Acura MDX 2007 Owner's Manual

µ
When you turn the wiper switch to
the ‘‘OFF’’ position, the wiper will
return to its parked position.
Rotate the switch
clockwise to turn the rear window
wiper ON. The wiper operates
intermittently.
The headlight washers can be
operated at any time by pressing the
headlight washer button located next
to the steering wheel column. The
headlights must be turned on to use
this button. In addition, the headlight
washer operates when the
windshield washers are f irst turned
on. The headlight washers use the same
f luid reservoir as the windshield
washers.
1.
2.
CONT INUED
Windshield Wipers and Washers
Headlight Washers(On Canadian models)Rear Window Wiper and Washer
ON
Inst rument s and Cont rols
117
——y

y
()-y
y

µ
µ
Hold past ON to turn the rear
window wiper on and to spray the
rear window washer.
Rotate the switch
counterclockwise to spray the
window washer.
When you shif t the transmission
to the reverse position with the
f ront windshield wipers activated,
the rear window wiper operates
automatically.
When the wiper control lever
position is INT, the rear wiper
operates intermittently. When it is
LO or HI, the rear wiper operates
continuously. Push down on the
lever to signal a lef t turn and up to
signal a right turn. To signal a lane
change, push lightly on the lever,
and hold it. The lever will return to
center when you release it or
complete a turn.
Turning the switch to
the ‘‘ ’’ position turns on the
parking lights, taillights, instrument
panel lights, side-marker lights, and
rear license plate lights.
Turning the switch to the ‘‘ ’’
position turns on the headlights. If
you leave the lights on with the key
removed f rom the ignition switch,
you will hear a reminder chime when
you open the driver’s door.
Turn signal
Of f
Parking and indicator lights
AUTO
Headlights on
High beams
Flashhighbeams
Fog lights of f
Fog lights on
Therearwindowwasherusesthe
same f luid reservoir as the wind-
shield washer. 1.
2.
3.
4.
5.
6.
7.
8.
9.
3.
4.
Turn Signal
Headlights
Turn Signal and Headlights
Windshield Wipers and Washers, Turn Signal and Headlights
118
——y


y
()-y
y

µµ
When the light switch is in either of
th ese positions, the lights on
indicator comes on as a reminder.
This indicator stays on if you leave
the lights on and turn the ignition
swit ch to the ACCESSORY (I) or
LOCK (0) position.
To switch from low
beams to high beams, push the left
lever forward until you hear a click.
The blue high beam indicator will
come on (see page ). Pull it back
to return to low beams. To flash the
high beams, pull the lever back
lightly, then release it. The high
beamsstayonaslongasyouhold
the lever back. Even
with the automatic lighting
feature turned on, we recommend
thatyouturnonthelightsmanually
when driving at night or in a dense
fog, or when you enter dark areas
such as long tunnels or parking
facilities.
To change the ‘‘AUTO LIGHT
SENSITIVITY’’ setting, see page .
Do not leave the light switch in
AUTO if you will not be driving the
vehicle f or an extended period (a
weekormore).Youshouldalsoturn
of f the lights if you plan to leave the
engine idling or of f f or a long time.
The automatic lighting
f eature turns on the headlights and
all other exterior lights, when it
senses low ambient light.
To turn on automatic lighting, turn
the light switch to AUTO at any time.
The lights will come on automatically
when the outside light level becomes
low (at dusk, f or example). The
lights on indicator comes on as a
reminder. The lights and indicator
will turn of f automatically when the
system senses high ambient light.
The lights will remain on when you
turn of f the ignition switch. They will
turn of f automatically when you
remove the key and open the driver’s
door. To turn them on again, either
turn the ignition switch to the ON
(II) position or turn the light switch
to .
70
103
Headlights
High BeamsAUTO
Inst rument s and Cont rols
119
——y


y
()-y
y

Turn the f og lights on and of f by
turning the switch next to the
headlight switch.
You can use the f og lights only when
the headlights are on low beam.
With the light switch in the AUTO
position, you can also use the f og
lights when the headlights turn on
automatically. They will go of f when
the headlights turn of f .
The automatic lighting f eature is
controlledbyasensorlocatedontop
of the dashboard. Do not cover this
sensor or spill liquids on it. With the headlight switch off, the
daytime running lights come on
when you turn the ignition switch to
the ON (II) position and release the
parkingbrake.Theyremainonuntil
you turn the ignition switch of f , even
if you set the parking brake.
When the headlights are on, the
daytime running lights are of f .
Headlights
Daytime Running L ights
Fog Lights
120
LIGHT SENSOR
——y

