SymptomDiagnostic procedure Also check for
23-99
























Voice guidance cannot be heard,
is broken up, or there is static
Symptom Troubleshooting
(see page 23-122) Volume or voice feedback setting (see
Owner’s manual)
Navigation unit
Harness/fuses/switches
Voice control does not work/
respond Symptom Troubleshooting
(see page 23-123) Navigation unit
The wrong color DVD is installed
The DVD is damaged or dirty
Microphone harness/switches
Navigation cannot control HVAC
by voice command Symptom Troubleshooting
(see page 23-130) Wrong color DVD is installed
Harness/fuses/switches
Wrong navigation unit (model code)
Navigation cannot control XM
radio Symptom Troubleshooting
(see page 23-130)Low or weak battery
Navigation cannot control audio
system Symptom Troubleshooting
(see page 23-129)Wrong color DVD
Navigation display buttons do not
work or respond properly Symptom Troubleshooting
(see page 23-121) Navigation unit
Open/short between the XM receiver
or the GA-Net bus
The wrong color DVD is installed
The DVD is damaged or dirty
Today’s Destinations button is
dim and not selectable in the
Enter destination by screen
(grayed-out) The client has not entered a group
of locations for Today’s
Destinations. This is normal. The
button is only selectable if the
client is using this functionSee Owner’s Manual
Some set-up and information
functions of the navigation
system are grayed-out and do not
work Client did not select OK from
Disclaimer screen. Refer to
System Function Diagram
(see page 23-111)
Previous Destinations button is
dim and not selectable in the
Enter destination by screen
(grayed-out) The vehicle may be new, or the
client deleted the destination.
Enter a destination, and allow the
system to route to it. After the trip,
the Previous Destinations button
will be selectable
Address cannot be found or
system gives poor routing Verify proper operation and
system limitations using the
owner’s manual
See Answering customer
question Navigation coverage
in general troubleshooting
Refer to Database limitation in
the navigation system manual
to report database errorsDatabase limitations (address not in
database)
Wrong color DVD installed
OPEN/CLOSE function of the
display does not work Symptom Troubleshooting
(see page 23-132) Navigation unit
Harness
Navigation display will not close Symptom Troubleshooting (see page 23-133) Navigation unit
Harness
Navigation display does not open
or opens part way Symptom Troubleshooting
(see page 23-133) Navigation unit
Harness
PC card will not play/card icon on
audio screen cannot be selected Symptom Troubleshooting
(see page 23-67)Navigation unit
(cont’d)
08/08/21 14:06:26 61SNR030_230_0102
ProCarManuals.com
DYNOMITE -2009-

SymptomDiagnostic procedure Also check for
23-100Navigation System
Symptom Troubleshooting Index (cont’d)

















Navigation display stays on with
ignition switch in LOCK (0)
Symptom Troubleshooting
(see page 23-129) Harness/fuses/switches
Aftermarket accessory connected to
the system
DVD read error messages Symptom Troubleshooting (see page 23-127) Navigation unit
Wrong color DVD installed
Damaged DVD
Navigation system will not go
beyond the disclaimer screen and
displays the OK button See navigation display buttons do
not work or respond properly
Wrong color DVD installed
Scratched or damaged DVD
Navigation unit
The navigation anti-theft code
card is lost or missing See anti-theft feature (see page
23-90)
The vehicle icon lags behind
when the vehicle turns See self-inertial navigation
limitations (see page 23-90) Aftermarket accessories connected to
the system
GPS antenna/cable
Navigation screen is darker than
normal or takes time to brighten
when it is cold See LCD display unit limitations
(see page 23-91)
The navigation clock is off by 1 to
3 hours after replacing the
navigation unit See service precautions (see page
23-92)
Perform map matching (see page
23-94)
GPS antenna/cable
Check and adjust the clock settings
A new navigation DVD is needed See obtaining a navigation DVD (see page 23-94)
Time is not correct Reset Time Adjustment in set-up The wrong colored DVD or version is installed
The DVD is scratched or dirty See ‘‘DVD Handling and Cleaning’’ (see page 23-95)Navigation unit
The wrong DVD was installed and
now the system does not function
properly See Precaution customer Sneak
Previews (see page 23-97)
Install the correct version DVD
Check any official Honda service
website for more service information
about the navigation system
A specific city cannot be found See How to answer client questions about navigation
coverage (see page 23-97) The DVD is scratched or dirty
Refer to Database limitation in the
navigation system manual to report
database errors
The Honda Globe Screen (not the
Acura Globe Screen) appears
every time the vehicle is started Symptom Troubleshooting
(see page 23-135)
Also see the symptom The wrong DVD
was installed and now the system does
not function properly
08/08/21 14:06:26 61SNR030_230_0103
ProCarManuals.com
DYNOMITE -2009-

