belt YAMAHA XMAX 400 2016 Owners Manual

TABLE OF CONTENTSSAFETY INFORMATION.................. 1-1
Further safe-riding points ............... 1-5
DESCRIPTION.................................. 2-1
Left view ......................................... 2-1
Right view ....................................... 2-2
Controls and instruments ............... 2-3
INSTRUMENT AND CONTROL
FUNCTIONS...................................... 3-1
Immobilizer system......................... 3-1
Main switch/steering lock............... 3-2
Indicator lights and warning
lights............................................ 3-3
Speedometer .................................. 3-5
Tachometer .................................... 3-6
Multi-function display ..................... 3-6
Anti-theft alarm (optional) ............. 3-10
Handlebar switches ...................... 3-10
Front brake lever .......................... 3-11
Rear brake lever ........................... 3-12
ABS (for ABS models) .................. 3-12
Fuel tank cap ................................ 3-13
Fuel ............................................... 3-14
Catalytic converters...................... 3-15
Seat .............................................. 3-16
Storage compartments................. 3-16
Adjusting the shock absorber
assemblies ................................ 3-18
Sidestand ..................................... 3-18
Ignition circuit cut-off system ....... 3-19FOR YOUR SAFETY –
PRE-OPERATION CHECKS............. 4-1
OPERATION AND IMPORTANT
RIDING POINTS................................ 5-1
Starting the engine .......................... 5-1
Starting off ...................................... 5-2
Acceleration and deceleration ........ 5-3
Braking ............................................ 5-3
Tips for reducing fuel
consumption ................................ 5-4
Engine break-in ............................... 5-4
Parking ............................................ 5-5
PERIODIC MAINTENANCE AND
ADJUSTMENT................................... 6-1
Owner’s tool kit ............................... 6-2
Periodic maintenance chart for the
emission control system .............. 6-3
General maintenance and
lubrication chart ........................... 6-4
Removing and installing panels ...... 6-8
Checking the spark plug ............... 6-11
Engine oil and oil filter element ..... 6-13
Final transmission oil..................... 6-15
Coolant.......................................... 6-16
Air filter elements and check
hoses and V-belt case air filter
element ...................................... 6-18
Checking the throttle grip free
play ............................................ 6-20Valve clearance............................. 6-20
Tires .............................................. 6-21
Cast wheels .................................. 6-22
Checking the front and rear brake
lever free play ............................ 6-23
Checking the front and rear brake
pads .......................................... 6-24
Checking the brake fluid level ...... 6-24
Changing the brake fluid .............. 6-26
Checking and lubricating the
cables ........................................ 6-26
Checking and lubricating the
throttle grip and cable ............... 6-26
Lubricating the front and rear
brake levers ............................... 6-27
Checking and lubricating the
centerstand and sidestand........ 6-27
Checking the front fork ................. 6-28
Checking the steering................... 6-29
Checking the wheel bearings ....... 6-29
Battery .......................................... 6-29
Replacing the fuses ...................... 6-31
Replacing a headlight bulb ........... 6-32
Tail/brake light .............................. 6-33
Front turn signal light .................... 6-33
Replacing a rear turn signal light
bulb ........................................... 6-33
Replacing the license plate light
bulb ........................................... 6-34
Auxiliary light ................................ 6-35
Troubleshooting............................ 6-35U1SDE1E0.book Page 1 Monday, September 23, 2013 3:55 PM

DESCRIPTION
2-1
2
EAU10411
Left view
1
5
8
2
4
3
7 6
9
10
11
12
1. Headlight (page 6-32)
2. Battery (page 6-29)
3. Main fuse (page 6-31)
4. Coolant reservoir cap (page 6-16)
5. Coolant level check window (page 6-16)
6. Rear storage compartment (page 3-16)
7. V-belt case air filter element (page 6-18)
8. Shock absorber assembly spring preload adjusting ring (page 3-18)9. Air filter element (left) (page 6-18)
10.Engine oil filter element (page 6-13)
11.Sidestand (page 3-18)
12.Front brake pads (page 6-24)U1SDE1E0.book Page 1 Monday, September 23, 2013 3:55 PM

