YAMAHA TDR 125 2000 Owner's Manual

3-6
INSTRUMENT AND CONTROL FUNCTIONS
1
2
3
4
5
6
7
8
9
1
2&
&%
%
Left RightBulb to be used
Destination
3
'
3
2
'
2
3
2
Halogen
bulb
Halogen
bulbFrance Sweden Portugal Spain
Greece Belgium Germany
Switzerland Finland Austria
England
Ireland 3 : High beam light on , 2: Low beam light on
': Auxiliary light on
12V
60/55W12V
60/55W
12V
35/35W12V
35/35W
EAU00136
Headlight beam variation
NOTE:
Right and left directions are those assumed from the position of a person facing the front of the motorcycle.
5AE-9-E3 (ENG) 4/11/0 11:06 AM Page 19

3-7
INSTRUMENT AND CONTROL FUNCTIONS
1
2
3
4
5
6
7
8
921
EAU00138Engine stop switch
The engine stop switch is a safety
device for use in an emergency such
as when the motorcycle overturns or
if trouble occurs in the throttle sys-
tem. Turn the switch to “#” to start
the engine.
In case of emergency, turn the switch
to “$” to stop the engine.
1. Engine stop switch
2. Start switch “,”
EAU00143Start switch “, ,
”
The starter motor cranks the engine
when pushing the start switch.
EC000005
cC
See starting instructions prior to
starting the engine.
5AE-9-E3 (ENG) 4/11/0 11:06 AM Page 20

3-8
1
EAU00152Clutch lever
The clutch lever is located on the left
handlebar, and the ignition circuit cut-
off system is incorporated in the
clutch lever holder. Pull the clutch
lever to the handlebar to disengage
the clutch, and release the lever to
engage the clutch. The lever should
be pulled rapidly and released slowly
for smooth clutch operation. (Refer to
the engine starting procedures for a
description of the ignition circuit cut-
off system.)
EAU00158Front brake lever
The front brake lever is located on
the right handlebar. Pull it toward the
handlebar to apply the front brake.
1. Front brake lever
INSTRUMENT AND CONTROL FUNCTIONS
1
2
3
4
5
6
7
8
9
1
1. Clutch lever
6
5
4
3
2
1 N1
EAU00157Shift pedal
This motorcycle is equipped with a
constant-mesh 6-speed transmission.
The shift pedal is located on the left
side of the engine and is used in
combination with the clutch when
shifting.
1. Shift pedal
N. Neutral
5AE-9-E3 (ENG) 4/11/0 11:06 AM Page 21

3-9
INSTRUMENT AND CONTROL FUNCTIONS
1
2
3
4
5
6
7
8
91
1. Rear brake pedal
EAU00162Rear brake pedal
The rear brake pedal is on the right
side of the motorcycle. Press down
on the brake pedal to apply the rear
brake.
NOTE:
This tank cap cannot be closed
unless the key is in the lock. The key
cannot be removed if the cap is not
locked properly.
EW000023
w
Be sure the cap is properly
installed and locked in place
before riding the motorcycle.
2
1
EAU02935
Fuel tank cap
To open
Open the lock cover. Insert the key
and turn it 1/4 turn clockwise. The
lock will be released and the cap can
be opened.
To close
Push the tank cap into position with
the key inserted. To remove the key,
turn it counterclockwise to the original
position. Then, close the lock cover.
1. Open
2. Unlock
5AE-9-E3 (ENG) 4/11/0 11:06 AM Page 22

3-10
INSTRUMENT AND CONTROL FUNCTIONS
1
2
3
4
5
6
7
8
9
EW000130
w
Do not overfill the fuel tank. Avoid
spilling fuel on the hot engine. Do
not fill the fuel tank above the bot-
tom of the filler tube or it may
overflow when the fuel heats up
later and expands.
EAU00185
cC
Always wipe off spilled fuel imme-
diately with a dry and clean soft
cloth. Fuel may deteriorate painted
surfaces or plastic parts.
3 2
1
1. Filler tube
2. Filling nozzle
3. Fuel level
EAU01183
Fuel
(except for Switzerland and
Austria)
Make sure there is sufficient fuel in
the tank. Fill the fuel tank to the bot-
tom of the filler tube as shown in the
illustration.
EW000130
w
Do not overfill the fuel tank. Avoid
spilling fuel on the hot engine. Do
not fill the fuel tank above the bot-
tom of the filler tube or it may
overflow when the fuel heats up
later and expands.
2
1 3 4
1. Filler tube
2. Filling nozzle
3. Leaf valve
4. Fuel level
EAU01184*
(for Switzerland and Austria)
Make sure there is sufficient fuel in
the tank. When refueling, be sure to
insert the filling nozzle into the filler
hole and fill the tank to the bottom of
the filler tube as shown in the illustra-
tion.
5AE-9-E3 (ENG) 4/11/0 11:06 AM Page 23

