by
turning the key 1/4 turn clockwise,
and remove the key.1.Fuel tank cap
2.Unlock
3.Open
3MB-9-E7 12/27/00 2:52 PM Page 18

3-7
INSTRUMENT AND CONTROL FUNCTIONS
1
23
4
5
6
7
8
9
NOTE:
The tank cap cannot be reinstalled
unless it is unlocked. The key must
remain in the cap until the cap is
properly installed and locked onto the
fuel tank.
EW000023
wBe sure the cap is properly
installed and locked in place
before riding the motorcycle.
21
1.Filler tube
2.Fuel level
EAU01183
Fuel(except for Switzerland and
Austria)
Make sure there is sufficient fuel in
the tank. Fill the fuel tank to the bot-
tom of the filler tube as shown in the
illustration.
EW000130
wDo not overfill the fuel tank. Avoid
spilling fuel on the hot engine. Do
not fill the fuel tank above the bot-
tom of the filler tube or it may
overflow when the fuel heats up
later and expands.
2
1 3 4
1.Filler tube
2.Filling nozzle
3.Leaf valve
4.Fuel level
EAU01184
Fuel(for Switzerland and Austria)
Make sure there is sufficient fuel in
the tank. When refueling, be sure to
insert the filling nozzle into the filler
hole and fill the tank to the bottom of
the filler tube as shown in the illustra-
tion.
3MB-9-E7 12/27/00 2:52 PM Page 19

3-11
INSTRUMENT AND CONTROL FUNCTIONS
1
23
4
5
6
7
8
9
1
EAU00212
Kick starterRotate the kick starter away from the
engine. Push the starter down lightly
with your foot until the gears engage,
then kick smoothly and forcefully to
start the engine. This model has a
primary-coupled kick starter so the
engine can be started in any gear if
the clutch is disengaged. However,
shifting to neutral before starting is
recommended.1.Kick starter
EAU02934
Steering lockTo lock the steering
Turn the handlebars all the way to
the right and open the steering lock
cover.
Insert the key and turn it 1/8 turn
counterclockwise. Then, push the key
in while turning the handlebars slight-
ly to the left and turn the key 1/8 turn
clockwise.
Check that the steering is locked,
remove the key and close the lock
cover.
1
1.Steering lock
To unlock the steering
Insert the key, push it in and turn it
1/8 turn counterclockwise so that it
moves out. Then, release and
remove the key.
3MB-9-E7 12/27/00 2:52 PM Page 23

3-12
INSTRUMENT AND CONTROL FUNCTIONS
1
23
4
5
6
7
8
9
To install
1.Insert the projections on the front
of the seat into the holders, then
tighten the seat bolts.
2.Install the panels.NOTE:
Make sure that the seat is securely
fitted.
1
EAU00261
Helmet holderTo open the helmet holder, insert the
key in the lock and turn it as shown.
To lock the helmet holder, turn the
key to its original position.
EW000030
wNever ride with a helmet in the hel-
met holder. The helmet may hit
objects, causing loss of control
and possibly an accident.1.Open
1
EAU01648
SeatTo remove
1.Remove panels D and E. (See
page 6-9 for panel removal and
installation procedures.)
2.Remove the seat bolts and lift
the seat upward.1.Bolt (
´2)
3MB-9-E7 12/27/00 2:52 PM Page 24

1,000 km and beyondFull throttle can be used.
EC000053
cC8
8
Never let engine speeds enter
the red zone.
8 8
If any engine trouble should
occur during the break-in peri-
od, consult a Yamaha dealer
immediately.
EAU00458
ParkingWhen parking the motorcycle, stop
the engine and remove the ignition
key. Turn the fuel cock to ÒOFFÓ
whenever stopping the engine.
EW000058
wThe exhaust system is hot. Park
the motorcycle in a place where
pedestrians or children are not
likely to touch the motorcycle. Do
not park the motorcycle on a slope
or soft ground; the motorcycle
may overturn.
EC000062
cCNever park this motorcycle in an
area that would cause a fire haz-
zard such as grass or other materi-
als that may easily burn.
5-6
OPERATION AND IMPORTANT RIDING POINTS
1
2
3
45
6
7
8
9 3MB-9-E7 12/27/00 2:52 PM Page 36

1
2
3
4
5
6
7
89
9-1
EAU01039
CONSUMER INFORMATION
1
1
EAU02944
Identification number
recordsRecord the key identification number,
vehicle identification number and
model label information in the spaces
provided for assistance when order-
ing spare parts from a Yamaha deal-
er or for reference in case the vehicle
is stolen.
1.KEY IDENTIFICATION
NUMBER:
2.VEHICLE IDENTIFICATION
NUMBER:
3.MODEL LABEL INFORMATION:
EAU01042
Key identification numberThe key identification number is
stamped on the key.
Record this number in the space pro-
vided and use it for reference when
obtaining a new key.
EAU01043
Vehicle identification
numberThe vehicle identification number is
stamped into the steering head pipe.
Record this number in the space pro-
vided.NOTE:
The vehicle identification number is
used to identify your motorcycle and
may be used to register your motor-
cycle with the licensing authority in
your state.
1.Key identification number1.Vehicle identification number
1
6
3MB-9-E7 12/27/00 2:52 PM Page 88
