WR450F
\bDX-28\b99-E3
OWNER’S MANUAL

Q Read this manual carefully before o\ferating this vehicle. This manual should stay with this vehicle if it is sold.
EAU46091

INTRODUCTION
EAU10103
Welcome to the Yamaha world of motorcycling!
As the owner of the WR450F, you are benefiting from Yamaha’s vast experience and newest technology regarding the de-
sign and manufacture of high-quality products, which have earned Yamaha a reputation for dependability.
Please take the time to read this manual thoroughly, so as to enjoy all advantages of your WR450F. The Owner’s Manual
does not only instruct you in how to operate, inspect and maintain your motorcycle, but also in how to safeguard yourself and
others from trouble and injury.
In addition, the many tips given in this manual will help keep your motorcycle in the best possible condition. If you have any
further questions, do not hesitate to contact your Yamaha dealer.
The Yamaha team wishes you many safe and pleasant rides. So, remember to put safety first!
Yamaha continually seeks advancements in pr oduct design and quality. Therefore, while this manual contains the most cur-
rent product information available at the time of printing, there may be minor discrepancies between your motorcycle and this
manual. If there is any question concerning this manual, please consult a Yamaha dealer.
WARNING
EWA10032
Please read this manual carefully and completely before operating this motorcycle.
1DX-9-E3.book 1 ページ ２０１４年２月１７日　月曜日　午後２時２１分

IMPORTANT MANUAL INFORMATION
EAU10134
Particularly important information is distinguished in this manual by the following notations:
*Product and specifications are subject to change without notice.
This is the safety alert symbol. It is used to alert you to potential personal injury
hazards. Obey all safety messages that follow this symbol to avoid possible injury
or death.
A WARNING indicates a hazardous situation wh
ich, if not avoided, could result in
death or serious injury.
A NOTICE indicates special precautions that must be taken to avoid damage to the
vehicle or other property.
A TIP provides key information to make procedures easier or clearer.
WARNING
NOTICETIP
1DX-9-E3.book 1 ページ ２０１４年２月１７日　月曜日　午後２時２１分

IMPORTANT MANUAL INFORMATION
EAU10201
WR450F
OWNER’S MANUAL
©2014 by Yamaha Motor Co., Ltd. 1st edition, February 2014All rights reserved.
Any reprinting or unauthorized use without the written permission of Yamaha Motor Co., Ltd.
is expressly prohibited. Printed in Japan.
1DX-9-E3.book 2 ページ ２０１４年２月１７日　月曜日　午後２時２１分

TABLE OF CONTENTSSAFETY INFORMATION................... 1-1
DESCRIPTION ................................... 2-1
Left view .......................................... 2-1
Right view ........................................ 2-2
Controls and instrument s................. 2-3
INSTRUMENT AND CONTROL
FUNCTIONS ....................................... 3-1
Main switch ...................................... 3-1
Indicator lights and warning lights ... 3-1
Multi-function display ....................... 3-2
Handlebar switches ......................... 3-7
Clutch lever...................................... 3-8
Shift pedal....... ............................. .... 3-8
Brake lever ...................................... 3-8
Brake pedal ..................................... 3-9
Fuel tank cap ................................... 3-9
Fuel................................................ 3-10
Fuel tank breather hose................. 3-11
Catalytic converter ......................... 3-11
Starter knob ................................... 3-12
Kickstarter....... ............................. .. 3-12
Steering lock .................................. 3-13
Seat ............................................... 3-13
Adjusting the front fork................... 3-14
Front fork bleeding......................... 3-15
Adjusting the shock absorber assembly .................................... 3-16
Sidestand....................................... 3-18
Ignition circuit cut-of f system ......... 3-19 FOR YOUR SAFETY –
PRE-OPERATION CHECKS
............. 4-1
OPERATION AND IMPORTANT
RIDING POINTS ................................. 5-1
Starting a cold engine ..................... 5-1
Starting a warm engine . .................. 5-3
Shifting ............................................ 5-3
Tips for reducing fuel consumption ................................ 5-4
Engine break-in ............................... 5-4
Parking ............................................ 5-5
PERIODIC MAINTENANCE AND
ADJUSTMENT ................................... 6-1
Owner’s tool kit................................ 6-2
Periodic maintenance chart for
the emission contro l system ........ 6-3
General maintenance and lubrication chart ........................... 6-4
Removing and installing the panel ............................................ 6-7
Checking the spark plug.................. 6-7
Engine oil and oil filter element ....... 6-8
Coolant .......................................... 6-13
Cleaning the air filter element and check hose.......................... 6-14
Adjusting the engine idling
speed ......................................... 6-17
Checking the throttle grip free play ............................................ 6-18 Valve clearance ............................. 6-18
Tires ............................................... 6-18
Spoke wheels ................................ 6-20
Adjusting the clutch lever free
play ............................................. 6-21
Checking the brake lever free play ............................................. 6-22
Checking the shift pedal ................ 6-23
Brake light switches ....................... 6-23
Checking the front and rear brake pads.................................. 6-23
Checking the brake fluid level ........ 6-24
Changing the brake fluid ................ 6-25
Drive chain slack............................ 6-25
Cleaning and lubricating the drive chain .................................. 6-27
Checking and lubricating the
cables ......................................... 6-27
Checking and lubricating the throttle grip and cable ................. 6-28
Checking and lubricating the brake and clutch levers .............. 6-28
Checking and lubricating the
brake pedal................................. 6-29
Checking and lubricating the
sidestand .................................... 6-29
Lubricating the swingarm pivots .... 6-29
Checking the front fork................... 6-30
Checking the steering .................... 6-30
Checking the wheel bearings......... 6-31
Battery ........................................... 6-311DX-9-E3.book 1 ページ ２０１４年２月１７日　月曜日　午後２時２１分

