Acura Integra 2001 Owners Manual

Digita
l Cloc k

The digital clock displays the time with the ignition switch ON (II). To see the time with the ignition off,
press and hold the wide button next
to the clock. To set the clock:
1. Turn the ignition switch ON (II) to display the time.
2. Swing down the front cover of the wide button next to the clockdisplay. You will see H, M, and

RESET buttons.
3. Press and hold the H button until
the hour advances to the desired
time.
4. Press and hold the M button until the numbers advance to thedesired time.
You can use the RESET button to quickly set the time to the nearest
hour. If the displayed time is before
the half hour, pressing the RESET
button sets the clock back to the
previous hour. If the displayed time
is after the half hour, pressing the RESET button sets the clock for-
ward to the beginning of the next
hour.
For example: 1:06 would RESET to 1:00.
1:52 would RESET to 2:00.
Instrument s an d Control s
M
HRESE
T

Beverag
e Holde r

To open the beverage holder, push on the front to get it to pop out
slightly. Then pull it out the rest of
the way. To close it, push it until it
latches.
Be careful when you are using the
beverage holder. A spilled liquid that
is very hot can scald you or your
passengers. Spilled liquids can also damage the upholstery, carpeting,
and electrical components in the
interior.

Instruments an d Control s

Pus
h

Consol
e Compartment , Cigarett e Lighte r
Consol e Compartmen t
To open the console compartment, pull up the front edge of the lid.
To close, lower the lid and push it down until it latches. The pocket on the underside of the
console compartment lid can be used
to hold cards. Cigarett
e Lighte r
The ignition switch must be in
ACCESSORY (I) or ON (II) for the cigarette lighter to work. To heat up
the lighter, push it in. It will pop out
when it is ready for use. Do not hold
the lighter in while it is heating up,
you could cause it to overheat.

Instrument s an d Control s
CIGARETT
E LIGHTE R
CAR D HOLDE R

CONSOL
E COMPARTMEN T

Ashtray
s

Open the front ashtray by pulling on
the front. Push it in to close it.
To remove the ashtray for emptying, push down on the metal plate inside,
then pull the ashtray out completely. The rear ashtray is at the rear end of
the center console. Open the ashtray
by swinging the upper edge of the liddown. To remove the ashtray for
emptying, open it, then lift up and out.
Use the ashtray only for cigarettes,
cigars, and other smoking materials. To prevent a possible fire and damage
to your car, don't put paper or other
things that can burn in the ashtray.

Instrument s an d Control s

ASHTRA
Y

ASHTRA Y
NOTIC
E

Interio
r Light s
Ceilin g Ligh t
The ceiling light has a three-position switch. In the OFF position, the light
does not come on. In the center
position, the ceiling light conies on
when you open either door. In the ON position, the ceiling light stays
on continuously. Spotlight
s

LS, GS and GS-R models

Turn on the spotlight by pushing the button next to each light. Push thebutton again to turn it off. You can
use the spotlights at all times. Carg
o Are a Ligh t
The cargo area light has a two- position switch. In the OFF (down)
position, the light does not come on.In the ON (up) position, the light
comes on when you open the hatch.

Instrument s an d Control s

DOO
R ACTIVATE D

Comfor
t an d Convenienc e Feature s

The heating and air conditioning* systems in your Acura provide a com-
fortable driving environment in all weather conditions.
The standard audio system has
many features. This section de-
scribes those features and how to
use them. (If you selected an optional audio system, refer to the
operating instructions that came
with it.)
Your Acura has an anti-theft audio system that requires a code number
to enable it.

