1.Shift pedal
N.Neutral
EAU00157
Shift pedalThis motorcycle is equipped with a
constant-mesh 5-speed transmission.
The shift pedal is located on the left
side of the engine and is used in
combination with the clutch when
shifting.INSTRUMENT AND CONTROL FUNCTIONS
1
23
4
5
6
7
8
9
1
EAU00158
Front brake leverThe front brake lever is located on
the right handlebar. Pull it toward the
handlebar to apply the front brake.
EAU00162
Rear brake pedalThe rear brake pedal is on the right
side of the motorcycle. Press down
on the brake pedal to apply the rear
brake.
1.Front brake lever
1
1.Rear brake pedal