y
()-y
y

If you turn the ignition switch to the
LOCK (0) position with the
headlight switch on, but do not open
the door and get out, the lights turn
off after 10 minutes (3 minutes, if
the switch is in the ‘‘AUTO’’
position).
The lights turn on again when you
unlock or open the driver’s door.
If you unlock the door, but do not
open it within 15 seconds, the lights
go off. With the driver’s door open,
you will hear a lights-on reminder
chime.
This
feature turns off the headlights,
all other exterior lights, and the
instrument panel lights within 15
seconds after you remove the key
and close the driver’s door.
To change the ‘‘HEADLIGHT AUTO
OFF TIMER’’ setting, see page .
The automatic lighting of f f eature
activates if you leave the headlight
switch in the ‘‘ ’’ or ‘‘ ’’
position or if the lights are turned on
by setting the switch in the ‘‘AUTO’’
position, and you remove the key,
then open and close the driver’s door.
If you see a ‘‘CHECK DRL
SYSTEM’’ message on the multi-
inf ormation display, there is a
problem with the daytime running
light system. Take your vehicle to a
dealer to have it checked.
When the multi-information display
shows a ‘‘DRL OFF’’ message, the
daytime running lights are of f .
Follow the procedure in the lef t
column to turn them on.
102
Headlights
Automatic Lighting Of f Feature
Inst rument s and Cont rols
121
——y

y
()-y
y

Make sure the rear window is clear
and you have good visibility before
starting to drive.
The defogger wires on the inside of
the rear window can be accidentally
damaged. When cleaning the glass,
always wipe side to side.
This button turns the rear window
defogger off and on. Pushing this
button also turns the mirror heaters
on or of f (see page ).
The rear window def ogger will clear
fog, frost, and thin ice from the
window. Push the def ogger button to
turn it on and off. The indicator in
the button lights to show the
def ogger is on. If you do not turn it
of f , the def ogger will shut itself of f
af ter about 15 minutes. It also shuts
of f when you turn of f the ignition.
You have to turn it on again when
you restart the vehicle.
Push the button between the center
vents to turn on the hazard warning
lights (f our-way f lashers). This
causes all f our outside turn signals
and both indicators in the instrument
panel to f lash. Use the hazard
warning lights if you need to park in
a dangerous area near heavy traffic,
or if your vehicle is disabled. 154
Rear Window Def ogger
Hazard Warning Button
Hazard Warning, Rear Window Def ogger
122
——y

y
()-y
y

´
´
µ´ µThe
level of brightness is shown on
the multi-information display while
you adjust it. It goes out 5 seconds
after you finish adjusting. To
reduce glare at night, the
instrument panel illumination dims
wh en you turn the light switch to
or . To cancel the glare
reduction function, set the
brightness to the highest level, then
press the button. You will hear a
beep when it is canceled.
Youcancustomizewhentheglare
reduction function starts. To change
‘‘AUTO INTERIOR
ILLUMINATION’’, see page f or
more inf ormation.
Adjust the brightness of the
instrument panel by pressing the
or button. Press the button to
increase the brightness and the
button to decrease it. You can adjust
the brightness with the headlight
switch on or of f . 95
Instrument Panel Brightness
Inst rument s and Cont rols
123
——y

y
()-y
y

Make any steering wheel
adjustments before you start driving.Move the steering wheel in, out, up,
or down by pushing and holding the
adjustment switch in that direction.Release the switch when the
steering wheel reaches the desired
position. Make sure the steering
wheel points towards your chest, not
toward your face, and that you can
see the instrument panel gauges and
indicators.
Steering Wheel A djustments
124
ADJUSTMENT SWITCH
Adjusting the steering wheel
position while driving may
cause you to lose control of the
vehicle and be seriously injured
inacrash.
Adjust the steering wheel only
when the vehicle is stopped.
——y

y
()-y
y

When you remove the key from the
ignition switch, the steering wheel
au tomatically moves fully in and up. If
your vehicle’s battery is
disconnected or goes dead, or the
fuse for the power tilt and telescopic
steering wheel is remove d, the
power tilt and telescopic steering
wheel system needs to be reset
when you reconnect the battery or
install the fuse.
Insert the key into the ignition
switch, and remove it. The steering
wheel automati cally moves fully in
and up to let you know the system is
reset.
To
change the ‘‘AUTO TILT &
TELESCOPE STEERING WHEEL’’
setting, see page .
The steering wheel then returns to
its original position when you insert
the key back in the ignition switch.
Steering wheel movement is also
controlled by the driving position
memory system (see page ). 155
99
Steering Wheel A djustments
Inst rument s and Cont rols
125
——y

y
()-y
y

These keys contain electronic
circuits that are activated by the
immobilizer system. They will not
work to start the engine if the
circuits are damaged.Protect the keys f rom direct
sunlight, high temperature, and
high humidity.
Donotdropthekeysorsetheavy
objects on them.
Keep the keys away f rom liquids.
If they get wet, dry them
immediately with a sof t cloth.
The master key fits all the locks on
your vehicle. The valet key works
only in the ignition and the driver’s
door lock. You can keep the glove
boxlockedwhenyouleaveyour
vehicle and the valet key at a parking
f acility. Youshouldhavereceivedakey
number tag with your keys. You will
need this key number if you ever
have to get a lost key replaced. Use
only Acura-approved key blanks. The valet key does not contain a
battery. Do not try to take it apart.
Keys and Locks
126
KEY
NUMBER
TAGMASTER KEY
WITH REMOTE
TRANSMITTER
VALET KEY
(Light Gray)
U.S. Entertainment Packages and
Canadian Elite Package models shown.
MDX, Technology, and Sport
Packages models shown.
——y

y
()-y

y
