YAMAHA YBR125 2014 Workshop Manual

PERIODIC MAINTENANCE AND ADJUSTMENT
6-18
6
EAU39814
Adjustin g the brake pe dal free
playThe brake pedal free play should mea-
sure 20.0–30.0 mm (0.79–1.18 in) at
the brake pedal end as shown. Period-
ically check the brake pedal free play
and, if necessary, adjust it as follows.
To increase the brake pedal free play,
turn the brake pedal free play adjusting
nut at the brake rod in direction (a). To
decrease the brake pedal free play,
turn the adjusting nut in direction (b).
WARNING
EWA10681
 After a djustin g the d rive chain
slack or removin g an d installin g
the rear wheel, always check
the brake ped al free play.
 If proper a djustment cannot be
o btaine d as descri bed , have a
Yamaha dealer make this a d-
justment.
 After a djustin g the b rake pe dal
free play, check the operation of
the brake li ght.
EAU44821
Checkin g the shift pe dalThe operation of the shift pedal should
be checked before each ride. If opera-
tion is not smooth, have a Yamaha
dealer check the vehicle.
1. Brake pedal free play
1. Brake pedal free play adjusting nut
1
(a) (b)
U51DE1E0.book Page 18 Thursday, August 29, 2013 4:41 PM

PERIODIC MAINTENANCE AND ADJUSTMENT
6-19
6
EAU22295
Brake light switchesThe brake light, which is activated by
the brake pedal and brake lever,
should come on just before braking
takes effect. If necessary, adjust the
rear brake light switch as follows, but
the front brake light switch should be
adjusted by a Yamaha dealer.
1. Remove panel A. (See page 6-7.)
2. Turn the rear brake light switch adjusting nut while holding the
rear brake light switch in place. To
make the brake light come on ear-
lier, turn the adjusting nut in direc- tion (a). To make the brake light
come on later, turn the adjusting
nut in direction (b).
3. Install the panel.
EAU22382
Checkin g the front brake pa ds
an d rear brake shoes The front brake pads and the rear
brake shoes must be checked for wear
at the intervals specified in the periodic
maintenance and lubrication chart.
EAU22431
Front brake pa ds
Each front brake pad is provided with
wear indicator grooves, which allow
you to check the brake pad wear with-
out having to disassemble the brake.
To check the brake pad wear, check
the wear indicator grooves. If a brake
pad has worn to the point that the wear
1. Rear brake light switch
2. Rear brake light switch adjusting nut
1. Brake pad wear indicator groove
U51DE1E0.book Page 19 Thursday, August 29, 2013 4:41 PM

PERIODIC MAINTENANCE AND ADJUSTMENT
6-20
6
indicator grooves have almost disap-
peared, have a Yamaha dealer replace
the brake pads as a set.
EAU43171
Rear
brake shoes
The rear brake is provided with a wear
indicator, which allows you to check
the brake shoe wear without having to
disassemble the brake. To check the
brake shoe wear, check the position of
the wear indicator while applying the
brake. If a brake shoe has worn to the
point that the wear indicator reaches
the wear limit mark, have a Yamaha
dealer replace the brake shoes as a
set.
EAU37003
Checkin g the brake flui d levelBefore riding, check that the brake fluid
is above the minimum level mark.
Check the brake fluid level with the top
of the reservoir level. Replenish the
brake fluid if necessary.
WARNING
EWA15981
Improper maintenance can result in
loss of b raking a bility. O bserve
these precautions: 
Insufficient brake flui d may al-
low air to enter the b rake sys-
tem, re ducing brakin g
performance.
 Clean the filler cap before re-
moving . Use only DOT 3 or DOT
4 brake flui d from a sealed con-
tainer.
 Use only the specifie d b rake flu-
i d ; otherwise, the ru bber seals
may deteriorate, causin g leak-
a g e.
 Refill with the same type of
brake flui d. A dding a brake flui d
other than DOT 3 or DOT 4 may
result in a harmful chemical re-
action.
 Be careful that water d oes not
enter the brake flui d reservoir
when refillin g. Water will si gnifi-
cantly lower the boilin g point of
the flui d an d may result in vapor
lock.
NOTICE
ECA17641
Brake flui d may damag e painte d
surfaces or plastic parts. Always
clean up spille d flui d imme diately.
1. Brake shoe wear limit mark
2. Brake shoe wear indicator
1
2
1. Minimum level mark
Specified b rake flui d:
DOT 3 or DOT 4
1
U51DE1E0.book Page 20 Thursday, August 29, 2013 4:41 PM

