INSTRUMENT AND CONTROL FUNCTIONS
3-3
2
34
5
6
7
8
9
To unlock the steering
Push the key in, and then turn it to
“OFF” while still pushing it.
WARNING

EWA10060
Never turn the key to “OFF” or
“LOCK” while the vehicle is moving,
otherwise the electrical systems will
be switched off, which may result in
loss of control or an accident. Make
sure that the vehicle is stopped be-
fore turning the key to “OFF” or
“LOCK”.
EAU33491
(Parking)
The steering is locked, and the taillights
and auxiliary lights are on. The hazard
light and turn signal lights can be turned
on, but all other electrical systems are
off. The key can be removed.
The steering must be locked before the
key can be turned to “ ”.
CAUTION:

ECA11020
Do not use the parking position for
an extended length of time, other-
wise the battery may discharge.
EAU11002
Indicator and warning lights
EAU11030
Turn signal indicator lights “” and
“”
The corresponding indicator light flash-
es when the turn signal switch is
pushed to the left or right.
EAU11080
High beam indicator light “”
This indicator light comes on when the
1. Turn signal indicator lights “ ” and “ ”
2. High beam indicator light “ ”
3. Immobilizer system indicator light “ ”
4. Engine trouble warning light “ ”
5. Anti-lock Brake System (ABS) warning
light “ ” (for ABS models)
1
2
3
4
5
ABS

INSTRUMENT AND CONTROL FUNCTIONS
3-4
1
2
3
4
5
6
7
8
9
high beam of the headlight is switched
on.

EAU11480
Engine trouble warning light “”
This warning light comes on when an
electrical circuit monitoring the engine
is defective. When this occurs, have a
Yamaha dealer check the self-diagno-
sis system.
The electrical circuit of the warning light
can be checked by turning the key to
“ON”. If the warning light does not come
on for a few seconds, then go off, have
a Yamaha dealer check the electrical
circuit.
EAU11551
ABS warning light “” (for ABS
models)
CAUTION:

ECA10830
If the ABS warning light comes on or
flashes while riding, the ABS may be
defective. If this occurs, have a
Yamaha dealer check the electrical
circuit.
See page 3-12 for an explanation of the
ABS.
The electrical circuit of the warning light
can be checked by setting the engine
stop switch to “” and turning the key
to “ON”. The warning light should come
on for a few seconds, and then go off. If
the warning light does not come on or
remains on, have a Yamaha dealer
check the electrical circuit.
WARNING

EWA11350
When the ABS warning light comes
on or flashes while riding, the brake
system reverts to conventional brak-
ing. Therefore, be careful not to
cause the wheel to lock during emer-
gency braking.
NOTE:

The ABS warning light may come on
while pushing the start switch and while
accelerating the engine with the scoot-
er on its centerstand, but this does not
indicate a malfunction.
EAU26872
Immobilizer system indicator light
“”
The electrical circuit of the indicator
light can be checked by turning the key
to “ON”.
If the indicator light does not come on
for a few seconds, then go off, have a
Yamaha dealer check the electrical cir-
cuit.
When the key is turned to “OFF” and 30
seconds have passed, the indicator
light will start flashing indicating the im-
mobilizer system is enabled. After 24
hours have passed, the indicator light
will stop flashing, however the immobi-
lizer system is still enabled.
NOTE:

This model is also equipped with a
self-diagnosis device for the immobiliz-
er system. If the immobilizer system is
defective, the indicator will start flash-
ing and the multi-function display will in-
dicate an error code when the key is
turned to “ON”. (See “Self-diagnosis
device” on page 3-5 for details.)
ABS

INSTRUMENT AND CONTROL FUNCTIONS
3-17
2
34
5
6
7
8
9

EAU14502
Storage compartments
Front storage compartment
To open the front storage compart-
ment, slide the lever up, and then pull
on the lever.
To close the front storage compart-
ment, push the lid into the original posi-
tion.
WARNING

EWA11160
Do not store heavy items in this
compartment.
Rear storage compartment
A helmet can be stored in the rear stor-
age compartment under the seat. (Seepage 3-15.) To store a helmet in the
rear storage compartment, place the
helmet upside-down with the front fac-
ing forward.
NOTE:


Some helmets cannot be stored in
the rear storage compartment be-
cause of their size or shape.

Do not leave your scooter unat-
tended with the seat open.
CAUTION:

ECA10080
Keep the following points in mind
when using the storage compart-
ment.

Since the storage compartmentaccumulates heat when ex-
posed to the sun, do not store
anything susceptible to heat in-
side it.

To avoid humidity from spread-
ing through the storage com-
partment, wrap wet articles in a
plastic bag before storing them
in the compartment.

