TIPBe sure to wipe off spilled oil on any parts af-
ter the engine and exhaust system have
cooled down. NOTICEECB00301In order to prevent clutch slippage (since
the engine oil also lubricates the clutch),
do not mix any chemical additives. Do
not use oils with a diesel specification of
“CD” or oils of a higher quality than
specified. In addition, do not use oils la-
beled “ENERGY CONSERVING II” or
higher.
 Make sure that no foreign material en-
ters the crankcase. 14. Start the engine, and then let it idle for
several minutes while checking it for oil
leakage. If oil is leaking, immediately turn
the engine off and check for the cause.
1. Engine oil dipstick
2. Arrow markRecommended engine oil:See page 10-1.
Oil quantity: Without oil filter cartridge replacement:2.20 L (2.33 US qt, 1.94 Imp.qt)
With oil filter cartridge replacement: 2.30 L (2.43 US qt, 2.02 Imp.qt)
1
2
U2MB7AE0.book Page 19 Thursday, January 29, 2015 3:42 PM

8-20
8
15. Turn the engine off, wait at least 10 min-utes, and then check the oil level and cor-
rect it if necessary.
16. Install the rubber cover.
17. Install the passenger seat cushion.EBU32370Final gear oilChecking the final gear oil level 1. Park the vehicle on a level surface.
2. Remove the final gear oil filler bolt and its gasket, and then check the oil level in the
final gear case. The oil level should be at
the brim of the filler hole. 3. If the oil is below the brim of the filler hole,
add sufficient oil of the recommended
type to raise it to the correct level.
NOTICE: Be sure no foreign material
enters the final gear case.
[ECB00422]
4. Check the gasket for damage, and re- place it if necessary.
5. Install the oil filler bolt and its gasket, and then tighten the bolt to the specified
torque.1. Final gear oil
2. Gasket
3. Final gear oil filler bolt
4. Correct oil level
24
3
1
U2MB7AE0.book Page 20 Thursday, January 29, 2015 3:42 PM

8-21
8
Changing the final gear oil1. Park the vehicle on a level surface.
2. Place an oil pan under the final gear case
to collect the used oil.
3. Remove the final gear oil filler bolt, the fi-
nal gear oil drain bolt and their gasket to
drain the oil. 4. Install the drain bolt and its new gasket,
and then tighten the bolt to the specified
torque.
5. Refill with the recommended final gear oil up to the brim of the filler hole. NOTICE:
Be sure no foreign material enters the
final gear case.
[ECB00422]
6. Check the oil filler bolt gasket for dam- age, and replace it if necessary.
7. Install the oil filler bolt and its gasket, and then tighten the bolt to the specified
torque.
Tightening torque:Final gear oil filler bolt:23 Nm (2.3 m·kgf, 17 ft·lbf)1. Final gear oil drain bolt
2. Gasket
21
Tightening torque: Final gear oil drain bolt:22 Nm (2.2 m·kgf, 16 ft·lbf)
Recommended oil: SAE 80 API GL-4 Hypoid gear oil
Oil quantity: 0.40 L (0.42 US qt, 0.35 Imp.qt)
U2MB7AE0.book Page 21 Thursday, January 29, 2015 3:42 PM

8-22
8
8. Check for oil leakage. If oil leakage isfound, check for the cause.EBU32380Differential gear oilChecking the differential gear oil level1. Park the vehicle on a level surface.
2. Remove the differential gear oil filler bolt
and its gasket, and then check the oil lev-
el. It should be up to the brim of the filler
hole. 3. If the level is low, add sufficient oil of the
recommended type to raise it to the
specified level. NOTICE: Be sure no for-
eign material enters the differential
gear case.
[ECB00412]
4. Check the gasket for damage, and re- place it if necessary.
5. Install the differential gear oil filler bolt and its gasket, and then tighten the bolt
to the specified torque.
Tightening torque:Final gear oil filler bolt:23 Nm (2.3 m·kgf, 17 ft·lbf)
1. Differential gear oil filler bolt
2. Gasket
3. Differential gear oil
4. Correct oil level
1
2
3
4
U2MB7AE0.book Page 22 Thursday, January 29, 2015 3:42 PM

8-23
8
Changing the differential gear oil1. Park the vehicle on a level surface.
2. Place an oil pan under the differential
gear case to collect the used oil.
3. Remove the differential gear oil filler bolt,
the differential gear oil drain bolt and their
gasket to drain the oil. 4. Install the differential gear oil drain bolt
and its new gasket, and then tighten the
bolt to the specified torque.
5. Refill the differential gear case with the recommended oil. NOTICE: Be sure no
foreign material enters the differential
gear case.
[ECB00412]
6. Check the oil filler bolt gasket for dam- age, and replace it if necessary.
7. Install the differential gear oil filler bolt and its gasket, and then tighten the bolt
to the specified torque.
Tightening torque:Differential gear oil filler bolt:23 Nm (2.3 m·kgf, 17 ft·lbf)1. Differential gear oil drain bolt
2. Gasket
12
Tightening torque: Differential gear oil drain bolt:9.8 Nm (0.98 m·kgf, 7.1 ft·lbf)
Recommended oil: SAE 80 API GL-4 Hypoid gear oil
Oil quantity: 0.18 L (0.19 US qt, 0.16 Imp.qt)
U2MB7AE0.book Page 23 Thursday, January 29, 2015 3:42 PM

