MOTORCYCLE CARE AND STORAGE8-3
8
NOTICE
ECA10801
Apply spray oil an d wax spar-
in gly an d make sure to wipe off
any excess.
 Never apply oil or wax to any
rubber an d plastic parts, b ut
treat them with a suita ble care
prod uct.
 Avoi d usin g a brasive polishin g
compoun ds as they will wear
away the paint.TIPConsult a Yamaha dealer for advice on
what products to use.
EAU41515
Stora geShort-term
Always store your motorcycle in a cool,
dry place and, if necessary, protect it
against dust with a porous cover. Be
sure the engine and the exhaust sys-
tem are cool before covering the mo-
torcycle.NOTICE
ECA10811
 Storin g the motorcycle in a
poorly ventilated room or cover-
in g it with a tarp, while it is still
wet, will allow water an d humi d-
ity to seep in an d cause rust.
 To prevent corrosion, avoi d
d amp cellars, sta bles ( because
of the presence of ammonia)
an d areas where stron g chemi-
cals are store d.Lon g-term
Before storing your motorcycle for sev-
eral months: 1. Follow all the instructions in the “Care” section of this chapter. 2. For motorcycles equipped with a
fuel cock that has an “OFF” posi-
tion: Turn the fuel cock lever to
“OFF”.
3. Drain the fuel tank and fuel lines, and the carburetor float chamber
by loosening the drain bolt; this
will prevent fuel deposits from
building up.
4. Perform the following steps to protect the cylinder, piston rings,
etc. from corrosion.a. Remove the spark plug cap and spark plug.
b. Pour a teaspoonful of engine oil into the spark plug bore.
c. Install the spark plug cap onto the spark plug, and then place
the spark plug on the cylinder
head so that the electrodes are
grounded. (This will limit spark-
ing during the next step.)
d. Turn the engine over several times with the starter. (This will
coat the cylinder wall with oil.)
e. Remove the spark plug cap from the spark plug, and then
install the spark plug and the
spark plug cap. WARNING! To
U1SN82E0.book Page 3 Friday, June 7, 2013 3:51 PM

MOTORCYCLE CARE AND STORAGE
8-4
8prevent
damag e or injury
from sparkin g, make sure to
g roun d the spark plu g elec-
tro des while turnin g the en-
g ine over.
[EWA10952]
5. Lubricate all control cables and
the pivoting points of all levers and
brake pedal.
6. Check and, if necessary, correct the tire air pressure, and then lift
the motorcycle so that both of its
wheels are off the ground. Alterna-
tively, turn the wheels a little every
month in order to prevent the tires
from becoming degraded in one
spot.
7. Cover the muffler outlet with a plastic bag to prevent moisture
from entering it.TIPMake any necessary repairs before
storing the motorcycle.U1SN82E0.book Page 4 Friday, June 7, 2013 3:51 PM

