Brake light switches .................................. 8-48
Checking and lubricating the cables......... 8-48
Checking and lubricating the front and rear brake levers ..................................... 8-49
Checking and lubricating the brake pedal ....................................................... 8-50
Checking the wheel hub bearings............. 8-50
Checking the stabilizer bushes ................. 8-51
Lubricating the rear knuckle pivots ........... 8-51
Lubricating the steering shaft ................... 8-52
Battery....................................................... 8-53
Replacing a fuse ....................................... 8-56
Replacing a headlight bulb ....................... 8-59
Adjusting a headlight beam ...................... 8-62
Replacing the brake/tail light bulb ............ 8-63
Removing a wheel ..................................... 8-64
Installing a wheel....................................... 8-64
Troubleshooting ........................................ 8-65
Troubleshooting charts ............................. 8-66
CLEANING AND STORAGE ........................... 9-1 Cleaning ...................................................... 9-1
Storage........................................................ 9-2 SPECIFICATIONS ........................................ 10-1
CONSUMER INFORMATION....................... 11-1
Identification numbers .............................. 11-1
INDEX .......................................................... 12-1
UB5K60E0.book Page 3 Monday, May 28, 2018 11:35 AM

3-1
3
EBU17681
DESCRIPTION
EBU17691Left view
EBU17701Right view
1. Radiator cap
2. Battery
3. Fuses
4. Air filter
5. Spark arrester
6. Rear brake light switch
7. Engine oil dipstick
8. Oil filter cartridge
9. Coolant reservoir
5
1
2,3
47
8
6
9
1. Rear shock absorber
2. Fuel tank cap
3. Tool kit
4. Storage compartment
5. Spark plug
6. Front shock absorber
7. Brake pedal
8. V-belt case drain plug
5
1
6
23
478
UB5K60E0.book Page 1 Monday, May 28, 2018 11:35 AM

4-29
4
EBU19186Auxiliary DC jackNOTICEECB03760Do not use any single electrical accessory or
combination of accessories that require more
than the stated capacity at any one time. This
may overload the circuit and cause the fuse to
blow.
TIPWhen using a winch or other electrical accesso-
ries, the power taken from the DC jack must be re-
duced accordingly. A 12-V accessory, such as a work light or radio
with the proper adapter, can be used when the
main switch is turned on. However, to prevent bat-
tery drain, use when the engine is running and the
headlights are turned off.1. Start the engine.
2. Turn the headlights off.
3. Turn the accessory off.
4. Open the auxiliary DC jack cap.
5. Insert the accessory power plug into the jack.
6. Turn the accessory on.TIP When inserting or removing the accessory pow-
er plug, turn the accessory off.
 When the auxiliary DC jack is not being used,
cover it with the cap.
1. Auxiliary DC jack cap
2. Auxiliary DC jackAuxiliary DC jack system capacity:
10.0 A (120 W)
21
UB5K60E0.book Page 29 Monday, May 28, 2018 11:35 AM

8-56
83. Install the battery holding plate by installing
the nuts.
4. Install the front carrier by installing the bolts and tightening them to the specified torques. 5. Install the panel.
TIP
Make sure the positive and negative battery
leads are installed as shown.
 Fully charge the battery before installing it. EBU30524Replacing a fuse
1. Positive battery lead (red)
2. Negative battery lead (black)Tightening torques:
Carrier bolt (upper):34 N·m (3.4 kgf·m, 25 lb·ft)
Carrier bolt (lower): 34 N·m (3.4 kgf·m, 25 lb·ft)
Carrier bolt (under the fenders): 7 N·m (0.7 kgf·m, 5.2 lb·ft)
12
1. Fuse box
2. Main fuse
3. EPS fuse (for EPS model)
4. Fuel injection system spare fuse
5. Fuel injection system fuse
2345
1
UB5K60E0.book Page 56 Monday, May 28, 2018 11:35 AM

