YAMAHA YXZ1000R SS 2019 Workshop Manual

4-21
4
EBU31402On–Command drive knob
“2WD/4WD/DIFF LOCK”Stop the vehicle and move the On–Command
drive knob to change the drive mode to two–
wheel drive, four–wheel drive, or four–wheel
drive with differential lock. Select the appro-
priate drive according to the terrain and driv-
ing conditions.
 “2WD” (two–wheel drive): Power is sup-
plied to the rear wheels only.
 “4WD” (four–wheel drive): Power is sup-
plied to the front and rear wheels.
1. Interior light switch “ ”
(a)(b)
1
1. On-Command drive knob “2WD/4WD/DIFF LOCK”
1
UB5H7AE0.book Page 21 Wednesday, July 4, 2018 1:37 PM

4-22
4
“DIFF LOCK” (four–wheel drive with the dif-
ferential gear locked): Power is supplied to
the front and rear wheels with the differen-
tial gear locked. Unlike standard four–wheel
drive, all wheels turn at the same speed re-
gardless of traction.EBU31413Accelerator pedalPress the accelerator pedal to increase en-
gine speed and thus vehicle speed. Release
the accelator pedal and spring tension will re-
turn the pedal to idle position.
EBU31421Brake pedalPress the brake pedal to slow or stop the ve-
hicle.
1. Accelerator pedal
1
1. Brake pedal
1
UB5H7AE0.book Page 22 Wednesday, July 4, 2018 1:37 PM

4-23
4
EBU35642Parking brake leverSetting the parking brake lever will help keep
the vehicle from moving while parked.
To engage the parking brake, pull the lever
firmly.
To release the parking brake, pull slightly on
the lever, press the release button, and then
push the lever to its original position.TIPSpring tension helps return the lever to its
original position. 
If you drive the vehicle with the parking
brake engaged, a buzzer will sound.
EBU36633YCC-S systemThis vehicle is equipped with the Yamaha
Chip Controlled-Shift system (YCC-S) with
AUTO DOWNSHIFT.
YCC-S allows the driver to operate the man-
ual transmission without having to operate
the clutch. AUTO DOWNSHIFT automatically
shifts the transmission into first gear when
coming to a stop under normal conditions.
The transmission is operated using the drive
select lever and the shift paddles. The drive
select lever is used to shift the transmission
into forward drive (first gear), neutral, and re-
verse gear. The shift paddles are used to shift
through the forward gears.
When the drive select lever or shift paddles
are moved, a signal is sent to the MCU (motor
control unit) which disengages the clutch, the
gear shift is made, and then the clutch is re-
1. Release button
2. Parking brake lever
12
UB5H7AE0.book Page 23 Wednesday, July 4, 2018 1:37 PM

4-24
4
engaged once the engine is running at proper
speed. Clutch engagement is controlled by
the MCU according to engine speed and oth-
er driving conditions.TIPThis is not an automatic transmission, only
the clutch system is automatic.
 The gears must be shifted by the driver, ex-
cept when AUTO DOWNSHIFT shifts the
transmission into first gear.
 See page 6-3 for more information on shift-
ing.
EBU36652Drive select lever and shift paddlesThe drive select lever is used to shift the
transmission into forward drive (first gear),
neutral, and reverse gear.1. Drive select lever
1
UB5H7AE0.book Page 24 Wednesday, July 4, 2018 1:37 PM

4-25
4
Use the shift paddles to shift through the for-
ward gears. Pull and release the shift
paddle “ ” to shift up. Pull and release the
shift paddle “ ” to shift down.TIPRead “Shifting and reverse driving” for shift-
ing instructions. (See page 6-3.)
EBU31451Fuel tank capRemove the fuel tank cap when refueling. To
open, turn counterclockwise. When finished
refueling, install the fuel tank cap by screwing
it down clockwise.EBU37390DoorsThe door handle is located on the inside of
each door.
1. Shift paddle “ ”
2. Shift paddle “ ”
+
–
2
1
1. Fuel tank cap
1
UB5H7AE0.book Page 25 Wednesday, July 4, 2018 1:37 PM

4-26
4
To open a door, pull the handle. To close a
door, push or pull the door inward until it is
securely latched. Be sure the door is SE-
CURELY LATCHED AFTER CLOSING IT.EBU33461SeatsTo remove a seat cushion, lift the front of the
cushion, and then pull the cushion off.1. Door
2. Handle
1
2
1. Driver seat cushion
1. Passenger seat cushion
1
1
UB5H7AE0.book Page 26 Wednesday, July 4, 2018 1:37 PM

4-27
4
To install a seat cushion, insert the projec-
tions on the rear of the seat cushion under the
seat frame, and then insert the projection on
the front of the cushion into the grommet
while pushing the cushion downward. Make
sure the seats are properly secured before
starting off. WARNING! A loose seat could
cause the operator to lose control, or cau-
se the operator or passenger to fall.
[EWB03510] EBU34993
Adjusting the driver seat positionThe driver seat position can be adjusted to
suit the driver’s preference.
WARNING! Nev-
er adjust the seat position while operating
the vehicle, otherwise the seat may sud-
denly change position, which may lead to
an accident.
[EWB03990]
To adjust the driver seat position, pull the
driver seat position adjusting lever upward
and move the seat to the desired position.1. Driver seat position adjusting lever
1
UB5H7AE0.book Page 27 Wednesday, July 4, 2018 1:37 PM

4-28
4
TIPAdjust the driver seat position and make sure
it is locked in place before starting off. EBU35002Adjusting the steering wheel positionThe steering wheel position can be adjusted
to suit the driver’s preference. WARNING!
Never adjust the steering wheel position
while operating the vehicle, otherwise the
steering wheel may suddenly change posi-
tion, which may lead to an accident.
[EWB04000]
To adjust the steering wheel position, pull the
steering wheel position adjusting lever and
move the steering wheel to the desired posi-
tion.
TIPAdjust the steering wheel position before
starting off. 1. Steering wheel position adjusting lever
1
UB5H7AE0.book Page 28 Wednesday, July 4, 2018 1:37 PM

4-29
4
EBU36953Rearview mirror (for SE/LE models)TIPAdjust the rearview mirror before starting off.
EBU36184Seat beltsAlways wear the seat belts properly while rid-
ing in the vehicle. (See page 7-5.)TIPIf the vehicle is driven without the driver
seat belt fastened, a buzzer will sound.
 If the vehicle is driven without the driver
seat belt fastened, engine power will be lim-
ited.
1. Rearview mirror (for SE/LE models)
1
1. Seat belt
1
1
UB5H7AE0.book Page 29 Wednesday, July 4, 2018 1:37 PM

4-30
4
EBU31503Glove compartmentStore lightweight or frequently used items,
such as your driving gloves or vehicle docu-
ments, in this compartment.
NOTICEECB02071To protect from damage, do not put metal
items, like tools, or sharply edged items di-
rectly in the glove compartment. If they
must be stored, wrap them in appropriate
cushioning material. EBU38570Storage compartments
1. Unlock.
2. Open.Glove compartment load limit: 4.5 kg (9 lb)
1
2
1. Storage compartment
1
UB5H7AE0.book Page 30 Wednesday, July 4, 2018 1:37 PM
