PERIODIC MAINTENANCE AND ADJUSTMENT
6-31
1
2
3
4
56
7
8
9
10
11
12
EAU23292
Checking the wheel bearingsThe front and rear wheel bearings must
be checked at the intervals specified in
the periodic maintenance and lubrica-
tion chart. If there is play in the wheel
hub or if the wheel does not turn
smoothly, have a Yamaha dealer check
the wheel bearings.
EAU52492
BatteryThe battery is located under the seat.
(See page 3-13.)
This model is equipped with a VRLA
(Valve Regulated Lead Acid) battery.
There is no need to check the electro-
lyte or to add distilled water. However,
the battery lead connections need to be
checked and, if necessary, tightened.
WARNING
EWA10761

Electrolyte is poisonous and
dangerous since it contains sul-
furic acid, which causes severe
burns. Avoid any contact with skin, eyes or clothing and al-
ways shield your eyes when
working near batteries. In case
of contact, administer the fol-
lowing FIRST AID.
EXTERNAL: Flush with plenty
of water.
INTERNAL: Drink large quan- tities of water or milk and im-
mediately call a physician.
EYES: Flush with water for 15 minutes and seek prompt
medical attention.

Batteries produce explosive hy-
drogen gas. Therefore, keep
sparks, flames, cigarettes, etc.,
away from the battery and pro-
vide sufficient ventilation when
charging it in an enclosed
space.

KEEP THIS AND ALL BATTER-
IES OUT OF THE REACH OFCHILDREN.
To charge the battery
Have a Yamaha dealer charge the bat-
tery as soon as possible if it seems to
have discharged. Keep in mind that the
1. Negative battery lead (black)
2. Positive battery lead (red)
3. Battery
1
2
3
1DX-9-E3.book 31 ページ ２０１４年２月１７日　月曜日　午後２時２１分

SPECIFICATIONS
8-2
1
2
3
4
5
6
78
9
10
11
12
2nd: 1.733 (26/15)
3rd:
1.313 (21/16)
4th: 1.050 (21/20)
5th: 0.840 (21/25)
Chassis:Frame type: Semi double cradle
Caster angle: 27.00 
Trail:
115 mm (4.5 in)Front tire:Type:With tube
Size:
80/100-21M/C 51P
Manufacturer/model: BRIDGESTONE/GRITTY-ED03 ERear tire:Type:
With tube
Size: 120/90-18M/C 65P
Manufacturer/model: BRIDGESTONE/GRITTY-ED04 E
Maximum load:
90 kg (198 lb)
* (Total weight of rider, cargo and accesso- ries)
Tire air pressure (measured on cold
tires):Loading condition:0–90 kg (0–198 lb)
Front:
150 kPa (1.50 kgf/cm
2, 22 psi)
Rear:
200 kPa (2.00 kgf/cm2, 29 psi)
Front wheel:Wheel type:Spoke wheel
Rim size:
21x1.60Rear wheel:Wheel type:Spoke wheel
Rim size:
18x2.15Front brake:Type:Single disc brake
Operation:
Right hand operation
Specified brake fluid: DOT 4Rear brake:Type:
Single disc brake
Operation: Right foot operation
Specified brake fluid: DOT 4
Front suspension:Type:Telescopic fork
Spring/shock absorber type: Coil spring/oil damper
Wheel travel: 300 mm (11.8 in)Rear suspension:Type:Swingarm (link suspension)
Spring/shock absorber type: Coil spring/gas-oil damper
Wheel travel:
299 mm (11.8 in)Electrical system:Ignition system:TCI
Charging system:
AC magnetoBattery:Model:YTZ7S(F)
Voltage, capacity:
12 V, 6.0 AhHeadlight:Bulb type:Halogen bulbBulb voltage, wattage  quantity:Headlight:
12 V, 35.0 W/35.0 W  1
Tail/brake light: LED
Front turn signal light:
12 V, 10.0 W  2
