YAMAHA TMAX 2003 Owner's Manual

3-4
INSTRUMENT AND CONTROL FUNCTIONS
3
EAU04426
Speedometer unitSpeedometer unit
The speedometer unit is equipped
with a speedometer, an odometer
and a tripmeter. The speedometer
shows riding speed. The odometer
shows the total distance traveled.
The tripmeter shows the distance
traveled since it was last set to zero.
123
1. Speedometer
2. Odometer/tripmeter
3.“Trip” button
EAU02950
Fuel gaugeFuel gauge
The fuel gauge indicates the amount
of fuel in the fuel tank. The needle
moves towards “E” (Empty) as the
fuel level decreases. When the nee-
dle reaches the red line, refuel as
soon as possible.
NOTE:
Do not allow the fuel tank to empty
itself completely.
1
2
1. Fuel gauge
2. Red line
Pushing the “Trip” button switches
the display between the odometer
mode “ODO” and the tripmeter mode
“TRIP”. To reset the tripmeter, enter
the “TRIP” mode, and then hold down
the “Trip” button for at least one sec-
ond. The tripmeter can be used
together with the fuel gauge to esti-
mate the distance that can be trav-
eled with a full tank of fuel. This infor-
mation will enable you to plan future
fuel stops.
5GJ-28199-E2 9/9/02 9:15 AM Page 19

3-5
EAU03124
Coolant temperature gaugeCoolant temperature gauge
This gauge indicates the coolant tem-
perature when the main switch is on.
The engine operating temperature
will vary with changes in weather and
engine load. If the needle points to
the red mark, stop your scooter and
let the engine cool. (See page 6-38
for details.)
EC000002
cC
Do not operate the engine if it is
overheated.
INSTRUMENT AND CONTROL FUNCTIONS
3
21
1. Coolant temperature gauge
2. Red mark
EAU04402
ClockClock
The digital clock shows the time
regardless of the main switch posi-
tion.
To set the clock:
1. Push or hold the hour setting
button “h” to change the hours.
2. Push or hold the minute setting
button “m” to change the min-
utes.
1 23
1. Digital clock
2. Hour setting button “h”
3. Minute setting button “m”
NOTE:
To set the clock after the power
source has been cut, first set the time
to 1:00 AM, and then set the clock to
the correct time.
5GJ-28199-E2 9/9/02 9:15 AM Page 20

3-6
INSTRUMENT AND CONTROL FUNCTIONS
3
EAU03840
Self-diagnosis device
This model is equipped with a self-
diagnosis device for the throttle posi-
tion sensor, the speed sensor, and
the overturn switch. If any of those
circuits are defective, the oil change
indicator light will flash.
If the indicator light flashes, have a
Yamaha dealer check the scooter as
soon as possible.
NOTE:
The oil change indicator light may
flash when the engine is revved with
the scooter on the centerstand, but
this does not indicate a malfunction.
EAU00118
Handlebar switches
Handlebar switches
EAU00120
Pass switch “PASS”Pass switch
Press this switch to flash the head-
light.
EAU03888
Dimmer switch “&/%”Dimmer switch
Set this switch to “&” for the high
beam and to “%” for the low beam.
1
2
3
4
1. Pass switch “PASS”
2. Dimmer switch “&/%”
3. Turn signal switch “4/6”
4. Horn switch “*”
EAU00109
Anti-theft alarm (optional)Anti-theft alarm (optional)
This scooter can be equipped with an
optional anti-theft alarm by a Yamaha
dealer. Contact a Yamaha dealer for
more information.
5GJ-28199-E2 9/9/02 9:15 AM Page 21

3-7
EAU03889
Turn signal switch “4/6”Turn signal switch
To signal a right-hand turn, push this
switch to “6”. To signal a left-hand
turn, push this switch to “4”. When
released, the switch returns to the
center position. To cancel the turn
signal lights, push the switch in after
it has returned to the center position.
EAU00129
Horn switch “*”Horn switch
Press this switch to sound the horn.
INSTRUMENT AND CONTROL FUNCTIONS
3
1
2
3
4
1. Pass switch “PASS”
2. Dimmer switch “&/%”
3. Turn signal switch “4/6”
4. Horn switch “*”
EAU03890
Engine stop switch “#/$”Engine stop switch
Set this switch to “#” before starting
the engine. Set this switch to “$” to
stop the engine in case of an emer-
gency, such as when the scooter
overturns or when the throttle cable is
stuck.
1
2
3
1. Engine stop switch “#/$”
2. Hazard switch “0”
3. Start switch “,”
EAU03826
Hazard switch “0”Hazard switch
With the key in the “ON” or “.” posi-
tion, use this switch to turn on the
hazard light (simultaneous flashing of
all turn signal lights).
The hazard light is used in case of an
emergency or to warn other drivers
when your scooter is stopped where
it might be a traffic hazard.
EC000006
cC
Do not use the hazard light for an
extended length of time, otherwise
the battery may discharge.
EAU03801
Start switch “,”Start switch
With the sidestand up, push this
switch while applying the front or rear
brake to crank the engine with the
starter.
EC000005
cC
See page 5-1 for starting instruc-
tions prior to starting the engine.
5GJ-28199-E2 9/9/02 9:15 AM Page 22

3-8
INSTRUMENT AND CONTROL FUNCTIONS
3
NOTE:
Right and left are defined as seen when standing in front of the scooter.
EAU00136
Headlight variationsHeadlight variations
1
2%
% &
&
Left Right AuxBulb to be used
Destination
2
1
1
31
3
2
1Halogen
bulb
Halogen
bulbGermany, Belgium, Switzerland, Spain
France, Greece, Italy, Netherlands,
Norway, Portugal, Sweden
England 3 : High beam light on 2: Low beam light on
': Auxiliary light on 1: Light off
12V
55W12V
60/55W
12V
60/55W12V
55W '
'
'
'
5GJ-28199-E2 9/9/02 9:15 AM Page 23

