Acura RL 2001 3.5 Owner's Manual

Carrying Cargo

Carrying Cargo in the Trunk or on
a Roof Rack Distribute cargo evenly on the
floor of the trunk, placing the
heaviest items on the bottom and as far forward as possible.
If you carry large items that
prevent you from closing the trunk
lid, exhaust gas can enter the
passenger area. To avoid the
possibility of carbon monoxide
poisoning, follow the instructions on page 49 . If you can carry any items on a
roof rack, be sure the total weight of the rack and the items does not
exceed the maximum allowable
weight. Please contact your Acura dealer for further information.

Before Driving

Driving
This section gives you tips on starting the engine under various
conditions, and how to operate the
automatic transmission. It also
includes important information on parking your car, the braking system,
the Vehicle Stability Assist System,
and facts you need if you are
planning to tow a trailer. Preparing to Drive......................... 180
Starting the Engine........................ 181
Starting in Cold Weatherat High Altitude ..................... 181
Automatic Transmission............... 182 Shift Lever Position Indicator.. 182
Shift Lever Positions................. 182
Engine Speed Limiter ............... 184
Shift Lock Release..................... 185
Parking............................................ 186
The Braking System...................... 187
Brake Wear Indicators.............. 187
Brake System Design................ 188
Anti-lock Brakes........................ 188 Important SafetyReminders.......................... 189
ABS Indicator......................... 189
Vehicle Stability Assist System.... 191 Driving in Bad Weather................ 194
Towing a Trailer............................ 196

Driving

Preparing to Drive

You should do the following checks and adjustments every day before
you drive your car.
1. Make sure all windows, mirrors, and outside lights are clean and
unobstructed. Remove frost, snow,or ice.
2. Check that the hood and trunk are
fully closed.

3. Visually check the tires. If a tire

looks low, use a gauge to check its
pressure.

4. Check that any items you may be

carrying with you inside are stored
properly or fastened down
securely.

5. Check the adjustment of the seat (see page 94 ).
6. Check the adjustment of the

inside and outside mirrors (see
page 99 ).

7. Check the adjustment of the

steering wheel (see page 7 1 ).

8. Make sure the doors are securely

closed and locked.

9. Fasten your seat belt. Check that

your passengers have fastened
their seat belts (see page 15 ).

10.Turn the ignition switch ON (II).

Check the indicator lights in the
instrument panel.

11.Start the engine (see page 181).
12.Check the gauges and indicator

lights in the instrument panel (see
page 53).

Driving

Starting the Engine

1. Apply the parking brake.
2. In cold weather, turn off all electrical accessories to reduce
the drain on the battery.
3. Make sure the shift lever is in Park. Press on the brake pedal.
4. Without touching the accelerator pedal, turn the ignition key to theSTART (III) position. If the engine
does not start right away, do not
hold the key in START (III) for
more than 15 seconds at a time.
Pause for at least 10 seconds
before trying again.
5. If the engine does not start within
15 seconds, or starts but stalls

right away, repeat step 4 with the
accelerator pedal pressed half-way
down. If the engine starts, release
pressure on the accelerator pedal so the engine does not race. 6. If the engine still does not start,
press the accelerator pedal all the
way down and hold it there while starting in order to clear flooding.
As before, keep the ignition key in the START (III) position for nomore than 15 seconds. Return tostep 5 if the engine does not start.
If it starts, lift your foot off the
accelerator pedal so the engine
does not race.

Starting in Cold Weather at High
Altitude (Above 8,000 feet/ 2,400 meters)

An engine is harder to start in cold weather. The thinner air found at
high altitude above 8,000 feet (2,400meters) adds to the problem.
Use the following procedure:
1. Turn off all electrical accessories

to reduce the drain on the battery.

2. Push the accelerator pedal half-

way to the floor and hold it there
while starting the engine. Do nothold the ignition key in START (III) for more than 15 seconds.
When the engine starts, release the accelerator pedal gradually as
the engine speeds up and smoothsout.

3. If the engine fails to start in step 2,

push the accelerator pedal to the
floor and hold it there while you
try to start the engine for no more
than 15 seconds. If the enginedoes not start, return to step 2.

Driving

Automatic Transmission

Your Acura's transmission has four
forward speeds, and is electronicallycontrolled for smoother shifting. It
also has a "lock-up" torque converter
for better fuel economy. You may
feel what seems like another shift
when the converter locks.
Shift Lever Position Indicator
This indicator between the fuel gauge and temperature gauge shows
which position the shift lever is in.
The "D4" indicator comes on for afew seconds when you turn theignition switch ON (II). If it flashes
while driving (in any shift position), it indicates a possible problem in the
transmission. Avoid rapid acceler- ation and have the transmission
checked by an authorized Acura
dealer as soon as possible. Shift Lever Positions
The shift lever has seven positions. It must be in Park or Neutral to start
the engine. When you are stopped in
D4, D3, 2,1, N or R, press firmly on
the brake pedal, and keep your footoff the accelerator pedal.

Driving
SHIFT LEVER

Automatic Transmission

Whenever you move the shift lever, slide it along the guide on the

console.

Park (P) — This position mechani-
cally locks the transmission. Use
Park whenever you are turning off or
starting the engine. To shift out of
Park, you must press on the brake
pedal and have your foot off the
accelerator pedal. Move the shift
lever to the right to shift out of the Park position.
If you have done all of the above and
still cannot move the lever out of
Park, see Shift Lock Release on page
185.

