NOTICEECB03020Do not use oils with a diesel specifica-
tion of “CD” or oils of a higher quality
than specified. In addition, do not use
oils labeled “ENE RGY CONSERVING II”
or higher.
 Make sure that no foreign material en-
ters the oil tank. EBU35322TransmissionMake sure there is no oil leaking from the
transmission case.EBU31760CoolantCheck the coolant level in the coolant reser-
voir when the engine is cold (the coolant level
will vary with engine temperature). The coolant level is satisfactory if it is be-
tween the minimum and maximum level
marks on the coolant reservoir. If the coolant
level is at or below the minimum level mark,
add additional coolant to bring the level up to
maximum level mark. If coolant is not avail-
able, add distilled water. Change the coolant
every two years. (See page 8-33.)
NOTICEECB02120Hard water or salt water is harmful to the
engine. You may use soft water if you can-
not get distilled water. EBU36020Final gearMake sure there is no oil leaking from the final
gear case.
Recommended engine oil type and quantity:
See page 10-1.
Coolant reservoir capacity (up to the maxi-
mum level mark):0.31 L (0.33 US qt, 0.28 Imp.qt)
U2HC7ME0.book Page 6 Tuesday, April 19, 2016 10:33 AM

8-16
8
6. If the oil level is not between the tip of thedipstick and the maximum level mark,
add sufficient oil of the recommended
type to raise it to the correct level.
7. Check the O-ring for damage, and re-
place it if necessary.
8. Install the engine oil tank filler cap.
9. Install the panel. To change the engine oil
1. Park the vehicle on a level surface.
2. Remove panel C. (See page 8-10.)
3. Remove the engine oil tank cover by re- moving the bolts.
4. Start the engine, warm it up for several minutes, and then turn it off.
5. Place an oil pan (or use a trough or funnel)
beneath the oil tank to collect the used
engine oil.1. Engine oil tank filler cap
2. O-ring
3. Engine oil dipstick
4. Maximum level mark
5. Tip of the engine oil dipstick
1
4
5
32
1. Engine oil tank cover
2. Bolt
1
2
U2HC7ME0.book Page 16 Tuesday, April 19, 2016 10:33 AM

8-19
8
12. Add 2.00 L (2.11 US qt, 1.76 Imp.qt) ofthe recommended engine oil to the oil
tank, and then install and tighten the en-
gine oil tank filler cap and the cylinder
head cap.
13. Start the engine, warm it up for several minutes, and then turn it off.
14. Remove the engine oil tank filler cap, and then add sufficient oil of the recommend-
ed type to raise it to the maximum level
mark on the dipstick.
TIPBe sure to wipe off spilled oil on any parts af-
ter the engine and exhaust system have
cooled down. NOTICEECB03020Do not use oils with a diesel specifica-
tion of “CD” or oils of a higher quality
than specified. In addition, do not use
oils labeled “ENERGY CONSERVING II”
or higher.
 Make sure that no foreign material en-
ters the oil tank.
Tightening torques:
Engine oil drain bolt:10 N·m (1.0 kgf·m, 7.2 lb·ft)
Engine oil tank drain bolt: 16 N·m (1.6 kgf·m, 12 lb·ft)
Recommended engine oil: See page 10-1.
Oil quantity: Oil change only:2.50 L (2.64 US qt, 2.20 Imp.qt)
Oil change and filter replacement: 2.70 L (2.85 US qt, 2.38 Imp.qt)
U2HC7ME0.book Page 19 Tuesday, April 19, 2016 10:33 AM

8-27
8
TIPThe transmission oil level should be between
the tip of the dipstick and the maximum level
mark. 4. If the oil level is at or below the tip of thedipstick, add sufficient oil of the recom-
mended type to raise it to the correct lev-
el. 5. Check the O-ring for damage, and re-
place it if necessary.
6. Install the transmission oil filler cap.
7. Install the panel.
To change the transmission oil 1. Park the vehicle on a level surface.
2. Remove panel B (page 8-10).
3. Place an oil pan under the transmission case to collect the used oil.
4. Remove the transmission oil filler cap, and then the transmission oil drain bolt
and its gasket to drain the oil from the
transmission case.1. Transmission oil filler cap
2. O-ring
3. Dipstick
4. Maximum level mark
5. Tip of the dipstick
1 3
245
U2HC7ME0.book Page 27 Tuesday, April 19, 2016 10:33 AM