3-9
EAU03882
Front brake leverBrake lever, front
The front brake lever is located on
the right handlebar grip. To apply the
front brake, pull this lever toward the
handlebar grip.
INSTRUMENT AND CONTROL FUNCTIONS
3
1
1. Front brake lever
EAU00163
Rear brake leverBrake lever, rear
The rear brake lever is located on the
left handlebar grip. To apply the rear
brake, pull this lever toward the han-
dlebar grip.
1
1. Rear brake lever
EAU03881
Fuel tank capFuel tank cap
To remove the fuel tank cap
1. Open the lid by pulling the lever
up.
2. Insert the key into the lock and
turn it clockwise. The lock will be
released and the fuel tank cap
can be removed.
1
1. Lid
5GJ-28199-E2 9/9/02 9:15 AM Page 24

3-10
INSTRUMENT AND CONTROL FUNCTIONS
3
To install the fuel tank cap
1. Align the match marks, insert the
fuel tank cap into the tank open-
ing, and then push down on the
cap.
2. Turn the key counterclockwise to
the original position, and then
remove it.
3. Close the lid.
EWA00047
w
Make sure that the fuel tank cap is
properly installed and locked in
place before riding the scooter.
1
1. Match marks
EAU00185
cC
Immediately wipe off spilled fuel
with a clean, dry, soft cloth, since
fuel may deteriorate painted sur-
faces or plastic parts.
EAU03753
FuelFuel
Make sure that there is sufficient fuel
in the tank. Fill the fuel tank to the
bottom of the filler tube as shown.
EW000130
w
8 8
Do not overfill the fuel tank,
otherwise it may overflow
when the fuel warms up and
expands.
8 8
Avoid spilling fuel on the hot
engine.
21
1. Fuel tank filler tube
2. Fuel level
5GJ-28199-E2 9/9/02 9:15 AM Page 25

3-11
EAU04284
ECA00104
cC
Use only unleaded gasoline. The
use of leaded gasoline will cause
severe damage to internal engine
parts, such as the valves and pis-
ton rings, as well as to the exhaust
system.
INSTRUMENT AND CONTROL FUNCTIONS
3Your Yamaha engine has been
designed to use regular unleaded
gasoline with a research octane num-
ber of 91 or higher. If knocking (or
pinging) occurs, use a gasoline of a
different brand or premium unleaded
fuel. Use of unleaded fuel will extend
spark plug life and reduce mainte-
nance costs.
EAU03802
Seat
Seat
To open the seat
1. Place the scooter on the center-
stand.
2. Insert the key into the main
switch, and then turn it counter-
clockwise.
NOTE:
Do not push inward when turning the
key.
3. Fold the seat up.
IGNITIONP
LOCK
ON
OFF
OPEN
PUSH
PUSH
a
a. Open.
Recommended fuel:
REGULAR UNLEADED
GASOLINE ONLY
Fuel tank capacity:
Total amount:
14 L
5GJ-28199-E2 9/9/02 9:15 AM Page 26

3-12
INSTRUMENT AND CONTROL FUNCTIONS
3 To close the seat
1. Fold the seat down, and then
push it down to lock it in place.
2. Remove the key from the main
switch if the scooter will be left
unattended.NOTE:
Make sure that the seat is properly
secured before riding.
1. Open the seat. (See page 3-11
for seat opening and closing pro-
cedures.)
2. Remove the backrest bolts.
3. Slide the backrest forward or
backward to the desired position.
4. Install and securely tighten the
backrest bolts.
5. Close the seat.
1
2
1. Rider backrest
2. Bolt (×2)EAU03880
Adjusting the rider backrestRider backrest, adjusting
The rider backrest can be adjusted to
the three different positions shown.
Adjust the backrest as follows.
1
1. Rider backrest
5GJ-28199-E2 9/9/02 9:15 AM Page 27

3-13
EAU01343
Shock absorberEAU00315
w
This shock absorber contains
highly pressurized nitrogen gas.
For proper handling, read and
understand the following informa-
tion before handling the shock
absorber. The manufacturer can-
not be held responsible for proper-
ty damage or personal injury that
may result from improper han-
dling.
8 8
Do not tamper with or attempt
to open the gas cylinder.
8 8
Do not subject the shock
absorber to an open flame or
other high heat sources, other-
wise it may explode due to
excessive gas pressure.
8 8
Do not deform or damage the
gas cylinder in any way, as
this will result in poor damp-
ing performance.
8 8
Always have a Yamaha dealer
service the shock absorber.
INSTRUMENT AND CONTROL FUNCTIONS
3
EAU03879
Helmet holderHelmet holder
The helmet holder is located under
the seat. A helmet holding cable is
provided beside the owner’s tool kit
to secure a helmet to the helmet
holder.
To secure a helmet to the helmet
holder
1. Open the seat. (See page 3-11
for opening procedures.)
2. Pass the helmet holding cable
through the buckle on the helmet
strap as shown, and then hook
the cable loop over the helmet
holder.
1
1. Helmet holder
3. Securely close the seat.EW000030
w
Never ride with a helmet attached
to the helmet holder, since the hel-
met may hit objects, causing loss
of control and possibly an acci-
dent.
To release the helmet from the hel-
met holder
Open the seat, remove the helmet
holding cable from the helmet holder
and the helmet, and then close the
seat.
5GJ-28199-E2 9/9/02 9:15 AM Page 28