(#'#
)
Overview
23-101
System Description
The navigation system is a highly sophisticated, hybrid locating system.
The navigation unit uses global positioning system (GPS) satellite signals, internal yaw and vehicle speed inputs, and
a map database to show where the vehicle is and to help guide you to a desired destination.
The navigation unit’s GPS receiver receives signals from the GPS, a network of 24 satellites in orbit ar ound the earth.
By receiving signals from several of these satellites, the navigation system can determine the latitude, l ongitude, and
elevation of the vehicle.
Signals from the system’s yaw rate sensor (inside the navigation unit) detects turns, and the ECM/PCM vehicle speed
pulse (VSP) and reverse signal enable the system to keep track of the vehicle’s speed and direction of travel. The
advantage of this hybrid system is that the system can track your position if either the GPS signal or the vehicle speed
signal is missing. For instance, when in a tunnel (no GPS), the speed signal is used to update your position on the map.
Alternately, while the vehicle is being transported on a ferry, GPS signals can show the vehicle position on the map as
it crosses the water.
The navigation system uses the location, direction, and speed information to display the appropriate map and
calculate a route to the destination entered. As you drive to a destination, the system provides both visual and audio
guidance. Audio guidance is sent to the audio unit, and an RGB graphics color signal is sent to the navigation display.
This navigation system also has voice recognition that allows voice control of most of the navigation, and audio
functions. The voice control switches (navigation TALK and navigation BACK buttons on the steering wheel) activate
the voice control system. The microphone on the ce iling receives your voice commands. For more information on this
feature, consult the navigation owner’s guide.
The illumination signal is used by the navigation unit to automatically switch the display mode between the Night and
Day display modes. When the headlights are on, the dash brightness control setting full brightness overrides the Night
display mode, and allows a daytime navigation display with the lights on.
When the navigation system is giving voice guidance commands, the front speakers are muted. When the voice
control system is being used (navigation TALK button pressed), all of the speakers are muted.
The internal GA-Net II bus passes information back and forth between the navigation display, the navigation unit, and
the audio system components. The information passed on this bus are touch button commands, audio muting signal,
audio (radio and XM), and any open in these bus lines can affect the navigation system or other audio accessory
operation.
The clock on the navigation display is set and maintained by the navigation unit. The time is automatically adjusted for
daylight savings, and time zone changes while driving. The time can be adjusted in setup.
Additional information is available about the navigation components following the System Diagram. A glossary of
terms that are used throughout this section follows the detailed information.
The Navigation System Manual in the glove box covers all of the system functions and settings. Use this as a resource
when evaluating a client concern.
(cont’d)
08/08/21 14:06:26 61SNR030_230_0104
ProCarManuals.com
DYNOMITE -2009-

Î
23-102Navigation System
System Description (cont’d)
Reverse signal
GPS antenna
AM/FM antenna Speakers
Navigation unit
Navi DVD
Navigation/Audio Display Screen
CLOCK
(Set by GPS)
Stereo Amplifier
(Premium sound
system)
Color
signal
Accessory
(MusicLink,
CD changer, etc.)
XM Receiver
XM antenna
(satellite &
terrestrial)
Auxiliary jack
assembly
Audio remote
switches
(steering wheel)
Illumination
Signal
(lighted buttons)
AM/FM
receiverCD Player
(CD, MP3, WMA)
Audio
processor
PC Card Slot (for playing audio
MP3, and WMA audio files) Navi
processor
(ECU)
GPS
receiver
Yaw rate sensor
(senses turning)
DVD player
(navi maps)
GA-Net
Audio
Audio
Section
Navigaion
Section
Illumination
(Night/Day
display mode)
ECM/PCM
(vehicle speed pulses) Microphone
(on ceiling) TALK/BACK
voice buttons
(’08 model) Climate control unit
08/08/21 14:06:27 61SNR030_230_0105
ProCarManuals.com
DYNOMITE -2009-