PERIODIC MAINTENANCE AND ADJUSTMENT
6-21
6As the brake pads wear, it is normal for
the brake fluid level to gradually go
down. A low brake fluid level may indi-
cate worn brake pads and/or brake
system leakage; therefore, be sure to
check the brake pads for wear and the
brake system for leakage. If the brake
fluid level goes down suddenly, have a
Yamaha dealer check the cause before further riding.
EAU22723
Chan gin g the brake flui dHave a Yamaha dealer change the
brake fluid at the intervals specified in
the periodic maintenance and lubrica-
tion chart. In addition, have the oil seals
of the brake master cylinder and cali-
per as well as the brake hose replaced
at the intervals listed below or whenev-
er they are damaged or leaking.
 Oil seals: Replace every two
years.
 Brake hose: Replace every four
years.
EAU22762
Drive chain slackThe drive chain slack should be
checked before each ride and adjusted
if necessary.
EAU22795
To check the drive chain slack
1. Place the motorcycle on the cen- terstand.
2. Shift the transmission into the neutral position.
3. Measure the drive chain slack as shown.
4. If the drive chain slack is incorrect, adjust it as follows.1. Drive chain slackDrive chain slack:20.0–30.0 mm (0.79–1.18 in)
U51DE1E0.book Page 21 Thursday, August 29, 2013 4:41 PM

PERIODIC MAINTENANCE AND ADJUSTMENT
6-22
6
EAU51241
To adjust the drive chain slack
Consult a Yamaha dealer before ad-
justing the drive chain slack. 1. Take the motorcycle off the cen- terstand, and then put the side-
stand down.
2. Remove the brake torque rod cot- ter pin, and then loosen the brake
pedal free play adjusting nut,
brake torque rod nut, and axle nut.
3. Loosen the drive chain puller lock- nut at each end of the swingarm. 4. Place the motorcycle on the cen-
terstand.
5. To tighten the drive chain, turn the drive chain slack adjusting bolt at
each end of the swingarm in direc-
tion (a). To loosen the drive chain,
turn the adjusting bolt at each end
of the swingarm in direction (b),
and then push the rear wheel for-
ward. NOTICE: Improper d rive
chain slack will overloa d the en-
g ine as well as other vital parts
of the motorcycle an d can lead
to chain slippa ge or b reakage.
To prevent this from occurrin g,
keep the drive chain slack with-
in the specifie d limits.
[ECA10572]
TIPUsing the alignment marks on each
side of the swingarm, make sure that
both drive chain pullers are in the same
position for proper wheel alignment.
6. Take the motorcycle off the cen-
terstand, and then put the side-
stand down.
7. Tighten both locknuts, and then tighten the axle nut and brake
torque rod nut to their specified
torques.
8. Insert a new cotter pin.
1. Drive chain slack adjusting bolt
2. Drive chain puller locknut
3. Axle nut
4. Brake torque rod nut
5. Brake torque rod cotter pin
6. Brake pedal free play adjusting nut
1
2
34
5
6
1. Alignment marks
2. Drive chain puller
3. Drive chain puller locknut
4. Drive chain slack adjusting bolt
Ti ghtenin g torques:
Axle nut: 80 Nm (8.0 m·kgf, 58 ft·lbf)
Brake torque rod nut: 19 Nm (1.9 m·kgf, 14 ft·lbf)
1
2
3
4
U51DE1E0.book Page 22 Thursday, August 29, 2013 4:41 PM

PERIODIC MAINTENANCE AND ADJUSTMENT
6-23
69. Adjust the brake pedal free play.
(See page 6-18.)
WARNING
EWA10661
After a djustin g the brake pe dal free
play, check the operation of the
b rake li ght.10. Make sure that the drive chain
pullers are in the same position,
the drive chain slack is correct,
and the drive chain moves
smoothly.
EAU23026
Cleanin g an d lu bricatin g the
d rive chainThe drive chain must be cleaned and
lubricated at the intervals specified in
the periodic maintenance and lubrica-
tion chart, otherwise it will quickly wear
out, especially when riding in dusty or
wet areas. Service the drive chain as
follows.NOTICE
ECA10584
The drive chain must b e lubricated
after washin g the motorcycle, ri din g
in the rain or ri din g in wet areas.1. Clean the drive chain with kero-
sene and a small soft brush.
NOTICE: To prevent d amaging
the O-rin gs, do not clean the
d rive chain with steam cleaners,
hi gh-pressure washers or inap-
propriate solvents.
[ECA11122]
2. Wipe the drive chain dry.
3. Thoroughly lubricate the drive chain with a special O-ring chain
lubricant. NOTICE: Do not use
en gine oil or any other lu bri-
cants for the drive chain, as they may contain su
bstances that
coul d damag e the O-rin gs.
[ECA11112]
U51DE1E0.book Page 23 Thursday, August 29, 2013 4:41 PM