8-57
8
YFM70KDXK / YFM70KDHK YFM70KPXK / YFM70KPAK / YFM70KPHK /
YFM70KPSK / YFM70KPLK
If an electrical problem is suspected, check the
fuse and replace it if necessary as follows.
1. Headlight fuse
2. Signaling system fuse
3. Radiator fan motor fuse
4. Ignition fuse
5. Auxiliary DC jack fuse
6. Spare fuse
12345
6
1. Headlight fuse
2. Radiator fan motor fuse
3. Signaling system fuse
4. Ignition fuse
5. Four-wheel-drive motor fuse
6. Auxiliary DC jack fuse
7. Spare fuse
123456
7
UB5K60E0.book Page 57 Monday, May 28, 2018 11:35 AM

8-58
8
NOTICEECB00641To prevent accidental short-circuiting, turn off
the main switch when checking or replacing a
fuse. 1. Turn off all electrical systems. (See page 4-1.)
2. Remove panel A. (See page 8-9.)
3. Remove the blown fuse, and then install anew fuse of the specified amperage.
WARNING! Always use a fuse of the spec-
ified rating, and never use a substitute ob-
ject in place of the proper fuse. An
improper fuse or a substitute object can
cause damage to the electrical system,
which could lead to a fire.
[EWB02173]
Specified fuses:Main fuse:40.0 A
Headlight fuse: 10.0 A (YFM70KDHK, YFM70KDXK)
15.0 A (YFM70KPSK, YFM70KPLK,
YFM70KPAK, YFM70KPHK,
YFM70KPXK)
Ignition fuse: 10.0 A
Four-wheel-drive motor fuse: 10.0 A (YFM70KPSK, YFM70KPLK,
YFM70KPAK, YFM70KPHK,
YFM70KPXK)
Signaling system fuse: 10.0 A
Auxiliary DC jack fuse: 10.0 A
Radiator fan motor fuse: 20.0 A
Fuel injection system fuse: 15.0 A
EPS fuse: 40.0 A (YFM70KPSK, YFM70KPLK,
YFM70KPAK, YFM70KPHK,
YFM70KPXK)
UB5K60E0.book Page 58 Monday, May 28, 2018 11:35 AM

8-59
8
4. Turn on the main switch and start the engine.
5. If the fuse immediately blows again, have a
Yamaha dealer check the vehicle.
EBU34223Replacing a headlight bulbIf a headlight bulb burns out, replace it with the
specified bulb as follows.
Left and right headlight bulbs1. Remove the cover at the rear of the headlight by pulling it off.
2. Remove the bulb cover by pulling it off. 3. Remove the socket by pushing it in and turn-
ing it counterclockwise.1. Cover at the rear of the headlight
1
1. Bulb cover
1. Socket
1
1
UB5K60E0.book Page 59 Monday, May 28, 2018 11:35 AM

10-5
10
Shock absorber:Hydraulic damper
Wheel travel: 232 mm (9.1 in)Electrical system:System voltage:12 V
Ignition system: TCI
Charging system:
AC magnetoBattery:Model:YTX20L-BS
Voltage, capacity:
12 V, 18.0 AhLights:Headlight:T19L, 30.0 W/30.0 W
Handlebar-mounted light:
T15H, 35.0 W/36.5 W (YFM70KPSK, YFM70KPLK,
YFM70KPAK, YFM70KPHK, YFM70KPXK)
Brake/tail light:
21.0 W/5.0 W
Meter lighting: LED (YFM70KPSK, YFM70KPLK, YFM70KPAK,
YFM70KPHK, YFM70KPXK)
Neutral indicator light: LED
High beam indicator light: LED (YFM70KPSK, YFM70KPLK, YFM70KPAK,
YFM70KPHK, YFM70KPXK) Fuel level warning light:
LED (YFM70KDHK, YFM70KDXK)
Reverse indicator light: LED
Coolant temperature warning light:
LED
Park indicator light: LED
Four-wheel-drive indicator light: 1.7 W (YFM70KDHK, YFM70KDXK)
Engine trouble warning light:
LED
High-range indicator light: LED (YFM70KPSK, YFM70KPLK, YFM70KPAK,
YFM70KPHK, YFM70KPXK)
Low-range indicator light: LED (YFM70KPSK, YFM70KPLK, YFM70KPAK,
YFM70KPHK, YFM70KPXK)
Differential gear lock indicator light: LED (YFM70KPSK, YFM70KPLK, YFM70KPAK,
YFM70KPHK, YFM70KPXK)
EPS warning light: LED (YFM70KPSK, YFM70KPLK, YFM70KPAK,
YFM70KPHK, YFM70KPXK)
Battery voltage warning light: LED (YFM70KPSK, YFM70KPLK, YFM70KPAK,
YFM70KPHK, YFM70KPXK)
Fuses:Main fuse:40.0 A
UB5K60E0.book Page 5 Monday, May 28, 2018 11:35 AM