To avoid transmission damage, come to a complete stop before shifting
into Park. The shift lever must be inPark before you can remove the key
from the ignition switch. Reverse (R) — To shift to Reverse
from Park, see the explanation under
Park. To shift to Reverse from
Neutral, come to a complete stop and
then shift. Push down on the shift
lever before shifting into Reverse
from Neutral.
Neutral (N) — Use Neutral if you need to restart a stalled engine, or if
it is necessary to stop briefly with
the engine idling. Shift to Park posi-
tion if you need to leave the car for any reason. Press on the brake pedal
when you are moving the shift lever from Neutral to another gear.

CONTINUED

Driving

Automatic Transmission

Drive (D4) — Use this position for
your normal driving. The transmis- sion automatically selects a suitable
gear for your speed and acceleration.
You may notice the transmission shifting up at higher speeds when
the engine is cold. This helps the engine warm up faster.
Drive (D3) —This position is similar
to D4, except only the first three
gears are selected. Use D3 when
towing a trailer in hilly terrain, or to
provide engine braking when going down a steep hill. D3 can also keep
the transmission from cycling
between third and fourth gears in stop-and-go driving.
For faster acceleration when in D3 or
D4, you can get the transmission to
automatically downshift by pushing
the accelerator pedal to the floor.
The transmission will shift down one or two gears, depending on your
speed.
Second (2) — This position locks
the transmission in second gear. It
does not downshift to first gear
when you come to a stop. Second gives you more power when climbing,and increased engine braking when
going down steep hills. Use second
gear when starting out on a slippery surface or in deep snow. It will help
reduce wheelspin.
First (1) — To shift from Second to
First, push down on the shift lever.
With the lever in this position, the transmission locks in First gear. By
upshifting and downshifting through 1, 2, D3 and D4, you can operate this
transmission much like a manual
transmission without a clutch pedal. Engine Speed Limiter
If you exceed the maximum speed
for the gear you are in, the engine speed will enter into the tachometer's
red zone. If this occurs, you may feel
the engine cut in and out. This iscaused by a limiter in the engine's
computer controls. The engine will
run normally when you reduce the RPM below the red zone.

Driving

Automatic Transmission

Shift Lock Release
This allows you to move the shift lever out of Park if the normalmethod of pushing on the brake
pedal does not work.
1. Set the Parking brake.
2. Remove the key from the ignition
switch.
3. Put a cloth on the edge of the Shift

Lock Release slot cover next to

the shift lever.

Use a small flat-tipped screwdriver
or small metal plate (neither are
included in the tool kit) to remove

the cover. Carefully pry off the

edge of the cover. 4. Insert the key in the Shift Lock

Release slot.

5. Push down on the key and move

the shift lever out of Park to
Neutral.

SHIFT LOCK RELEASE SLOT
6. Remove the key from the Shift

Lock Release slot, then reinstall
the cover. Make sure the notch on
the cover is on the right side. Depress the brake pedal and
restart the engine.

If you need to use the Shift Lock
Release, it means your car is
developing a problem. Have the car
checked by your Acura dealer.

Driving

Parking

Always use the parking brake when
you park your car. The indicator on the instrument panel shows that the
parking brake is not fully released; itdoes not indicate that the parking
brake is firmly set. Make sure the
parking brake is set firmly or your car may roll if it is parked on an

incline.

Set the parking brake before you put
the transmission in Park. This keeps
the car from moving and putting pressure on the parking mechanism
in the transmission — making it
easier to move the shift lever out of
Park when you want to drive away. If the car is facing uphill, turn the
front wheels away from the curb.
If the car is facing downhill, turn the
front wheels toward the curb.
Make sure the parking brake is fully
released before driving away.
Driving with the parking brake
partially set can overheat or damage the rear brakes. Parking Tips Make sure the moonroof and the
windows are closed.
Turn off the lights.Place any packages, valuables, etc.,
in the trunk or take them with you.
Lock the doors with the key or the
remote transmitter. Check the
indicator on the driver's door to
verify that the security system is set.
Never park over dry leaves, tall
grass, or other flammable
materials. The three way catalytic converter gets very hot, and could
cause these materials to catch on

fire.

Driving

The Braking System

Your Acura is equipped with disc brakes at all four wheels. A powerassist helps reduce the effort needed
on the brake pedal. The ABS helps
you retain steering control when
braking very hard.
Put your foot on the brake pedal only
when you intend to brake. Resting
your foot on the pedal keeps the
brakes applied lightly, causing them
to build up heat. Heat build-up can
reduce how well your brakes work. It also keeps your brake lights on all
the time, confusing drivers behind

you.
Constant application of the brakes
when going down a long hill builds up heat and reduces their effective-
ness. Use the engine to assist the
brakes by downshifting to a lower gear and taking your foot off the
accelerator pedal.
Check your brakes after driving
through deep water. Apply the
brakes moderately to see if they feel
normal. If not, apply them gently and
frequently until they do. Since a longer distance is needed to stop
with wet brakes, be extra cautious and alert in your driving. Brake Wear Indicators
All four brakes have audible brake
wear indicators.
When the brake pads need replacing,
you will hear a distinctive metallic "screeching" sound when you apply
the brakes. If you do not have the
brake pads replaced, they will begin screeching all the time.
Your brakes may sometimes squeal or squeak when you apply them
lightly. Do not confuse this with the
brake wear indicators. They make a
very audible "screeching."

Driving
