YAMAHA WR 450F 2016 Owners Manual

ELECTRICAL COMPONENTS
9-81
▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲
EAS2GC1405CHECKING THE FUEL INJECTOR
1. Remove:• Fuel injector
Refer to “THROTTLE BODY” on page 8-7.
2. Check: • Fuel injector resistance
Out of specification  Replace.
▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼
a. Disconnect the fuel injector coupler from the
fuel injector.
b. Connect the pocket tester (  10) to the
fuel injector coupler.
c. Measure the fuel injector resistance.
▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲
Resistance 12 
Pocket tester 90890-03112
Analog pocket tester YU-03112-C
• Positive tester probe 
Injector terminal “1”
• Negative tester probe 
Injector terminal “2”
12
12

ELECTRICAL COMPONENTS
9-82

10
TROUBLESHOOTING
TROUBLESHOOTING.................................................................................... 10-1
GENERAL INFORMATION ...................................................................... 10-1
STARTING FAILURES ............................................................................. 10-1
INCORRECT ENGINE IDLING SPEED ................................................... 10-1
POOR MEDIUM-AND-HIGH-SPEED PERFORMANCE .......................... 10-2
SHIFTING IS DIFFICULT ......................................................................... 10-2
SHIFT PEDAL DOES NOT MOVE ........................................................... 10-2
JUMPS OUT OF GEAR............................................................................ 10-2
CLUTCH SLIPS ........................................................................................ 10-2
CLUTCH DRAGS ..................................................................................... 10-2
OVERHEATING ....................................................................................... 10-2
OVERCOOLING ....................................................................................... 10-3
POOR BRAKING PERFORMANCE ......................................................... 10-3
FRONT FORK OIL LEAKING ................................................................... 10-3
FAULTY FRONT FORK LEGS ................................................................. 10-3
UNSTABLE HANDLING ........................................................................... 10-3
HEADLIGHT DOES NOT COME ON ....................................................... 10-4
HEADLIGHT BULB BURNT OUT............................................................. 10-4
TAILLIGHT DOES NOT COME ON ......................................................... 10-4
LIST OF SELF-DIAGNOSTIC AND FAIL-SAFE ACTIONS ........................... 10-5

TROUBLESHOOTING
10-1
EAS2GC1406
TROUBLESHOOTING
EAS2GC1407GENERAL INFORMATION
TIP
The following guide for troubleshooting does
not cover all the possible causes of trouble. It
should be helpful, however, as a guide to basic
troubleshooting. Refer to the relative procedure
in this manual for checks, adjustments, and re-
placement of parts.
EAS2GC1408STARTING FAILURES
Engine
1. Cylinder and cylinder head• Loose spark plug
• Loose cylinder head or cylinder
• Damaged cylinder head gasket
• Damaged cylinder gasket
• Worn or damaged cylinder
• Incorrect valve clearance
• Improperly sealed valve
• Incorrect valve-to-valve-seat contact
• Incorrect valve timing
• Faulty valve spring
• Seized valve
2. Piston and piston ring(s) • Improperly installed piston ring
• Damaged, worn or fatigued piston ring
• Seized piston ring
• Seized or damaged piston
3. Air filter • Improperly installed air filter
• Clogged air filter element
4. Crankcase and crankshaft • Improperly assembled crankcase
• Seized crankshaft
Fuel system
1. Fuel tank • Empty fuel tank
• Clogged fuel tank breather hose
• Deteriorated or contaminated fuel
• Clogged or damaged fuel hose
2. Fuel pump
• Faulty fuel pump
3. Throttle body • Deteriorated or contaminated fuel
• Sucked-in air Electrical system
1. Battery
• Discharged battery
• Faulty battery
2. Fuse • Blown, damaged or incorrect fuse
• Improperly installed fuse
3. Spark plug • Incorrect spark plug gap
• Incorrect spark plug heat range
• Fouled spark plug
• Worn or damaged electrode
• Worn or damaged insulator
4. Ignition coil • Cracked or broken ignition coil body
• Broken or shorted primary or secondary coils
5. Ignition system • Faulty ECU
• Faulty crankshaft position sensor
• Broken generator rotor woodruff key
6. Switches and wiring
• Faulty ECU
• Faulty engine stop switch
• Broken or shorted wiring
• Faulty neutral switch
• Improperly grounded circuit
• Loose connections
7. Starting system • Faulty starter motor
• Faulty starter relay
• Faulty starting circuit cut-off relay
• Faulty starter clutch
EAS2GC1409INCORRECT ENGINE IDLING SPEED
Engine
1. Cylinder and cylinder head• Incorrect valve clearance
• Damaged valve train components
2. Air filter • Clogged air filter element
Fuel system
1. Throttle body • Damaged or loose throttle body joint
• Improperly synchronized throttle bodies
• Improper throttle cable free play
• Flooded throttle body

