Navigation unit button illumination does not
work (with navigation)
YES
NO
YES
NO YES
NO
YES
NO
23-58Audio System
Symptom Troubleshooting (cont’d)
NAVIGATION UNIT CONNECTOR A (17P)
ILL (RED)
GAUGE CONTROL MODULE (TACH) 36P CONNECTOR ILL (RED)
NAVIGATION UNIT CONNECTOR A (17P) ILL (GRY)NOTE: Check the vehicle battery condition first.
 Check the connectors for poor connections or loose terminals.
1. Turn the ignition switch to ON (II).
2. Turn the combination lighting switch to the parking light position.
3. Check the illumination of the navigation unit buttons.
Intermittent problem: the navigation unit is
OK at this time. Check for loose or poor
connections at navigation unit connector A (17P).
Go to step 4.
4. Check the illumination of several other buttons not related to the navigation system.
Go to step 5.
Troubleshoot the interior lights. Start by
checking the No. 14 (7.5 A) fuse in the under-dash
fuse/relay box. If the fuse is OK, check for an open
in the wire between the under-dash fuse/relay box
and the navigation unit.
5. Turn the ignition switch to LOCK (0).
6. Disconnect navigation unit connector A (17P). NOTE: Eject all the discs before removing the navigation unit to prevent damaging the CD player’s load
mechanism.
 Remove the PC card before removing the navigation unit.
7. Disconnect gauge control module (tach) 36P connector. 8. Check for continuity between navigation unit
connector A (17P) terminal No. 1 and gauge control
module (tach) 36P connector terminal No. 14.
Go to step 9.
Repair open in the wire between the gauge
control module and the navigation unit.
9. Turn the ignition switch to ON (II).
10. With the headlight switch still on, measure the voltage between navigation unit connector A (17P)
terminal No. 10 and body ground.
Check the connections at navigation unit
connector A (17P). If all connections are OK, replace
the navigation unit (see page 23-155).
Repair open in the wire between the under-
dash fuse/relay box and the navigation unit.
Wire side of female terminals
Wire side of female terminals
Wire side of female terminalsAre the buttons illuminated?
Are the buttons illuminated? Is there continuity?
Is there battery voltage?
08/08/21 14:05:30 61SNR030_230_0061
ProCarManuals.com
DYNOMITE -2009-

Î

Î

(#'#
)

µ µ
´
µ
µ
µ
µ µ
µ
µ
µ
Audio unit button illumination does not
work (without navigation)
YES
NO
YES
NO YES
NO
YES
NO
23-59
AUDIO UNIT CONNECTOR A (17P)
ILL (RED)
GAUGE CONTROL MODULE (TACH) 36P CONNECTOR ILL (RED)
AUDIO UNIT CONNECTOR A (17P) ILL (GRY)NOTE: Check the vehicle battery condition first.
 Check the connectors for poor connections or loose terminals.
1. Turn the ignition switch to ON (II).
2. Turn the combination lighting switch to the parking light position.
3. Check the illumination of the audio unit buttons.
Intermittent problem: the audio unit is OK at
this time. Check for loose or poor connections at
the audio unit connector A (17P).
Go to step 4.
4. Check the illumination of several other buttons not relatedtotheaudiosystem.
Go to step 5.
Troubleshoot the interior lights. Start by
checking the No. 14 (7.5 A) fuse in the under-dash
fuse/relay box. If the fuse is OK, check for an open
in the wire between the under-dash fuse/relay box
and the audio unit.
5. Turn the ignition switch to LOCK (0).
6. Disconnect audio unit connector A (17P). NOTE: Eject all the discs before removing the audio
unit to prevent damaging the CD player’s load
mechanism.
7. Disconnect gauge control module (tach) 36P connector. 8. Check for continuity between audio unit connector
A (17P) terminal No. 1 and gauge control module
(tach) 36P connector terminal No. 14.
Go to step 9.
Repair open in the wire between the gauge
control module and the audio unit.
9. Turn the ignition switch to ON (II).
10. With the headlight switch still on, measure the voltage between audio unit connector A (17P)
terminal No. 10 and body ground.
Check the connections at audio unit
connector A (17P). If all the connections are OK,
replace the audio unit (see page 23-80).
Repair open in the wire between the under-
dash fuse/relay box and the audio unit.
Wire side of female terminals
Wire side of female terminals
Wire side of female terminals
Are the buttons illuminated?
Are the buttons illuminated? Is there continuity?
Is there battery voltage?
08/08/21 14:05:31 61SNR030_230_0062
ProCarManuals.com
DYNOMITE -2009-

