PERIODIC MAINTENANCE AND MINOR REPAIR
6
EAU04400
Engine oil and oil filter
elementThe engine oil level should be
checked before each ride. In addition,
the oil must be changed and the oil
filter element cleaned at the intervals
specified in the periodic maintenance
and lubrication chart.
To check the engine oil level
1. Place the motorcycle on a level
surface and hold it in an upright
position.NOTE:
Make sure that the motorcycle is
positioned straight up when checking
the oil level. A slight tilt to the side
can result in a false reading.2. Start the engine, warm it up for
several minutes, and then turn it
off.3. Wait a few minutes until the oil
settles, and then check the oil
level through the check window
located at the bottom-right side
of the crankcase.
NOTE:
The engine oil should be between the
minimum and maximum level marks.4. If the engine oil is below the
minimum level mark, add suffi-
cient oil of the recommended
type to raise it to the correct
level.
2
3 1
1. Engine oil level check window
2. Maximum level mark
3. Minimum level mark
To change the engine oil (with or
without oil filter element cleaning)
1. Start the engine, warm it up for
several minutes, and then turn it
off.
2. Place an oil pan under the
engine to collect the used oil.
3. Remove the engine oil filler cap
and drain bolt to drain the oil
from the crankcase.
1
1. Engine oil filler cap
5RS-9-E0 (TW125) 7/30/01 6:03 PM Page 39

6-13
PERIODIC MAINTENANCE AND MINOR REPAIR
6 3. Pull the air filter element out.
4. Remove the sponge material
from the air filter element frame,
clean it with solvent, and then
squeeze the remaining solvent
out.
1
2
1. Sponge material
2. Air filter element frame
5. Apply oil of the recommended
type to the entire surface of the
sponge material, and then
squeeze the excess oil out.NOTE:
The sponge material should be wet
but not dripping.6. Pull the sponge material over the
air filter element frame.
7. Insert the element into the air fil-
ter case.
EC000082
cC8Make sure that the air filter ele-
ment is properly seated in the
air filter case.
8The engine should never be
operated without the air filter
element installed, otherwise
the piston and/or cylinder may
become excessively worn.8. Install the air filter case cover by
installing the screws.
9. Install the panel.
Recommended oil:
Engine oil
5RS-9-E0 (TW125) 7/30/01 6:03 PM Page 43

6-24
PERIODIC MAINTENANCE AND MINOR REPAIR
6
EAU03774
Checking the brake fluid
levelInsufficient brake fluid may allow air
to enter the brake system, possibly
causing it to become ineffective.
Before riding, check that the brake
fluid is above the minimum level mark
and replenish if necessary. A low
brake fluid level may indicate worn
brake pads and/or brake system
leakage. If the brake level is low, be
sure to check the brake pads for
wear and the brake system for leak-
age.
1
1. Minimum level mark
8Brake fluid may deteriorate paint-
ed surfaces or plastic parts.
Always clean up spilled fluid
immediately.
8As the brake pads wear, it is nor-
mal for the brake fluid level to
gradually go down. However, if
the brake fluid level goes down
suddenly, have a Yamaha dealer
check the cause. Observe these precautions:
8When checking the fluid level,
make sure that the top of the
brake fluid reservoir is level.
8Use only the recommended qual-
ity brake fluid, otherwise the rub-
ber seals may deteriorate, caus-
ing leakage and poor braking
performance.
8Refill with the same type of brake
fluid. Mixing fluids may result in a
harmful chemical reaction and
lead to poor braking perfor-
mance.
8Be careful that water does not
enter the brake fluid reservoir
when refilling. Water will signifi-
cantly lower the boiling point of
the fluid and may result in vapor
lock. Recommended brake fluid:
DOT 4
5RS-9-E0 (TW125) 7/30/01 6:03 PM Page 54

8-1
EAU01038
SPECIFICATIONS
8
Specifications
Model TW125
Dimensions
Overall length 2,135 mm
Overall width 820 mm
Overall height 1,120 mm
Seat height 820 mm
Wheelbase 1,350 mm
Ground clearance 255 mm
Minimum turning radius 2,100 mm
Basic weight (with oil and full
fuel tank)127 kg
Engine
Engine type Air-cooled 4-stroke, SOHC
Cylinder arrangement Forward inclined
single cylinder
Displacement 124 cm
3
Bore ×Stroke 57.0 ×48.8 mm
Compression ratio 10:1
Starting system Electric starter
Lubrication system Wet sumpEngine oil
Type
Recommended engine oil
classification API Service SE, SF, SG type
or higher
cCBe sure to use motor oils that do not contain anti-friction
modifiers. Passenger car motor oils (often labeled “ENERGY
CONSERVING II”) contain anti-friction additives which will
cause clutch and/or starter clutch slippage, resulting in
reduced component life and poor engine performance.
Capacity
Without oil filter element
removal 1.0 L
With oil filter element removal 1.1 L
Total amount (dry engine) 1.3 L
–10° 0° 10° 20° 30°
40°
SAE 10W/30
SAE 10W/40
SAE 20W/40
SAE 20W/50
–20°
SAE 15W/40 50°C
5RS-9-E0 (TW125) 7/30/01 6:03 PM Page 79

8-3
SPECIFICATIONS
8
Maximum load* 180 kg
Air pressure (cold tire)
up to 90 kg load*
Front
150 kPa (1.50 kgf/cm
2, 1.50 bar)
Rear
150 kPa (1.50 kgf/cm
2, 1.50 bar)
90 kg load–Maximum
load*
Front
150 kPa (1.50 kgf/cm
2, 1.50 bar)
Rear
175 kPa (1.75 kgf/cm
2, 1.75 bar)
*Total weight of rider, passenger, cargo and accessoriesWheels
Front
Type Spoke wheel
Size 18 ×2.50
Rear
Type Spoke wheel
Size 14M/C ×MT4.50Brakes
Front
Type Single disc brake
Operation Right hand
Fluid DOT 4
Rear
Type Drum brake
Operation Right foot
Suspension
Front
Type Telescopic fork
Rear
Type Swingarm (Monocross
suspension)
Spring/shock absorber
Front Coil spring/oil damper
Rear Coil spring/gas-oil damper
Wheel travel
Front 150 mm
Rear 150 mm
5RS-9-E0 (TW125) 7/30/01 6:03 PM Page 81
