key YAMAHA YZF-R1 2000 User Guide

OPERATION AND IMPORTANT RIDING POINTS
5-5
5
EAU03172
0–1,000 km
Avoid prolonged operation above
5,000 r/min.
1,000–1,600 km
Avoid prolonged operation above
6,000 r/min.
EC000052
CAUTION:@ After 1,000 km of operation, the en-
gine oil must be changed and the oil
filter cartridge replaced. @1,600 km and beyond
The vehicle can now be operated nor-
mally.
EC000053
CAUTION:@ l
Keep the engine speed out of
the tachometer red zone.
l
If any engine trouble should oc-
cur during the engine break-in
period, immediately have a
Yamaha dealer check the vehi-
cle.
@
NOTE:During and after the engine break-in
period, the exhaust heat may cause
discoloration of the exhaust pipe, but
this is normal.
EAU00460
ParkingWhen parking, stop the engine, and
then remove the key from the main
switch.
EW000058
WARNING
@ l
Since the engine and exhaust
system can become very hot,
park in a place where pedestri-
ans or children are not likely to
touch them.
l
Do not park on a slope or on
soft ground, otherwise the
motorcycle may overturn.
@
E_5jj_Operation.fm Page 5 Wednesday, February 2, 2000 5:18 PM

PERIODIC MAINTENANCE AND MINOR REPAIR
6-34
6
EC000102
CAUTION:@ l
Always keep the battery
charged. Storing a discharged
battery can cause permanent
battery damage.
l
To charge a sealed-type (MF)
battery, a special (constant-
voltage) battery charger is re-
quired. Using a conventional
battery charger will damage the
battery. If you do not have ac-
cess to a sealed-type (MF) bat-
tery charger, have a Yamaha
dealer charge your battery.
@
EAU01754
Replacing the fuses The fuse box is located under the rider
seat. (See page 3-14 for rider seat re-
moval and installation procedures.)
If a fuse is blown, replace it as follows.
1. Turn the key to “OFF” and turn off
the electrical circuit in question.
2. Remove the blown fuse, and then
install a new fuse of the specified
amperage.1. Headlight fuse
2. Radiator fan fuse
3. Ignition fuse
4. Signaling system fuse
5. Odometer fuse
6. Spare fuse (´ 3)
1. Main fuse
2. Spare main fuseSpecified fuses:
Main fuse: 30 A
Headlight fuse: 20 A
Signaling system fuse: 20 A
Radiator fan fuse: 10 A
Ignition fuse: 15 A
Odometer fuse: 10 A
E_5jj_Periodic.fm Page 34 Wednesday, February 2, 2000 5:18 PM

PERIODIC MAINTENANCE AND MINOR REPAIR
6-35
6
EC000103
CAUTION:@ Do not use a fuse of a higher amper-
age rating than recommended to
avoid causing extensive damage to
the electrical system and possibly a
fire. @3. Turn the key to “ON” and turn on
the electrical circuit in question to
check if the device operates.
4. If the fuse immediately blows
again, have a Yamaha dealer
check the electrical system.
EAU00826
Replacing the headlight bulb This motorcycle is equipped with a
quartz bulb headlight. If the headlight
bulb burns out, replace it as follows.
1. Disconnect the headlight coupler,
and then remove the headlight
bulb cover.2. Unhook the headlight bulb holder,
and then remove the defective
bulb.1. Coupler
2. Headlight bulb cover
1. Headlight bulb holder
E_5jj_Periodic.fm Page 35 Wednesday, February 2, 2000 5:18 PM

CONSUMER INFORMATION
9
Identification numbers ........................................................................ 9-1
Key identification number ................................................................... 9-1
Vehicle identification number.............................................................. 9-1
Model label ........................................................................................ 9-2
E_5jj_ConsumerTOC.fm Page 1 Wednesday, February 2, 2000 5:19 PM