Î

(#'#
)
´
µµ
µ
µ
µ
µ
µ µ
µ
Display does not dim or brighten with
dimmer (without navigation)
YES
NO
YES
NO
YES
NO YES
NO
23-60Audio System
Symptom Troubleshooting (cont’d)
AUDIO UNIT CONNECTOR A (17P)
ILL (GRY)
ILL (RED)
NOTE:
 Check the vehicle battery condition first.
 Check the connectors for poor connections or loose terminals.
1. Turn the ignition switch to ON (II).
2. Turn the combination light switch ON and OFF to see if the symptom can be duplicated.
Go to step 3.
Operation is normal.
3. Turn the combination light switch to OFF.
4. Rotate the illumination control dial.
Operation is normal.
Go to step 5.
5. Disconnect, and check audio unit connector A (17P) for a loose or a poor connection.
NOTE: Eject all the discs before removing the audio
unit to prevent damaging the CD player’s load
mechanism.
Go to step 6.
Operation is normal.
6. Turn the ignition switch to LOCK (0).
7. Remove the audio unit (see page 23-80). 8. Turn the ignition switch to ON (II).
9. Measure the voltage between audio unit connector
A (17P) terminals No. 1 and No. 10. Rotate the dash
brightness controller buttons to see if the voltage
changes.
Substitute a known-good audio unit
(see page 23-80), and recheck. If the symptom/
indication goes away, replace the original audio
unit. If symptom is still present, substitute a known-
good center panel display and recheck. If the
symptom/indication goes away, replace the
original center panel display (see page 23-80).
Repair open in the wire between the under-
dash fuse/relay box and the gauge control
module.
Wire side of female terminals
Is it duplicated?
Does the illumination dim and brighten normally asy ou r ot at e t he d i al ?
Reconnect aud i o uni t connect or A ( 17 P), andr echeck t he sy mpt om; d oes i t st i l l appear ? Does t he v ol t age change?
08/08/21 14:05:31 61SNR030_230_0063
ProCarManuals.com
DYNOMITE -2009-

(#'
)
(#'
)
µ
µ
µ
µ µ
µ
µ
µ
Audio disc does not load Audio disc does not eject
YES
NO
YES
NO YES
NO
YES
NO
23-6123-61
NOTE:
 Check the vehicle battery condition first.
 Check the connectors for poor connections or loose terminals.
 Disc labels should not be used in the navigation unit or audio unit. They may damage the player
mechanism.
 Make sure the disc is compatible with the system (see the owner’s manual for more information).
1. Insert a known-good disc to see if the symptom can be duplicated.
Operation is normal. If the disc loads
normally, but will not play, go to audio disc does
not play (see page 23-62).
Go to step 2.
2. Insert another disc.
The original disc is faulty.
 With navigation: Replace the navigation unit (see page 23-155).
 Without navigation: Replace the audio unit (see page 23-80). NOTE:
 Check the vehicle battery condition first.
 Check the connectors for poor connections or loose terminals.
 Disc labels should not be used in the navigation unit or audio unit. They may damage the player
mechanism.
1. Turn on the audio system.
Go to step 2.
Go to power switch will not turn ON (see page
23-35).
2. Check to see if the disc ejects correctly with no binding by pushing the EJECT button.
Operation is normal.
 With navigation: Replace the navigation unit (see page 23-155).
 Without navigation: Replace the audio unit (see page 23-80).
Does t he d i sc l oad ?
Does t he d i sc l oad ? Does the system turn on?
Does the disc eject normally?
08/08/21 14:05:31 61SNR030_230_0064
ProCarManuals.com
DYNOMITE -2009-

(#'
)(#'
)
µ
µ
µ
µ µ
µ
µ
µ
Special Tools Required
YES
NO
YES
NO Special Tools Required
YES
NO
YES
NO
Audio disc does not play Audio disc skips
23-6223-62Audio System
Symptom Troubleshooting (cont’d)
Diagnostics CD 07AAZ-SDBA100
NOTE:
 Check the vehicle battery condition first.
 Check the connectors for poor connections or loose terminals.
1. Try loading a known-good disc.
Go to step 2.
Go to audio disc does not load (see page
23-61).
2. Insert the audio diagnostic CD (T/N: 07AAZ- SDBA100) in the navigation unit or audio unit.
The original disc is faulty, or has an
unreadable format.
 With navigation: Replace the navigation unit (see page 23-155).
 Without navigation: Replace the audio unit (see page 23-80).  Diagnostics CD 07AAZ-SDBA100
 Skip Test CD 07AAZ-SDBA200 (ABEX-TCD-725B)
 Skip Test CD 07AAZ-SDBA300 (ABEX-TCD-721)
1. Confirm the vehicles tires are properly inflated.
2. Check the clients CD for scratches, fingerprints, and marks.
NOTE: Do this following test with audio unit bass
and treble set to clients listening performance.
When comparing to known-good vehicles,
comparison should be performed on same model
and trim level.
3. Test drive to identify when the CD skips. The diagnostics CD (T/N: 07AAZ-SDBA100) can be used
if clients CD is not available. Use tracks 10 to 12.
Go to step 4.
Operation is normal.
4. Compare the clients CD that skips in a known-good vehicle under the same conditions.
Operation is normal.
Go to step 5.
NOTE: Do this following test with vehicle parked
and engine running.
Does t he d i sc l oad ?
Does t he d i sc pl ay ? Does t he CD sk i p? Does t he CD sk i p i n t he k now n-good v ehi cl e und ert he same cond i t i ons?
08/08/21 14:05:31 61SNR030_230_0065
ProCarManuals.com
DYNOMITE -2009-