SPECIFICATIONS
9-1
9
Dimensions:Overall length:YZ85 1822 mm (71.7 in)
YZ85E 1822 mm (71.7 in)
YZ85LW 1900 mm (74.8 in)
YZ85LWE 1900 mm (74.8 in)
Overall width:
758 mm (29.8 in)
Overall height: YZ85 1161 mm (45.7 in)
YZ85E 1161 mm (45.7 in)
YZ85LW 1205 mm (47.4 in)
YZ85LWE 1205 mm (47.4 in)
Seat height: YZ85 864 mm (34.0 in)
YZ85E 864 mm (34.0 in)
YZ85LW 904 mm (35.6 in)
YZ85LWE 904 mm (35.6 in)
Wheelbase:
YZ85 1258 mm (49.5 in)
YZ85E 1258 mm (49.5 in)
YZ85LW 1286 mm (50.6 in)
YZ85LWE 1286 mm (50.6 in)
Ground clearance: YZ85 351 mm (13.82 in)
YZ85E 351 mm (13.82 in)
YZ85LW 393 mm (15.47 in)
YZ85LWE 393 mm (15.47 in)Wei ght:Curb weight:
YZ85 71 kg (157 lb)
YZ85E 71 kg (157 lb)
YZ85LW 73 kg (161 lb)
YZ85LWE 73 kg (161 lb)
Engine:Engine type:
Liquid cooled 2-stroke
Cylinder arrangement:
Single cylinder
Displacement: 84 cm³
Bore × stroke:
47.5 × 47.8 mm (1.87 × 1.88 in)
Compression ratio:
8.20 : 1
Starting system: Kickstarter
Lubrication system: PremixEngine oil:Type:
YAMALUBE 2RTransmission oil:Type:
YAMALUBE 4 (10W-40) or SAE 10W-40
Oil change quantity: 0.50 L (0.53 US qt, 0.44 Imp.qt)Coolin g system:Radiator capacity (including all routes):
0.54 L (0.57 US qt, 0.48 Imp.qt)Air filter:Air filter element:Wet elementFuel:Recommended fuel:Premium unleaded gasoline only
Fuel tank capacity: 5.0 L (1.32 US gal, 1.10 Imp.gal)
Car buretor:Type × quantity:
PWK28 x 1Spark plu g(s):Manufacturer/model:
NGK/BR10EG
Spark plug gap: 0.5–0.6 mm (0.020–0.024 in)Clutch:Clutch type:Wet, multiple-discTransmission:Primary reduction ratio:
3.611 (65/18)
Final drive: Chain
Secondary reduction ratio: YZ85 3.428 (48/14)
YZ85E 3.428 (48/14)
YZ85LW 3.714 (52/14)
YZ85LWE 3.714 (52/14)
Transmission type:
Constant mesh 6-speed
Operation: Left foot operation
Gear ratio: 1st:2.454 (27/11)
2nd: 1.882 (32/17)
3rd:
1.529 (26/17)
4th: 1.294 (22/17)
U1SN82E0.book Page 1 Friday, June 7, 2013 3:51 PM

SPECIFICATIONS
9-2
9
5th:1.130 (26/23)
6th: 1.000 (25/25)
Chassis:Frame type:Semi double cradle
Caster angle: YZ85 26.30 °
YZ85E 26.30 °
YZ85LW 26.90 °
YZ85LWE 26.90 °
Trail:
YZ85 88 mm (3.5 in)
YZ85E 88 mm (3.5 in)
YZ85LW 105 mm (4.2 in)
YZ85LWE 105 mm (4.2 in)Front tire:Type:With tube
Size:
YZ85 70/100-17 40M
YZ85E 70/100-17 40M
YZ85LW 70/100-19 42M
YZ85LWE 70/100-19 42M
Manufacturer/model: DUNLOP/MX51FRear tire:Type:
With tube Size:
YZ85 90/100-14 49M
YZ85E 90/100-14 49M
YZ85LW 90/100-16 52M
YZ85LWE 90/100-16 52M
Manufacturer/model: DUNLOP/MX51
Tire air pressure (measure d on col d
tires):
Front:
100 kPa (1.00 kgf/cm², 15 psi)
Rear:
100 kPa (1.00 kgf/cm², 15 psi)
Front wheel:Wheel type:Spoke wheel
Rim size:
YZ85 17x1.40
YZ85E 17x1.40
YZ85LW 19x1.40
YZ85LWE 19x1.40Rear wheel:Wheel type:Spoke wheel
Rim size:
YZ85 14x1.60
YZ85E 14x1.60
YZ85LW 16x1.85
YZ85LWE 16x1.85Front brake:Type:
Single disc brake
Operation:
Right hand operation Specified brake fluid:
DOT 4
Rear brake:Type:
Single disc brake
Operation: Right foot operation
Specified brake fluid: DOT 4Front suspension:Type:Telescopic fork
Spring/shock absorber type: Coil spring/oil damper
Wheel travel:
275.0 mm (10.83 in)Rear suspension:Type:Swingarm (link suspension)
Spring/shock absorber type:
Coil spring/gas-oil damper
Wheel travel: YZ85 282.0 mm (11.10 in)
YZ85E 282.0 mm (11.10 in)
YZ85LW 287.0 mm (11.30 in)
YZ85LWE 287.0 mm (11.30 in)Electrical system:Ignition system:
CDI
U1SN82E0.book Page 2 Friday, June 7, 2013 3:51 PM

