YAMAHA T105 1998 User Guide

EAA61400Key identification number
The key identification number is stamped
on the key.
Record this number in the space provided
and use it for reference when obtaining a
new key.EAA60700Frame serial number
The frame serial number is stamped into
the the frame.EAA70001Engine serial number
The engine serial number is stamped into
the crankcase.
10
T105(E) O/M-1 9/11/01 11:16 AM Page 10 (1,1)

Position Function Key removal
EAB00000
CONTROL FUNCTIONS
EAB00100Main switch
The main switch controls the ignition and lighting systems. Its operation is described
below.
11
ON
Electrical circuits are switched on.
The engine can be started.Cannot be removed.
Can be removed.
Can be removed. All electrical circuits are switched off.
The steering is locked and all
electrical circuits are switched off. OFF
LOCK
T105(E) O/M-1 9/11/01 11:16 AM Page 11 (1,1)

EAB10000Indicator lights
12
1Turn indicator light
2Neutral indicator light
3Top gear indicator light
4High beam indicator light
Description Function
Turn indicator light
“5”:
Neutral indicator
light “N”:
Top gear indicator
light “TOP”:
High beam indica-
tor light “&”:Flashes when the
turn switch is
“ON”.
Lights when the
transmission is in
neutral.
Light when the
transmission is in
top (4th) gear.
Lights when the
headlight high
beam is used.
T105(E) O/M-1 9/11/01 11:16 AM Page 12 (1,1)

Fuel gauge Instrument panel
13
1Speedometer2Odometer
3Fuel gauge
Description Function
Speedometer
OdometerShows riding speed.
Shows accumlated
mileage.
Shows the fuel level
in the fuel tank.
T105(E) O/M-1 9/11/01 11:16 AM Page 13 (1,1)

Position Function Handlebar switches
Lights switch
Dimmer switch
Turn signal switch
14
1Lights switch2Dimmer switch3Turn signal switch
Position Function
ON
OFF
Headlight, taillight and meter lights
comes on when engine is running.
Headlight, taillight and meter lights
does not come on.
Position Function
&(HI)
% (LO)Turns on the headlight high
beam.
Turns on the headlight low
beam.4
6
OFFTurns on the left flasher.
Turns on the right flasher.
Turns off the flasher.
Push the switch in after it has
returned to center position.
∇
T105(E) O/M-1 9/11/01 11:16 AM Page 14 (1,1)

Horn switch
Start switch
15
4Horn switch5Start switch
Position Function
*
(HORN)The horn sounds when push-
ing the switch.Position Function
START
The starter motor cranks the
engine when pushing the
switch.
T105(E) O/M-1 9/11/01 11:16 AM Page 15 (1,1)

EAB80001Shift pedal
This motorcycle is equipped with a con-
stant-mesh 4-speed transmission. The shift
pedal is located on the left side of the en-
gine.EAB90001Front brake lever
The front brake lever is located on the right
handlebar. Pull it toward the handlebar to
apply the front brake.
16
1Shift pedal N. Neutral1Front brake lever
T105(E) O/M-1 9/11/01 11:16 AM Page 16 (1,1)

EAB90101Rear brake pedal
The rear brake pedal is on the right side of
the motorcycle. Press down on the brake
pedal to apply the rear brake.EAC01300*Fuel tank cap
To add fuel, open the seat. Then remove
the fuel tank cap by turning it counterclock-
wise.
(See page 20 to open the seat.)
17
1Rear brake pedal1Fuel tank cap
T105(E) O/M-1 9/11/01 11:16 AM Page 17 (1,1)

EAC20100Starter lever 1
The starter lever is located on the left han-
dlebar. Starting a cold engine requires a
richer fuel mixture. In such a case, turn the
starter lever to the left. After the engine is
warm, turn the lever to its original position.EAC60700Kick starter
Rotate the kick starter away from the en-
gine. Push the starter down lightly with
your foot until the gears engage, then kick
smoothly and forcefully to start the engine.
18
1Starter lever1Kick starter
T105(E) O/M-1 9/11/01 11:16 AM Page 18 (1,1)

EAC30401Steering lock
The steering is locked when the main
switch is turned to “LOCK”. To lock the
steering, turn the handlebars all the way to
the left. With the key at “OFF”, push it into
the main switch and release it, turn it coun-
terclockwise to “LOCK”, and remove it. To
release the lock, turn the key to “OFF”.
19
1Push2Release3Turn
