YAMAHA VIKING 2015 Service Manual
Manufacturer: YAMAHA, Model Year: 2015, Model line: VIKING, Model: YAMAHA VIKING 2015Pages: 182, PDF Size: 3.82 MB
Page 41 of 182
4-9
1
2
34
5
6
7
8
9
10
11
12
13
14
To set the clock1. Set the display to the clock mode.
2. Push the “SELECT” button and “RESET”button together for at least three sec-
onds.
3. When the hour digits start flashing, push
the “RESET” button to set the hours.
4. Push the “SELECT” button, and the minute digits will start flashing.
5. Push the “RESET” button to set the min- utes.
6. Push the “SELECT” button, and then re-
lease it to start the clock. Voltage display mode
This display shows the battery voltage.
“ ” appears for 1 second when the volt-
age display mode is first selected, and then
“ ” appears and the battery voltage is dis-
played.
If the battery voltage is less than 10 volts, “LO”
is displayed, and if the voltage is above 16
volts, “HI” is displayed.
1XP7C_EE.book Page 9 Monday, June 9, 2014 5:17 PM
Page 42 of 182
4-10
4
5
6
7
8
9
10
11
12
13
14
NOTICEIf the voltage display indicates “LO” or
“HI”, there may be trouble with the battery
charging circuit or the battery may be
faulty. If this occurs, have a Yamaha dealer
check or repair the vehicle.
Fuel meter1. Fuel level warning indicator
2. Fuel meter 3. “E” segmentThe fuel meter indicates the amount of fuel in
the fuel tank. The display segments of the fuel
meter disappear from “F” (full) towards “E”
(empty) as the fuel level decreases. When the
“E” segment disappears and the fuel level
warning indicator flashes, refuel as soon as
possible.
1
23
1XP7C_EE.book Page 10 Monday, June 9, 2014 5:17 PM
Page 43 of 182
4-11
1
2
34
5
6
7
8
9
10
11
12
13
14
TIPThis fuel meter is equipped with a self-diagno-
sis system. If a problem is detected in an elec-
trical circuit, all the display segments and fuel
level warning indicator start flashing. If this oc-
curs, have a Yamaha dealer check the electri-
cal circuit.
Self-diagnosis device1. Error code display
2. Engine trouble warning light “ ”This model is equipped with a self-diagnosis
device for various electrical circuits.
If a problem is detected in any of those cir-
cuits, the engine trouble warning light comes
on or flashes, and the multi-function display
indicates an error code.
If the multi-function display indicates an error
code, note the code number, and then have a
Yamaha dealer check the vehicle.
2
1
1XP7C_EE.book Page 11 Monday, June 9, 2014 5:17 PM
Page 44 of 182
4-12
4
5
6
7
8
9
10
11
12
13
14
NOTICEIf the multi-function display indicates an
error code, the vehicle should be checked
as soon as possible in order to avoid en-
gine damage.
EVU00240Light switch “ / / ”1. Light switch “ / / ”Set the switch to “ ” to turn on the low beam
and the taillights.
Set the switch to “ ” to turn on the high
beam and the taillights.
Set the switch to “ ” to turn off the head-
lights and taillights.
L
H
1
L
HL
H
1XP7C_EE.book Page 12 Monday, June 9, 2014 5:17 PM
Page 45 of 182
4-13
1
2
34
5
6
7
8
9
10
11
12
13
14
NOTICEDo not use the headlights with the engine
turned off for an extended period of time.
The battery may discharge to the point
that the starter motor will not operate
properly. If this should happen, remove
the battery and recharge it.
EVU01183On-Command drive knob “2WD/4WD/
DIFF LOCK”1. On-Command drive knob “2WD/4WD/DIFF LOCK”This vehicle is equipped with an On-Com-
mand drive knob to select the drive mode.
The knob has three positions: “2WD”, “4WD”,
and “DIFF LOCK”. Select the appropriate
drive according to terrain and conditions.●
“2WD” (two-wheel drive): Power is supplied
to the rear wheels only.1
1XP7C_EE.book Page 13 Monday, June 9, 2014 5:17 PM
Page 46 of 182
4-14
4
5
6
7
8
9
10
11
12
13
14
●
“4WD” (four-wheel drive): Power is sup-
plied to the rear and front wheels.
●
“DIFF LOCK” (four-wheel drive with the dif-
ferential gear locked): Power is supplied to
the rear and front wheels with the differen-
tial gear locked. Unlike the “4WD” mode, all
wheels turn at the same speed regardless
of traction.
Horn switch “ ”Press the switch to sound the horn.1. Horn switch “ ”
1
1XP7C_EE.book Page 14 Monday, June 9, 2014 5:17 PM
Page 47 of 182
4-15
1
2
34
5
6
7
8
9
10
11
12
13
14
EVU00260Accelerator pedalPress the accelerator pedal down to increase
engine speed. Spring tension returns the ped-
al to the rest position when released. Always
check that the accelerator pedal returns nor-
mally before starting the engine.1. Accelerator pedal
EVU00270Brake pedalPress the brake pedal to slow or stop the ve-
hicle.1. Brake pedal
1
1
1XP7C_EE.book Page 15 Monday, June 9, 2014 5:17 PM
Page 48 of 182
4-16
4
5
6
7
8
9
10
11
12
13
14
EVU00280Parking brake leverThe parking brake lever is located at the right
side of the steering wheel. Setting the parking
brake lever will help keep the vehicle from
moving while parked.
To set the parking brake, pull the lever rear-
ward completely.
To release the parking brake, pull rearward on
the lever, press the release button, and then
push the lever all the way forward.
Spring tension helps return the lever to the re-
leased position.1. Parking brake lever 2. Release button
EVU00290Drive select leverThe drive select lever is used to shift the vehi-
cle into the low, high, neutral, and reverse po-
sitions. (Refer to page 6-4 for the drive select
lever operation.)1. Drive select lever
12
1
1XP7C_EE.book Page 16 Monday, June 9, 2014 5:17 PM
Page 49 of 182
4-17
1
2
34
5
6
7
8
9
10
11
12
13
14
EVU00300Fuel tank cap1. Fuel tank capTo openRemove the fuel tank cap by turning it coun-
terclockwise.
To closeInstall the fuel tank cap by turning it clockwise.
DoorsTo open a door, pull the latch outward. To
close a door, push or pull the door inward until
it is securely latched. Be sure the door is SE-
CURELY LATCHED AFTER CLOSING IT.1. Latch2. Door
1
1
2
1XP7C_EE.book Page 17 Monday, June 9, 2014 5:17 PM
Page 50 of 182
4-18
4
5
6
7
8
9
10
11
12
13
14
EVU00330SeatsTo remove a seat cushion, lift the front of the
cushion, and then pull the cushion off.1. Driver seat cushion
2. Passenger seat cushion ( × 2)
To install a seat cushion, insert the projections
on the rear of the seat cushion under the seat
frame, and then insert the projection on the
front of the cushion into the grommet while
pushing the cushion downward. Make sure
the seats are properly secured before riding.
WARNING! A loose seat could cause the operator to lose control, or cause the oper-
ator or passengers to fall.
1
2
1XP7C_EE.book Page 18 Monday, June 9, 2014 5:17 PM