Since the storage compartment
may get wet while the scooter is
being washed, wrap any articles
stored in the compartment in a
plastic bag.

Do not keep anything valuable
or breakable in the storage com-
partment.
CAUTION:

ECA11270
Do not leave the seat open for an ex-
tended period of time, otherwise the
light may cause the battery to dis-
charge.
WARNING

EWA11241

Do not exceed the load limit of
1. Storage compartment opening lever
2. Lid
1
2

1. Rear storage compartment
1

INSTRUMENT AND CONTROL FUNCTIONS
3-19
2
34
5
6
7
8
9 this system regularly as described
below and have a Yamaha dealer re-
pair it if it does not function proper-

ly.
EAU15371
Ignition circuit cut-off system
The ignition circuit cut-off system (com-
prising the sidestand switch and brake
light switches) has the following func-
tions.

It prevents starting when the side-
stand is up, but neither brake is ap-
plied.

It prevents starting when either
brake is applied, but the sidestand
is still down.

It cuts the running engine when the
sidestand is moved down.
Periodically check the operation of the
ignition circuit cut-off system according
to the following procedure.
WARNING

EWA10250
If a malfunction is noted, have a
Yamaha dealer check the system be-
fore riding.

5-1
1
2
3
4
5
6
7
8
9

OPERATION AND IMPORTANT RIDING POINTS
EAU15970
WARNING

EWA11250

Become thoroughly familiar
with all operating controls and
their functions before riding.
Consult a Yamaha dealer re-
garding any control or function
that you do not thoroughly un-
derstand.

Never start the engine or oper-
ate it in a closed area for any
length of time. Exhaust fumes
are poisonous, and inhaling
them can cause loss of con-
sciousness and death within a
short time. Always make sure
that there is adequate ventila-
tion.

For safety, always start the en-
gine with the centerstand down.

When the centerstand is down
and the engine is idling, keep
your hands and feet away from
the rear wheel.
EAU36510
Starting the engine
CAUTION:

ECA10250
See page 5-4 for engine break-in in-
structions prior to operating the ve-
hicle for the first time.
In order for the ignition circuit cut-off
system to enable starting, the side-
stand must be up.
WARNING

EWA10290

Before starting the engine,
check the function of the igni-
tion circuit cut-off system ac-
cording to the procedure
described on page 3-19.

Never ride with the sidestand
down.
1. Turn the key to “ON” and make
sure that the engine stop switch is
set to “”.
CAUTION:

ECA15020
The following warning lights, indica-
tor light and indicators should comeon for a few seconds, then go off.

Engine trouble warning light

ABS warning light (for ABS
models)

Immobilizer system indicator
light

V-belt replacement indicator

Oil change indicator
If a warning light, indicator light or
indicator does not go off, see page
3-3 or 3-5 for the corresponding
warning light, indicator light or indi-
cator circuit check.
2. Close the throttle completely.
3. Start the engine by pushing the
start switch while applying the front
or rear brake.
NOTE:

If the engine does not start, release the
start switch, wait a few seconds, and
then try again. Each starting attempt
should be as short as possible to pre-
serve the battery. Do not crank the en-
gine more than 10 seconds on any one
attempt.

PERIODIC MAINTENANCE AND MINOR REPAIR
6-31
2
3
4
5
67
8
9

EAU23760
Replacing the headlight bulb
This model is equipped with a quartz
bulb headlight. If the headlight bulb
burns out, replace it as follows.
1. Disconnect the headlight coupler,
and then remove the bulb cover.
2. Unhook the headlight bulb holder,
and then remove the defective
bulb.
WARNING

EWA10790
Headlight bulbs get very hot. There-
fore, keep flammable products away
from a lit headlight bulb, and do not
touch the bulb until it has cooled
down.
3. Place a new headlight bulb into po-
sition, and then secure it with the
bulb holder.
CAUTION:

ECA10660
Do not touch the glass part of the
headlight bulb to keep it free from
oil, otherwise the transparency ofthe glass, the luminosity of the bulb,
and the bulb life will be adversely af-
fected. Thoroughly clean off any dirt
and fingerprints on the headlight
bulb using a cloth moistened with al-
cohol or thinner.
4. Install the headlight bulb cover,
and then connect the coupler.
5. Have a Yamaha dealer adjust the
headlight beam if necessary.
1. Headlight coupler
2. Headlight bulb cover
1
2