µ´
ÎÎ
µ
µ µ
µ
AUDIO REMOTE SWITCH TABLE
YES
NO YES
NO
23-64Audio System
Symptom Troubleshooting (cont’d)
NAVIGAION UNIT CONNECTOR B (22P)
AUDIO REMOTE
GND (BRN) AUDIO REMOTE
SW (PNK) NAVIGAION UNIT CONNECTOR B (22P)
AUDIO REMOTE
GND (BRN) AUDIO REMOTE
SW (PNK)
4. Measure the resistance between navigation unit
connector B (22P) terminals No. 6 and No. 7 as
specified in the table.
Go to step 5.
Repair open or high resistance in the circuit
between the navigation unit and the audio remote
switch. If the wires are OK, replace the cable reel
(see page 24-200). 5. Check for continuity between navigation unit
connector B (22P) terminals No. 6 and No. 7 and
body ground individually.
Repair short to body ground in the circuit
between the navigation unit and the audio remote
switch. If the wires are OK, replace the cable reel
(see page 24-200).
Replace the navigation unit (see page 23-155).
Button held down VOL DOWNVOLUP CH( ) CH( ) MODE No
button
pressed
Resistance about 100about
357 about
775 about
1.7 k about
3.7 k about
10 k
Wire side of female terminals Wire side of female terminals
IstheresistanceOK?Is there continuity?
08/08/21 14:05:32 61SNR030_230_0067
ProCarManuals.com
DYNOMITE -2009-

Î

(#'#
)
µ
µ µ
µ
µ
µ
YES
NO
YES
NO
YES
NO
Audio disc cannot be inserted and/or ejected
(with navigation)
23-6623-66Audio System
Symptom Troubleshooting (cont’d)
AUDIO UNIT CONNECTOR B (20P)
REMOTE GND (BRN) AUDIO REMOTE SW (PNK)
5. Check for continuity between audio unit connector B (20P) terminals No. 6 and No. 7 and body ground
individually.
Repair short to body ground in the circuit
between audio unit and the audio remote switch. If
the wires are OK, replace the cable reel (see page
24-200).
Replace the audio unit (see page 23-80). NOTE:
 Check the vehicle battery condition first.
 Check the connectors for poor connections or loose terminals.
 Disc labels should not be used in the navigation unit or audio unit. They may damage the player
mechanism.
 Make sure the disc is compatible with the system (see the owner’s manual for more information).
1. Press the OPEN/CLOSE button to open the navigation display.
2. Try inserting an audio CD.
The system is OK at this time.
Go to step 3.
3. Press the CD eject button.
The system is OK at this time.
Replace the navigation unit (see page 23-155).
Wire side of female terminals
I s t her e cont i nui t y ? Does t he pl ay er accept t he CD?
Does the player eject the CD?
08/08/21 14:05:32 61SNR030_230_0069
ProCarManuals.com
DYNOMITE -2009-