8-24
8
8. Check for oil leakage. If oil leakage isfound, check for the cause.EBU33660CoolantThe coolant level should be checked before
each ride. In addition, the coolant must be
changed at the intervals specified in the peri-
odic maintenance and lubrication chart.
Checking the coolant level1. Park the vehicle on a level surface.
2. Check the coolant level in the coolant reservoir when the engine is cold as the
coolant level varies with engine tempera-
ture.TIPThe coolant should be between the minimum
and maximum level marks.
3. If the coolant is at or below the minimum
level mark, remove the coolant reservoir
cap, add coolant to the maximum level
mark, and install the reservoir cap.
Tightening torque:Differential gear oil filler bolt:23 Nm (2.3 m·kgf, 17 ft·lbf)
1. Coolant reservoir cap
2. Maximum level mark
3. Minimum level markCoolant reservoir capacity (up to the maxi-
mum level mark):0.28 L (0.30 US qt, 0.25 Imp.qt)
123
U2MB7AE0.book Page 24 Thursday, January 29, 2015 3:42 PM

8-25
8
Changing the coolant
WARNING
EWB01891Wait for the engine and radiator to cool be-
fore removing the radiator cap. You could
be burned by hot fluid and steam blown
out under pressure. Always place a thick
rag over the cap when opening. Allow any
remaining pressure to escape before com-
pletely removing the cap. 1. Park the vehicle on a level surface.
2. Remove the hood. (See page 8-10 forhood removal and installation proce-
dures.)
3. Place a container under the engine to col- lect the used coolant.
4. Remove the radiator cap. 5. Remove the coolant drain bolt and its
gasket to drain the coolant from the en-
gine and radiator.
1. Radiator cap
1
U2MB7AE0.book Page 25 Thursday, January 29, 2015 3:42 PM

8-26
8
6. Place a container under the coolant res-ervoir to collect the used coolant.
7. Remove the coolant reservoir cap. 8. Disconnect the coolant reservoir hose,
and then drain the coolant from the cool-
ant reservoir.
9. After draining the coolant, thoroughly flush the cooling system with clean tap
water.
10. Install the coolant drain bolt and its new gasket and then tighten the bolt to the
specified torque.1. Coolant drain bolt
2. Gasket
1 2
1. Coolant reservoir cap
2. Coolant reservoir hose
12
U2MB7AE0.book Page 26 Thursday, January 29, 2015 3:42 PM

8-27
8
11. Connect the coolant reservoir hose.
12. Pour the recommended coolant into theradiator until it is full.
13. Pour the recommended coolant into the
reservoir to the maximum level mark, and
then install the reservoir cap.NOTICEECB02190Mix antifreeze with distilled water only.
However, if distilled water is not available,
soft water may be used for refilling. Do not
use hard water or salt water since they are
harmful to the engine.
14. Remove the right panel and right rearpanel. (See page 8-11 for right panel and
right rear panel removal and installation
procedures.)
15. Loosen the water pump air bleed bolt, without removing it, to allow all of the air
to escape from the air bleed bolt hole.
Tightening torque:Coolant drain bolt:8 Nm (0.8 m·kgf, 5.8 ft·lbf)
Antifreeze/water mixture ratio: 1:1
Recommended antifreeze: High-quality ethylene glycol antifreeze con-
taining corrosion inhibitors for aluminum
engines
Coolant quantity: Radiator (including all routes):2.85 L (3.01 US qt, 2.51 Imp.qt)
Coolant reservoir (up to the maximum level
mark): 0.28 L (0.30 US qt, 0.25 Imp.qt)
U2MB7AE0.book Page 27 Thursday, January 29, 2015 3:42 PM

8-28
8
16. When coolant begins to flow out of thebolt hole, tighten the water pump air
bleed bolt to the specified torque.
17. Loosen the cylinder head air bleed bolt, without removing it, to allow all of the air
to escape from the air bleed bolt hole. 18. When coolant begins to flow out of the
bolt hole, tighten the cylinder head air
bleed bolt to the specified torque.
19. Start the engine and let it idle for ten min- utes.
20. Rev the engine five times.
21. Pour additional coolant into the radiator until it is full.1. Water pump air bleed boltTightening torque:Water pump air bleed bolt:8 Nm (0.8 m·kgf, 5.8 ft·lbf)
1
1. Cylinder head air bleed boltTightening torque:Cylinder head air bleed bolt:10 Nm (1.0 m·kgf, 7.2 ft·lbf)
1