INSTRUMENT AND CONTROL FUNCTIONS
3-7
3 an oil change indicator
a V-belt replacement indicator
TIPBe sure to turn the key to “ON” be-
fore using the “SELECT” and “RE-
SET” buttons.
When the key is turned to “ON”, all
of the display segments of the
multi-function display will appear
one after the other and then disap-
pear, in order to test the electrical
circuit.
For the UK, the distance traveled
is displayed in miles and the tem-
perature reading is displayed in
°C.
For other countries, the distance
traveled is displayed in kilometers
and the temperature reading is
displayed in °C.Odometer and tripmeter modes
Pushing the “SELECT” button switch-
es the display between the odometer
mode “Odo” and the tripmeter modes
“Trip” in the following order:
Odo → Trip 1 → Trip 2 → OdoWhen approximately 2.0 L (0.53 US
gal, 0.44 Imp.gal) of fuel remains in the
fuel tank, the bottom segment of the
fuel meter will start flashing, and the
display will automatically change to the
fuel reserve tripmeter mode “Trip F”
and start counting the distance trav-
eled from that point. In that case, push-
ing the “SELECT” button switches the
display between the various tripmeter
and odometer modes in the following
order:
Trip F → Trip 1 → Trip 2 → Odo → Trip
F
To reset a tripmeter, select it by push-
ing the “SELECT” button until “Trip” or
“Trip F” , push the “RESET” button for
at least one second. If you do not resetthe fuel reserve tripmeter manually, it
will reset itself automatically and the
display will return to the prior mode af-
ter refueling and traveling 5 km (3 mi).
TIPThe display cannot be changed back

button.Fuel meter
With the key in the “ON” position, the
fuel meter indicates the amount of fuel
in the fuel tank. The display segments
of the fuel meter disappear towards
“E” (Empty) as the fuel level decreases.
When the fuel level reaches the bottom
segment near “E”, the bottom segment
will flash. Refuel as soon as possible.
Coolant temperature meter
With the key in the “ON” position, the
coolant temperature meter indicates
the temperature of the coolant. The
coolant temperature varies with
changes in the weather and engine
load. If the top segment and coolant
temperature “C” “H” indicator flash,
stop the vehicle and let the engine
1. Fuel reserve tripmeterZAUM1010
1/21/2CLOCKOUT TEMP
°C
TRIP1
1
U1SDE1E0.book Page 7 Monday, September 23, 2013 3:55 PM

INSTRUMENT AND CONTROL FUNCTIONS
3-8
3cool. (See page 6-37.)
NOTICE
ECA10022
Do not continue to operate the en-
gine if it is overheating.Oil change indicator “OIL CHANGE”
This indicator flashes at the initial 1000
km (600 mi), then at 5000 km (3000 mi)
and every 5000 km (3000 mi) thereafter
to indicate that the engine oil should be
changed.
After changing the engine oil, reset the
oil change indicator. (See page 6-13.)
If the engine oil is changed before the
oil change indicator comes on (i.e. be-
fore the periodic oil change interval has
been reached), the indicator must bereset after the oil change for the next
periodic oil change to be indicated at
the correct time. (See page 6-13.)
The electrical circuit of the indicator
can be checked by turning the key to
“ON”
The indicator comes on for a few sec-
onds and then goes off.
If the indicator does not come on, have
a Yamaha dealer check the electrical
circuit.
TIPThe oil change indicator may flash
when the engine is revved with the
scooter on the centerstand, but this
does not indicate a malfunction.V-belt replacement indicator “V-
BELT”
This indicator flashes every 20000 km
(12500 mi) when the V-belt needs to be
replaced.
The electrical circuit of the indicator
can be checked by turning the key to
“ON”
If the indicator does not come on, have
a Yamaha dealer check the electrical
circuit.Self-diagnosis device
This model is equipped with a self-di-
agnosis device for various electrical
circuits.
If a problem is detected in any of those
circuits, the multi-function display will
indicate an error code.
If the multi-function display indicates
an error code, note the code number,
and then have a Yamaha dealer check
the vehicle.
NOTICE
ECA11791
If the multi-function display indi-
cates an error code, the vehicle
should be checked as soon as pos-
sible in order to avoid engine dam-
age.The self-diagnosis device also detects
problems in the immobilizer system
circuits.
If a problem is detected in the immobi-
lizer system circuits, the immobilizer
system indicator light will flash and the
multi-function display will indicate an
error code when the key is turned to
“ON”.
ZAUM1011
1/21/2CLOCKOUT TEMP
°C
TRIP1
U1SDE1E0.book Page 8 Monday, September 23, 2013 3:55 PM