9-1
9
10
EAU01039
9-CONSUMER INFORMATION
EAU02944
Identification numbersRecord the key identification number,
vehicle identification number and
model label information in the spaces
provided below for assistance when or-
dering spare parts from a Yamaha
dealer or for reference in case the vehi-
cle is stolen.
1. KEY IDENTIFICATION NUMBER:CA-02E2. VEHICLE IDENTIFICATION
NUMBER:CA-02E3. MODEL LABEL INFORMATION:CA-01EEAU01041
Key identification numberThe key identification number is
stamped into the key tag. Record this
number in the space provided and use
it for reference when ordering a new
key.
EAU01043
Vehicle identification numberThe vehicle identification number is
stamped into the steering head pipe.
Record this number in the space pro-
vided.NOTE:@ The vehicle identification number is
used to identify your motorcycle and
may be used to register your motor-
cycle with the licensing authority in
your area. @
1. Key identification number
1. Vehicle identification number
E_5jj_Consumer.fm Page 1 Wednesday, February 2, 2000 5:19 PM

10-INDEXAAir filter element, cleaning ...................... 6-15
Anti-theft alarm (optional) .........................3-8BBattery ................................................... 6-33
Brake and clutch levers, checking and
lubricating ............................................ 6-30
Brake fluid, changing ............................. 6-26
Brake fluid level, checking...................... 6-25
Brake lever............................................. 3-11
Brake pedal............................................ 3-11
Brake pedal, lubricating.......................... 6-30
Brake pedal position, adjusting .............. 6-23CCables, checking and lubricating............ 6-29
Carburetors, adjusting............................ 6-17
Care.........................................................7-1
Clutch lever ............................................ 3-10
Clutch lever free play, adjusting ............. 6-22
Controls and instruments .........................2-3
Conversion table ......................................8-5
Coolant .................................................. 6-11
Changing .......................................... 6-13
Checking .......................................... 6-11
Cowlings and panels, removing and
installing ................................................6-5DDrive chain, lubricating ........................... 6-28
Drive chain slack .................................... 6-27
Adjusting .......................................... 6-27
Checking .......................................... 6-27
EEngine break-in ....................................... 5-4
Engine idling speed ............................... 6-17
Engine oil and oil filter cartridge ............... 6-8
Engine, starting a cold ............................. 5-1
Engine, starting a warm ........................... 5-3
EXUP system ........................................ 3-22FFront and rear brake pads, checking ..... 6-24
Front and rear suspension settings ........ 3-21
Front fork, adjusting ............................... 3-16
Front fork, checking ............................... 6-31
Front wheel ........................................... 6-39
Installing........................................... 6-40
Removing......................................... 6-39
Fuel ....................................................... 3-12
Fuel consumption, tips for reducing ......... 5-4
Fuel tank breather hose ......................... 3-13
Fuel tank cap ......................................... 3-11
Fuses, replacing .................................... 6-34HHandlebar switches ................................. 3-9
Dimmer switch ................................... 3-9
Engine stop switch ............................. 3-9
Horn switch ........................................ 3-9
Light switch ........................................ 3-9
Pass switch ........................................ 3-9
Start switch ...................................... 3-10
Turn signal switch .............................. 3-9
Headlight bulb, replacing ....................... 6-35
Helmet holders ...................................... 3-15
IIdentification numbers ..............................9-1
Ignition circuit cut-off system ..................3-23
Indicator lights ..........................................3-2
Coolant temperature warning light ......3-3
Fuel level warning light .......................3-2
High beam indicator light ....................3-2
Neutral indicator light ..........................3-2
Oil level warning light ..........................3-3
Turn signal indicator light ....................3-2KKey identification number .........................9-1LLeft view...................................................2-1
Luggage strap holders ...........................3-22MMain switch/steering lock .........................3-1
Model label ..............................................9-2
Motorcycle, supporting ...........................6-38OOwner’s tool kit ........................................6-1PParking.....................................................5-5
Periodic maintenance and lubrication
chart ......................................................6-2
Pre-operation check list ............................4-1
E_5jjIX.fm Page 1 Wednesday, February 2, 2000 5:20 PM