Î
Î
µµ
Navigation Function
Function Diagram
Vehicle Speed Pulse
23-103
STEERING BUTTONS MICROPHONE
GA Net bus AUDIO UNIT
LCD
SWITCH
Destination
DVD ROM
YAW RATE SENSOR GPS tuning
GPS RECEIVER
NAVIGATION UNIT
XM RECEIVER GPS ANTENNA Reception of radio
wave from satellite
Data pcocess
concerning map
and vehivle position
Perception of
vehicle position
ECM/PCM
(VEHICLE SPEED PULSE)
Detection of
travel distansce Detection of
vehicle position
Detection of
direction change
Correction of
map matching
Map scroll
Change of reduced
scale of map Guide
processing Audio
guidance
NAVIGATION
DISPLAY
VOICE
PROMPTS
Sensor power
NAVIGATION UNIT
ECM/PCM DISTANCE
DETECTION
CIRCUIT
The navigation system is composed of the navigation unit, the ECM/PCM (vehicle speed signal), the GPS antenna, the
microphone, the voice control switch, the XM receiver, and the climate control unit.
These units communicate with each other on the GA-Net bus.
The vehicle speed pulse is sent by the ECM/PCM. The ECM/PCM receives a signal from the countershaft speed sensor,
then it processes the signal, and transmits it to the speedometer and other systems.
(cont’d)
08/08/21 14:06:27 61SNR030_230_0106
ProCarManuals.com
DYNOMITE -2009-

ÎGA-Net Bus Configuration
23-104Navigation System
System Description (cont’d)
Navigation unit
XM Receiver Accessory
(Music Link, CD changer etc.)
The GA-Net bus passes audio and navigation commands throughout the navigation and audio components.
These commands include audio/XM selections by voice, and XM station and music title names. Because the entire bus
is daisy chained between components (see diagram below), any open or short in the GA-Net bus harness will cause
any or all of these functions to become inoperative. The addition of any factory audio accessory must maintain the
continuity of the GA-Net bus by installing the Y cable included with the accessory kit.
08/08/21 14:06:27 61SNR030_230_0107
ProCarManuals.com
DYNOMITE -2009-

ÎGlobal Positioning System (GPS)
Position Detection Image with GPS Satellite
Precision of GPS
GPS ICONCOLOR NUMBER OF
SATELLITES CONDITION DESCRIPTION
GPS Antenna
GPS Receiver and Clock
23-106 Navigation System
System Description (cont’d)
The global positioning system (GPS) enables the navigation system to determine the current position of the vehicle by
using the signals transmitted from the satellites in orbit around the earth. The sate
llites transmit the satellite
identification signal, orbit information, transmission time signal, and other information. When the GPS receiver
receives a signal from four or more satellites simultaneously, it calculates the current position of the vehicle based on
the distance to each satellite and the satellite’s positions in its respective orbit.
The precision of the GPS varies according to the number of satellites from which signals are received and the view of
the sky. The accuracy is indicated by the color and shape of the GPS icon shown on the display.
No GPS icon None Faulty reception The GPS can’t be utilized due to a faulty GPS receiver, open in the wire, or other
fault or interference.
White GPS icon 2 or less Impossible to detect vehicle positionGPS function is normal. The satellite
signals received by the GPS are too few to
detect the vehicle position.
Green GPS icon 3 Vehicle position detectable in 2 dimensionsThe longitude and latitude of the vehicle
position can be detected. (Less precise
than detection in three dimensions)
4 or more Vehicle position detectable in 3 dimensions (elevation
displayed) The longitude, latitude and the altitude of
the vehicle position can be detected. (More
precise than detection in two dimensions)
The GPS antenna amplifies and transmits the signals received from the satellites to the GPS receiver.
The GPS receiver is built into the navigation unit. It calculates the vehicle position by receiving the signal from the GPS
antenna. The current time vehicle position and signal reception condition is transmitted from the GPS receiver to the
navigation unit to adjust vehicle position.
08/08/21 14:06:28 61SNR030_230_0109
ProCarManuals.com
DYNOMITE -2009-