OPERATION AND IMPORTANT RIDING POINTS
5-1
5
EAU15952
Read the Owner’s Manual carefully to
become familiar with all controls. If
there is a control or function you do not
understand, ask your Yamaha dealer.
WARNING
EWA10272
Failure to familiarize yourself with
the controls can lead to loss of con-
trol, which could cause an accident
or injury.
EAU48021
TIPThis model is equipped with a lean an-
gle sensor to stop the engine in case of
a turnover. In this case, the multi-func-
tion display indicates error code 30,
but this is not a malfunction. Turn the

the error code. Failing to do so will pre-
vent the engine from starting even
though the engine will crank when
pushing the start switch.
EAUS1893
Starting the engineNOTICE
ECA10251
See page 5-4 for engine break-in in-
structions prior to operating the ve-
hicle for the first time.In order for the ignition circuit cut-off
system to enable starting, the side-
stand must be up.
See page 3-19 for more information.
1. Turn the key to “ON”.
The following warning light, indi-
cator light and indicators should
come on for a few seconds, then
go off.
Engine trouble warning light
ABS warning light (for ABS
models)
Immobilizer system indicator
light
V-belt replacement indicator
Oil change indicator
U1SDE1E0.book Page 1 Monday, September 23, 2013 3:55 PM

PERIODIC MAINTENANCE AND ADJUSTMENT
6-4
6
EAU1770H
General maintenance and lubrication chartNO. ITEM CHECK OR MAINTENANCE JOBODOMETER READING
ANNUAL
CHECK 1000 km
(600 mi)10000 km
(6000 mi)20000 km
(12000 mi)30000 km
(18000 mi)40000 km
(24000 mi)
1 Air filter elements•Replace.√√
2 Air filter check hose• Clean.√√√√√
3V-belt case air filter
element• Clean.√√√√√
4*Front brake• Check operation, fluid level and
vehicle for fluid leakage.√√√√√√
• Replace brake pads. Whenever worn to the limit
5*Rear brake• Check operation, fluid level and
vehicle for fluid leakage.√√√√√√
• Replace brake pads. Whenever worn to the limit
6*Brake hoses• Check for cracks or damage.
• Check for correct routing and
clamping.√√√√√
• Replace. Every 4 years
7*Brake fluid• Replace. Every 2 years
8*Wheels• Check runout and for damage.√√√√
9*Tires• Check tread depth and for dam-
age.
• Replace if necessary.
• Check air pressure.
• Correct if necessary.√√√√√
10*Wheel bearings• Check bearing for looseness or
damage.√√√√
U1SDE1E0.book Page 4 Monday, September 23, 2013 3:55 PM

PERIODIC MAINTENANCE AND ADJUSTMENT
6-6
6
EAU34492
TIPEngine air filters and V-belt air filter
• This model’s engine air filters are equipped with disposable oil-coated paper elements, which must not be cleaned
with compressed air to avoid damaging them.
• The engine air filter elements need to be replaced and the V-belt air filter element needs to be serviced more fre-
quently when riding in unusually wet or dusty areas.21*Cooling system• Check coolant level and vehicle
for coolant leakage.√√√√√
• Change coolant. Every 3 years
22Final transmission
oil• Check vehicle for oil leakage.√√ √
• Change.√√√√√√
23*V-belt• Replace. When the V-belt replacement indicator flashes [every 20000 km (12500 mi)]
24*Front and rear
brake switches• Check operation.√√√√√√
25Moving parts and
cables• Lubricate.√√√√√
26*Throttle grip• Check operation.
• Check throttle grip free play, and
adjust if necessary.
• Lubricate cable and grip housing.√√√√√
27*Lights, signals and
switches• Check operation.
• Adjust headlight beam.√√√√√√ NO. ITEM CHECK OR MAINTENANCE JOBODOMETER READING
ANNUAL
CHECK 1000 km
(600 mi)10000 km
(6000 mi)20000 km
(12000 mi)30000 km
(18000 mi)40000 km
(24000 mi)
U1SDE1E0.book Page 6 Monday, September 23, 2013 3:55 PM

