Select the anchor point you want
to use. Lif t the cargo area f loor,
then remove the anchor cover
with a small f lat-tipped
screwdriver.When a child reaches the
recommended weight or height limit
for a forward-facing child seat, the
child should sit in a back seat on a
booster seat and wear a lap/shoulder
belt.
Each third row seat has a tether
anchorage point on the tailgate sill. Followsteps1through2of the
second row installation. The f ollowing pages give
instructions on how to check proper
seat belt f it, what kind of booster
seat to use if one is needed, and
important precautions f or a child
who must sit in f ront.
2. 1.
T hird Row Inst allat ionProtecting L arger Children
Installing a Child Seat, Protecting L arger Children
50
Allowing a child age 12 or under
to sit in front can result in injury
or death if the passenger’s front
airbag inflates.
If a child must ride in front,
move the vehicle seat as far
back as possible, use a booster
seat if needed, have the child
sit up properly and wear the
seat belt properly.

To determine if a lap/shoulder belt
properly f its a child, have the child
put on the seat belt, then ask
yourself :Does the child sit all the way back
against the seat?
Do the child’s knees bend
comf ortably over the edge of the
seat? Does the shoulder belt cross
between the child’s neck and arm?
Is the lap part of the belt as low as
possible, touching the child’s
thighs?
Will the child be able to stay
seated like this f or the whole trip?
If you answer yes to all these
questions, the child is ready to wear
the lap/shoulder belt correctly. If
you answer no to any question, the
child needs to ride on a booster seat. A child who has outgrown a f orward- f acing child seat should ride in a
back seat and use a booster seat
until the lap/shoulder belt f its them
properly without the booster.
1.
2. 3.
4.
5.
CONT INUED
Checking Seat Belt Fit
Using a Booster Seat
Protecting L arger Children
Driver and Passenger Saf ety
51

Some states also require children to
use a booster seat until they reach a
given age or weight (e.g., 6 years or
60lbs).Besuretocheckcurrent
laws in the state or states where you
intend to drive.
If a child who uses a booster seat
must ride in f ront, move the vehicle
seat as far back as possible and be
sure the child is wearing the seat
belt properly.A child may continue using a booster
seat until the tops of their ears are
even with the top of the vehicle’s or
booster’s seat-back. A child of this
height should be tall enough to use
the lap/shoulder belt without a
booster seat.
If the passenger’s front airbag
inf lates in a moderate to severe
f rontal collision, the airbag can cause
serious injuries to a child who is
unrestrained, improperly restrained,
sitting too close to the airbag, or out
of position.
A side airbag also poses risks. If any
part of a larger child’s body is in the
path of a deploying side airbag, the
child could receive possibly serious
injuries.
Booster seats can be high-back or
low-back. Whichever style you select,
make sure the booster seat meets
f ederal saf ety standards and that you
f ollow the booster seat maker’s
instructions.
The National Highway Traffic Safety
Administration and Transport
Canada recommend that all children
age 12 and under be properly
restrained in a back seat.
Protecting L arger Children
When Can a L arger Child Sit in
Front
52

If you decide that a child can saf ely
ride up f ront, be sure to:Caref ully read the owner’s manual,
and make sure you understand all
seat belt instructions and all saf ety
inf ormation.
Move the vehicle seat to the rear-
most position.
Have the child sit up straight, back
against the seat, and feet on or
near the f loor.
Check that the child’s seat belt is
properly and securely positioned.
Supervise the child. Even mature
children sometimes need to be
reminded to f asten the seat belts
or sit properly. This could result in
serious neck injuries during a crash.
This could cause
very serious injuries during a crash.
It also increases the chance that the
child will slide under the belt in a
crash and be injured.
If they do, they could
be very seriously injured in a crash.
Devices intended to improve a
child’s comf ort or reposition the
shoulder part of a seat belt can make
the belt less ef f ective and increase
the chance of serious injury in a
crash.
Of course, children vary widely. And
while age may be one indicator of
when a child can saf ely ride in f ront,
there are other important f actors you
should consider.
To saf ely ride in f ront, a child must
be able to f ollow the rules, including
sitting properly, and wearing the seat
belt properly throughout a ride. Physically, a child must be large
enough f or the lap/shoulder belt to
properly f it (see page ). If the seat
belt does not f it properly, with or
without the child sitting on a booster,
the child should not sit in f ront.
51
Do not let a child wear a seat belt
across t he neck.
Do not let a child put the shoulderpart of a seat belt behind t he back orunder the arm.
T wo children should never use thesame seat belt .
Do not put any accessories on a seatbelt.
Physical Size
Maturity
Protecting L arger Children
Additional Saf ety Precautions
Driver and Passenger Saf ety
53

Your vehicle’s exhaust contains
carbon monoxide gas. You should
have no problem with carbon
monoxide entering the vehicle in
normal driving if you maintain your
vehicle properly.High levels of carbon monoxide can
collect rapidly in enclosed areas,
such as a garage. Do not run the
engine with the garage door closed.
Even with the door open, run the
engine only long enough to move the
vehicle out of the garage.With the tailgate open, air flow can
pull exhaust gas into your vehicle’s
interior and create a hazardous
condition. If you must drive with the
tailgate open, open all the windows
and set the heating and cooling
system/climate control system as
shown below.
If you must sit in your parked vehicle
with the engine running, even in an
unconf ined area, adjust the heating
and cooling system/climate control
system as f ollows:
Select the f resh air mode.
Select the mode.
Turn the f an on high speed.
Set the temperature control to a
comfortable setting.
The vehicle is raised f or an oil
change.
You notice a change in the sound
of the exhaust.
The vehicle was in an accident
that may have damaged the
underside.
Have the exhaust system inspected
f or leaks whenever:
1.
2.
3.
4.
Carbon Monoxide Hazard
54
Carbon monoxide gas is toxic.
Breathing it can cause
unconsciousness and even kill
you.
Avoid any enclosed areas or
activities that expose you to
carbon monoxide.