TABLE OF CONTENTS
Replacing the fuse......................... 6-32
Replacing the headlight bulb ......... 6-33
Tail/brake light ............................... 6-34
Replacing a turn signal light bulb ............................................ 6-35
Replacing the license plate light bulb ............................................ 6-35
Replacing the auxiliary light
bulb ........................................... 6-36
Supporting the motor cycle ............. 6-37
Front wheel.................................... 6-37
Rear wheel .................................... 6-39
Troubleshooting............................. 6-40
Troubleshooting charts .................. 6-42
MOTORCYCLE CARE AND
STORAGE .......................................... 7-1
Matte color caution .......................... 7-1
Care................................................. 7-1
Storage ............................................ 7-3
SPECIFICATIONS .............................. 8-1
CONSUMER INFORMATION ............. 9-1
Identification numbers ..................... 9-1
INDEX ............................................... 10-1
1DX-9-E3.book 2 ページ ２０１４年２月１７日　月曜日　午後２時２１分

1-1
1
2
3
4
5
6
7
8
9
10
11
12
SAFETY INFORMATION
EAU53005
Be a Responsible Owner
As the vehicle’s owner, you are respon-
sible for the safe and proper operation
of your motorcycle.
Motorcycles are single-track vehicles.
Their safe use and operation are de-
pendent upon the use of proper riding
techniques as well as the expertise of
the operator. Every operator should
know the following requirements before
riding this motorcycle.
He or she should:
Obtain thorough instructions from
a competent source on all aspects
of motorcycle operation.

Observe the warnings and mainte-
nance requirements in this Own-
er’s Manual.

Obtain qualified training in safe
and proper riding techniques.

Obtain professional technical ser-
vice as indicated in this Owner’s
Manual and/or when made neces-
sary by mechanical conditions.

Never operate a motorcycle with-
out proper training or instruction. Take a training course. Beginners
should receive training from a cer-
tified instructor. Contact an autho-
rized motorcycle dealer to find out
about the training courses nearest
you.
Safe Riding
Perform the pre-operation checks each
time you use the vehicle to make sure it
is in safe operating condition. Failure to
inspect or maintain the vehicle properly
increases the possibility of an accident
or equipment damage. See page 4-1
for a list of pre-operation checks.

This motorcycle is designed to car-
ry the operator only.

No passengers.

This motorcycle is intended to use
as a competition model including
enduro usage.

This motorcycle is not designed
nor intended for continuous
“Paved Road” use. Never use this
motorcycle on highway (motor-
way)/expressway.

If any of the components that are
necessary for the vehicle to com-
ply with regulations are modified or replaced with non-specified com-
ponents, the vehicle will no longer
meet the regulations.

Watch carefully for other vehicles
when operating on unpaved public
streets or roads. Make sure you
know your country’s laws and reg-
ulations before you ride on un-
paved public streets or roads.

The failure of motorists to detect
and recognize motorcycles in traf-
fic is the predominating cause of
automobile/motorcycle accidents.
Many accidents have been caused
by an automobile driver who did
not see the motorcycle. Making
yourself conspicuous appears to
be very effective in reducing the
chance of this type of accident.
Therefore:
Wear a brightly colored jacket.
Use extra caution when you are
approaching and passing
through intersections, since in-
tersections are the most likely
places for motorcycle accidents
to occur.
Ride where other motorists can see you. Avoid riding in another
1DX-9-E3.book 1 ページ ２０１４年２月１７日　月曜日　午後２時２１分

SAFETY INFORMATION
1-2
12
3
4
5
6
7
8
9
10
11
12
motorist’s blind spot.
Never maintain a motorcycle without proper knowledge. Con-
tact an authorized motorcycle
dealer to inform you on basic
motorcycle maintenance. Cer-
tain maintenance can only be
carried out by certified staff.

