YAMAHA XV125S 2000 Workshop Manual

1
2
3
4
5
6
7
8
9
6-18
PERIODIC MAINTENANCE AND MINOR REPAIR
NOTE:
These limits may be different by
regulation from country to country.
If so, conform to the limits speci-
fied by the regulations of your own
country.
Tire inspection
Always check the tires before oper-
ating the motorcycle. If center
tread depth reaches the limit as
shown, if the tire has a nail or glass
fragments in it, or if the side wall is
cracked, contact a Yamaha dealer
immediately and have the tire
replaced.
1. Side wall
a. Tread depth
1a
Manufacturer Size Type
CHENG SHIN 3.00-18 47P C-916
Manufacturer Size Type
CHENG SHIN
130/90-15M/C 66PC-915
REAR
Minimum tire tread
depth (front and rear)1.6 mm
FRONTEAU00681
w
8Operating the motorcycle with
excessively worn tires
decrease riding stability and
can lead to loss of control.
Have excessively worn tires
replaced by a Yamaha dealer
immediately. Brakes, tires, and
related wheel parts replace-
ment should be left to a
Yamaha Service Technician.
8Patching a punctured tube is
not recommended. If it is
absolutely necessary to do so,
use great care and replace the
tube as soon as possible with
a good quality replacement.
5AJ-9-E3 (XV125S)<3.1E> 4/5/0 5:01 PM Page 49

6-19
1
2
3
4
5
6
7
8
9
12b
a
c
EAU00694Clutch lever free play
adjustment
The clutch lever free play should
be adjusted to 10 ~ 15 mm.
1. Loosen the locknut at the
clutch lever.
2. Turn the adjusting bolt at the
clutch lever in direction ato
increase free play or in direc-
tion bto decrease free play.
3. Tighten the locknut at the
clutch lever.
If the specified free play cannot be
obtained, proceed with the follow-
ing steps.
1. Locknut
2. Adjusting bolt
c. Free play
PERIODIC MAINTENANCE AND MINOR REPAIR
EAU00685Wheels
To ensure maximum performance,
long service, and safe operation,
note the following:
8Always inspect the wheels
before a ride. Check for cracks,
bends or warpage of the
wheel. Be sure the spokes are
tight and undamaged. If any
abnormal condition exists in a
wheel, consult a Yamaha deal-
er. Do not attempt even small
repairs to the wheel. If a wheel
is deformed or cracked, it must
be replaced.
8Tires and wheels should be
balanced whenever either one
is changed or replaced. Failure
to have a wheel balanced can
result in poor performance,
adverse handling characteris-
tics, and shortened tire life.8Ride at moderate speeds after
changing a tire since the tire
surface must first be broken in
for it to develop its optimal
characteristics.
5AJ-9-E3 (XV125S)<3.1E> 4/5/0 5:01 PM Page 50

1
2
3
4
5
6
7
8
9
6-20
PERIODIC MAINTENANCE AND MINOR REPAIR
12
a
b
4. Loosen the locknut at the
clutch lever.
5. Turn the adjusting bolt at the
clutch lever in direction ato
loosen the cable.
6. Loosen the locknut at the
crankcase side.
7. Turn the adjusting nut at the
crankcase in direction ato
increase free play or in direc-
tion bto decrease free play.
8. Tighten the locknut at the
crankcase and the clutch lever.
1. Locknut
2. Adjusting nut
1
2
a
bc
EAU00696Front brake lever free play
adjustment
The free play at the front brake
lever should be 2 ~ 5 mm.
1. Loosen the locknut.
2. Turn the adjusting bolt in
direction ato increase free
play or in direction bto
decrease free play.
3. After adjusting, tighten the
locknut.
1. Locknut
2. Adjusting bolt
c. Free play
EW000099
w
8Check the brake lever free
play. Be sure the brake is
working properly.
8A soft or spongy feeling in the
brake lever can indicate the
presence of air in the brake
system. This air must be
removed by bleeding the
brake system before the
motorcycle is operated. Air in
the system will cause greatly
diminished braking capability
and can result in loss of con-
trol and an accident. Have a
Yamaha dealer inspect and
bleed the system if necessary.
5AJ-9-E3 (XV125S)<3.1E> 4/5/0 5:01 PM Page 51