PERIODIC MAINTENANCE AND ADJUSTMENT
6-24
6
EAU23098
Checking an d lu bricatin g the
ca blesThe operation of all control cables and
the condition of the cables should be
checked before each ride, and the ca-
bles and cable ends should be lubri-
cated if necessary. If a cable is
damaged or does not move smoothly,
have a Yamaha dealer check or re-
place it. WARNING! Dama ge to the
outer housin g of cab les may result
in internal rustin g an d cause inter-
ference with ca ble movement. Re-
place damag ed cab les as soon as
possi ble to prevent unsafe con di-
tions.
[EWA10712] EAU49921
Checkin
g an d lu bricatin g the
throttle grip an d ca bleThe operation of the throttle grip
should be checked before each ride. In
addition, the cable should be lubricat-
ed by a Yamaha dealer at the intervals
specified in the periodic maintenance
chart.
EAU23144
Checkin g an d lu bricatin g the
b rake an d clutch leversThe operation of the brake and clutch
levers should be checked before each
ride, and the lever pivots should be lu-
bricated if necessary.
Brake lever
Clutch lever
Recommen ded lu bricant:
Yamaha cable lubricant or other
suitable cable lubricant
U51DE1E0.book Page 24 Thursday, August 29, 2013 4:41 PM

PERIODIC MAINTENANCE AND ADJUSTMENT
6-25
6
EAU23184
Checking an d lu bricatin g the
b rake pe dalThe operation of the brake pedal
should be checked before each ride,
and the pedal pivot should be lubricat-
ed if necessary.
EAU23215
Checkin g an d lu bricatin g the
centerstan d an d si destan dThe operation of the centerstand and
sidestand should be checked before
each ride, and the pivots and metal-to-
metal contact surfaces should be lubri-
cated if necessary.
WARNING
EWA10742
If the centerstan d or si destan d d oes
not move up an d d own smoothly,
have a Yamaha dealer check or re-
pair it. Otherwise, the centerstan d or
si destan d coul d contact the groun d
an d d istract the operator, resultin g
in a possi ble loss of control.
Recommen ded lu bricants:
Brake lever:
Silicone grease
Clutch lever:
Lithium-soap-based grease
Recommen ded lu bricant:
Lithium-soap-based grease
U51DE1E0.book Page 25 Thursday, August 29, 2013 4:41 PM

PERIODIC MAINTENANCE AND ADJUSTMENT
6-26
6
EAUM1653
Lubricatin g the swin garm piv-
otsThe swingarm pivots must be lubricat-
ed by a Yamaha dealer at the intervals
specified in the periodic maintenance
and lubrication chart.
EAU23273
Checkin g the front forkThe condition and operation of the
front fork must be checked as follows
at the intervals specified in the periodic
maintenance and lubrication chart.
To check the con dition
Check the inner tubes for scratches,
damage and excessive oil leakage.
To check the operation 1. Place the vehicle on a level surfa- ce and hold it in an upright posi-
tion. WARNING! To avoi d injury,
securely support the vehicle so
there is no dan ger of it fallin g
over.
[EWA10752]
2. While applying the front brake, push down hard on the handle-
bars several times to check if the
front fork compresses and re-
bounds smoothly.
Recommen ded lu bricant:
Lithium-soap-based grease
Recommen ded lu bricant:
Lithium-soap-based grease
U51DE1E0.book Page 26 Thursday, August 29, 2013 4:41 PM

PERIODIC MAINTENANCE AND ADJUSTMENT
6-27
6
NOTICE
ECA10591
If any damage is foun d or the front
fork does not operate smoothly,
have a Yamaha d ealer check or re-
pair it.
EAU45512
Checkin g the steerin gWorn or loose steering bearings may
cause danger. Therefore, the operation
of the steering must be checked as fol-
lows at the intervals specified in the
periodic maintenance and lubrication
chart.
1. Place the vehicle on the center- stand. WARNING! To avoi d inju-
ry, securely support the vehicle
so there is no dan ger of it fallin g
over.
[EWA10752]
2. Hold the lower ends of the front fork legs and try to move them for-
ward and backward. If any free
play can be felt, have a Yamaha
dealer check or repair the steer-
ing.
EAU23292
Checkin g the wheel bearin gsThe front and rear wheel bearings must
be checked at the intervals specified in
the periodic maintenance and lubrica-
tion chart. If there is play in the wheel
hub or if the wheel does not turn
smoothly, have a Yamaha dealer
check the wheel bearings.
U51DE1E0.book Page 27 Thursday, August 29, 2013 4:41 PM