10-6
10
Headlight fuse:10.0 A (YFM70KDHK, YFM70KDXK)
15.0 A (YFM70KPSK, YFM70KPLK, YFM70KPAK,
YFM70KPHK, YFM70KPXK)
Signaling system fuse:
10.0 A
Ignition fuse: 10.0 A
Auxiliary DC jack fuse: 10.0 A
Fuel injection system fuse:
15.0 A
Four-wheel-drive motor fuse: 10.0 A (YFM70KPSK, YFM70KPLK, YFM70KPAK,
YFM70KPHK, YFM70KPXK)
Radiator fan motor fuse: 20.0 A
EPS fuse: 40.0 A (YFM70KPSK, YFM70KPLK, YFM70KPAK,
YFM70KPHK, YFM70KPXK)EBU30403Noise and vibration levels statement (for Eu-
rope)
The figures quoted are emission levels and are not
necessarily safe working levels. Whilst there is a
correlation between the emission and exposure
levels, this cannot be used reliably to determine
whether or not further precautions are required. Factors that influence the actual level of exposure
of work-force include the characteristics of the
work room, the other sources of noise, etc. i.e. the
number of machines and other adjacent process-
es, and the length of time for which an operator is
exposed to the noise. Also the permissible expo-
sure level can vary from country. This information,
however, will enable the user of the machine to
make a better evaluation of the hazard and risk.UB5K60E0.book Page 6 Monday, May 28, 2018 11:35 AM

12-2
12
Fuses, replacing ........................................................... 8-56HHandlebar switches ..................................................... 4-12
Headlight beam, adjusting ........................................... 8-62
Headlight bulb, replacing ............................................. 8-59
High beam indicator light ............................................... 4-3
High-range indicator light (YFM70KPXK / YFM70KPAK / YFM70KPHK / YFM70KPSK /
YFM70KPLK) ............................................................... 4-2
Horn switch .................................................................. 4-14IIdentification numbers ................................................. 11-1
Indicator lights and warning lights ................................. 4-1
Instruments, lights and switches ................................... 5-7LLabel locations ............................................................... 1-1
Light switch .................................................................. 4-14
Low-range indicator light (YFM70KPXK / YFM70KPAK / YFM70KPHK / YFM70KPSK /
YFM70KPLK) ............................................................... 4-2MMain switch .................................................................... 4-1
Maintenance and lubrication chart ................................8-5
Maintenance chart, emission control system ................ 8-3
Model label ................................................................... 11-1
Multi-function display .....................................................4-6NNeutral indicator light .....................................................4-2
OOn-Command drive switch “4WD/LOCK” (YFM70KPXK / YFM70KPAK / YFM70KPHK /
YFM70KPSK / YFM70KPLK) ..................................... 4-16
Override switch (YFM70KPXK / YFM70KPAK / YFM70KPHK / YFM70KPSK / YFM70KPLK) ............. 4-14
Owner’s Manual and tool kit .......................................... 8-2PPanels, removing and installing ..................................... 8-9
Park indicator light ......................................................... 4-3
Parking ........................................................................... 6-4
Parking on a slope ......................................................... 6-5
Part locations ................................................................. 3-1RRear brake, adjusting the lever, pedal free play .......... 8-44
Rear knuckle pivots, lubricating ................................... 8-51
Reverse indicator light ................................................... 4-2
Riding your ATV ............................................................. 7-1SSafety information .......................................................... 2-1
Seat .............................................................................. 4-24
Shock absorber assemblies, adjusting the front and
rear (YFM70KPXK / YFM70KPAK / YFM70KPHK /
YFM70KPSK / YFM70KPLK) ..................................... 4-26
Spark arrester, cleaning ............................................... 8-39
Spark plug, checking ................................................... 8-17
Specifications .............................................................. 10-1
Speed limiter ................................................................ 4-19
Stabilizer bushes, checking ......................................... 8-51
Starting the engine ......................................................... 6-1
Start switch .................................................................. 4-14