6-21
1
2
3
4
5
6
7
8
9Free play
The rear brake pedal free play
should be adjusted to 20 ~ 30 mm
at the brake pedal end. Turn the
adjusting nut on the brake rod in
direction ato increase free play or
in direction bto decrease free
play.
1. Adjusting nut
1
a
b
PERIODIC MAINTENANCE AND MINOR REPAIR
EAU01199Rear brake pedal height and
free play adjustment
EW000104
w
It is advisable to have a Yamaha
dealer make this adjustment.
Pedal height
The brake pedal should be posi-
tioned so that its top end is
approximately 60 mm above the
top of the footrest.
1. Footrest
a. Pedal height: 60 mm
b. Free play
1. Loosen the locknut.
2. Turn the adjusting bolt in
direction ato raise pedal
height or in direction bto
lower pedal height.
3. Tighten the locknut.
EW000108
w
After adjusting the pedal height,
adjust brake pedal free play.
1. Locknut
2. Adjusting bolt
1
2
ba1
ab
5AJ-9-E3 (XV125S)<3.1E> 4/5/0 5:01 PM Page 52

1
2
3
4
5
6
7
8
9
6-22
PERIODIC MAINTENANCE AND MINOR REPAIR
EW000106
w
8Brake pedal free play should
be checked whenever the
chain is adjusted or the rear
wheel is removed and then
reinstalled.
8Check the operation of the
brake light after adjusting the
rear brake.
8If it is impossible to make
proper adjustment, consult a
Yamaha dealer.
EAU00713Brake light switch
adjustment
The rear brake light switch is acti-
vated by the brake pedal and is
properly adjusted when the brake
light comes on just before braking
takes effect. To adjust the rear
brake light switch, hold the switch
body so it does not rotate while
turning the adjusting nut.
Turn the adjusting nut in direction
ato make the brake light come on
earlier.
Turn the adjusting nut in direction
bto make the brake light come on
later.
1. Brake light switch
2. Adjusting nut
1
2
a
b
EAU00720Checking the front brake
pads and rear brake shoes
EAU00725
Front brake
A wear indicator groove is provid-
ed on each brake pad. This indica-
tor allows checking of brake pad
wear without disassembling the
brake. Inspect the groove. If the
groove has almost disappeared,
ask a Yamaha dealer to replace the
pads.
1. Indicator groove
1
5AJ-9-E3 (XV125S)<3.1E> 4/5/0 5:01 PM Page 53

6-23
1
2
3
4
5
6
7
8
98Use only the designated quali-
ty brake fluid. Otherwise, the
rubber seals may deteriorate,
causing leakage and poor
brake performance.
NOTE:
If DOT 4 is not available, DOT 3 can
be used.
8Refill with the same type of
brake fluid. Mixing fluids may
result in a harmful chemical
reaction and lead to poor
brake performance.
8Be careful that water does not
enter the master cylinder when
refilling. Water will significant-
ly lower the boiling point of
the fluid and may result in
vapor lock. Recommended brake fluid:
DOT 4
PERIODIC MAINTENANCE AND MINOR REPAIR
EAU00727
Rear brake
Apply the brake and inspect the
wear indicator.
If the indicator reaches the wear
limit line, ask a Yamaha dealer to
replace the shoes.
1. Wear limit line
2. Wear indicator
EAU00732Inspecting the brake fluid
level
Insufficient brake fluid may let air
enter the brake system, possibly
causing the brakes to become inef-
fective.
Before riding, check that the brake
fluid is above the minimum level
and fill when necessary.
Observe these precautions:
8When checking the fluid level,
make sure the top of the mas-
ter cylinder is level by turning
the handlebars.
1. Minimum level mark
1
2
1
5AJ-9-E3 (XV125S)<3.1E> 4/5/0 5:01 PM Page 54