CONSUMER INFORMATION
10-1
10
EAU40793
Id entification num bersRecord the vehicle identification num-
ber and model label information in the
spaces provided below for assistance
when ordering spare parts from a
Yamaha dealer or for reference in case the vehicle is stolen.
VEHICLE IDENTIFICATION NUMBER:
MODEL LABEL INFORMATION:
EAU26401
Vehicle i dentification num ber
The vehicle identification number is
stamped into the steering head pipe.
Record this number in the space pro-
vided.TIPThe vehicle identification number is
used to identify your motorcycle and
may be used to register your motorcy-
cle with the licensing authority in your
area.
EAU26461
Mo del la bel
The model label is affixed to the loca-
tion shown. Record the information on
this label in the space provided. This
information will be needed when order-
ing spare parts from a Yamaha dealer.
1. Vehicle identification number
1. Model label
U1SN82E0.book Page 1 Friday, June 7, 2013 3:51 PM

INDEXAAir filter element, cleaning .................... 7-12BBrake and clutch levers, checking and lubricating ........................................... 7-24
Brake fluid, changing ............................ 7-22
Brake fluid level, checking .................... 7-20
Brake lever .............................................. 4-2
Brake lever free play, checking............. 7-19
Brake pedal............................................. 4-2
Brake pedal, checking and lubricating ........................................... 7-25CCables, checking and lubricating ......... 7-24
Carburetor, adjusting ............................ 7-14
Care ........................................................ 8-1
Clutch lever ............................................. 4-1
Clutch lever free play, adjusting ........... 7-18
Coolant ................................................. 7-10DDrive chain, cleaning and lubricating .... 7-23
Drive chain slack................................... 7-22EEngine break-in....................................... 6-3
Engine idling speed .............................. 7-14
Engine, starting a warm .......................... 6-1
Engine stop button ................................. 4-1FFront and rear brake pads, checking.... 7-20
Front fork, adjusting................................ 4-7
Front fork, bleeding ................................ 4-9
Front fork, checking .............................. 7-26
Fuel ......................................................... 4-3
Fuel cock ................................................ 4-5 Fuel tank breather hose.......................... 4-5
Fuel tank cap .......................................... 4-3
HHandlebar switch ................................... 4-1IIdentification numbers .......................... 10-1KKickstarter .............................................. 4-6LLabels, location ...................................... 1-1MMatte color, caution ............................... 8-1
Model label ........................................... 10-1PParking ................................................... 6-4
Part locations ......................................... 3-1
Periodic maintenance and lubrication
chart ..................................................... 7-2RRear suspension, lubricating ................ 7-25SSafety information .................................. 2-1
Seat ........................................................ 4-7
Shifting ................................................... 6-2
Shift pedal .............................................. 4-1
Shift pedal, checking ............................ 7-19
Shock absorber assembly, adjusting ..... 4-9
Sidestand ............................................. 4-12
Spark plug, checking.............................. 7-8
Specifications ......................................... 9-1
Starter (choke) knob ............................... 4-6
Starting and warming up a cold engine .................................................. 6-1
Steering, checking................................ 7-27 Storage ...................................................8-3
Supporting the motorcycle ...................7-28
Swingarm pivots, lubricating ................7-26
TThrottle grip and cable, checking and
lubricating ...........................................7-24
Throttle grip free play, adjusting ...........7-15
Tires ......................................................7-15
Transmission oil ......................................7-9
Troubleshooting ....................................7-31
Troubleshooting charts .........................7-32VVehicle identification number ................10-1WWheel bearings, checking .....................7-27
Wheel (front) ..........................................7-28
Wheel (rear) ...........................................7-29
Wheels ..................................................7-17
