Acura RL 2001 3.5 Owner's Manual

Audio System

To store a frequency:
1. Select the desired band, AM or FM. FM1 and FM2 let you store
two frequencies with each Preset
button.

2. Use the TUNE or SEEK function to tune the radio to a desired
station.

3. Pick the Preset button you want for that station. Press the buttonand hold it until you hear a beep.
4. Repeat steps 1 to 3 to store a total of six stations on AM and twelve
on FM.
Once a station's frequency is stored,
simply press and release the proper
Preset button to tune to it.
The preset frequencies will be lost if your car's battery goes dead, is
disconnected, or the radio fuse is

removed.

Comfort and Convenience Features
STEREO

INDICATOR

PRESET BUTTONS

PWR/VOL KNOB

AM/FM BUTTON
TUNE/SEEK BAR

Audio System

AUTO SELECT — If you are traveling far from home and can no
longer receive the stations yon
preset, you can use the Auto Select
feature to find stations in the local
area.

To activate Auto Select, press the
A. SELECT button. A. SELECT will appear in the display, and the system
will go into scan mode for several seconds. It automatically scans both
bands, looking for stations with strong signals. It stores the frequen-
cies of six AM stations and twelve
FM stations in the preset buttons.
You can then use the preset buttons to select those stations.
If you are in a remote area, Auto
Select may not find six strong AM
stations or twelve strong FM stations.
If this happens, you will see a "0"
displayed when you press any preset
button that does not have a station
stored.
PRESET BUTTONS
With Auto Select on, you cannot manually store any frequencies in
the preset buttons. If you do not like
the stations found by Auto Select,
you can use the TUNE and SEEK
functions to find other stations. Auto Select does not erase the
frequencies that you preset pre-
viously. When you return home, turn off Auto Select by pressing the
A. SELECT button. The preset buttons will then select the fre-quencies you originally set.

Comfort and Convenience Features

TUNE/SEEK BAR
AUTO SELECT
INDICATOR
AM/FM BUTTON
AUTO SELECT BUTTON

Audio System

Adjusting the Sound Balance/Fader — These two
controls adjust the strength of thesound coming from each speaker.
The Balance control adjusts the side- to-side strength, while the Fadercontrol adjusts the front-to-back
strength.

To adjust the fader, push on the BASS/FADER control knob to get it
to pop out. Pull it out slightly farther,and adjust the front-to-back sound to
your liking. Push the knob back in
when you are done so you cannot change the setting by accidentally
bumping it.
To adjust the balance, push on the
TREBLE/BALANCE control knob to get it to pop out. Pull it out slightly farther, and adjust the side-to-side
sound to your liking. Push the knob
back in when you are done so you cannot change the setting by
accidentally bumping it.
BASS/FADER

CONTROL TREBLE/BALANCE
CONTROL

Treble/Bass — Use these controls to adjust the tone to your liking.
To adjust the Treble level, push on the TREBLE/BALANCE control
knob to get it to pop out. Without
pulling it out farther, turn the knob
to adjust the treble level. Push the
knob back in when you are done so
you cannot change the setting by accidentally bumping it. To adjust the Bass level, push on the
BASS/FADER control knob to get it
to pop out. Without pulling it out
farther, turn the knob to adjust the
bass level. Push the knob back in
when you are done so you cannot change the setting by accidentally
bumping it.
Comfort and Convenience Features

Audio System

Audio System Lighting
You can use the instrument panel
brightness control dial to adjust the il- lumination of the audio system (seepage 66). The audio system
illuminates when the parking lights
are on, even if the radio is turned off.
Radio Frequencies

Your Acura's radio can receive the
complete AM and FM bands.

Those bands cover these frequen-
cies:

AM band:
530 to 1,710 kilohertz

FM band:

87.7 to 107.9 megahertz
Radio stations on the AM band are
assigned frequencies at least ten
kilohertz apart (530, 540, 550).
Stations on the FM band are
assigned frequencies at least 0.2

megahertz apart (87.9, 88.1, 88.3). Stations must use these exact
frequencies. It is fairly common for
stations to round-off the frequency in
their advertising, so your radio could
display a frequency of 100.9 even
though the announcer may identity

the station as "FM101."

Radio Reception How well your Acura's radio receives
stations is dependent on many
factors, such as the distance from
the station's transmitter, nearby
large objects, and atmospheric
conditions.
A radio station's signal gets weaker as you get farther away from itstransmitter. If you are listening to an
AM station, you will notice the sound volume becoming weaker, and the station drifting in and out. If you are
listening to an FM station, you will
see the stereo indicator flickering off
and on as the signal weakens.
Eventually, the stereo indicator will go off and the sound will fade
completely as you get out of range of
the station's signal.
Driving very near the transmitter of
a station that is broadcasting on a frequency close to the frequency of
the station you are listening to can
also affect your radio's reception.
You may temporarily hear both stations, or hear only the station you
are close to.

Comfort and Convenience Features
CONTINUED

Audio System

Radio signals, especially on the FM
band, are deflected by large objects
such as buildings and hills. Your
radio then receives both the direct signal from the station's transmitter,
and the deflected signal. This causes
the sound to distort or flutter. This is a main cause of poor radio receptionin city driving. Radio reception can be affected by
atmospheric conditions such as
thunderstorms, high humidity, and
even sunspots. You may be able to
receive a distant radio station one
day and not receive it the next day
because of a change in conditions.
Electrical interference from passing
vehicles and stationary sources can
cause temporary reception problems. As required by the FCC:
Changes or modifications not expressly
approved by the party responsible for compliance could void the user's
authority to operate the equipment.
Comfort and Convenience Features

Audio System

Operating the Cassette Player

The ignition switch must be in
ACCESSORY (I) or ON (II). Make sure the tape opening on thecassette is facing to the right, then
insert the cassette most of the way
into the slot. The system will pull it
in the rest of the way, and begin to

play.

