Page 14 of 104
Safety information
1-5
1Aftermarket Tires an
d Rims
The tires and rims that came with your
motorcycle were designed to match
the performance capabilities and to
provide the best combination of han-
dling, braking, and comfort. Other
tires, rims, sizes, and combinations
may not be appropriate. Refer to page
6-17 for tire specifications and more in-
formation on replacing your tires.
Transportin g the Motorcycle
Be sure to observe following instruc-
tions before transporting the motorcy-
cle in another vehicle. Remove all loose items from the
motorcycle.
Check that the fuel cock (if
equipped) is in the “OFF” position
and that there are no fuel leaks.
Point the front wheel straight
ahead on the trailer or in the truck
bed, and choke it in a rail to pre-
vent movement.
Shift the transmission in gear (for
models with a manual transmis-
sion).
Secure the motorcycle with tie-
downs or suitable straps that are
attached to solid parts of the mo-
torcycle, such as the frame or up-
per front fork triple clamp (and not,
for example, to rubber-mounted
handlebars or turn signals, or
parts that could break). Choose
the location for the straps carefully
so the straps will not rub against
painted surfaces during transport.
The suspension should be com-
pressed somewhat by the tie-
downs, if possible, so that the mo-
torcycle will not bounce exces-
sively during transport.
UBEHEBE0.book Page 5 Friday, October 22, 2021 10:23 AM
Page 72 of 104
Periodic maintenance an d a djustment
6-19
6 Tires age, even if they have not been
used or have only been used occasion-
ally. Cracking of the tread and sidewall
rubber, sometimes accompanied by
carcass deformation, is an evidence of
ageing. Old and aged tires shall be
checked by tire specialists to ascertain
their suitability for further use.
WARNING
EWA10462
The front an
d rear tires shoul d b e of
the same make an d d esi gn, other-
wise the han dlin g characteristics of
the vehicle may be different, which
coul d lea d to an acci dent.After extensive tests, only the tires list-
ed below have been approved for this
model by Yamaha. The listed optional tire is designed for
more off-road use than the original tire
and the maximum speed rating is dif-
ferent from the original tire.
WARNING
EWAM1060
Never excee
d the tire’s maximum
speed rating. Otherwise the tire may
b e damag ed at hi gh spee d an d
coul d lea d to an acci dent.
Front tire:
Size:
90/90 - 21 M/C 54V M+S
Speed rating:
240 km/h (149 mph)
Manufacturer/model: PIRELLI/SCORPION RALLY STR
A
Rear tire: Size:
150/70 R18 M/C 70V M+S
Speed rating: 240 km/h (149 mph)
Manufacturer/model: PIRELLI/SCORPION RALLY STR
Optional tire
Front tire:Size:90/90 – 21 M/C 54R M+S
Speed rating: 170 km/h (105 mph)
Manufacturer/model:
MICHELIN/ANAKEE WILD
Rear tire: Size:
150/70 R18 M/C 70R M+S
Speed rating: 170 km/h (105 mph)
Manufacturer/model: MICHELIN/ANAKEE WILD
UBEHEBE0.book Page 19 Friday, October 22, 2021 10:23 AM
Page 96 of 104
Specifications
8-1
8
Dimensions:Overall length:2370 mm (93.3 in)
Overall width:
905 mm (35.6 in)
Overall height: 1455 mm (57.3 in)
Seat height: 875 mm (34.4 in)
Wheelbase:
1595 mm (62.8 in)
Ground clearance: 240 mm (9.45 in)
Minimum turning radius: 2.8 m (9.47 ft)Wei ght:Curb weight:
204 kg (450 lb)Engine:Combustion cycle:
4-stroke
Cooling system: Liquid cooled
Valve train: DOHC
Cylinder arrangement:
Inline
Number of cylinders: 2-cylinder
Displacement: 689 cm³
Bore × stroke:
80.0 × 68.6 mm (3.15 × 2.70 in) Starting system:
Electric starter
Engine oil:Recommended brand:
SAE viscosity grades:
10W-40
Recommended engine oil grade: API service SG type or higher, JASO
standard MA
Engine oil quantity:
Without oil filter cartridge replacement: 2.30 L (2.43 US qt, 2.02 Imp.qt)
With oil filter cartridge replacement:
2.60 L (2.75 US qt, 2.29 Imp.qt)Coolant quantity:Coolant reservoir (up to the maximum level
mark):0.25 L (0.26 US qt, 0.22 Imp.qt) Radiator (including all routes):
1.60 L (1.69 US qt, 1.41 Imp.qt)
Fuel:Recommended fuel:
Unleaded gasoline (E10 acceptable)
Octane number (RON): 90
Fuel tank capacity: 16 L (4.2 US gal, 3.5 Imp.gal)
Fuel reserve amount:
4.3 L (1.14 US gal, 0.95 Imp.gal)Fuel injection:Throttle body:ID mark: 1WS1 51Drivetrain:Gear ratio:
1st:2.846 (37/13)
2nd:
2.125 (34/16)
3rd: 1.632 (31/19)
4th: 1.300 (26/20)
5th:
1.091 (24/22)
6th: 0.964 (27/28)Front tire:Type:
With tube
Size: 90/90 - 21 M/C 54V M+S
–20 –10 0 1020 30 40 50 C
10 30 50 70 90 110
0 130 F
SAE 10W-40
UBEHEBE0.book Page 1 Friday, October 22, 2021 10:23 AM
Page 97 of 104
Specifications
8-2
8
Speed rating:240 km/h (149 mph)
Manufacturer/model: PIRELLI/SCORPION RALLY STR ARear tire:Type:With tube
Size: 150/70 R18 M/C 70V M+S
Speed rating:
240 km/h (149 mph)
Manufacturer/model: PIRELLI/SCORPION RALLY STROptional tire:Front tire:
Type:With tube
Size:
90/90 – 21 M/C 54R M+S
Speed rating: 170 km/h (105 mph)
Manufacturer/model: MICHELIN/ANAKEE WILD
Rear tire:
Type: With tube
Size:
150/70 R18 M/C 70R M+S
Speed rating: 170 km/h (105 mph)
Manufacturer/model: MICHELIN/ANAKEE WILD
Loa din g:Maximum load:
190 kg (419 lb)
(Total weight of rider, passenger, cargo and
accessories)Front brake:Type:
Hydraulic dual disc brakeRear brake:Type:
Hydraulic single disc brakeFront suspension:Type:
Telescopic forkRear suspension:Type:Swingarm (link suspension)Electrical system:System voltage:12 VBattery:Model:
YTZ10S
Voltage, capacity: 12 V, 8.6 Ah (10 HR)Bul b watta ge:Headlight:
LED
Brake/tail light: LED
Front turn signal light: 10.0 W × 2
Rear turn signal light:
10.0 W × 2 Auxiliary light:
LED
License plate light: 5.0 W × 1