TROUBLESHOOTING
10-2
Electrical system
1. Battery• Discharged battery
• Faulty battery
2. Spark plug • Incorrect spark plug gap
• Incorrect spark plug heat range
• Fouled spark plug
• Worn or damaged electrode
• Worn or damaged insulator
• Faulty spark plug cap
3. Ignition coil
• Broken or shorted primary or secondary coil
• Cracked or broken ignition coil
4. Ignition system • Faulty ECU
• Faulty crankshaft position sensor
• Broken generator rotor woodruff key
EAS2GC1410POOR MEDIUM-AND-HIGH-SPEED PER-
FORMANCE
Refer to “STARTING FAILURES” on page 10-
1.
Engine
1. Air filter
• Clogged air filter element
Fuel system
1. Fuel pump • Faulty fuel pump
2. Throttle body
• Defective throttle body
3. ECU • Faulty ECU
EAS2GC1411SHIFTING IS DIFFICULT
Refer to “CLUTCH” on page 6-41.
EAS2GC1412SHIFT PEDAL DOES NOT MOVE
Engine
1. Shift shaft
• Bent shift shaft
2. Shift drum and shift forks • Foreign object in a shift drum groove
• Seized shift fork
• Bent shift fork guide bar
3. Transmission
• Seized transmission gear
• Foreign object between transmission gears
• Improperly assembled transmission
EAS2GC1413
JUMPS OUT OF GEAR
Engine
1. Shift shaft• Incorrect shift pedal position
• Improperly returned stopper lever
2. Shift forks
• Worn shift fork
3. Shift drum • Incorrect axial play
• Worn shift drum groove
4. Transmission • Worn gear dog
EAS2GC1414CLUTCH SLIPS
Engine
1. Clutch• Improperly assembled clutch
• Loose or fatigued clutch spring
• Worn friction plate
• Worn clutch plate
2. Engine oil
• Incorrect oil level
• Incorrect oil viscosity (low)
• Deteriorated oil
EAS2GC1415CLUTCH DRAGS
Engine
1. Clutch• Unevenly tensioned clutch springs
• Warped pressure plate
• Bent clutch plate
• Swollen friction plate
• Bent clutch push rod
• Damaged clutch boss
• Burnt primary driven gear bushing
2. Engine oil • Incorrect oil level
• Incorrect oil viscosity (high)
• Deteriorated oil
EAS2GC1416OVERHEATING
Engine
1. Cylinder head and piston• Heavy carbon buildup
• Clogged coolant passages
2. Engine oil
• Incorrect oil level
• Incorrect oil viscosity
• Inferior oil quality

