DESCRIPTION
2-3
13. Clutch lever (page 3-4, 6-18)
14. Left handlebar switches (page 3-3)
15. Speedometer (page 3-2)
16. Right handlebar switches (page 3-3)
17. Front brake lever (page 3-5, 6-18)18. Throttle grip (page 6-14, 6-24)
19. Fuel tank cap (page 3-5)
20. Main switch (page 3-1)
13 14 15 16 17
18
19
20
Controls/Instruments
5FY-9-E0 (TW200) 7/29/02 10:54 AM Page 10

3-1
LOCKOFFON
EAU00029
Main switch/Steering lock
The main switch controls the igni-
tion and lighting systems. Its oper-
ation is described below.
EAU00032
ON:
All electrical circuits are switched
on, and the headlight, meter light,
taillight and front position lights
come on. The engine can be start-
ed. The key cannot be removed in
this position.
EAU00038
OFF:
All electrical circuits are switched
off. The key can be removed in this
position.
EAU00042
LOCK:
The steering is locked in this posi-
tion and all electrical circuits are
switched off.
The key can be removed in this
position.
To lock the steering, turn the han-
dlebars all the way to the left. With
the key at “OFF”, push it into the
main switch and release it, turn it
counterclockwise to “LOCK” and
remove it.
To release the lock, turn the key to
“OFF”.
EW000016
w
Never turn the key to “OFF” or
“LOCK” when the motorcycle is
moving. The electrical circuits will
be switched off which may result
in loss of control or an accident. Be
sure the motorcycle is stopped
before turning the key to “OFF” or
“LOCK”.
EAU00027
INSTRUMENT AND CONTROL FUNCTIONS
1
2
3
4
5
6
7
8
9
5FY-9-E0 (TW200) 7/29/02 10:54 AM Page 11

3-2
123
EAU00056Indicator lights
EAU00059Turn indicator light “TURN”
This indicator flashes when the
turn switch is moved to the left or
right.
EAU00062Neutral indicator light “NEUTRAL”
This indicator comes on when the
transmission is in neutral.
1. Turn indicator light “TURN”
2. High beam indicator light
“HIGH BEAM”
3. Neutral indicator light “NEUTRAL”
EAU00064
High beam indicator light “HIGH
BEAM”
This indicator comes on when the
headlight high beam is used.
INSTRUMENT AND CONTROL FUNCTIONS
1
2
3
4
5
6
7
8
9
1
2
EAU00098Speedometer
The speedometer shows riding
speed.
This speedometer is equipped with
an odometer.
1. Speedometer
2. Odometer
5FY-9-E0 (TW200) 7/29/02 10:54 AM Page 12

3-3
INSTRUMENT AND CONTROL FUNCTIONS
1
2
3
4
5
6
7
8
9
1
23
EAU00118Handlebar switches
EAU00122Dimmer switch “LIGHTS”
Turn the switch to “HI” for the high
beam and to “LO” for the low
beam.
EAU00128Turn signal switch “TURN”
This is a three-position switch. The
center position is off.
Turn to “L” to turn on the left
flasher, and to “R” for the right
flasher. Be sure to turn the switch
off after completing a turn.
1. Dimmer switch “LIGHTS”
2. Turn signal switch “TURN”
3. Horn switch “HORN”
EAU00130Horn switch “HORN”
Press the switch to sound the horn.1
2
EAU00137
Engine stop switch “ENGINE
STOP”
The engine stop switch is a safety
device for use in an emergency
such as when the motorcycle over-
turns or if trouble occurs in the
throttle system. Turn the switch to
“RUN” to start the engine. In case
of emergency, turn the switch to
“OFF” to stop the engine.
1. Engine stop switch “ENGINE STOP”
2. Start switch “START”
5FY-9-E0 (TW200) 7/29/02 10:54 AM Page 13

3-4
EAU00141Start switch “START”
The starter motor cranks the
engine when pushing the start
switch.
EC000005
cC
See starting instructions prior to
starting the engine.
INSTRUMENT AND CONTROL FUNCTIONS
1
2
3
4
5
6
7
8
9
EAU00152Clutch lever
The clutch lever is located on the
left handlebar, and the ignition cir-
cuit cut-off system is incorporated
in the clutch lever holder. Pull the
clutch lever to the handlebar to dis-
engage the clutch, and release the
lever to engage the clutch. The
lever should be pulled rapidly and
released slowly for smooth clutch
operation. (Refer to the engine
starting procedures for a descrip-
tion of the ignition circuit cut-off
system.)
1
N5
4
3
2
1
EAU00157
Shift pedal
This motorcycle is equipped with a
constant-mesh 5-speed transmis-
sion.
The shift pedal is located on the
left side of the engine and is used
in combination with the clutch
when shifting.
N. Neutral
1. Shift pedal
5FY-9-E0 (TW200) 7/29/02 10:54 AM Page 14