PERIODIC MAINTENANCE AND ADJUSTMENT
6-18
6
EAUM3051
Air filter elements and check
hoses and V-belt case air filter
elementThe air filter elements and the V-belt
case air filter element should be ser-
viced at the intervals specified in the
periodic maintenance and lubrication
chart. Service all air filter elements
more frequently if you are riding in un-
usually wet or dusty areas.
Replacing the air filter elements
1. Place the scooter on the center-
stand.TIPContinue as follows for each air filter el-
ement.2. Remove the air filter case cover by
removing the rubber caps and
screws.Left
Right
3. Pull the air filter element out.Left
Right
4. Insert a new air filter element into
the air filter case.
5. Install the air filter case cover by
installing the screws. NOTICE:
Make sure that each filter ele-
ment is properly seated in its
1. Screw
2. Air filter case cover
3. Rubber cap
1. Screw
2. Air filter case cover
3. Rubber cap
1
21
13
3
1
1
23
1. Air filter element
1. Air filter element
1
1
U1SDE1E0.book Page 18 Monday, September 23, 2013 3:55 PM

PERIODIC MAINTENANCE AND ADJUSTMENT
6-19
6case. Always replace both air fil-
ter elements at the same time,
otherwise poor engine perfor-
mance or damage to the engine
may result. The engine should
never be operated without the
filter elements installed, other-
wise the piston(s) and/or cylin-
der(s) may become excessively
worn.
[ECA12924]
6. Install the rubber caps.
To clean the air filter check hoses
1. Check the hose at the bottom of
both air filter cases for accumulat-
ed dirt or water.
LeftRight
2. If dirt or water is visible, remove
the hose, clean it, and then install
it.
Cleaning the V-belt case air filter el-
ement
1. Remove panel A. (See page 6-8.)
2. Remove the left air filter case cov-
er.
3. Remove the V-belt air filter case
cover by removing the screws.4. Remove the V-belt case air filter
element by removing the screws.1. Air filter check hose
1
1. Air filter check hose
1
1. Screw
2. V-belt air filter case cover
1. Screw
2. V-belt case air filter elementZAUM10312
11
2
1 1
U1SDE1E0.book Page 19 Monday, September 23, 2013 3:55 PM

PERIODIC MAINTENANCE AND ADJUSTMENT
6-20
6 5. Lightly tap the V-belt case air filter
element to remove most of the
dust and dirt, and then blow out
the dirt with compressed air as
shown.
6. Check the V-belt case air filter ele-
ment for damage and replace it if
necessary.
7. Install the V-belt case air filter ele-
ment by installing the screws.
NOTICE: Make sure that the V-
belt filter element is properly
seated in its case.
[ECA12942]
8. Install the V-belt air filter case cov-
er by installing the screws.
9. Install the left air filter case cover.
10. Install the panel.
EAU21385
Checking the throttle grip free
playThe throttle grip free play should mea-
sure 3.0–5.0 mm (0.12–0.20 in) at the
inner edge of the throttle grip. Periodi-
cally check the throttle grip free play
and, if necessary, have a Yamaha deal-
er adjust it.
EAU21402
Valve clearanceThe valve clearance changes with use,
resulting in improper air-fuel mixture
and/or engine noise. To prevent this
from occurring, the valve clearance
must be adjusted by a Yamaha dealer
at the intervals specified in the periodic
maintenance and lubrication chart.
1. Throttle grip free play
U1SDE1E0.book Page 20 Monday, September 23, 2013 3:55 PM