TROUBLESHOOTING
10-3
Cooling system
1. Coolant• Low coolant level
2. Radiator • Damaged or leaking radiator
• Faulty radiator cap
• Bent or damaged radiator fin
3. Water pump • Damaged or faulty water pump
• Damaged hose
• Improperly connected hose
• Damaged pipe
• Improperly connected pipe
Fuel system
1. Throttle body • Damaged or loose throttle body joint
2. Air filter • Clogged air filter element
Chassis
1. Brake(s) • Dragging brake
Electrical system
1. Spark plug • Incorrect spark plug gap
• Incorrect spark plug heat range
2. Ignition system • Faulty ECU
• Faulty coolant temperature sensor
EAS2GC1417OVERCOOLING
Cooling system
1. Coolant temperature sensor• Faulty coolant temperature sensor
EAS2GC1418POOR BRAKING PERFORMANCE
Chassis
1. Brake(s)• Worn brake pad
• Worn brake disc
• Air in hydraulic brake system
• Leaking brake fluid
• Defective master cylinder kit
• Faulty brake caliper kit
• Faulty brake caliper seal
• Loose union bolt
• Damaged brake hose
• Oil or grease on the brake disc
• Oil or grease on the brake pad
• Incorrect brake fluid level
EAS2GC1419FRONT FORK OIL LEAKING
Chassis
1. Front fork• Bent, damaged, or rusty inner tube
• Cracked or damaged outer tube
• Improperly installed oil seal
• Damaged oil seal lip
• Incorrect oil level (high)
• Loose damper rod assembly bolt
• Damaged damper rod assembly bolt copper
washer
• Cracked or damaged cap bolt O-ring
EAS2GC1420FAULTY FRONT FORK LEGS
Chassis
1. Front fork • Bent or damaged inner tube
• Bent or damaged outer tube
• Broken fork spring
• Bent or damaged damper rod
• Incorrect oil viscosity
• Incorrect oil level
EAS2GC1421UNSTABLE HANDLING
Chassis
1. Handlebar• Bent or improperly installed handlebar
2. Steering head components • Improperly installed upper bracket
• Improperly installed lower bracket(improperly tightened ring nut)
• Bent steering stem
• Damaged ball bearing or bearing race
3. Front fork leg (s) • Uneven oil levels (both front fork legs)
• Unevenly tensioned fork spring (both front fork legs)
• Broken fork spring
• Bent or damaged inner tube
• Bent or damaged outer tube
4. Swingarm • Worn bearing or bushing
• Bent or damaged swingarm
5. Rear shock absorber assembly (-ies) • Faulty rear shock absorber spring
• Leaking oil or gas
6. Tire (s) • Uneven tire pressures (front and rear)
• Incorrect tire pressure
• Uneven tire wear

TROUBLESHOOTING
10-4
7. Wheel (s)• Incorrect wheel balance
• Broken or loose spoke
• Damaged wheel bearing
• Bent or loose wheel axle
• Excessive wheel runout
8. Frame • Bent frame
• Damaged steering head pipe
• Improperly installed bearing race
EAS2GC1422HEADLIGHT DOES NOT COME ON
Electrical system
1. Headlight• Fuse open circuit
• Wrong headlight bulb
• Too many electrical accessories
• Hard charging
• Incorrect connection
• Improperly grounded circuit
• Poor contacts (start switch)
• Burnt-out headlight bulb
EAS2GC1423HEADLIGHT BULB BURNT OUT
Electrical system
1. Headlight
• Wrong headlight bulb
• Faulty battery
• Faulty rectifier/regulator
• Improperly grounded circuit
• Faulty start switch
• Headlight bulb life expired
EAS2GC1424TAILLIGHT DOES NOT COME ON
Electrical system
1. Taillight• Wrong taillight LED
• Too many electrical accessories
• Incorrect connection
• Faulty battery