Many accidents involve inexperi-
enced operators.
Make sure that you are qualifiedand that you only lend your mo-
torcycle to other qualified opera-
tors.
Know your skills and limits. Staying within your limits may
help you to avoid an accident.
We recommend that you prac- tice riding your motorcycle until
you have become thoroughly fa-
miliar with the motorcycle and all
of its controls.

Many accidents have been caused
by error of the motorcycle opera-
tor. A typical error made by the op-
erator is veering wide on a turn
due to excessive speed or under-
cornering (insufficient lean angle
for the speed). Always obey the speed limit and
never travel faster than warrant-
ed by road and traffic conditions.
Always signal before turning or changing lanes. Make sure that
other motorists can see you.

Ride cautiously in unfamiliar ar-
eas. You may encounter hidden
obstacles that could cause an ac-
cident.

The posture of the operator is im-
portant for proper control. The op-
erator should keep both hands on
the handlebar and both feet on the
operator footrests during operation
to maintain control of the motorcy-
cle.

Never ride under the influence of
alcohol or other drugs.
Protective Apparel
The majority of fatalities from motorcy-
cle accidents are the result of head in-
juries. The use of a safety helmet is the
single most critical factor in the preven-
tion or reduction of head injuries.

Always wear an approved helmet.

Wear a face shield or goggles.
Wind in your unprotected eyes could contribute to an impairment
of vision that could delay seeing a
hazard.

The use of a jacket, heavy boots,
trousers, gloves, etc., is effective in
preventing or reducing abrasions
or lacerations.

Never wear loose-fitting clothes,
otherwise they could catch on the
control levers, footrests, or wheels
and cause injury or an accident.

Always wear protective clothing
that covers your legs, ankles, and
feet. The engine or exhaust sys-
tem become very hot during or af-
ter operation and can cause burns.
Avoid Carbon Monoxide Poisoning
All engine exhaust contains carbon
monoxide, a deadly gas. Breathing car-
bon monoxide can cause headaches,
dizziness, drowsiness, nausea, confu-
sion, and eventually death.
Carbon Monoxide is a colorless, odor-
less, tasteless gas which may be pres-
ent even if you do not see or smell any
engine exhaust. Deadly levels of car-
bon monoxide can collect rapidly and
you can quickly be overcome and un-
1DX-9-E3.book 2 ページ ２０１４年２月１７日　月曜日　午後２時２１分

SAFETY INFORMATION
1-3
1
2
3
4
5
6
7
8
9
10
11
12 able to save yourself. Also, deadly lev-
els of carbon monoxide can linger for
hours or days in enclosed or poorly
ventilated areas. If you experience any
symptoms of carbon monoxide poison-
ing, leave the area immediately, get
fresh air, and SEEK MEDICAL TREAT-
MENT.

Do not run engine indoors. Even if
you try to ventilate engine exhaust
with fans or open windows and
doors, carbon monoxide can rap-
idly reach dangerous levels.

Do not run engine in poorly venti-
lated or partially enclosed areas
such as barns, garages, or car-
ports.

Do not run engine outdoors where
engine exhaust can be drawn into
a building through openings such
as windows and doors.
Loading
Adding accessories or cargo to your
motorcycle can adversely affect stabili-
ty and handling if the weight distribution
of the motorcycle is changed. To avoid
the possibility of an accident, use ex-
treme caution when adding cargo or accessories to your motorcycle. Use
extra care when riding a motorcycle
that has added cargo or accessories.
Here, along with the information about
accessories below, are some general
guidelines to follow if loading cargo to
your motorcycle:
The total weight of the operator, acces-
sories and cargo must not exceed the
maximum load limit.
Operation of an
overloaded vehicle could cause an
accident.
When loading within this weight limit,
keep the following in mind:

Shifting weights can create a sud-
den imbalance. Make sure that ac-
cessories are securely attached to
the motorcycle before riding.
Check accessory mounts fre-
quently.
Properly adjust the suspension for your load (suspension-ad-
justable models only), and
check the condition and pres-
sure of your tires. Never attach any large or heavy
items to the handlebar, front
fork, or front fender. These
items, including such cargo as
sleeping bags, duffel bags, or
tents, can create unstable han-
dling or a slow steering re-
sponse.

This vehicle is not designed to
pull a trailer or to be attached to
a sidecar.
Genuine Yamaha Accessories
Choosing accessories for your vehicle
is an important decision. Genuine
Yamaha accessories, which are avail-
able only from a Yamaha dealer, have
been designed, tested, and approved
by Yamaha for use on your vehicle.
Many companies with no connection to
Yamaha manufacture parts and acces-
sories or offer other modifications for
Yamaha vehicles. Yamaha is not in a
position to test the products that these
aftermarket companies produce.
Therefore, Yamaha can neither en-
dorse nor recommend the use of ac-
cessories not sold by Yamaha or
modifications not specifically recom-
Maximum load: 90 kg (198 lb)
1DX-9-E3.book 3 ページ ２０１４年２月１７日　月曜日　午後２時２１分