µ
µ µ
µ
µ
Navigation Unit
Calculation of Vehicle Position
Map Matching Tuning
GPS Tuning
Distance Tuning
Route Guidance
Audio Guidance
DVD-ROM
23-107
The navigation unit calculates the vehicle position and guides you to the destination. The unit performs map matching
correction, GPS correction, and distance tuning. It also controls the menu functions and the DVD-ROM drive, and
interprets voice commands. With control of all these items, the navigation unit makes the navigation picture signal,
then it transmits the signal to the navigation display and audio driving instructions to the audio unit.
The navigation unit calculates the vehicle position (the driving direction and the current position) by receiving the
directional change signals from the yaw rate sensor and the travel distance signals from the PCMs vehicle speed pulse
(VSP) signal.
The map matching tuning is accomplished by indicating the vehicle position on the roads on the map. The map data
transmitted from the DVD-ROM is checked against the vehicle position data, and the vehicle position is indicated on
the nearest road. Map matching tuning does not occur when the vehicle travels on a road not shown on the map, or
when the vehicle position is far away from a road on the map.
The GPS tuning is accomplished by indicating the vehicle position as the GPS’s vehicle position. The navigation unit
compares its calculated vehicle position data with the GPS vehicle position data. If there is large difference between
the two, the indicated vehicle position is adjusted to the GPS vehicle position.
The distance tuning reduces the difference between the travel distance signal from the VSP and the distance data on
the map. The navigation unit compares its calculated vehicle position data with the GPS vehicle position data. The
navigation unit then decreases the tuning value when the vehicle position is always ahead of the GPS vehicle position,
and it increases the tuning value when the vehicle position is always behind the GPS vehicle position.
The navigation unit can calculate different routes to a selected destination. You have five options:
 Direct Route Calculate a route that is the most direct.
 Easy Route Calculate a route that minimizes the number of turns needed.
 Minimize Freeways Calculate a route that avoids freeway travel. If that is not possible, keep the am ount of
freeway travel to a minimum.
 Minimize Toll Roads Calculate a route that avoids, or minimizes travel on toll roads.
 Maximize Freeways Calculate a route that uses freeways as much as possible.
The navigation unit transmits audio driving instructions before entering an intersection or passing a junction.
The audio instructions come through the audio unit to the front speakers.
NOTE: The front speakers are muted whenever the navigation system is giving guidance commands, and all of the
speakers are muted when the voice control system is being used.
The map data (including all scale rates) is stored in the DVD-ROM. The map data includes:  Road distances, road widths, speed limits, traffic regulations, passing time at junction, distances to junctions, and the driving instructions for audio guidance.
 Latitude and longitude GPS.
(cont’d)
08/08/21 14:06:28 61SNR030_230_0110
ProCarManuals.com
DYNOMITE -2009-

ÎAudio Unit (Built in the navigation unit)
Navigation Display
Microphone
Navigation TALK Button
Navigation BACK Button
23-108Navigation System
System Description (cont’d)
The audio unit receives the audio driving instructions from the navigation unit, and transmits the instructions through
the front speakers even when the audio system is in use.
The navigation display uses liquid crystal display (LCD). The LCD is a 6.5-inch-diagonal, thin film transistor (TFT),
stripe type with 65,536 color, The color film and fluorescent light are laid out on the back of the liquid crystal film. The
touch sensor on the front of the LCD consists of a touch sensitive resistive membrane with an infinite number of
possible touch locations.
The microphone (on the ceiling, near the front map light) receives voice commands and transmits them to the
navigation unit for interpretation.
Activates the voice control system in the navigation unit to accept voice commands.
Returns the display to the previous screen (similar function as the CANCEL button).
08/08/21 14:06:28 61SNR030_230_0111
ProCarManuals.com
DYNOMITE -2009-