LIST OF SELF-DIAGNOSTIC AND FAIL-SAFE ACTIONS
10-5
EAS2GC1425
LIST OF SELF-DIAGNOSTIC AND FAIL-SAFE ACTIONS
LIST OF DIAGNOSTIC CODES
COMMUNICATION ERROR WITH YAMAHA DIAGNOSTIC TOOLFault
code Item Page
12 Crankshaft position sensor: no normal signals are received from the crankshaft position sensor. 9-35
13 Intake air pressure sensor: open or short circuit detected. 9-37
14 Intake air pressure sensor: hose system malfunction (clogged or de- tached hose) 9-38
15 Throttle position sensor: open or short circuit detected. 9-39
16 Throttle position sensor: stuck throttle position sensor is detected. 9-41
21 Coolant temperature sensor: open or short circuit detected. 9-42
22 Intake air temperature sensor: open or short circuit detected. 9-43
30 Latch up detected. 9-44
33 Ignition coil: open or short circuit detected in the primary lead of the ignition coil. 9-45
39 Injector: open or short circuit detected. 9-47
41 Lean angle sensor: open or short circuit detected. 9-48
43 Fuel system voltage: incorrect voltage supplied to the fuel injector and fuel pump. 9-49
44 EEPROM fault code number: an error is detected while reading or writing on EEPROM. 9-50
46 Charging voltage is abnormal. 9-51
50 Faulty ECU memory. (When this malfunction is detected in the ECU, the fault code number might not appear on the meter.) 9-52
Fault code Item Page
Waiting
for con-
nection No communication signal is received from the ECU.
9-52
Er-2 Signals from the ECU cannot be re ceived within the specified period
of time. 9-53
Er-3 Data from the ECU cannot be received correctly. 9-54
Er-4 Registered data cannot be received from the Yamaha diagnostic tool. 9-55

LIST OF SELF-DIAGNOSTIC AND FAIL-SAFE ACTIONS
10-6
SENSOR OPERATION TABLEDiag-
nostic code No. Item Display Procedure
01 Throttle position sensor sig- nal
• Fully closed position
• Fully opened position • 11–14
• 109–116 • Check with throttle valve
fully closed.
• Check with throttle valve fully open.
03 Intake air pressure Displays the intake air pres- sure.Operate the throttle while
pushing the start switch. (If
the display value changes,
the performance is OK.)
05 Intake air temperature Displays the intake air tem- perature.Compare the actually mea-
sured intake air tempera-
ture with the Yamaha
diagnostic tool display val-
ue.
06 Coolant temperature When engine is cold: Dis- plays temperature closer to
air temperature.
When engine is hot: Displays
current coolant temperature.Compare the actually mea-
sured coolant temperature
with the Yamaha diagnostic
tool display value.
07 Vehicle speed pulses Vehicle speed pulse 0–999Check that the number in-
creases when the front
wheel is rotated. The num-
ber is cumulative and does
not reset each time the
wheel is stopped.
08 Lean angle sensor • Upright
• Overturned Displays the output voltage.
• 0.4–1.4
• 3.7–4.4 Remove the lean angle
sensor, and incline it more
than 45 degrees.
09 Monitor voltage Displays the fuel system volt- age.
• Approximately 12.0 (V)—
21 Neutral switch • Gear in neutral
• Gear not in neutral •ON
•OFF Operate the shift pedal.
60 EEPROM fault code display • No fault
• CO adjustment value
• Setting tool adjustment values 0–8 for fuel injec-
tion amount or ignition tim-
ing •00
•01
•07
—
61 Malfunction history ( ) code No. display *1
• There is no history.
• There is some history. •00
• Other: Displays the fault
code of ( ). —

LIST OF SELF-DIAGNOSTIC AND FAIL-SAFE ACTIONS
10-7
*1: Symbols used in the explanations of the malfunction history: Normal
: There is currently a malfunction or abnormal condition. : A malfunction or abnormal condition occurred prev iously, but the affected system or component
is currently operating normally. 62 Malfunction history ( )
code No. erasure *1
• There is no history.
• There is some history. •00
• Other: Displays the total
number of ( ) and ( ). Replace all ( ) with ( )
by the operation start pro-
cessing.
64 Setting history display • There is no history.
• There is some history.
• History is unknown (Histo-ry data is damaged). Displays the presence or ab-
sence of the setting history by
Power Tuner.
•00
•01
•02
—
65 Setting map erasure • There is no setting.
• There is some setting. Displays the presence or ab-
sence of the setting history by
Power Tuner.
•00
•01 Erase all setting maps by
the operation start process-
ing.
70 Program version number Displays a program version No.—
Diag-
nostic code No. Item Display Procedure