3-11
INSTRUMENT AND CONTROL FUNCTIONS
1
2
3
4
5
6
7
8
9
EAU00191
NOTE:
If knocking or pinging occurs, use a
different brand of gasoline or higher
octane grade.
EAU01084
Catalyzer
(for Switzerland and Austria)
This motorcycle is equipped with a
catalytic converter in the exhaust
chamber.
EW000128
w
The exhaust system is hot during
and directly after engine operation.
Make sure the exhaust system has
cooled down before making any
adjustment to or lubricating the
motorcycle.
EC000114
cC
The following must be observed to
prevent a fire hazard or other dam-
ages.
8 8
Use only unleaded gasoline.
Use of leaded gasoline will
cause unrepairable damage to
the catalytic converter.
8 8
Never park this motorcycle in
an area that would cause a fire
hazard such as grass or other
materials that may easily burn.
8 8
Do not allow the engine to idle
for very long.Recommended fuel:
Regular unleaded gasoline
with a research octane
number of 91 or higher.
Fuel tank capacity:
Total:
11.0 L
Reserve:
2.2 L
5AE-9-E3 (ENG) 4/11/0 11:06 AM Page 24

3-12
INSTRUMENT AND CONTROL FUNCTIONS
1
2
3
4
5
6
7
8
9ON1
1. Arrow mark pointing to “ON”
EAU03050
Fuel cock
The fuel cock supplies fuel from the
tank to the carburetor while filtering it
also.
The fuel cock has three positions:
OFF
With the lever in this position, fuel will
not flow. Always return the lever to
this position when the engine is not
running.ON
With the lever in this position, fuel
flows to the carburetor. Normal riding
is done with the lever in this position.
1
OFF
1. Arrow mark pointing to “OFF”
EAU02956
Two-stroke engine oil
Make sure the two-stroke engine oil
is at the specified level. Fill with oil as
necessary.
1
1. Filler cap
Recommended oil:
Yamalube 2 or 2-stroke
engine oil (JASO FC grade or
ISO EG-C, EG-D grade)
Oil quantity:
1.2 L
OFF: closed positionON: normal position
5AE-9-E3 (ENG) 4/11/0 11:06 AM Page 25

1
a
b1
RES
This indicates reserve. If you run out
of fuel while riding, move the lever to
this position. Fill the tank at the first
opportunity. Be sure to set the lever
back to “ON” after refueling!EAU02976
Starter (choke) “1”
Starting a cold engine requires a rich-
er air-fuel mixture. A separate starter
circuit supplies this mixture.
Move in direction ato turn on the
starter (choke).
Move in direction bto turn off the
starter (choke).
EAU01619Seat
To remove
Insert the key into the lock and turn it
clockwise.
1. Starter(choke) “1” 1. Unlock
3-13
INSTRUMENT AND CONTROL FUNCTIONS
1
2
3
4
5
6
7
8
9
1
RES
1. Arrow mark pointing to “RES”
RES: reserve position
5AE-9-E3 (ENG) 4/11/0 11:06 AM Page 26

3-14
INSTRUMENT AND CONTROL FUNCTIONS
1
2
3
4
5
6
7
8
9
EAU00260Helmet holder
To open the helmet holder, insert the
key in the lock and turn it as shown.
To lock the helmet holder, replace
the holder in its original position.
EW000030
w
Never ride with a helmet in the hel-
met holder. The helmet may hit
objects, causing loss of control
and possibly an accident.
EAU00295
Rear shock absorber
adjustment
This shock absorber is equipped with
a spring preload adjusting ring.
Adjust spring preload as follows.
Turn the adjusting ring in direction a
to increase spring preload and in
direction bto decrease spring pre-
load.
Make sure that the appropriate notch
in the adjusting ring is aligned with
the position indicator on the rear
shock absorber. To install
Insert the projection on the front of
the seat into the seat holder. Push
down on the seat and remove the
key.
NOTE:
Make sure that the seat is securely
fitted.
1
2
1. Projection
2. Seat holder
1
1. Open
a
b1
1. Adjusting ring
5AE-9-E3 (ENG) 4/11/0 11:06 AM Page 27

3-15
1
2
3
4
5
6
7
8
9
1
2
1
1. Position indicator1. Y.E.I.S.
2. Y.P.V.S.
EAU00315
w
This shock absorber contains
highly pressurized nitrogen gas.
Read and understand the following
information before handling the
shock absorber. The manufacturer
cannot be held responsible for
property damage or personal
injury that may result from improp-
er handling.
8 8
Do not tamper with or attempt
to open the cylinder assembly.
8 8
Do not subject the shock
absorber to an open flame or
other high heat source. This
may cause the unit to explode
due to excessive gas pres-
sure.
8 8
Do not deform or damage the
cylinder in any way. Cylinder
damage will result in poor
damping performance.
8 8
Take your shock absorber to a
Yamaha dealer for any service.
EAU00325
Note on handling of the
Yamaha Energy Induction
System (Y.E.I.S.)
Handle the air chamber and hose
with special care. Improper installa-
tion or damaged parts will result in
poor performance. Replace any
cracked or damaged parts immedi-
ately. No modification of this system
in any form can be made.
EC000022
cC
Never attempt to modify the
Yamaha Energy Induction System.
INSTRUMENT AND CONTROL FUNCTIONS
1
2
3
4
5
6
7
8
9
HardStan-
Softdard
Adjusting
98 7 6 5 4 321
Position