(#'#
)
PC card will not play/card icon on audio
screen cannot be selected (with navigation)
23-67
Unfortunately there are no error messages, and no
diagnostics for the PC card. There are many reasons
why a card won’t play audio files in the audio unit. The card may not be fully inserted into the slot. Eject the card, and inspect for warping or damage to the
edge connector. N ever use excessive force to insert a
card. This can result in damage to the pins in the rear
of the slot.
 The client’s card may contain audio files that are not recognized by the system. Only MP3, and WMA
music files are played.
 The flash card type may not be accepted by the system. Only Compact Flash and ATA cards have
been tested.
 The card’s PCMCIA adaptor may be preventing a known-good card from playing. New PCMCIA
adaptors are constantly being released, and have not
been tested.
 The card’s capacity may exceed 1 GB. Only cards with capacities of up to 1 GB (1000 MB) have been
tested.
 There may not be any files on the card. Some cards have write protection, make sure it is turned off
before putting files on the card.
 Although flash memory chips are reliable, occasionally they develop bad sectors or other
formatting errors that prevents them from playing.
The customer should re-format the card using the
FAT, or FAT32 format.  The card may have been damaged by heat. Suggest
that the client remove their card when exiting the
vehicle.
 The client may have formatted the card using the format NTFS. Only the formats FAT, and FAT32 are
accepted by the system.
 Hard Disc Drive (HDD) cards may not work properly in the system and can overheat and quit functioning,
particularly in a hot vehicle. They are not
recommended.
 The filing structure of the card may exceed the specification of 8 folder levels deep, 99 folders
maximum, and 999 total tracks maximum. If any of
these limitations is exceeded, the system may not
properly display or play the tracks.
NOTE: A delay when first inserting a card is normal.
The system is reading the File Tag information for
album names, artist, and song titles and there is no
hour glass, The delay length depends on the number of
tracks, and the complexity of the folder structure.
See the audio section glossary for an explanation of the
terms used above.
08/08/21 14:05:32 61SNR030_230_0070
ProCarManuals.com
DYNOMITE -2009-

(#'#
)
Î
(#'#
)
´µ
µ
µ
µ
µ
µ
µ
µ µ
µ
Error code: XM NO SIGNAL or XM ANTENNA
is displayed (with navigation) XM radio display is blank and no station
information is displayed (with navigation)
YES
NO
YES
NO
YES
NO
YES
NO YES
NO
23-6823-68Audio System
Symptom Troubleshooting (cont’d)
XM RECEIVER CONNECTOR A (14P)
B(BLU)
NOTE: Check the vehicle battery condition first.
 Check the connectors for poor connections or loose terminals.
 Check XM radio reception in an open area. Poor reception/interference can be caused by tall buildings,
mountains, or high-voltage power lines.
1. Check that the XM receiver connectors properly connected.
Go to step 2.
Reconnect the connector. If the error message
does not go away, go to step 2.
2. Check the connector at the XM antenna and XM antenna lead.
Go to step 3.
Reconnect the connector. If the error message
does not go away, go to step 3.
3. Substitute known-good XM antenna (see page 23-88).
Replace the XM antenna (see page 23-88).
Go to step 4.
4. Substitute known-good XM receiver (see page 23-82).
Replace the XM receiver (see page 23-82).
Replace the XM antenna lead. NOTE:
 Check the vehicle battery condition first.
 Check the connectors for poor connections or loose terminals.
1. Disconnect XM receiver connector A (14P).
2. Measure the voltage between XM receiver connector A (14P) terminal No. 1 and body ground.
Go to step 3.
Repair open in the wire between the XM
receiver and the navigation unit connector.
3. Reconnect XM receiver connector A (14P).
Wire side of female terminals
I s t he connect or connect ed ?
I s t he connect or connect ed ?Is the error message gone?Is the error message gone? Is there battery voltage?
08/08/21 14:05:32 61SNR030_230_0071
ProCarManuals.com
DYNOMITE -2009-

ÎÎ
µ
µ
µ
µ
From terminal To terminals
YES
NO Navigation
unit connector XM receiver
connector Wire color
YES
NO
23-70 Audio System
Symptom Troubleshooting (cont’d)
XM RECEIVER CONNECTOR A (14P)
XM RECEIVER CONNECTOR A (14P)
NAVIGATION UNIT CONNECTOR E (14P)
13. Check for continuity between XM receiver
connector A (14P) according to the table.
A9 (BRN) A9 (BLU), A10 (PNK)A9 (BLU) A10 (PNK)
Short in the wire(s) between the navigation
unit and the XM receiver. Replace the affected
shielded harness.
Go to step 14. 14. Check for continuity between navigation unit
connector E (14P) and XM receiver connector A
(14P) according to the table.
E9 A9 BLU
E10 A10 PNK
Substitute a known-good XM receiver
(see page 23-82), then reconnect all connectors and
recheck. If the symptom/indication goes away,
replace the original XM receiver. If symptom/
indication is still present, replace the navigation
unit (see page 23-155).
Open in the wire(s) between the navigation
unit and the XM receiver. Replace the affected
shielded harness.
Wire side of female terminals
Wire side of female terminals
Wire side of female terminals
I s t her e cont i nui t y bet w een any of t he t er mi nal s?
Is there continuity?
08/08/21 14:05:33 61SNR030_230_0073
ProCarManuals.com
DYNOMITE -2009-