1
2
3
4
5
6
7
8
9
6-24
PERIODIC MAINTENANCE AND MINOR REPAIR
8Brake fluid may deteriorate
painted surfaces or plastic
parts. Always clean up spilled
fluid immediately.
8Have a Yamaha dealer check
the cause if the brake fluid
level goes down.EAU00742Brake fluid replacement
The brake fluid should be replaced
only by trained Yamaha service
personnel. Have the Yamaha deal-
er replace the following compo-
nents during periodic maintenance
or when they are damaged or leak-
ing:
8oil seals (every two years)
8brake hoses (every four years)
EAU00744Drive chain slack check
NOTE:
Spin the wheel several times and
find the tightest position of the
chain. Check and/or adjust the
chain slack while it’s in this tightest
position.
To check the chain slack the motor-
cycle must be held straight up with
both wheels on the ground and
without rider. Check the slack at
the position shown in the illustra-
tion. Normal slack is approximately
30 ~ 40 mm. If the slack exceeds
40 mm, adjust.
a. Chain slack
a
5AJ-9-E3 (XV125S)<3.1E> 4/5/0 5:01 PM Page 55

6-25
1
2
3
4
5
6
7
8
9To tighten the chain, turn the
chain adjusting nuts in direc-
tion a. To loosen the chain,
turn the chain adjusting nuts in
direction band push the
wheel forward. Turn each
chain adjusting nut exactly the
same amount to maintain cor-
rect axle alignment. There are
marks on each side of the
swingarm. Use these marks to
align the rear wheel.
EC000096
cC
Too little chain slack will overload
the engine and other vital parts.
Keep the slack within the specified
limits.
5. After adjusting, be sure to
tighten each chain adjusting
locknut. Then tighten the axle
nut to the specified torque.
Tightening torque:
Axle nut:
105 Nm (10.5 m·kg)
PERIODIC MAINTENANCE AND MINOR REPAIR
EAU00750Drive chain slack adjustment
1. Loosen the rear brake pedal
free play adjusting nut.
1. Rear brake pedal free play adjusting nut
2. Remove the cotter pin from
the axle nut.
3. Loosen the axle nut.
4. Loosen the chain adjusting
locknuts on each side of the
swingarm.
1. Cotter pin
2. Alignment marks
3. Locknut
4. Chain adjusting nut
5. Axle nut
1
1
2
5
b
a
43
5AJ-9-E3 (XV125S)<3.1E> 4/5/0 5:01 PM Page 56

1
2
3
4
5
6
7
8
9
6-26
PERIODIC MAINTENANCE AND MINOR REPAIR
7. Adjust the free play in the
brake pedal.
EW000103
w
Check the operation of the brake
light after adjusting the rear brake.
1
6. Insert a new cotter pin into the
axle nut and bend the end of
the cotter pin as shown. If the
notch in the axle nut and the
cotter pin hole do not match,
tighten the nut slightly to align
them.
EW000110
w
Always use a new cotter pin on
the axle nut.
1. Cotter pin
EAU00769Drive chain lubrication
The chain consists of many parts
which work with each other. If the
chain is not maintained properly, it
will wear out quickly. Therefore,
the chain must be serviced regular-
ly. This service is especially neces-
sary when riding in dusty areas.
This motorcycle is equipped with a
sealed type chain. Steam cleaning,
high-pressure washes, and sol-
vents can damage chain so do not
use these for cleaning it. Use only
kerosene to clean the drive chain.
Wipe it dry, and thoroughly lubri-
cate it with SAE 30 ~ 50W motor
oil. Do not use any other lubricants
on the drive chain. They may con-
tain solvents that could damage
the sealed chain.
5AJ-9-E3 (XV125S)<3.1E> 4/5/0 5:01 PM Page 57

6-27
1
2
3
4
5
6
7
8
9
EAU00773Throttle cable and grip
lubrication
The throttle twist grip assembly
should be greased at the time that
the cable is lubricated, since the
grip must be removed to get at the
end of the throttle cable. After
removing the screws, hold the end
of the cable up in the air and put in
several drops of lubricant. With the
throttle grip disassembled, coat the
metal surface of the grip assembly
with a suitable all-purpose grease.
PERIODIC MAINTENANCE AND MINOR REPAIR
EC000097
cC
Be sure to oil the chain after wash-
ing the motorcycle or riding in the
rain.
EAU02962Cable inspection and
lubrication
EW000112
w
Damage to the outer housing of
cables may lead to internal rusting
and interfere with the cable move-
ment. Replace damaged cables as
soon as possible to prevent unsafe
conditions.
Lubricate the cables and cable ends.
If a cable does not operate smooth-
ly, ask a Yamaha dealer to replace it.
Recommended lubricant:
Engine oil
5AJ-9-E3 (XV125S)<3.1E> 4/5/0 5:01 PM Page 58