µ
Glossary
Item Definition
23-109
The following is a glossary of terms pertaining to the Voice Recognition Navigation System.Active noise cancellation
(ANC) The active noise cancellation system cancels some of the vehicle noise. This occurs in the 1,500 2,400 rpm
range. Microphones detect the low frequency sound, and the system outputs a canceling sound from the audio
speaker.
Address Book The HFL system can import a copy of the phone book from and approved HFL compatible phone and display the imported phone book on the navigation screen as the address book. See the Owner’s Manual for more
information.
B-CAN Body CAN Bus (see CAN)
Bread-crumbs (White
dots) Off road tracking dots that can be followed on the map to retrace your route back to a mapped (digitized) road.
This function can be turned on/off in Setup screen 1.
CAN Controller Area Network. This communication network allows processors in the vehicle to send/receive information. The fuel pulses used by the MID trip computer are received from the ECM/PCM using the F-CAN
(Fast Controller Area Network) bus.
CPU Central Processing Unit. The main device within the navigation unit that coordinates the rest of the electronic functions.
CSS Countershaft (Output) Speed Sensor. This sensor reads the output shaft speed at the transmission and provides a speed pulse to the ECM/PCM.
Database This consists of the Map data, and the POI (Points Of Interest) data stored on the DVD.
DBW Drive By Wire. Allows electrical control of the throttle without the need of a mechanical linkage.
DCA Detailed Coverage Area. Main metropolitan areas in the Lower 48 states, and Canada are mapped to this level. See the navigation system manual for a list of these areas.
DTC DTC Diagnostic Trouble Codes. Use HDS tablet to obtain, and troubleshoot the cause of these codes.
Dead reckoning The use of the speed signal, and yaw rate sensor to position the vehicle on the map even when tall buildings, or driving in a tunnel obscures the GPS signal.
Digitized road A road that appears on the navigation screen. The road name appears at the bottom of the navigation screen. If the user drives off road, the navigation system displays not on a digitized road, and after 1/2 mile, the bread-
crumbs appear.
Disclaimer screen Screen containing cautionary information. It is meant to be read carefully and acknowledged by the customer when using the navigation system.
DVD or DVD-ROM Digital Versatile Disk. The navigation program and database resides on this disk. See the Navigation Owner’s Manual for information on how to order a replacement or an update DVD.
ECM Engine Control Module. Typically referred to as the ECM.
FAQ Frequently Asked Questions. See the navigation system manual for a list of the customer FAQs, and troubleshooting information.
F-CAN Fast CAN Bus (see CAN)
GA-NET The GA-NET allows the audio unit to communicate with all the audio and navigation components in a vehicle. If there is an open in the GA-NET, components or the entire audio and navigation system may appear inoperative.
GPS Global Positioning System. A network of 24 satellites in orbit around the earth. The navigation system can simultaneously receive signals from up to 12 satellites to accurately position the vehicle on the map.
HDS Honda Diagnostic System. A hand held tablet PC used for diagnosing vehicle problems. This device can be used to obtain DTC codes for diagnosis of the navigation system and CAN related problems.
HFL HandsFreeLink uses Bluetooth technology as a wireless link between it and an approved Bluetooth compatible cell phone. See the vehicle Owner’s manual or Quick Start Guide for more information.
HIP (AcuraLink) Honda Information Platform (see AcuraLink)
H/U Head Unit. The audio unit in the dash.
Initialization This refers to the period needed to re-acquire the GPS satellite orbital information whenever the navigation system power has been disconnected. This can take from 10 to 45 minutes.
Interface Dial This control device consists of a rotating knob and the buttons surrounding it. This device allows control of the navigation, audio, and climate functions displayed on the screen.
Jog Dial See interface dial.
(cont’d)
08/08/21 14:06:29 61SNR030_230_0112
ProCarManuals.com
DYNOMITE -2009-