1. Headlight bulb holder
2. Unhook.
1
2

1. Do not touch the glass part of the bulb.
1

SPECIFICATIONS
8-3
2
3
4
5
6
7
89

Tail/brake light:
12 V, 5.0 W/21.0 W
×
2
Front turn signal/position light:
12 V, 21 W/5.0 W
×
2
Rear turn signal light:
12 V, 21.0 W
×
2
Auxiliary light:
12 V, 5.0 W
×
2
Licence plate light:
12 V, 5.0 W
×
1
Meter lighting:
14 V, 2.0 W
×
3
High beam indicator light:
14 V, 1.4 W
×
1
Turn signal indicator light:
14 V, 1.4 W
×
2
Engine trouble warning light:
14 V, 1.4 W
×
1
ABS warning light:
XP500A 14 V, 1.4 W
×
1
Immobilizer system indicator light:
LED

Fuses:
Main fuse:
30.0 A
Headlight fuse:
15.0 A
Signaling system fuse:
XP500 20.0 A
XP500A 15.0 A
Ignition fuse:
10.0 A
Parking lighting fuse:
10.0 A Radiator fan fuse:
15.0 A
Electronic fuel injection fuse:
10.0 A
ABS control unit fuse:
XP500A 5.0 A
ABS motor fuse:
XP500A 30.0 A
Backup fuse:
10.0 A

INDEX
A
ABS (for ABS models) ............................ 3-12
ABS warning light (for ABS models) ......... 3-4
Acceleration and deceleration................... 5-2
Air filter element, cleaning....................... 6-16
Anti-theft alarm (optional).......................... 3-9
B
Battery..................................................... 6-27
Brake fluid, changing .............................. 6-24
Brake fluid level, checking ...................... 6-23
Brake lever, front..................................... 3-11
Brake lever, rear ..................................... 3-11
Brake levers, lubricating.......................... 6-25
Braking ...................................................... 5-3
C
Care .......................................................... 7-1
Catalytic converter .................................. 3-14
Centerstand and sidestand, checking
and lubricating ...................................... 6-25
Chain drive oil ......................................... 6-13
Coolant.................................................... 6-15
Cowlings and panels, removing and
installing.................................................. 6-6
D
Dimmer switch ........................................ 3-10
E
Engine break-in ......................................... 5-4
Engine idling speed................................. 6-17
Engine oil and oil filter cartridge .............. 6-10
Engine stop switch .................................. 3-10
Engine trouble warning light...................... 3-4
F
Front and rear brake lever free play........ 6-21
Front and rear brake pads, checking ...... 6-22Front fork, checking .................................6-26
Fuel ..........................................................3-14
Fuel consumption, tips for reducing ...........5-4
Fuel tank cap ...........................................3-13
Fuses, replacing ......................................6-29
H
Handlebar switches ...................................3-9
Hazard switch ..........................................3-10
Headlight bulb, replacing .........................6-31
Helmet holder ..........................................3-16
High beam indicator light ...........................3-3
Horn switch ..............................................3-10
I
Identification numbers................................9-1
Ignition circuit cut-off system ...................3-19
Immobilizer system ....................................3-1
Immobilizer system indicator light ..............3-4
Indicator and warning lights .......................3-3
K
Key identification number ..........................9-1
M
Main switch/steering lock ...........................3-2
Model label ................................................9-2
Multi-function display .................................3-5
P
Parking.......................................................5-5
Part locations .............................................2-1
Pass switch ..............................................3-10
Periodic maintenance and lubrication
chart ........................................................6-3
Pre-operation check list .............................4-2
R
Rear brake lock lever ...............................3-11
Rear brake lock lever cable, adjusting .....6-21Rider backrest, adjusting ......................... 3-15
S
Safe-riding points ...................................... 1-4
Safety information ..................................... 1-1
Seat ......................................................... 3-15
Shock absorber ....................................... 3-18
Sidestand ................................................ 3-18
Spark plugs, checking ............................... 6-9
Specifications ............................................ 8-1
Speedometer ............................................. 3-5
Starting off ................................................. 5-2
Starting the engine .................................... 5-1
Start switch .............................................. 3-10
Steering, checking ................................... 6-26
Storage ...................................................... 7-3
Storage compartments ............................ 3-17
T
Tachometer ............................................... 3-5
Throttle cable free play, checking............ 6-18
Throttle grip and cable, checking and
lubricating .............................................. 6-24
Tires ........................................................ 6-19
Tool kit ....................................................... 6-1
Troubleshooting....................................... 6-32
Troubleshooting charts ............................ 6-33
Turn signal indicator lights......................... 3-3
Turn signal switch.................................... 3-10
V
Valve clearance ....................................... 6-18
Vehicle identification number .................... 9-1
W
Wheel bearings, checking ....................... 6-27
Wheels .................................................... 6-21