These labels are in the locations
shown. They warn you of potential
hazards that could cause serious
injury. Read these labels caref ully.
If a label comes of f or becomes hard
to read (except for the U.S.
dashboard label which is removed by
the owner), contact your Acura
dealer f or a replacement.
CONT INUED
U.S. models only
Saf ety L abels
Driver and Passenger Saf ety
55
RADIATOR CAP
HOOD DASHBOARD
BATTERY LABEL

U.S. modelsCanadian models Canadian models
U.S. models
On vehicles with side curtain airbags
Saf ety L abels
56
SUN VISOR
DOORJAMBS

This section gives inf ormation about
the controls and displays that
contribute to the daily operation of
your vehicle. All the essential
controls are within easy reach............................
Control Locations .58
............................
Instrument Panel .59
..........
Instrument Panel Indicators . 60
.............................................
Gauges .68
Controls Near the Steering ...........................................
Wheel .70
Windshield Wipers and ...................................
Washers .71
Rear Window Wiper and .....................................
Washer .73
...........
Turn Signal and Headlights . 74
........
Instrument Panel Brightness . 76
.................
Hazard Warning Button . 76
.................
Rear Window Def ogger . 77
.........................................
Fog Light .77
..........
Steering Wheel Adjustment . 78
..................................................
Keys .79
........................
Immobilizer System .80
................................
Ignition Switch .81
......................................
Door Locks .82
.......................
Remote Transmitter .83
.................................................
Seats .86
....................................
Seat Heaters .91
..............................
Power Windows .92
.........................................
Moonroof .93
.................................
Parking Brake .94 .............................................
Mirrors .95
Driving Position Memory ..........................................
System .97
.................................
Interior Lights .99
.........
Interior Convenience Items . 101
.....................
Beverage Holders .102
.............
Console Compartment . 102
..................................
Glove Box .102
...................
Rear Compartment . 103
.............................
Cargo Hooks .103
...................................
Sun Visor .103
............................
Vanity Mirror .103
........
Accessory Power Sockets . 104
Instruments and Controls
Inst rument s and Cont rols
57

Control L ocations
58
MIRROR
CONTROLS
HOOD RELEASE
HANDLEPARKING BRAKE
PEDALREAR A/C CONTROL ACCESSORY POWER SOCKET GLOVE BOX AUDIO SYSTEM
CLIMATE CONTROL SYSTEM
GAUGES
POWER DOOR LOCK
SWITCHES
POWER WINDOW
SWITCHES FUEL FILL DOOR
RELEASE
INSTRUMENT PANEL (P.
59)
(P.68)
(P.82)
(P.96)
(P.92)
(P.94)(P.111)
(P.104)(P.102) (P.112)
(P.106)
MOONROOF (P.93)
(P.190) (P.189)

Î
Î
Î
CONT INUED
The U.S. instrument panel is shown. Dif f erences f or the Canadian models are noted in the text.
Instrument Panel
Inst rument s and Cont rols
59
VEHICLE STABILITY ASSIST
SYSTEM (VSA) INDICATOR
MALFUNCTION INDICATOR
LAMP
LOW OIL PRESSURE
INDICATOR
IMMOBILIZER SYSTEM
INDICATORSUPPLEMENTAL RESTRAINT
SYSTEM INDICATOR
DOOR AND TAILGATE
OPEN MONITOR
TIRE PRESSURE MONITOR
LOW FUEL INDICATOR LIGHTS ON
INDICATOR
WASHER LEVEL
INDICATOR
SEAT BELT
REMINDER
INDICATOR PARKING
BRAKE AND
BRAKE
SYSTEM
INDICATOR
TPMS INDICATOR
LOW TIRE PRESSURE
INDICATOR
BRAKE LAMP
INDICATOR
VSA ACTIVATION
INDICATOR ANTI-LOCK BRAKE SYSTEM
INDICATOR
CRUISE CONTROL
INDICATOR
HIGH BEAM INDICATOR
MAINTENANCE
REQUIRED
INDICATOR
VTM- 4INDICATOR
A/T TEMPERATURE
INDICATOR CHARGING SYSTEM
INDICATOR (P.60)
(P.60)
(P.67) (P.64)
(P.64) (P.62)/
(P.66)
(P. 63)
(P.65) (P.
62)
(P. 65) (P.
61)
(P.66)
(P.
66)
(P.60)
(P.60) (P.64) (P.63)
(P.61) (P.
60)
(P.63)
(P.63) (P.
61)
SIDE AIRBAG OFF
INDICATOR
(P.273)