The tape direction indicator will light to show you which side of the cassette is playing. The indicates
the side you inserted facing upward
is now playing. If you want to play
the other side, press the PROG/ PLAY button.
Dolby B noise reduction turns on
when you insert a cassette. The indicator in the button will light.
If the tape was not recorded with
Dolby B noise reduction, turn it off by pressing the button. When the system reaches the end of
the tape, it will automatically reversedirection and play the other side. If
you want to remove the cassette from the drive, press the EJECT
button.
If you turn the system off while a
tape is playing, either with the PWR/
VOL knob or by turning off the ignition, the cassette will remain in
the drive. When you turn the system
back on, the tape will begin playing
where it left off.
To switch to the radio or CD changer while listening to a tape,
press the AM/FM or CD/TAPE but-
ton. To change back to the cassette
player, press the CD/TAPE button.
Tape Search Functions

With a cassette playing, you can use the FF, REW, TMS, or REPEAT
function to find a desired program.
FF/REW — Fast Forward and
Rewind move the tape rapidly. To
rewind the tape, push the REW
button. The indicator in this button
will light. To fast forward the tape, push the FF button. The indicator in
this button will light. Press thePROG/PLAY button to take thesystem out of rewind or fast forward.
When the system reaches the end of the tape, it reverses direction and
begins to play if in fast forward, or it
begins to play if in rewind.
CONTINUED

Comfort and Convenience Features

Audio System

TMS — The Tape Music Search Function allows you to find the
beginning of a song or passage. To activate TMS, push either side of the
TMS bar (— or +). To find the beginning of the song or passagecurrently playing, push the bar on
the - side. You will see TMS indicator and the indicator in the
REW button flashing. To find the
beginning of the next song, push the bar on the + side. You will see TMS
indicator and the indicator in the FF
button flashing.

CD/TAPEBUTTON
TMS BAR

PROG/PLAY

BUTTON
FAST FORWARD

BUTTON

Comfort and Convenience Features
AM/FM

BUTTON REWIND
BUTTON
REPEAT

BUTTON

TAPE DIRECTION INDICATOR

CASSETTE SLOT

PWR/VOL KNOB

EJECT BUTTON

DOLBY
BUTTON

TMS INDICATOR

Audio System

REPEAT — The Repeal function continuously replays the current
song or passage. Press the REPEAT
button to activate it; you will see
REPEAT displayed as a reminder.
When the system reaches the end of the song or passage currently
playing, it will automatically go into
rewind. When it senses the
beginning of the same song or
passage, the system returns to PLAY mode. It will continue to repeat thissame program until you deactivate
REPEAT by pressing the button

again.

Pressing the REW or FF button also
turns off REPEAT.
The TMS and REPEAT functions use silent periods on the tape to find
the end of a song or passage. These
features may not work to your satisfaction if there is almost no gap
between selections, a high noise
level between selections, or a silent
period in the middle of a selection. REWIND BUTTON

REPEAT INDICATOR
FAST FORWARD
BUTTON
TMS BAR
REPEAT BUTTON

Comfort and Convenience Features

Audio System

Caring for the Cassette Player
The cassette player picks up dirt and oxides from the tape. This contami-
nation builds up over time and
causes the sound quality to degrade.
To prevent this, you should clean the player after every 30 hours of use.
Your dealer has a cleaning kit
available.

If you do not clean the cassette
player regularly, it may eventually
become impossible to remove the
contamination with a normal
cleaning kit.
Use 100-minute or shorter cassettes.
Cassettes longer than that use
thinner tape that may break or jam
the drive. Look at the cassette before you
insert it. If the tape is loose, tighten
it by turning a hub with a pencil or
your finger.
If the label is peeling off, remove it
from the cassette or it could cause
the cassette to jam in the player. Never try to insert a warped or
damaged cassette in the player.
When they are not in use, store cassettes in their cases to protect
them from dust and moisture. Never
place cassettes where they will be exposed to direct sunlight, high heat,or high humidity. If a cassette is
exposed to extreme heat or cold, let
it reach a moderate temperature
before inserting it in the player.
Never try to insert foreign objects
into the cassette player. If you see the error indication (3.5 RL with navigation
system)/ (3.5 RL without
navigation system) on the display,
press the EJECT button to remove
the cassette from the unit. Make sure the tape is not damaged. If the
cassette will not eject or the error
indication stays on after the cassette ejects, take the car to your Acura

dealer.

Comfort and Convenience Features

Audio System

Operating the CD Changer

A Compact Disc changer is standard equipment. It holds up to six discs,
providing several hours of continu- ous entertainment. You operate the
CD changer with the same controls
used for the radio and cassette

player.

To load the CDs in the magazine and load the magazine into the CD
changer, refer to page 159. Play onlystandard round discs. Odd-shaped
CDs may jam in the drive or cause
other problems.
Do not play discs with disc
accessories such as protective seals
or rubbers. Using them may also
cause the audio system to

malfunction.

To operate the CD changer, the igni- tion switch must be in ACCESSORY (I) or ON (II).
PRESET BUTTONS

PWR/VOL KNOB

REPEAT BUTTON

CD/TAPE BUTTON AUTO SELECT BUTTON
Select the CD mode by pressing the CD/TAPE button. You will see "CD"
in the display. The system will start
to play the first track of the first disc
in the magazine. You will see the disc and track number displayed. When that disc ends, the next disc in
the magazine is loaded and played.
After the last disc finishes, the system returns to disc 1.
Comfort and Convenience Features
AM/FM BUTTON
SEEK BAR
CONTINUED