3-5
INSTRUMENT AND CONTROL FUNCTIONS
1
2
3
4
5
6
7
8
9
1
2
EAU00158Front brake lever
The front brake lever is located on
the right handlebar. Pull it toward
the handlebar to apply the front
brake.
1. Unlock
2. Open
EAU00162Rear brake pedal
The rear brake pedal is on the right
side of the motorcycle. Press down
on the brake pedal to apply the
rear brake.
EAU00177
Fuel tank cap
TO OPEN:
Insert the key and turn it 1/4 turn
counterclockwise. Turn the cap 1/3
turn counterclockwise and remove
it from the tank.
TO CLOSE:
Put the cap in the filler neck and
turn it 1/3 turn clockwise. Lock the
cap by turning the key 1/4 turn
clockwise, and remove the key.
5FY-9-E0 (TW200) 7/29/02 10:54 AM Page 15

1
2
EAU01183Fuel
Make sure there is sufficient fuel in
the tank. Fill the fuel tank to the
bottom of the filler tube as shown
in the illustration.
EW000130
w
Do not overfill the fuel tank. Avoid
spilling fuel on the hot engine. Do
not fill the fuel tank above the bot-
tom of the filler tube or it may
overflow when the fuel heats up
later and expands.
EAU00185
cC
Always wipe off spilled fuel imme-
diately with a dry and clean soft
cloth. Fuel may deteriorate painted
surfaces or plastic parts.
1. Filler tube
2. Fuel level
NOTE:
The tank cap cannot be reinstalled
unless it is unlocked. The key must
remain in the cap until the cap is
properly installed and locked onto
the fuel tank.
EW000023
w
Be sure the cap is properly
installed and locked in place
before riding the motorcycle.
3-6
INSTRUMENT AND CONTROL FUNCTIONS
1
2
3
4
5
6
7
8
9
5FY-9-E0 (TW200) 7/29/02 10:54 AM Page 16

3-7
EAU00187
INSTRUMENT AND CONTROL FUNCTIONS
1
2
3
4
5
6
7
8
9 Recommended fuel:
Regular gasoline
Fuel tank capacity:
Total:
7.0 L
Reserve:
1.7 L
ONFUEL
RES
OFF
1ON
1. Arrow mark
EAU01121Fuel cock
The fuel cock supplies fuel from
the tank to the carburetor while fil-
tering it also.
The fuel cock has three positions,
which should be set as shown in
the illustrations.
OFF: With the fuel cock in this
position, fuel will not flow.
Always set the fuel cock to
this position when the engine
is not running.ON: With the fuel cock in this
position, fuel flows to the car-
buretor. Set the fuel cock to
this position when starting
the engine and while riding.
RES
ONFUEL
OFF
1
1. Arrow mark
OFFON
5FY-9-E0 (TW200) 7/29/02 10:54 AM Page 17

3-8
INSTRUMENT AND CONTROL FUNCTIONS
1
2
3
4
5
6
7
8
9
ab
1
EAU00210Starter(choke) “1”
Starting a cold engine requires a
richer air-fuel mixture. A separate
starter circuit supplies this mixture.
Move in direction ato turn on the
starter(choke).
Move in direction bto turn off the
starter(choke).
1. Starter (choke) “1”
RES: This indicates reserve. If you
run out of fuel while riding,
set the fuel cock to this posi-
tion.
Fill the tank at the first oppor-
tunity. Be sure to set the fuel
cock back to “ON” after refu-
eling!
OFF
ONFUEL RES
1
RES
1. Arrow mark
RES
EAU00212Kick starter
Rotate the kick starter away from
the engine. Push the starter down
lightly with your foot until the
gears engage, then kick smoothly
and forcefully to start the engine.
This model has a primary-coupled
kick starter so the engine can be
started in any gear if the clutch is
disengaged. However, shifting to
neutral before starting is recom-
mended.
1
1. Kick starter
5FY-9-E0 (TW200) 7/29/02 10:54 AM Page 18

3-9
INSTRUMENT AND CONTROL FUNCTIONS
1
2
3
4
5
6
7
8
9
EAU01092Seat
To remove the seat, remove the
bolts.
1
1. Bolt (×2)
To install the seat, insert the pro-
jection on the front of the seat into
the holder and push down on the
seat, then tighten the bolts.
NOTE:
Make sure that the seat is securely
fitted.
1
2
EAU00260Helmet holder
To open the helmet holder, insert
the key in the lock and turn it as
shown. To lock the helmet holder,
replace the holder in its original
position.
EW000030
w
Never ride with a helmet in the
helmet holder. The helmet may hit
objects, causing loss of control
and possibly an accident.
1. Open
2. Helmet holder