* Air conditioning is optional on the

Type-R model in Canada.
Heating and Cooling........................ 94

What Each Control Does............ 94How to Use the System............... 96
To Turn Everything Off........... 101

Audio System................................. 102

Operating the Radio.................. 103

Adjusting the Sound.................. 106
Radio Frequencies..................... 107

Radio Reception......................... 107
Operating the CD Player.......... 109
Operating the CD Changer...... 111
Protecting Compact Discs........ 112 CD Player Error Indications..... 113
CD Changer Error

Indications.............................. 114

Operating the Cassette

Player...................................... 115

Tape Search Functions............. 116 Caring for the Cassette
Player...................................... 118

Theft Protection........................ 119

Comfor t an d Convenienc e Feature s

Heatin
g an d Coolin g
Proper use of the Heating and Cooling system can make the
interior dry and comfortable, and
keep the windows clear for best
visibility.
(Canadian Type-R model only)
If your car does not have air
conditioning, it can be installed at
any time. Your dealer will install a Genuine Acura air conditioning
system that meets Acura's high
quality standards and is designed to
exactly fit your car. Please contact
your dealer for more information.
Wha t Eac h Contro l Doe s
Fa n Contro l Leve r
Sliding this lever to the right
increases the fan's speed, which increases air flow. Temperatur
e Contro l Leve r

Sliding this lever to the right
increases the temperature of the air

flow.

Ai r Conditionin g (A/C ) Butto n
This button turns the air condi- tioning ON and OFF. The indicatorin the button lights when the A/C is
on.
Recirculatio
n Butto n
This button controls the source of the air going into the system. When
the indicator in this button is lit, air
from the car's interior is sent through the system again (Recircula-
tion mode). When the indicator is off, air is brought in from outside the car (Fresh Air mode).
Comfor t an d Convenienc e Feature s MOD
E BUTTON SRECIRCULATIO
N
BUTTO N AI
R CONDITIONIN G
BUTTO N

TEMPERATUR E
CONTRO L LEVE R
FA
N CONTRO L

LEVE R

Heatin
g an d Coolin g

Mod e Button s
Use the MODE buttons to select the
vents the air flows from. Some air
will flow from the dashboard corner
vents in all modes. Air flows from the center
and corner vents in the dashboard. Air flow is divided between
the vents in the dashboard and the
floor vents. Air flows from the floor

vents.
Air flow is divided between
the floor vents and the defroster
vents at the base of the windshield. Air flows from the defroster
vents at the base of the windshield.
Comfort an d Convenienc e Feature s

Heatin
g an d Coolin g
Ven t Control s
You can adjust the direction of the air coming from the dashboard vents
by moving the tab in the center of each vent up-and-down and side-to-
side.
The vents in the corners of the
dashboard can be opened and closed
with the dials underneath them. Ho
w to Us e th e Syste m
This section covers how to set up the system controls for ventilation,
heating, cooling, dehumidifying, and defrosting.
The engine must be running for the heater and air conditioning to
generate hot and cold air. The heateruses engine coolant to warm the air.
If the engine is cold, it will be several
minutes before you feel warm air
coming from the system.
The air conditioning does not rely on engine temperature.

Comfor t an d Convenienc e Feature s

CENTE
R VEN T SID
E VEN T

Heatin
g an d Coolin g
It is best to leave the system in Fresh
Air mode under almost all conditions. Keeping the system in Recirculation
mode, particularly with the A/C off,
can cause the windows to fog up.
Switch to Recirculation mode when
you are driving through smoky or dusty conditions, then switch back to
Fresh Air mode when the condition
clears.

The outside air intakes for the heating and cooling system are at
the base of the windshield. Keepthese clear of leaves and other
debris.
Ventilation
The flow-through ventilation system draws in outside air, circulates it
through the interior, then exhausts it
through vents near the hatch. 1. Slide the temperature control lever
all the way to the left.
Make sure the A/C is off.
2. Select
and Fresh Air mode.
3. Set the fan to the desired speed.

CONTINUED

Comfor t an d Convenienc e Feature s
MOD
E BUTTON S
RECIRCULATIO
N
BUTTO N
AI
R CONDITIONIN G
BUTTO N

TEMPERATUR E
CONTRO L LEVE R
FA
N CONTRO L

LEVE R