8-29
8
8. Start the engine and drive the vehicle fora few minutes to circulate the transmis-
sion oil.
9. Park the vehicle on a level surface, stop the engine, and then check the transmis-
sion case for oil leakage.TIPIf oil is leaking confirm that the transmission
oil filler cap is properly installed and then have
a Yamaha dealer check the transmission. 10. Check the transmission oil level and cor- rect if necessary.
11. Install the panel.EBU36050Final gear oilCheck the oil level and change the final gear
oil at the intervals specified in the general
maintenance and lubrication chart.
Checking the final gear oil level 1. Park the vehicle on a level surface. 2. Remove the final gear oil filler bolt and its
gasket, and then check the oil level in the
final gear case. The oil level should be at
the brim of the filler hole.
3. If the oil is below the brim of the filler hole, add sufficient oil of the recommended
type to raise it to the correct level.
NOTICE: Be sure no foreign material
enters the final gear case.
[ECB00422]
1. Final gear oil
2. Gasket
3. Final gear oil filler bolt
4. Correct oil level
24
3
1
U2HC7ME0.book Page 29 Tuesday, April 19, 2016 10:33 AM

8-32
8
3. If the level is low, add sufficient oil of therecommended type to raise it to the
specified level. NOTICE: Be sure no for-
eign material enters the differential
gear case.
[ECB00412]
4. Check the gasket for damage, and re- place it if necessary.
5. Install the differential gear oil filler bolt and its gasket, and then tighten the bolt
to the specified torque. Changing the differential gear oil
1. Park the vehicle on a level surface.
2. Place an oil pan under the differential
gear case to collect the used oil.
3. Remove the differential gear oil filler bolt,
the differential gear oil drain bolt and their
gasket to drain the oil.1. Differential gear oil filler bolt
2. Gasket
3. Differential gear oil
4. Correct oil level
1
2
3
4
Tightening torque:Differential gear oil filler bolt:23 N·m (2.3 kgf·m, 17 lb·ft)1. Differential gear oil drain bolt
2. Gasket
1 2
U2HC7ME0.book Page 32 Tuesday, April 19, 2016 10:33 AM

8-37
8
TIPIf a torque wrench is not available when in-
stalling the spark plug, a good estimate of the
correct torque is 1/4–1/2 turn past finger tight.
However, the spark plug should be tightened
to the specified torque as soon as possible. NOTICEECB02900Do not use any tools to remove or install
the spark plug cap, otherwise the ignition
coil coupler may be damaged. The spark
plug cap may be difficult to remove be-
cause the rubber seal on the end of the cap
fits tightly. To remove the spark plug cap,
simply twist it back and forth while pulling
it out; to install it, twist it back and forth
while pushing it in.
EBU35423Air filter maintenanceThis model is equipped with two air filter ele-
ments, a primary foam-type air filter and a
secondary paper-type air filter.
The primary air filter is easily accessed and
should be cleaned and oiled every 300–600
km (200–400 mi).
The secondary air filter is more difficult to ac-
cess, cannot be cleaned, and should be re-
placed by a Yamaha dealer every 2000–5000
km (1200–3000 mi).1. Primary air filter
2. Secondary air filter
1
2
U2HC7ME0.book Page 37 Tuesday, April 19, 2016 10:33 AM

8-41
8
10. Thoroughly apply Yamalube foam air fil-ter oil (or other quality liquid foam air fil-
ter—do not use a spray-type product) to
the foam material. The foam air filter ele-
ment should be wet but not dripping.
11. Pull the foam air filter element over its frame.
12. Install the air filter.
13. Install the air filter case cover and lock it
into place by turning the air filter case
cover lock clockwise.
TIPMake sure that the match mark on the cover
lock is aligned with the close match mark on
the air filter case cover. 14. Install the panel.EBU35130Cleaning the air filter case check hosesThere is a check hose on each side of the air
filter case. If dust or water collects in a check
hose, empty the hose and clean the air filter
element and air filter case.1. Match mark
1
U2HC7ME0.book Page 41 Tuesday, April 19, 2016 10:33 AM

9-2
9
7. Automotive-type wax may be applied toall painted and chrome-plated surfaces.
Avoid combination cleaner-waxes. Many
contain abrasives which may scratch the
paint or protective finish. When finished,
start the engine and let it idle for several
minutes.EBU32741StorageLong term storage (60 days or more) of your
vehicle will require some preventive proce-
dures to guard against deterioration. Make
any necessary repairs before storing the vehi-
cle.
After thoroughly cleaning the vehicle, prepare
for storage as follows:
1. Fill the fuel tank with fresh fuel and add the specified amount of Fuel Med Rx or
another high-quality fuel stabilizer prod-
uct. Follow the instructions on the prod- uct label. Operate the vehicle for at least
5 minutes to distribute treated fuel
through the fuel system.
2. Remove the spark plugs and pour one ta- blespoon of fresh engine oil into each cyl-
inder and then re-install the spark plugs.
Remove the spark plug wires and ground
them. Operate the electric starter to turn
the engine over several times and coat
the cylinder walls with oil.
3. Lubricate all control cables.
4. Put the frame on stands or blocks to raise all wheels off the ground.
5. Tie a plastic bag over the exhaust pipe outlet to prevent moisture from entering.
Specified amount:1 oz of stabilizer to each gallon of fuel (or
7.5 ml of stabilizer to each liter of fuel)
